QXO-AP460SCWireless Access Point

AP460C,AP460S6C,andAP460S12C HardwareUserGuide Installandviewspecificationsandcomplianceinformation forAP460C,AP460S6C,andAP460S12Cdevices. AP460C, AP460S6C, and AP460S12C Tri Radio 802.11ax access points are based on advanced radio technology and IP67 rated for harsh and extreme outdoor environments, with an extended temperature range from -40 C - +60 C. The tri-radio design delivers 802.11ax 2x2:2 and 4x4:4 data rates concurrently on the 2.4 and 5 GHz radios, with a third radio as a dedicated dual-band sensor. For regulatory and compliance information, see "Regulatory Compliance Statements". Important! Change the Country Code Ifyouraccesspoint isconfiguredforthe WorldRegulatory Domain, it isimportant to set the country code to the country in which the AP willbe deployedto meet regulatory requirementsandforoptimalwirelessoperation. To do this, follow these steps: Thecountrycodeselection isforWorldmodelsonlyandisnot availabletoFCC,CAN,andothercountry-specificmodels.PerFCCreg- ulations,allWi-Fiproductsmarketedin theUnitedStatesmust beset toU.S.channelsonly. 1.Power on the AP and allow it to find and connect to ExtremeCloud IQ. Once the AP is connected it appears in the table of devices in the Manage > Devices window. 2.Select the check box next to the AP, and then select Assign Country Code from the Actions drop-down list. In the dialog box, select the appropriate country from the drop-down list, and then select Save. 3.Upload your changes to the device. Safety Guidelines Safety Guidelines The information in this section applies to AP460C , AP460S6C, and AP460S12C devices. The following safety icons are used in these guidelines to identify the type of precaution: AP460C, AP460S6C, AP460S12C Hardware Guide1 AP460C, AP460S6C, AP460S12C Hardware Guide1 Thisicon indicatesageneralcaution. Failure to comply with acaution notification can result in damage to equipment. Thisicon indicatesan electricalcaution. Failure to comply with an electricalnotification can result in seriousinjury or death, andextensive damage to equipment. Thisicon indicatesalasercaution. Failure to comply with alasercaution can result in seriousinjury. The following table lists the safety precautions you should follow when installing your AP460C , AP460S6C, and AP460S12C devices. Extreme Networksdevicesmust be installedby aprofessionalinstallerwho iscertifiedto installthese typesofdevices andto ensure that they are properly groundedandmeet applicable localandnationalelectricalcodes. These devicesare intendedforindooruse only. Warning: ThisisaClassA product. In adomestic environment thisproduct may cause radio interference in which case the usermay be requiredto take adequate measures. Do not installthe device in an environment where the operatingambient temperature might exceedthe recom- mendedranges. Forproductsavailable in the USA/Canadamarket, forthe 2.4 GHz band, only channels1-11 can be operated. Selec- tion ofotherchannelsisnot possible. Changesormodificationsmade to thisdevice that are not expressly approvedby the party responsible forcom- pliance couldvoidthe user'sauthority to operate the equipment. Use only attachmentsandaccessoriesspecifiedby Extreme Networks. These devicesare not intendedforuse by persons(includingchildren) with reducedphysical, sensory, ormentalcap- abilities, orwith lackofexperience ofknowledge unlessthey are given supervision orinstruction concerninguse ofthe devicesby aperson who isresponsible fortheirsafety. Children shouldbe supervisedto ensure that they do not play with the devices. Electrostatic discharge (ESD) can damage equipment andimpairelectricalcircuitry. ESD damage occurswhen elec- tronic componentsare improperly handledandcan result in complete orintermittent failures. Be sure to follow ESD-pre- vention procedureswhen handlingelectronic componentsandequipment. During operation, the surfaces of these devices can become hot. Use caution when handling. To meet federalradiation exposure requirements, these devicesshouldbe installedat aminimum distance of12"(30 cm) from people oranimals. Install the AP The followingsectionsdescribe how to mount yourAPin an outdoorlocation on apole orflat surface. Shipping Carton Contents The AP460C,AP460S6C,andAP460S12Cshippingcarton containsthe followingitems: lAP460C , AP460S6C, and AP460S12C chassis with two installedM20 cable gland assemblies and plugs, and two installedM25 seal caps. lHardware bag containing grounding hardware (M4 screw, split washer, and lock washer) lReadMe card. Installthe AP AP460C, AP460S6C, AP460S12C Hardware Guide2 AP460C, AP460S6C, AP460S12C Hardware Guide2 Mount the AP460C,AP460S6C,orAP460S12Chorizontally orvertically on apole usingthe built-in bracketson the hardware, oron asolidflat sur- face usingan accessory bracket (see"Accessories"). These devicescan be installedin even the most extreme outdoorenvironments. The fol- lowingsectionsdescribe the installation process. Before youinstallthe device, make sure that youhave allthe materialsandtoolsnecessary, andfamiliarize yourselfwith the safety andsite haz- ardwarnings. Forbest performance,deploydevicesin relativelyopen areasat least 100'(30.5m)apart fromeach other. Required Tools To installyourdevice horizontally orvertically on apole, youwillneedthe followingitems: lTwo hose clampsthat accommodate the diameterofthe pole to which youare mountingthe device. lA slottedscrewdriverto tighten the hose clamps. Installation Methods Install the Device on a Vertical or Horizontal Pole Use the followingstepsto installthe device on averticalorhorizontalpole. 1. Threadtwo hose strapsofthe correct diameterforthe pole through the slotsin on the backofthe device andaroundthe pole. Hose straps shouldbe 1/2"(12 or13 mm) wide andmade ofstainlesssteel. 2. While holdingthe device against the pole, use aslottedscrewdriverto tighten first the topandthen the bottom hose strapscrewsto amin- imum torque ofat least 14 inch-poundsuntilthe device issecure. Make sure that the LAN glandsare facingdow…

