QXO-RBTBFWireless LAN PC card

802.11a PC Card Installation and Specifications 903xxxx ENJOY THE FREEDOM OF WIRELESS NETWORKING ENTERASYS.COM ™ DRAFT Notice Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. © 2003 Enterasys Networks TM All rights reserved. Enterasys Networks, Inc. 35 Industrial Way Rochester, NH 03867 Order Number: 903xxxx-xx DRAFT February 2003 Web Site: www.enterasys.com/products/wireless ENTERASYS, ENTERASYS NETWORKS, NETSIGHT, ROAMABOUT, and any logos associated therewith, are trademarks of Enterasys Networks, Inc. in the United States and other countries. Microsoft, Windows, and Windows NT are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. PC Card is a trademark of PCMCIA in the United States and other countries. All other trademarks and registered trademarks are the property of their respective holders. DRAFT Regulatory Information Exposure to Radio Frequency Radiation. The radiated output power of the IEEE 802.11 RoamAbout PC Card is far below the FCC radio frequency exposure limits. Nevertheless, the RoamAbout PC Card shall be used in such a manner that the potential for human contact during normal operation is minimized. When using this device in combination with RoamAbout Outdoor Antenna products, a certain separation distance between antenna and nearby persons has to be kept to ensure RF exposure compliance. Refer to the Regulatory Statements as identified in the documentation that comes with those products for additional information. Interference Statement. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the distance between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio or TV technician for help. Enterasys Networks is not responsible for any radio or television interference caused by unauthorized modification of the devices included in this kit, or the substitution or attachment of connecting cables and equipment other then specified by Enterasys Networks. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. For country-specific approvals, please consult the Radio Certification Information document included in this kit. Visit the RoamAbout Wireless web site for updated country approvals. Canada - Industry Canada (IC). This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. cet appareil de la class B respecte toutes les exigences du Reglement sur le matereil brouiller du Canada Product Safety. CAUTION: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. USA UL 1950, UL Listed CanadaCUL 1950 DRAFT Technical Specifications. Mechanical Specifications Dimensions: (LxWxH) 114.55 x 54 x 9.65 mm (4.51 x 2.26 x .38 in) Weight62.4 grams (2.2 oz) Radio Characteristics Receiver Sensitivity dBm See Table 1. Output Power13 dBm StandardsIEEE 802.11a, WiFi Certified PC Card Power Characteristics Receive Mode430 mA Transmit Mode540 mA Power Supply 3.3 V Temperature and Humidity Operation -20 o to 50 o C (-4 o F to 122 o F) Storage -30 o to 66 o C (-22 o to 150.8 o F) HumidityMaximum 95%, no condensation allowed. Compatibility Operating System Microsoft Windows 98, Me, 2000, XP and windows NT (with the RoamAbout driver) PC Card• All RoamAbout 802.11 PC Cards • Hot Swapping supported DRAFT Getting Help For additional support related to this device or document, contact Enterasys Networks using one of the following methods: Before calling Enterasys Networks, please have the following information ready: •Your Enterasys Networks service contract number •A description of the problem •A description of any action(s) already taken to resolve the problem •The serial and revision numbers of all involved Enterasys Networks products in the network •A description of your network environment (for example, layout, cable type) •Network load and frame size at the time of trouble (if known) •The device history (for example, have you returned the device before, is this a recurring problem) •Any previous Return Material Authorization (RMA) numbers World Wide Web: www.enterasys.com/ products/wireless Phone: North America: (603) 332-9400 Europe: 353 61 701 910 Asia: +800 8827-2878 Internet mail: [email protected]…

Text truncated - open the document above for the full version.

