ExtremeWireless 802.11ax AP302W Indoor Access Point AP302W Overview The AP302W access point is an indoor model 802.11ax wallplate access point. The access point supports Wi-Fi 6, features built-in dual -band radios, three WiFi internal antennas, and one Bluetooth Low Energy (BLE) antenna. The AP302W access point can be mounted on a flat surface such as a wall, to a junction box, and can be installed on a desk stand.The AP302W access point has the following features:•Radios: – Two 802.11ax radios (one 2x2 2.4 GHz and 5 GHz radio, and one 2x2 5 GHz radio) – One IoT Radio (2.4 GHz/IEEE 802.15.4 Zigbee) • Console port: custom micro-USB cable • Six, 10/100/1000 Mbps ports: – Rear ports: •One Ethernet (ETH) port with Power over Ethernet (PoE) in•One pass through port –Bottom ports: •Two ETH ports•One ETH port with power-sourcing-equipment (PSE)•One pass through port • LEDs: One – The LED indicator will be on during reset • One software reset button • One Kensington lock • One USB 2.0 type A connector, supports up to 2.5W • Power: PoE 802.3at and 802.3af (see Ta b l e 1 for details) • Antennas: four internal antennas •Temperature: – Operating temperature: 0 °C to +40 °C (32 °F to +104 °F) – Non-operating temperature: -40 °C to +70 °C (-40 °F to +158 °F) •Enclosure: PlasticTa b l e 1 AP302W Power source Figure 1 Front and back views of AP302W Note: The AP302W requires a minimum base firmware of WiNG 7.6.0 or IQEngine 10.3r0. Power source Description PSE port (up to 12.5 W) USB port (2.5 W) PoE at 802.3at 802.3at is provided through ETH0 Yes Yes 802.3af 802.3af is provided through ETH0 No Yes External 12 VDC power supply (optional; ordering part #37215- PWR 12 VDC,2A, 2.5 mm x 5.5 mm connector) Power is provided through an external DC power supply plugged into an AC source No Yes Note: PoE power is disabled when external power supply is used. Figure 2 Bottom ports on AP302W access pointTable 2 Bottom ports on AP302W access pointStatus LED • Amber color indicates non-operational status• Green color indicates normal operational statusLight SensorThe light sensor is located on the front face of the access point but is not visibly marked.AP302W Box ContentsEnsure that the following items are available:All optional brackets and accessories are sold separately. For detailed installation instructions about all mounting procedures, refer to the ExtremeWireless AP302W Access Point Installation Guide in the Extreme Networks Documentation Support site. Install the Access PointUse these instructions as guidelines for mounting and connecting the AP302Waccess points easily and safely. The AP302W comes with a stainless-steel mo unting bracket that can be used to mount the access point on flat surfaces such a wall or solid ceiling, or to a junction box. An optional desk stand is available for mounting the access point to a desk. To o l s R e q u i r e d • One < 1/4 in. flat-head or #1 Phillips head screwdriver • One torx screwdriver with T8 or VT8 bit Install the Access Point on a Wall Pre-installation checklist:• The mounting surface, item, and hardware must be able to support the access point in all environmental conditions. • The mounting surface must be flat. 1 Using the stainless-steel mounting bracket as a template, mark and drill the wall installation holes on the wall. Callout Description 1 12 VDC power supply 2 Pass through port 3 ETH1 and PoE out port 4ETH2 port 5ETH3 port 6 Status LED Ta b l e 3 C o n t e n t s o f t h e A P 3 0 2 W B ox Quantity Item 1 AP302W Quick Reference 1Access point1 Mounting bracket for wall or junction box or solid ceiling 1 Flat head T8 locking screw 2 Flat pan head 6-32, 14 mm long black screws for USA junction box attachment 2 Pan head M3.5x16 mm long screws for solid wall or anchor attachment 2 25 mm long white plastic screw-in anchors 1 100 mm RJ45 cable (not including connectors), CAT.5E flat LAN cable Electrical Hazard: Only qualified personnel must perform installation procedures. Note: For system Ethernet lines with receptacle, use the included RJ45 to RJ45 cable to connect the Ethernet cable to the access point.For system Ethernet lines without receptacle, connect the system Ethernet cable into the access point back ETH0 port.Note: The installer must supply the required tools for installation. 2 Insert the screws into the mounting bracket wall installation holes as shown in Figure 3 , and use the screw-in anchors, if needed. Figure 3 Wall installation holes3 Insert the Ethernet cable into the ETH0 port. 4 Insert the access point onto the bracket locking tab and slide it down until it is fully seated onto the bracket. 5 Attach the security locking screw to the secu rity locking tab on the wall bracket, and lock the access point in place. If you want to install the access point on a solid ceiling or a dry wall, you need to create a hole from behind the wall to run the RJ45 cable. For more information, refer to the ExtremeWireless AP302W Access Point Installation Guide. Install the Access Point on a Junction Box Use the stainless steel mounting bracket to mount the access point on a junction box.1 Remove the screws from the box. 2 Line up the bracket holes with the large hole on the box. 3 Using the aligned holes, attach the bracket to the box using the screws removed from the box earlier. Figure 4 Stainless-steel mounting bracket for wall or junction boxTable 4 Stainless-steel mounting bracket parts4 Connect the Ethernet cable or the RJ45 flat cable to the access point. 5 Align the keyhole slots and posts, and then slide the access point onto the bracket until it is fully seated in place. 6 Using a security torx T-8 or a VT-8 screw, secure the bracket locking tab for physical security. Install the Access Point on a Desk StandUse the optional desk stand, that need to be purchased separately, for this installation.1 Line up the access point on the mounting tabs of the desk stand. Note: When you line up the holes, the bracket locking tab must be pointing up and the box m…