Text truncated - open the document above for the full version.

6480 Via Del Oro / San Jose, CA 95119 / +1-408-579-2800 / ExtremeNetworks.com Professional Installation Declaration Date: July 21, 2020 FCC Grant Number: QXO-AP460SC ISED Registration Number: 4141B – AP460SC To Whom It May Concern: Please be advised that due to the unique Market and function targeted by this product, this product will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel that has special trained professional to install this product and will not be sold directly to the general public through retail store. The product can be operated after connecting to the service provider. Then the service provider would control the available bands according to the install location of the product. FunctionSupport Type Support Band AP MasterWLAN 2.4GHz/Bluetooth/Thread/WLAN 5GHz Band 1~4 Client Slave without Radar Detection (Sensor Mode) WLAN 2.4GHz/Bluetooth/Thread/WLAN 5GHz Band 1+4 Bridge MasterWLAN 2.4GHz/Bluetooth/Thread/WLAN 5GHz Band 1+4 Master WLAN 2.4GHz/Bluetooth/Thread/WLAN 5GHz Band 1+4Mesh Note 1: The above information was declared by manufacturer. Note 2: FCC for 5GHz, it supports B1~B4 indoor and outdoor Note 3: ISED for 5GHz, it supports B1~B4 indoor and B2~B4 outdoor. Note 4: MIC for 5GHz, it supports B1~B3 indoor and B3 outdoor Sincerely, Applicant’s company name : Extreme Networks, Inc. Applicant’s company address : 6480 Via Del Oro, San Jose, CA 95119 United States Of America Thomas Whissel / Regulatory Compliance Manager Name and Job Title : E-Mail : [email protected] +1-603-952-5861 Tel :

Declaration Of Authorization Date: 2020-07-21 We Name: Extreme Networks, Inc Address: 6480 Via Del Oro, San Jose, CA 95119 City: San Jose Country: United States Declare that: Agent Company name: DEKRA Testing and Certification (Suzhou) Co., Ltd. Address: No.99 Hongye Rd., Suzhou Industrial Park, 215006 City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: Wireless Access Point Type designation: AP460SC Trademark: Extreme Networks FCC ID: QXO-AP460SC IC: 4141B-AP460SC on our behalf. Sincerely, Thomas Whissel / Regulatory Compliance Manager Extreme Networks, Inc Notes: (1): Required for FCC &IC application (2): For it must be the Grantee Code “owner” or the authorized agent.