802.11a PC Card Installation and Specifications 9033774 DRAFT ENJOY THE FREEDOM OF WIRELESS NETWORKING ENTERASYS.COM ™ NOTICE Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 35 Industrial Way Rochester, NH 03867 © 2003 Enterasys Networks, Inc. All rights reserved. Part Number: 903xxxx DRAFT FEB 28-03 Enterasys Networks and ROAMABOUT are registered trademarks and ENTERASYS ROAMABOUT, and any logos associated therewith, are trademarks of Enterasys Networks, Inc. in the United States and other countries. Microsoft, Windows, and Windows NT are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. PC Card is a trademark of PCMCIA in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Regulatory Information Exposure to Radio Frequency Radiation. The radiated output power of the IEEE 802.11 RoamAbout PC Card is far below the FCC radio frequency exposure limits. Nevertheless, the RoamAbout PC Card shall be used in such a manner that the potential for human contact during normal operation is minimized. When using this device in combination with RoamAbout Outdoor Antenna products, a certain separation distance between antenna and nearby persons has to be kept to ensure RF exposure compliance. Refer to the Regulatory Statements as identified in the documentation that comes with those products for additional information. Interference Statement. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the distance between the equipment and the receiver. •Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio or TV technician for help. Enterasys Networks is not responsible for any radio or television interference caused by unauthorized modification of the devices included in this kit, or the substitution or attachment of connecting cables and equipment other then specified by Enterasys Networks. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. For country-specific approvals, please consult the Radio Certification and Regulatory Information document included in this kit. Visit the RoamAbout Wireless web site for updated country approvals. Canada - Industry Canada (IC). This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. cet appareil de la class B respecte toutes les exigences du Reglement sur le matereil brouiller du Canada. CAUTION: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Getting Help For additional support related to this device or document, contact Enterasys Networks using one of the following methods: Before contacting Enterasys Networks for technical support, have the following information ready: •Your Enterasys Networks service contract number •A description of the failure •A description of any action(s) already taken to resolve the problem •The serial and revision numbers of all involved Enterasys Networks products in the network •A description of your network environment (layout, cable type) •Network load and frame size at the time of trouble (if known) •The device history (for example, have you returned the device before, is this a recurring problem, etc.) •Any previous Return Material Authorization (RMA) numbers World Wide Web: www.enterasys.com/support Phone: (603) 332-9400 1-800-872-8440 (toll-free in the U.S. and Canada) For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/support/gtac-all.html Internet mail: [email protected] To send comments or suggestions concerning this document to the Technical Writing Department: [email protected] Make sure to include the document Part Number in the email message. 1 RoamAbout 802.11a PC Card This document provides the system requirements, installation procedure, and technical specifications for the RoamAbout 802.11a PC Card. Before in…

Text truncated - open the document above for the full version.

802.11a PC Card Installation and Specifications 9033774 DRAFT ENJOY THE FREEDOM OF WIRELESS NETWORKING ENTERASYS.COM ™ NOTICE Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 35 Industrial Way Rochester, NH 03867 © 2003 Enterasys Networks, Inc. All rights reserved. Part Number: 903xxxx DRAFT FEB 28-03 Enterasys Networks and ROAMABOUT are registered trademarks and ENTERASYS ROAMABOUT, and any logos associated therewith, are trademarks of Enterasys Networks, Inc. in the United States and other countries. Microsoft, Windows, and Windows NT are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. PC Card is a trademark of PCMCIA in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Regulatory Information Exposure to Radio Frequency Radiation. The radiated output power of the IEEE 802.11 RoamAbout PC Card is far below the FCC radio frequency exposure limits. Nevertheless, the RoamAbout PC Card shall be used in such a manner that the potential for human contact during normal operation is minimized. This 802.11a RoamAbout PC Card is intended for indoor use only. Interference Statement. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the distance between the equipment and the receiver. •Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio or TV technician for help. Enterasys Networks is not responsible for any radio or television interference caused by unauthorized modification of the devices included in this kit, or the substitution or attachment of connecting cables and equipment other then specified by Enterasys Networks. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. For country-specific approvals, please consult the Radio Certification and Regulatory Information document included in this kit. Visit the RoamAbout Wireless web site for updated country approvals. Canada - Industry Canada (IC). This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. cet appareil de la class B respecte toutes les exigences du Reglement sur le matereil brouiller du Canada. CAUTION: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Getting Help For additional support related to this device or document, contact Enterasys Networks using one of the following methods: Before contacting Enterasys Networks for technical support, have the following information ready: •Your Enterasys Networks service contract number •A description of the failure •A description of any action(s) already taken to resolve the problem •The serial and revision numbers of all involved Enterasys Networks products in the network •A description of your network environment (layout, cable type) •Network load and frame size at the time of trouble (if known) •The device history (for example, have you returned the device before, is this a recurring problem, etc.) •Any previous Return Material Authorization (RMA) numbers World Wide Web: www.enterasys.com/support Phone: (603) 332-9400 1-800-872-8440 (toll-free in the U.S. and Canada) For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/support/gtac-all.html Internet mail: [email protected] To send comments or suggestions concerning this document to the Technical Writing Department: [email protected] Make sure to include the document Part Number in the email message. 1 RoamAbout 802.11a PC Card This document provides the system requirements, installation procedure, and technical specifications for the RoamAbout 802.11a PC Card. Before installing the PC Card, please review the Regulatory information included in the RoamAbout Radio Certification and Regulatory Information document included with the PC Card. System Requirements When you install the RoamAbout PC Card, you must also install its …

