QY6L170NDLCD MONITOR

Page 1 17 inch SXGA TFT LCD Color Monitor USER’S MANUAL Advanced Color TFT LCD Monitor 17 inch SXGA TFTLCD Color Monitor Page 2 17 inch SXGA TFT LCD Color Monitor CONTENTS 0. Connections3 1. Quick Start4 2. Product Overview4 3. Plug & Play 4 4. Usage Notice5 5. Package Checklist6 6. Front Button & Function7 7. OSD Operation8 8. Troubleshooting13 9. Specifications14 10. Video Mode Support15 11. FCC Notice 16 LIFE SUPPORT APPLICATIONS These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify for any damage resulting from such improper use or sale. The information presented in this document may form a part of quotation or contract under the agreement of both parties. Otherwise, this datasheet is subjected to be changed without notice. Page 3 17 inch SXGA TFT LCD Color Monitor 0. CONNECTIONS Analog RGB DC in Audio Out 12V Adapter Audio In Speaker DVI D-Sub 15P Signal cable DVI 25P Signal cable Page 4 17 inch SXGA TFT LCD Color Monitor •Connect the 15-pin D-sub connector to the VGA port of PC. •Connect the opposite side of VGA cable to TFT LCD monitor. •Plug in the Audio cables to the proper connecter of your monitor. •Plug in the power cord to AC/DC adapter power inlet and 110V / 220V consent. •Plug in the 12V DC output to TFT LCD monitor. •Turn on PC and TFT LCD monitor. •Adjust the display. (SXGA, 1280x1024 pixels, 24 bit color) 1. QUICK START 2. PRODUCT OVERVIEW This 19” SXGA TFT LCD Monitor, accepts standard analog RGB signal. This monitor supports SXGA and lower resolutions at the frame frequency up to 75Hz. Lower resolution modes can be expanded to full screen through the expansion algorithm. The user interface includes Audio, Display, Scaling, Control, Auto Adjust, and additional features. This monitor contains high-end LCD controller, which have high performance and user friendly interfaces. Fancy design monitor makes your desk simple and luxury. The LCD monitor neither emits harmful rays nor requires space. Moreover, it conforms to VESA DPMS (Display Power Management Signaling) requirement, therefore energy consumption is remarkably little. Actual power consumption of LCD monitor is less than 35 watts during the operation, in contrast CRT monitor. These features guarantee you with safe, clean, and healthy environment. 3. PLUG & PLAY This monitor supports VESA DDC 1/2B requirements, therefore it is truly Plug-and- Play for all PCs. No hardware or software change needed. It finds optimum setting value automatically without any diskette installation by DDC process. • DDC Process Abbreviation of ‘Display Data Channel’. The format of data exchange between Monitor & VGA Card. Page 5 17 inch SXGA TFT LCD Color Monitor 4. USAGE NOTICE Warning Please do not open or disassemble the products, because it may cause electric shock. Please be advised all the warnings, precautions, and maintenance advice as recommended in this user’s manual in order to maximize the life of your monitor. Do: •Turn off the monitor before cleaning its surface. •Periodically wipe its surface with a soft and dry cloth. •Use the quality and safety-approved AD/DC adapter. •Disconnect the power plug from the AC outlet when the product is not in use for long time. Do not expose the monitor to: •Extremely hot, cold, and humid environments during operation. •Area susceptible to dust. •Direct sunlight •Abrasive cleaners, waxes, and solvents Page 6 17 inch SXGA TFT LCD Color Monitor 5. PACKAGE CHECKLIST 17” TFT LCD MONITOR * After open the box, check if all the package is included. If there is missing package, contact the purchase Shop. User’s ManualAC/DC Adaptor Power Cord VGA Cable Audio CableDVI Cable (Option) Page 7 17 inch SXGA TFT LCD Color Monitor (1) POWER Turn On/ Turn Off the Monitor (2) LED Operation Status of the Monitor. (Green : ON / Red : No Signal) Orange (Flickering) : Suspend Mode or Disconnect of VGA Cable (3) Source Rotate signal source (Analog RGB/DVI) Select OSD Menu/ Save the changed value (4) AUTO Select OSD Menu/ Save the changed value Auto Adjust (5) MENU Activate OSD Menu/ Exit Menu (6) DOWN/UP ( ) Move menu (OSD Menu) (7) VOLUME ( ) Move menu/ Decrease and Increase Menu value (OSD Menu) Volume Control Hot Key 6. FRONT BUTTON & FUNCTION Source (Auto) Menu LEDPower Menu Page 8 17 inch SXGA TFT LCD Color Monitor 7. OSD OPERATION Contrast (Common) ◀Distinct ▶Vague Contrast +- Brightness (Common) ◀Dark ▶Bright Brightness +- 7.1 Color Control This control allows you to make adjustment to Contrast & brightness of the display screen. Page 9 17 inch SXGA TFT LCD Color Monitor + Gamma Correct. Color Temp. & Adjust FunctionSelect this control menu, then move to the desired color temperature among 9300K, 6500K or USER for custom setting. In User Mode, adjust R,G,B color control. 7.2 Picture Page 10 17 inch SXGA TFT LCD Color Monitor H.Position & V.Position FunctionSelect this control menu, and then use ◀▶buttons to center the image horizontally on the screen. Phase +- MismatchMatch Phase Colck FunctionSelect this control menu, and then use ◀▶buttons to optimize screen quality by removing noise. Sharpness Sharpness 1 2 3 4 5 Auto Adjust & Auto Color FunctionThis control will automatically make adjustments to the horizontal and vertical size, horizontal and vertical position, phase and color. 7.3 Function Page 11 17 inch SXGA TFT LCD Color Monitor Language FunctionUse◀ ▶ buttons to choose language from English, Spanish (ESPAÑOL), German (DEUTSCH), Italian (ITALIANO), French (FRANÇAIS) 7.4 OSD Menu OSD H.V. Position FunctionMoves the OSD window location ◀ ▶ ◀ ▶ Translucent FunctionChanges the background color of OSD window. (Translucent / Opaque) Page 12 17 inch SXGA TFT LCD Color Monitor 7.5. Miscellaneous Signal Source FunctionChoose from Analog & DVI Reset FunctionUser …

