P/N 9034646 Enterasys ® Wireless Access Points Installation Guide WS-AP3705i Draft Wireless Access Point i Notice Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810  2012 Enterasys Networks, Inc. All rights reserved. Part Number: 9034646 July 2012 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS SECURE NETWORKS, NETSIGHT, ENTERASYS NETSIGHT, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and/or other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: https://extranet.enterasys.com/downloads/ Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Draft ii Hazardous Substances This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): 1.The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. 2.When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. 3.It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. 4.It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). Draft iii ѻѻક䇈ᯢк䰘ӊ Supplement to Product Instructions ᳝↦᳝ᆇ⠽䋼៪ܗ㋴(Hazardous Substance) 䚼ӊৡ鹵 (Parts) 䪙 3E ∲ +J 䬝 &G ݁Ӌ䫀 &U  ໮1.㘨㣃 3%% ໮1.Ѡ㣃䝮 3%'( 䞥ሲ䚼ӊ (Metal Parts) hƻ ƻ ƻ ƻ ƻ ⬉䏃῵ഫ (Circuit Modules) hƻ ƻ ƻ ƻ ƻ ⬉㓚ঞ⬉㓚㒘ӊ (Cables & Cable Assemblies) hƻ ƻ ƻ ƻ ƻ ล᭭੠㘮ড়⠽䚼ӊ (Plastic and Polymeric parts) ƻƻ ƻ ƻ ƻ ƻ ⬉䏃ᓔ݇ (Circuit Breakers) ƻƻ ƻ ƻ ƻ ƻ  ƻ˖ 㸼冫䆹᳝↦᳝ᆇ⠽䋼೼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ৿䞣ഛ೼SJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is below the relevant threshold of the SJ/T 11363-2006 standard. h˖ 㸼冫䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ೼䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ৿䞣䍙ߎSJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖DŽ Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in the parts is above the relevant threshold of the SJ/T 11363-2006 standard.  ᇍ䫔ଂП᮹ⱘ᠔ଂѻકᴀ㸼ᰒ冫 ߯߃կᑨ䫒ⱘ⬉ᄤֵᙃѻકৃ㛑ࣙ৿䖭ѯ⠽䋼DŽ⊼ᛣ೼᠔ଂѻકЁৃ㛑Ӯгৃ㛑ϡӮ৿᳝᠔᳝᠔߫ⱘ䚼ӊDŽ This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.  䰸䴲঺໪⡍߿ⱘᷛ⊼דᷛᖫЎ䩜ᇍ᠔⍝ঞѻકⱘ⦃ֱՓ⫼ᳳᷛᖫᶤѯ䳊䚼ӊӮ ᳝ϔϾϡৠⱘ⦃ֱՓ⫼ᳳ ՟བ⬉∴ऩܗ῵ഫ 䌈೼݊ѻકϞ ד⦃ֱՓ⫼ᳳ䰤া䗖⫼Ѣѻકᰃ೼ѻક᠟ݠЁ᠔㾘ᅮⱘᴵӊϟᎹ԰ The Environmentally Friendly Use Period (EFUP) for all enclosed products and their parts are per the symbol shown here, unless otherwise marked. Certain parts may have a different EFUP (for example, battery modules) and so are marked to reflect such. The Environmentally Friendly Use Period is valid only when the product is operated under the conditions defined in the product manual. Draft iv Enterasys Networks, Inc. Firmware License Agreement BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END…

Text truncated - open the document above for the full version.

Report No.: 120517E03 1 of 8 CONSTRUCTION PHOTOS OF EUT Report No.: 120517E03 2 of 8

Joan HuangYu ChangYu Chang 2012/5/22012/5/22012/5/2 WS-AP3705I  Device Label (1) 970000011708G R1.00 69.40 84.40 27.40 19.40 Model: WS-AP3705I LAN: 20B3991E6D11 1WLAN: 20B3991E6D78 S/N: YYWWXXXX90RR 0WLAN: 20B3991E6D70 PROG #: YYWWXXXX90RR0000 Model: WS-AP3705i N826 FCC ID: QXO-WSAP3705IIC ID: 4138A-WSAP3705 Made in China(C3) 100037-656 Complies with RSS-210 ICES-003 CLASS BThis device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Input Voltage Range: Input 48V 0.67A FCC ID: QXO-WSAP3705I IC: 4138A-WSAP3705

Label Location

Report No.: 120517E03 1 of 6 CONSTRUCTION PHOTOS OF EUT Report No.: 120517E03 2 of 6 Report No.: 120517E03 3 of 6 Report No.: 120517E03 4 of 6 Report No.: 120517E03 5 of 6 Report No.: 120517E03 6 of 6