Text truncated - open the document above for the full version.

Curtis-Straus LLC 527 Great Road Littleton, Massachusetts 01460 Tel: 978.486.8880 Fax: 978.486.8828 Web: www.curtis-straus.com Worldwide Regulatory Approvals Experts ® February 28, 2003 Federal Communications Commission Re: FCC Part 15 Certification for Enterasys Networks (FCC ID: QXO-RBTBF) We are submitting an application for Enterasys Networks UNII band Wireless Network Card model 802.11A Super Rate Wireless LAN PC Card. Please note that we are simultaneously requesting the following services: Certification Request for Confidentiality Enterasys is requesting that the Block Diagram, Schematics and Circuit Description be kept confidential in the FCC application because of the proprietary design developed by Enterasys that is unique to the industry. Please feel free to contact me with any questions. Best regards, Michael Buchholz Senior EMC Manager

Curtis-Straus LLC 527 Great Road Littleton, Massachusetts 01460 Tel: 978.486.8880 Fax: 978.486.8828 Web: www.curtis-straus.com Worldwide Regulatory Approvals Experts ® February 28, 2003 Federal Communications Commission Re: FCC Part 15 Certification for Enterasys Networks (FCC ID: QXO-RBTBF) In regards to this application, when filling out the online Form 731, we inadvertently left out our own contact information for correspondence with the FCC. I would like to request that the following information is used regarding correspondence for this application: Michael Buchholz Curtis-Straus LLC 527 Great Rd Littleton, MA 01460 Phone: 978.486.8880 Fax: 978.486.8828 email: [email protected] Sorry for the inconvenience. Please feel free to contact me with any questions. Best regards, Michael Buchholz Senior EMC Manager