6480 Via Del Oro / San Jose, CA 95119 / +1-408-579-2800 / ExtremeNetworks.com FCC Confidentiality Long Term Letter Date：2020-07-21 Federal Communications Commission Authorization and Evaluation Division FCC ID: QXO-AP460SC Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Diagram Block Diagram Operational Description SW SECURITY DESCRIPTION The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Sincerely, Thomas Whissel, Senior Manager, Regulatory Compliance Extreme Networks, Inc

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-External Photo Page 1 / 3 External Photographs (1) EUT Photo (2) EUT Photo DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-External Photo Page 2 / 3 (3) EUT Photo (4) EUT Photo DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-External Photo Page 3 / 3 (5) EUT Photo (6) EUT Photo

图 40 63 1. MATERIAL: WHITE MATTE PET, T=0.1 ADHESIVE: ACRYLIC 2. FINISH: FINISH: ,T=0.025 3. COLOR: ORIGINAL MATERIAL COLOR:Pantone420C : BLACK, 4. UL APPROVED, PGJI2,PRINTED,. 5. 7.:30mm±0.2mm,30~120mm±0.3mm,120~315mm±0.5mm,315±0.8mm 8. ,3±0.5mm, 3±0.3mm 9. 10.TEST REQUIREMENTS NOTE: TEST ITEMTEST SPECTEST CONDITIONCRITERIA 1 ISO Class.: 1 ASTM Class.: 4 B ASTM D3359-02/ ISO 2409:2007 Detach ment of small flake s of the co ating at the interse ct ions of the cu ts. A cr oss-cu t area not si gnifica ntly greater than 5% is affect ed. See manual before use 40 63 2.0 0.8 R 2.0, 4PLS AP460SC -FCC FCC ID: QXO-AP460SC -CAN IC:4141B-AP460SC ICES-3(B)/NMB-3(B) Patents Pending Made in China 510177 Rev. B This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful int erference, and (2)this device must accept any int erference received, including int erference that may cause undesired operation. 37-57V DC, 0.43A 23.3W Max. Extreme Networks Inc. 6480 Via Del Oro, San Jose, CA 95119, USA Patents: www.extremenetworks.com/patents -WR D33194 RoHS R-C-EXR-AP460SC Complies with IMDA Standards DA106976 201-200232 型號 產品名稱：無線接入點 中國製造

DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 1 / 8 Internal Photographs (1) EUT Photo (AP460S6C) (2) EUT Photo (AP460S6C) DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 2 / 8 (3) EUT Photo (AP460S6C) (4) EUT Photo (AP460S6C) DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 3 / 8 (5) EUT Photo (AP460S12C) (6) EUT Photo (AP460S12C) DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 4 / 8 (7) EUT Photo (AP460S12C) (8) EUT Photo (AP460S12C) DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 5 / 8 (9) EUT Photo (AP460S12C) (10) EUT Photo DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 6 / 8 (11) EUT Photo (12) EUT Photo DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 7 / 8 (13) EUT Photo (14) EUT Photo DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 Report no.: 2032034R-RF-Internal Photo Page 8 / 8 (15) EUT Photo (16) EUT Photo

