QZXPC100019PCMCIA Wireless Network Card

Flarion Technologies, Inc.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Oct 01, 2003
Application Purpose: Original Equipment
Date of Application: Sep 30, 2003
Equipment Note: PCMCIA Wireless Network Card
Frequency Range: 1890.75000000 - 1894.25000000
Company: Flarion Technologies, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