UltraTech Group of Labs April 1, 2003 Re: FCC ID QXO-RBTBF Applicant: Enterasys Networks, Inc. Correspondence Reference Number: 25001 731 Confirmation Number: EA398168 Q4) SAR values are unexpectedly low - what are possible reasons? Dipole validation at 250mW gives ~12 W/kg - divide by 10 for 25mW gives ~1.2 W/kg. Some independent means to confirm that EUT was operating properly would be helpful. Please describe SAR lab EUT conducted power test, including eqpt list and photos. A4) The low SAR obtained for this particular unit may be as a result of poor antenna matching. We suspect this due to the antenna specs which state a minimum 3dBi peak gain across the band. The peak EIRP measured by Curtis Straus was as low as -1.76dBi indicating there was almost a 5dB mismatch difference between antenna specified gain and the measured gain when the antenna is integrated with into the PCMCIA card. Another factor which may explain the difference between extrapolated dipole validation numbers to this EUT antenna is that the EUT antenna displays an omnidirectional pattern in the horizontal plane which may indicate that the main axis of the EUT antenna is aligned to provide minimal coupling to the phantom. In the dipole validation case, the dipole is orientated to provide maximum coupling to the phantom as the dipole elements are in a plane parallel to the phantom surface. If the dipole elements were orientated orthogonal to the phantom surface, we may get a more representative estimate of the expected SAR from antennas where the main elements are orthogonal to the phantom surface such as in a case where an omni monopole is placed orthogonal to the phantom surface. Also it is well known that a very small distance change (either in air or in tissue) at this frequency band could make a huge difference in SAR as well. Therefore, the direct comparison from the extrapolated dipole number to the actual EUT measurement is somewhat less meaningful. An HP8900D Peak Power Meter was used to measure the RF peak conducted power at UltraTech Labs to corroborate the power settings used in the SAR measurements. The RF cable for RF conducted power measurement was provided by Enterasys and the cable loss was specified as 0.2 dB @ 5GHz by Enterasys. Regards, JaeWook Choi SAR system engineer UltraTech Labs. Email: [email protected] 31040/SIT A96/TH/0093 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

REPORT: ED0838-1 FCC ID: QXO-RBTBF EXHIBIT: External Photos MODEL: RBTBF-AX Page 1 of 2 _____________________________________________________________ Curtis-Straus LLC •• 527 Great Road •• Littleton, MA •• TEL (978) 486-8880 •• FAX (978) 486-8828 REPORT: ED0838-1 FCC ID: QXO-RBTBF EXHIBIT: External Photos MODEL: RBTBF-AX Page 2 of 2 _____________________________________________________________ Curtis-Straus LLC •• 527 Great Road •• Littleton, MA •• TEL (978) 486-8880 •• FAX (978) 486-8828

4 3 21 A B CC B A APPRDATEDRAFTZONEECOREVDESC REPLACED DWG #: REVISIONS 12 3 4 PART NO. ALL SHARP EDGES DEBURR AND BREAK CONCENTRICITY .005 TIR 63 .XXX +/- .005 .XX +/- .010 .X +/- .030 B SIZEPREFIX REVISION SHEET SCALE OF TITLE DIMENSIONS IN INCHES DO NOT SCALE THIS DRAWING MATERIAL FINISH SYMBOLLEGEND E1 2 4. REVISION DELTA NOTE FLAG ITEM INDICATOR C 1989 UNLESS OTHERWISE SPECIFIED ALL MACHINE SURFACES PROPRIETARY NOTICE THIS DRAWING IS THE PROPERTY OF CABLETRON INC. AND IS TO BE RETURNED UPON DEMAND OR TERMINATION OF THE TRANSACTION FOR WHICH IT WAS FURNISHED. USE OF ANY INFORMATION CON- TAINED ON THIS DRAWING FOR ANY PURPOSE OTHER THAN EXPRESSLY AUTHORIZED IN WRITING BY CABLETRON, INC. IS PROHIBITED. ENGINEER SEE NOTES NOTES: 1. General Description: This specification defines the detail requirements for an adhesive backed thermal transfer printable label intended to be surface printed with additional information at point of final assembly. 2. Material: Base: 2 mil White Polyester. Cap: None. Adhesive: 1 mil Permanent Pressure Sensitive Acrylic, Flexcon V-23. Liner: Adhesive shall be protected by an easy release liner. 3. Configuration / Dimension Artwork: 1.66 Inch Wide x 2.61 Inch High X 0.05 Inch Radius. Put-Up: Labels to be supplied on rolls, kiss cut to liner. The distance between the end of one label and the start of the next label shall be 0.12 Inch. All matrix shall be removed from the liner. Labels to be "Copy Position 5" (Wound In). 890A0354-00 0801 W F MCCARTHY LABEL, PC CARD, ROAMABOUT, BLANK 1 / 1 1 1 0125 AUG 02 WFMALLWFM 2.61 1.66 0.05 R 4 PLACES