Text truncated - open the document above for the full version.

1 Jun 2004 BLOCK DIAGRAM DUAL_LP REFERENCE 4 : Block Diagram DC 12V (From Adapter) DC-DC Converter MCU OSD Control (To Key PCB) SCALAR Analog RGB (From PC) PA N E L INVTERTER Module Power Control DC 12V 3 Wire + 5V + 3.3V + 2.5V Block Diagram + 3.3V + 2.5V + 5V Control AUDIO Control DVI (From PC) 24.576

E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 14of 20 October 04, 2004 EUT Front Rear

E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 20of 20 October 04, 2004 Appendix – Sample Label & Location

LPS DEVICE CO.,LTD. Model : L170ND S/N : - Power : 12V / 4.1A FCC ID : QY6L170ND Made in KOREA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation

E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 15of 20 October 04, 2004 Inside Ac/dc Adaptor E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 16of 20 October 04, 2004 Main board (component side) Main board (solder side) E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 17of 20 October 04, 2004 Inverter Board ( component side ) Inverter Board ( solder side ) E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 18of 20 October 04, 2004 OSD Board ( Component side ) OSD Board ( solder side ) E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 19of 20 October 04, 2004 LCD Panel ( Component side ) LCD Panel ( solder side )

E E M M I I T T E E S S T T R R E E P P O O R R T T FCC EVALUATION REPORT FOR CERTIFICATION KOREA Standard Technology Test report No.: KST-FCC0428 Applicant’s Name : LPS Device Co.,Ltd. Applicant’s Address : Rm 606 6F, Joongang Induspia2 Apt. Factory 144-5, Sangdaewon-dong, Sungnam-si, Kyunggi-Do , KOREA Manufacturer’s Name : LPS Device Co.,Ltd. Manufacturer’s Address : Rm 606 6F, Joongang Induspia2 Apt. Factory 144-5, Sangdaewon-dong, Sungnam-si, Kyunggi-Do , KOREA EUT’s: FCC ID : QY6L170ND Product Name : LCD Monitor Model Number(s) : L170ND Product Options : N/A Category : FCC Part 15 subpart B Class B Computing Digital Device Supplementary Information The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with measurement procedures specified in ANSI C63.4-2000 . I attest to the accuracy of data and all measurements reported herein were performed by or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test Date : Oct 01, 2004. Issued Date : Oct 04 , 2004 Te s t e d b y : Approved by: Choi, Jae-RakLee, Weon-Woo E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 2of 20 October 04, 2004 Contents 1. Description of Device 2. Test Facility 3. MAP 4. Test system configuration 5. Description of E.U.T. 6. Summary of test results. 7. Test results. 8. Photographs. Appendix. Schematics Specifications. E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 3of 20 October 04, 2004 1. Description of Device 1) Kind of equipment: LCD Monitor 2) FCC ID: QY6L170ND 3) Model Name: L170ND 4) Serial No.: None 5) Type of Sample Tested: Pre-production 6) High Frequency Used: 24.576 MHz 7) Adapter Model name: LSE9901B1250 Manufacturer: LI SHIN INTERNATIONAL ENTERPRISE CORP. Serial no: A20413027571 8) Power Rating: 1phase AC100-240V, 50/60Hz, 1.5A Output: DC 12V, 4.16A 9) Tested Power supply: 1phase AC120V, 60Hz 10) Date of : October , 2004 11) Manufacture: LPS DEVICE CO.,LTD. 12) Description of Operating: Scroll All “H” Character Resolution 1024*768 , Vertical Frequency: 75Hz 13) Dates of Test: October 1, 2004 14) Place of Tests: Korea Standard Technology EMC site 15) Test Report No: