Installing the Enterasys Wireless Outdoor AP3660 For complete installation instructions and information about the Enterasys Wireless Outdoor AP3660, see the Enterasys Wireless Outdoor AP3660 Installation Guide at http:/ /www.enterasys.com/support/manuals. Overview of the Enterasys Wireless Outdoor AP3660 The Enterasys Wireless Outdoor AP enables you to extend your Wireless LAN beyond the boundaries of indoor locations. They are resistant to harsh outdoor conditions and extreme temperatures. Using the advanced wireless distribution mesh feature of Enterasys Wireless LAN, the Enterasys Wireless Outdoor AP3660 can extend your Wireless LAN to outdoor locations without Ethernet cabling. A mounting bracket is a vailable to enable quick and easy mounting of the Enterasys Wireless Outdoor APs to walls and poles. Figure 1 Enterasys Wireless Outdoor AP3660 The Enterasys Wireless Outdoor AP3660 supports the 902.11n, 802.11a, 802.11g, and full backward compatibility with legacy 802.11b devices. The Enterasys Wireless Outdoor AP3660 with external antenna connectors supports a variety of antennas, providing range and coverage versatility. The Enterasys Wireless Outdoor AP3660 interoperates fully with Enterasys Wireless LAN, including support for Vo WLAN, branch office mode, guest services, RTLS, availability and mobility features. Unpacking the Enterasys Wireless Outdoor AP3660 Unpack the AP from its carton. The following components are supplied with the Enterasys Wireless Outdoor AP3660 package •1 mounting bracket •2 stainless steel tie back straps that support pole diameters up to 4 inches •4 M6 screws •4 washers Electrical Hazard: Only qualified personnel should perform installation procedures. Antenna Connectors •4 spring washers •1 ground screw •RJ45 waterproof connector assembly •A printed copy of the Enterasys Wireless Outdoor Access Point Quick Reference ‐ AP3660 Mounting and Connecting the Enterasys Wireless Outdoor AP3660 Mounting and connecting the Enterasys Wireless Outdoor AP3660 can be accomplished easily and safely by following the instructions in the full Enterasys Wireless Outdoor Access Point AP3660 Installation Guide. The installation of the Outdoor AP should be performed by a professional installer to ensure proper operation and compliance with safety guidelines. Mounting the Outdoor AP3660: 1. Attach the mounting bracket to the AP3660 using four M6 screws and washers. You can attach the bracket to the AP in either the vertical or horizontal position as shown in Figures 2 and 3. Figure 2 Mounting Bracket - Vertical Position Figure 3 Mounting Bracket - Horizontal Position 2. You can mount the AP3660 to either a pole or a wall: a. To mount the AP3660 with the attached mounting bracket to a pole, use the supplied stainless steel tie back straps. You can mount the AP3660 to a pole in one of three possible configurations, as shown in Figures 4, 5, and 6. Note: Before you start mounting the Enterasys Wireless Outdoor AP3660, read the Safety Guidelines below. Figure 4 AP3660 - Pole Mount Option 1 Figure 5 AP3660 - Pole Mount Option 2 Figure 6 AP3660 - Pole Mount Option 3 b.Mount the AP3660 and the attached mounting bracket to a wall using four wood/gyprock screws as shown in Figure 7. Figure 7 AP3660 - Wall Mount 3.Install the external antenna intended for area coverage. For information about antenna selection and installation, refer to the External Antenna Site Preparation and Installation Guide. 4.Attach the external antenna cables to the RP‐N connectors on the AP. Connecting and powering the AP You can power up the AP in one of the following ways: •Power over Ethernet: Adding PoE injector You can provide power to the Ethernet cable with a PoE injector. The PoE injector must be 802.3at compliant. The PoE injector is not provided with the AP. A waterproof RJ45 connector is provided to connect the Po E injector to the AP3660. You must connect the RJ45 connector to the RJ45 cable. For instructions, refer to the full Enterasys Wireless Outdoor Access Point AP3660 Installation Guide. •Power by external power supply: You can purchase an external power supply unit (WS‐ PS3660‐MR) to power the AP. See yo ur Enterasys sales representative for details. For power supply installation instructions, refer to the Enterasys Wireless Outdoor Access Point AP3660 Installation Guide. Regulatory and Compliance information Federal Communications Commission (FCC) Notice: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Industry Canada Notice: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations for the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouil lage radioélectrique édicté par le ministère des Communications du Canada. Refer to the HiPath Wireless Controller, Access Points, and Convergence Software User Guide Installation Guide, Appendix B, ʺRegulatory information,ʺ for complete regulatory information. Warning: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment 17x11 bleed template; DragonNotice; large text Safety Guidelines This section contains notices that you have to adhere to ensure your personal safety and to prevent any damage to the equipment. Qualified Personnel: Grounding Warning: Lightning Protection Warning: Electrical Hazard: Only qualified personnel should perform installation procedures. Within the context of the safety notes in this documentation qualified persons are defined …