C 4 3 21 5 A B D E 5 E D C B A REVISIONS REPLACED DWG #: DESCREVECOZONEDRAFTDATEAPPR 12 3 4 PART NO. ALL SHARP EDGES DEBURR AND BREAK CONCENTRICITY .005 TIR 63 .XXX +/- .005 .XX +/- .010 .X +/- .030 C SIZEPREFIX REVISION SHEET SCALE OF TITLE DIMENSIONS IN INCHES THIS DRAWING DO NOT SCALE MATERIAL FINISH SYMBOLLEGEND E1 2 4. REVISION DELTA NOTE FLAG ITEM INDICATOR UNLESS OTHERWISE SPECIFIED ALL MACHINE SURFACES PROPRIETARY NOTICE THIS DRAWING IS THE PROPERTY OF ENTERASYS NETWORKS INC. AND IS TO BE RETURNED UPON DEMAND OR TERMINATION OF THE TRANSACTION FOR WHICH IT WAS FURNISHED. USE OF ANY INFORMATION CON- TAINED ON THIS DRAWING FOR ANY PURPOSE OTHER THAN EXPRESSLY AUTHORIZED IN WRITING BY ENTERASYS NETWORKS, INC. IS PROHIBITED. ENGINEER SEE NOTES C 2000 NOTES: 1. INSIDE OF TOP COVER (ITEM 1) SHOWN WITH "TOP RF ABSORBER" (ITEM 6) APPLIED (SEE VIEW A). 2. INSIDE OF BOTTOM COVER (ITEM 2) SHOWN WITH "BOTTOM RF ABSORBER" (ITEM 7) APPLIED (SEE VIEW B). 3. INSIDE OF BOTTOM COVER WITH MODULE (ITEM 3) INSTALLED AND "POWER AMP RF ABSORBER" (ITEM 8) APPLIED. ITEM 8 USES POWER AMP ON THE MODULE FOR POSITIONING (SEE VIEW C). 4. ASSEMBLE FRAME KIT AFTER THE ABOVE STEPS AND ULTRASONICALLY WELD. 5. APPLY FRONT LABEL (ITEM 4). 6. APPLY REAR LABEL (ITEM 5). REAR LABEL IS TO BE PRINTED ON DEMAND. REAR LABEL IS TO CONTAIN THE FOLLOWING INFORMATION: MODEL NUMBER, ALL REGULATORY INFORMATION MAC ADDRESS SERIAL NUMBER 0124 AUG 02 WFM ALL PRELIMINARY 9403700-00 0903 NONE 1 1 W F MCCARTHY WFM ROAMABOUT PC CARD, 54 MB ASSEMBLY 0205 JAN 03WFMALL PRELIMINARY WFME005936 VIEW A SEE NOTE 1 VIEW B SEE NOTE 2 VIEW C SEE NOTE 3 6 7 3 8 REAR VIEW SEE NOTE 6 FRONT VIEW SEE NOTES 4 & 5 1 2 4 5 EXAMPLE OF REAR LABEL SCALE: NONE