KST-FCC0428 E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 4of 20 October 04, 2004 2. Test Facility The open field test site and conducted measurement facility are used for these testing, where are located following address and drawing. This site was fully described in a report dated November 14, 2002, that was submitted to the FCC. Korea Standard Technology ( KOSTEC Co., Ltd) Head office: 4F, 1503-2, Kwanyang-dong, Dongan-gu, Anyang-shi, Kyunggi-do, Korea Telephone No : 82-31-388-2051 Facsimile No: 82-31-388-2052 Test Lab :180-254, Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Telephone No : 82-31-222-4251 Facsimile No: 82-31-222-4252 MIC(Ministry of Information and Communication) No: KR0042 FCC Filing No. : 525762 VCCI Membership Number : 2005 VCCI Registration Number : R-1657 / C-1763 E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 5of 20 October 04, 2004 3. MAP Korea Hwasung-shi (open area test site) KOSTEC Co., Ltd E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 6of 20 October 04, 2004 4. Test System Configuration Operation Environment Ambient Temperature ( °C ) Humidity ( % ) Pressure ( hPa ) 10m Open Area site 24.9 49 998 Shielded room: 24 42 997 Test site These testing were performed following locations ; Shielded room : Conducted Emission, 10m Open Area Site: Radiated Emission Measurement Uncertainty All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to uncertainties are test receiver, Cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna frequency interpolation, measurement distance variation, site imperfection, mismatch, and system repeatability. Based on NIS 80,81, The measurement uncertainty level with a 95% confidence level were applied. sample calculation Conducted emission The field strength is calculated by adding the LISN factor, cable loss from the measured reading. The sample calculation is as follows: FS = MR + LF + CL MR = Meter Reading LF = LISN Factor CL = Cable Loss If MR is 30dB, LISN Factor 1dB, CL 1dB The result (MR) is 30 + 1 + 1 = 32dBuV E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 7of 20 October 04, 2004 5. Description of E.U.T. Product Description Manufactured By: LPS Device Co.,Ltd. Address: Rm 606 6F, Joongang Induspia2 Apt. Factory 144-5, Sangdaewon-dong, Sungnam-si, Kyunggi-Do , KOREA Model: L170ND Serial Number: None Configuratio…

Text truncated - open the document above for the full version.

E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 8of 20 October 04, 2004 Peripherals No Description Manufacturer Model / Part # Serial Number 1 Personal computer HP Pabilion T212k KRJ32101BH 2 LCD MONITOR LPS Device Co.,Ltd. L170ND None 3 AC/DC Adapter LI SHIN INTERNATIONAL ENTERPRISE CORP. LSE9901B1250 A20413027571 4 Printer HP C2605A SG42R1CO5B 5 Ac/dc adapter HP Deskwriter None 6 Headset None Hdppycdll None 7 Keyboard HP 5219 BN31719954 8 Mouse HP M042K0 30205141 E.U.T Test Configuration (example) 6. Summary of test results Modification to the E.U.T. - None Result : - PASS 7 3 2 8 4 5 6 1 E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 12of 20 October 04, 2004 8.PHOTOGRAPHS Conducted emission ( Front ) Conducted emission ( Rear ) E E M M I I T T E E S S T T R R E E P P O O R R T T Report reference No: KST-FCC0428 KOSTEC Co.,Ltd. 180-254,Annyung-Ri, Taean-Yup, Hwasung-shi, Kyunggi-do, Korea Tel : +82-31-222-4251 Fax: +82-31-222-4252 http://www.kosteclab.com Page : 13of 20 October 04, 2004 Radiated Emission ( Front ) Radiated Emission ( Rear )