RF Exposure Evaluation Declaration Product Name : Wireless Access Point Model No. : AP460SC FCC ID : QXO-AP460SC Applicant : Extreme Networks, Inc Address : 6480 Via Del Oro, San Jose, CA 95119 Date of Receipt : May. 11, 2020 Issued Date : Aug. 06, 2020 Report No. : 2032034R-RF-US-P20V01 Report Version : V1.0 The test results presented in this report relate only to the object tested. The measurement result is considered in conformance with the requirement if it is within the prescribed limit, It is not necessary to account the uncertainty associated with the measurement result, unless the specification, standard or customer have special requirements This report shall not be reproduced, except in full, without the written approval of the Issuing CB Testing Laboratory This report is not used for social proof in China (or Mainland China) market. Report No: 2032034R-RF-US-P20V01 Page: 2 of 13 Te s t R e p o r t C e r t i f i c a t i o n Issued Date: Aug. 06, 2020 Report No.: 2032034R-RF-US-P20V01 Product Name : Wireless Access Point Applicant : Extreme Networks, Inc Address : 6480 Via Del Oro, San Jose, CA 95119 Manufacturer : Extreme Networks, Inc Address : 6480 Via Del Oro, San Jose, CA 95119 Model No. : AP460SC Brand : Extreme Networks FCC ID : QXO-AP460SC EUT Voltage : DC 37~57V Applicable Standard : KDB 447498D01V06 FCC Part1.1310 Test Result : Complied Performed Location : DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Designation Number: CN1199 Documented By : (Project Assistant: Kitty Li) Reviewed By : (Technical Supervisor: Frank He) Approved By : (Supervisor: Jack Zhang) Report No: 2032034R-RF-US-P20V01 Page: 3 of 13 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm2. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 2032034R-RF-US-P20V01 Page: 4 of 13 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : Wireless Access Point Test Item : RF Exposure Evaluation Test Site : AC-6 Note: Model AP460SC have two antenna configurations called AP460S6C and AP460S12C, they are the same except the antenna type and antenna gain. We evaluated AP460S6C for conducted test item, AP460S6C, AP460S12C for radiated test item and conducted emission, shown in the report is the worst data of AP460S6C, AP460S12C. Antenna Information: BLE: AP460S6C: Antenna Model No. N/A Antenna Manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX Antenna Technology SISO MIMO Basic methodology Sectorized antenna systems Cross-polarized antennas Unequal antenna gains, with equal transmit powers Spatial Multiplexing Cyclic Delay Diversity (CDD) Antenna Type PIFA Antenna 3(Radio 3) Gain 7.90 dBi Report No: 2032034R-RF-US-P20V01 Page: 5 of 13 AP460S12C: Antenna Model No. N/A Antenna Manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX Antenna Technology SISO MIMO Basic methodology Sectorized antenna systems Cross-polarized antennas Unequal antenna gains, with equal transmit powers Spatial Multiplexing Cyclic Delay Diversity (CDD) Antenna Type PIFA Antenna 3(Radio 3) Gain 6.63 dBi Report No: 2032034R-RF-US-P20V01 Page: 6 of 13 WLAN 2.4GHz: AP460S6C: Antenna Model No. N/A Antenna Manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX Antenna Technology SISO MIMO Basic methodology Sectorized antenna systems Cross-polarized antennas Unequal antenna gains, with equal transmit powers Spatial Multiplexing Cyclic Delay Diversity (CDD) Antenna Type PIFA Antenna Gain(Radio 1) Antenna Technology Ant Gain (dBi) Ant 4(Radio 1) 7.83 Antenna Gain(Radio 2) Antenna Technology Ant Gain (dBi) SISO Ant1 (Radio 2) 7.88 Ant2 (Radio 2) 7.88 CDD 7.88 dBi for Power; 10.89 dBi for PSD Beam-forming 10.89 dBi for Power; 10.89 dBi for PSD Report No: 2032034R-RF-US-P20V01 Page: 7 of 13 AP460S12C: Antenna Model No. N/A Antenna Manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX Antenna Technology SISO MIMO Basic methodology Sectorized antenna systems Cross-polarized antennas Unequal antenna gains, with equal transmit powers Spatial Multiplexing Cyclic Delay Diversity (CDD) Antenna Type PIFA Antenna Gain(Radio 1) Antenna Technology Ant Gain (dBi) Ant 4(Radio 1) 5.53 Antenna Gain(Radio 2) Antenna Technology Ant Gain (dBi) SISO Ant1 (Radio 2) 7.12 Ant2 (Radio 2) 6.16 CDD 7.12 dBi for Power; 10.13 dBi for PSD Beam-forming 10.13 dBi for Power; 10.13 dBi for PSD Report No: 2032034R-RF-US-P20V01 Page: 8 of 13 WLAN 5GHz: AP460S6C: Antenna Model No. N/A Antenna Manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX 4*TX+4*RX Antenna Technology SISO MIMO Basic methodology Sectorized antenna systems Cross-polarized antennas Unequal antenna gains, with equal transmit powers Spatial Multiplexing Cyclic Delay Diversity (…