C 4 3 21 5 A B D E 5 E D C B A REVISIONS REPLACED DWG #: DESCREVECOZONEDRAFTDATEAPPR 12 3 4 PART NO. ALL SHARP EDGES DEBURR AND BREAK CONCENTRICITY .005 TIR 63 .XXX +/- .005 .XX +/- .010 .X +/- .030 C SIZEPREFIX REVISION SHEET SCALE OF TITLE DIMENSIONS IN INCHES THIS DRAWING DO NOT SCALE MATERIAL FINISH SYMBOLLEGEND E1 2 4. REVISION DELTA NOTE FLAG ITEM INDICATOR UNLESS OTHERWISE SPECIFIED ALL MACHINE SURFACES PROPRIETARY NOTICE THIS DRAWING IS THE PROPERTY OF ENTERASYS NETWORKS INC. AND IS TO BE RETURNED UPON DEMAND OR TERMINATION OF THE TRANSACTION FOR WHICH IT WAS FURNISHED. USE OF ANY INFORMATION CON- TAINED ON THIS DRAWING FOR ANY PURPOSE OTHER THAN EXPRESSLY AUTHORIZED IN WRITING BY ENTERASYS NETWORKS, INC. IS PROHIBITED. ENGINEER SEE NOTES C 2000 NOTES: 1. INSIDE OF TOP COVER (ITEM 1) SHOWN WITH "TOP RF ABSORBER" (ITEM 6) APPLIED (SEE VIEW A). 2. INSIDE OF BOTTOM COVER (ITEM 2) SHOWN WITH "BOTTOM RF ABSORBER" (ITEM 7) APPLIED (SEE VIEW B). 3. INSIDE OF BOTTOM COVER WITH MODULE (ITEM 3) INSTALLED AND "POWER AMP RF ABSORBER" (ITEM 8) APPLIED. ITEM 8 USES POWER AMP ON THE MODULE FOR POSITIONING (SEE VIEW C). 4. ASSEMBLE FRAME KIT AFTER THE ABOVE STEPS AND ULTRASONICALLY WELD. 5. APPLY FRONT LABEL (ITEM 4). 6. APPLY REAR LABEL (ITEM 5). REAR LABEL IS TO BE PRINTED ON DEMAND. REAR LABEL IS TO CONTAIN THE FOLLOWING INFORMATION: MODEL NUMBER, ALL REGULATORY INFORMATION MAC ADDRESS SERIAL NUMBER 0124 AUG 02 WFM ALL PRELIMINARY 9403700-00 0903 NONE 1 1 W F MCCARTHY WFM ROAMABOUT PC CARD, 54 MB ASSEMBLY 0205 JAN 03WFMALL PRELIMINARY WFME005936 REAR VIEW SEE NOTE 6 FRONT VIEW SEE NOTES 4 & 5 1 2 4 5 EXAMPLE OF REAR LABEL SCALE: NONE

REPORT: ED0838-1 FCC ID: QXO-RBTBF EXHIBIT: Internal Photos MODEL: RBTBF-AX Page 1 of 2 _____________________________________________________________ Curtis-Straus LLC •• 527 Great Road •• Littleton, MA •• TEL (978) 486-8880 •• FAX (978) 486-8828 REPORT: ED0838-1 FCC ID: QXO-RBTBF EXHIBIT: Internal Photos MODEL: RBTBF-AX Page 2 of 2 _____________________________________________________________ Curtis-Straus LLC •• 527 Great Road •• Littleton, MA •• TEL (978) 486-8880 •• FAX (978) 486-8828

February 20, 2003 File No.: ENEN-001-SAR ENTRASYS NETWORKS 35 Industrial Way Rochester, NH 03867 USA NOT TRANSFERABLE This Verification Certificate is hereby issued to the named GRANTEE and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below: GRANTEE'S NAME: ENTRASYS NETWORKS PRODUCT UNDER TEST: 802.11A SUPER RATE WIRELESS LAN PC CARD MODEL NO.: RBTBF-AX FCC ID: 5N5-RBTBF OPERATING FREQUENCY RANGE: 5180 ~ 5320 MHz RF OUTPUT POWER: 14.55 dBm conducted EXPOSURE CATEGORY: General Population/Uncontrolled MAX. PEAK SPATIAL-AVERAGE SAR 1g : 0.062 W/Kg APPLICABLE STANDARDS: SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA ) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST Technology ( NIST) Approved by: Tri M. Luu, P.Eng. V.P. – Engineering UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 00-034

802.11A SUPER RATE WIRELESS LAN PC CARD Model No.: RBTBF-AX Tested For ENTRASYS NETWORKS 35 Industrial Way Rochester, NH 03867 USA In Accordance With SAR (Specific Absorption Rate) Requirements using guidelines establi…

Text truncated - open the document above for the full version.