Report No.: SA120517E03 1 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 RF EXPOSURE REPORT REPORT NO.: SA120517E03 MODEL NO.: WS-AP3705i FCC ID: QXO-WSAP3705I RECEIVED: May 17, 2012 TESTED: June 16 to 21, 2012 ISSUED: July 04, 2012 APPLICANT: Enterasys Networks, Inc. ADDRESS: 50 Minuterman Road Andover, MA 01810 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120517E03 2 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA120517E03 3 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120517E03 Original release July 04, 2012 Report No.: SA120517E03 4 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 1. CERTIFICATION PRODUCT: Wireless Access Point BRAND NAME: Enterasys Networks MODEL NO.: WS-AP3705i TEST SAMPLE: MASS-PRODUCTION APPLICANT: Enterasys Networks, Inc. TESTED DATE: June 16 to 21, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: WS-AP3705i ) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 04, 2012 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: July 04, 2012 ( May Chen, Deputy Manager ) Report No.: SA120517E03 5 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 22cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120517E03 6 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: For 2.4GHz Transmitter Circuit Manufacture Model name Antenna Gain Antenna Type Connector Gain (dBi) Chain (0) WHA YU GROUP C037-511135-A (SSR-13314) 3.97 PIFA I-PEX Chain (1) WHA YU GROUP C037-511135-A (SSR-13314) 3.91 PIFA I-PEX For 5GHz Transmitter Circuit Manufacture Model name Antenna Gain Antenna Type Connector Gain (dBi) Chain (0) WHA YU GROUP C037-511135-A (SSR-13314) 5G Band1: 3.74 5G Band2: 3.92 5G Band3: 3.95 5G Band4: 3.87 PIFA I-PEX Chain (1) WHA YU GROUP C037-511135-A (SSR-13314) 5G Band1: 3.87 5G Band2: 3.84 5G Band3: 3.72 5G Band4: 3.98 PIFA I-PEX The EUT incorporates CDD function with 802.11a, 802.11b, 802.11g and MIMO function with 802.11n. Report No.: SA120517E03 7 of 10 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. …

Text truncated - open the document above for the full version.

Report No.: RF120517E03 1 of 86 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 FCC TEST REPORT (15.247) REPORT NO.: RF120517E03 MODEL NO.: WS-AP3705i FCC ID: QXO-WSAP3705I RECEIVED: May 17, 2012 TESTED: May 25 to June 21, 2012 ISSUED: July 04, 2012 APPLICANT: Enterasys Networks, Inc. ADDRESS: 50 Minuterman Road Andover, MA 01810 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120517E03 2 of 86 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 8 3. GENERAL INFORMATION ..................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT(WLAN) ........................................................... 9 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 18 4. TEST TYPES AND RESULTS (For 2.4GHz, 2412 ~ 2462MHz Band) ................... 20 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 20 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 20 4.1.2 TEST INSTRUMENTS .......................................................................................... 20 4.1.3 TEST PROCEDURES .......................................................................................... 21 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 21 4.1.5 TEST SETUP ....................................................................................................... 22 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 22 4.1.7 TEST RESULTS ................................................................................................... 23 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 25 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 25 4.2.2 TEST INSTRUMENTS .......................................................................................... 26 4.2.3 TEST PROCEDURES .......................................................................................... 27 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 27 4.2.5 TEST SETUP ....................................................................................................... 28 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 28 4.2.7 TEST RESULTS ................................................................................................... 29 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 42 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 42 4.3.2 TEST INSTRUMENTS .......................................................................................... 42 4.3.3 TEST PROCEDURE ............................................................................................. 42 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 42 4.3.5 TEST SETUP ....................................................................................................... 42 4.3.6 EUT OPERATING CONDITIONS ...............................................…

Text truncated - open the document above for the full version.

Report No.: RF120517E03-1 1 of 57 Report Format Version 5.0.0 Report No.: 110719E01, 120110E14 FCC TEST REPORT(15.407) REPORT NO.: RF120517E03-1 MODEL NO.: WS-AP3705i FCC ID: QXO-WSAP3705I RECEIVED: May 17, 2012 TESTED: May 25 to June 21, 2012 ISSUED: July 04, 2012 APPLICANT: Enterasys Networks, Inc. ADDRESS: 50 Minuterman Road Andover, MA 01810 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120517E03-1 2 of 57 Report Format Version 5.0.0 Report No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 14 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 15 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 16 4. TEST TYPES AND RESULTS .............................................................................. 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS ................................................................................................... 21 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 23 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 23 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 24 4.2.3 TEST INSTRUMENTS .......................................................................................... 25 4.2.4 TEST PROCEDURES .......................................................................................... 26 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 26 4.2.6 TEST SETUP ....................................................................................................... 27 4.2.7 EUT OPERATING CONDITION ............................................................................ 27 4.2.8 TEST RESULTS ................................................................................................... 28 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 37 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 37 4.3.2 TEST INSTRUMENTS .......................................................................................... 37 4.3.3 TEST PROCEDURE ............................................................................................. 38 4.3.4 DEVIATION FROM TEST STANDARD ...............................................................…

Text truncated - open the document above for the full version.

Report No.: 120517E03, 120517E03-1 1 of 2 Report No.: 110719E01, 120110E14 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 120517E03, 120517E03-1 2 of 2 Report No.: 110719E01, 120110E14 RADIATED EMISSION TEST
