R3MW1300V01802.11b/g Wireless Access Point / Router

Cipherium bonalinx-W 1300 Administrator’ s Manual © 2004 Cipherium Systems Co., Ltd. Cipherium bonalinx-W 1300 Administrator's Manual Version 1.0.0 Cipherium bonalinx-W 1300 Administrator’ s Manual © 2004 Cipherium Systems Co., Ltd. Copyright The intellectual property rights and copyright of this manual belong to Cipherium Systems Co., Ltd. and are protected by the R.O.C. copyright laws and international copyright laws. No part or the manual in its entirety may be transshipped, transmitted, duplicated, distributed, displayed, published, or broadcasted in any form or by any means without the prior written permission of Cipherium Systems Co., Ltd. The trademarks mentioned in the manual belong to the owners of the respective registered companies or organizations. Please contact Cipherium Systems if you have any questions on copyright: Tel.: +886-2-2731-6669 Fax:+886-2-2731-7776 E-mailǺ[email protected] Cipherium bonalinx-W 1300 Administrator’ s Manual i Table of Contents 1.Preface....................................................................................................... 1 1.1.Brief Introduction of bonalinx -W 1300.......................................................1 1.2.Before you Read.....................................................................................2 1.2.1.Audience........................................................................................2 1.2.2.Document Convention.....................................................................2 2.Product Description............................................................................... 3 2.1.Package Contents...................................................................................3 2.2.Front Panel.............................................................................................3 2.3.Hardware Specifications..........................................................................5 2.4.Technical Specifications...........................................................................6 2.4.1.Standards.......................................................................................6 2.4.2.Networking.....................................................................................6 2.4.3.Firewall...........................................................................................6 2.4.4.User Management...........................................................................6 2.4.5.Administration.................................................................................7 2.4.6.Accounting......................................................................................7 3.Installation................................................................................................ 8 3.1.Installing the bonalinx -W 1300 .................................................................8 3.1.1.System Requirements.....................................................................8 3.1.2.Installation Procedure......................................................................8 3.1.3.Setting the PC for the Public LAN and Private LAN Sections 9 3.2.Getting Started......................................................................................17 3.2.1.System Concept............................................................................17 3.2.2.Connecting Network Devices.........................................................19 3.2.3.Begin Installation...........................................................................20 4.Console Interface..................................................................................26 Cipherium bonalinx-W 1300 Administrator’ s Manual ii 4.1.Main Menu of Console interface.............................................................26 4.2.Utilities for network debugging of Console interface.................................27 4.3.Change admin password of Console interface.........................................28 4.4.Reload factory default of Console interface.............................................29 4.5.Restart Cipherium bonalinx-W 1300.......................................................29 5.Web Management Interface...............................................................30 5.1.System Configuration............................................................................31 5.1.1.Configuration Wizard.....................................................................31 5.1.2.System Information.......................................................................44 5.1.3.WAN Configuration........................................................................46 5.1.4.Authentication Configuration..........................................................48 5.2.User Authentication...............................................................................61 5.2.1 Authentication Policy..........................................................................61 5.2.2 Group Configuration...........................................................................71 5.2.3Black List Configuration.....................................................................72 5.2.4Guest User Configuration..................................................................74 5.2.5Roaming Configuration......................................................................75 5.2.6Additional Configuration.....................................................................77 5.2.7On-demand User Configuration..........................................................82 5.3Group Profile........................................................................................88 5.3.1Firewall Profile..................................................................................88 5.3.2Specific Route Profiles.......................................................................91 5.3.3Login Schedule Profiles.....................................................................92 5.4Network Configuration............…

Text truncated - open the document above for the full version.

Mike Kuo From: [email protected] Sent: July01 2004 Thursday 1:23 AM To: Mike Kuo Cc: [email protected]; [email protected] Subject: RE: Cipherium System Co., Ltd. , FCC ID: R3MW1300V01, AssessmentNO.: AN04T3991 7/1/2004 Hi Mike, Reply to Question #2 is not acceptable. Manufacturer can not base upon end user to comply regulatory requirements. Attached please find FCC policy in dealing with user selectable channel. Manufacturer must incorporate a way to prevent the user to select the transmitting channel above Channel 11 ( 2462 MHz ). Please provide technical information on how to achieve above requirement. Ans #2: The user manual has been modified in page 41, specifing channel 12, 13 will be disabled by software and only Channel 1-11 are applicable. Please refer to it. Best regards, Ting Hi W. K. : Reply to Question #2 is not acceptable. Manufacturer can not base upon end user to comply regulatory requirements. Attached please find FCC policy in dealing with user selectable channel. Manufacturer must incorporate a way to prevent the user to select the transmitting channel above Channel 11 ( 2462 MHz ). Please provide technical information on how to achieve above requirement. Best Regards Mike Kuo -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Thursday, June 17, 2004 11:11 PM To: Mike Kuo Cc: [email protected]; [email protected]; [email protected] Subject: FW: Cipherium System Co., Ltd. , FCC ID: R3MW1300V01, Assessment NO.: AN04T3991 Mike Kuo <[email protected]> 2004/06/19 09:32 AM "'[email protected]'" <[email protected]>, Mike Kuo <[email protected]> [email protected], [email protected], [email protected] Hi Mike, Please refer to the following for our replies. Thank you for your advice. Best Rgds, WK -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Wednesday, June 16, 2004 12:36 PM To: [email protected] Subject: Cipherium System Co., Ltd. , FCC ID: R3MW1300V01, Assessment NO.: AN04T3991 Question #1: Submitted schematic diagram only applicable to digital portion of AP. Please provide schematic diagram for the transmitter. Answer #1: The schematic diagram for the transmitter is provided in the revised file below. Question #2: Page 41 and 52 of user manual provide the information to the end user to choose the channel list based upon the location of usage. Page 41 only indicates that this device can be used for 13 channel operation. Please provide technical information on how the device will be restricted with 11 channel operation in the U.S. and prevent the end user to use any additional channel which are not authorized. Answer #2: The customer re-words the contents of "Caution" on Page 41 and asks us to directly submit it to you for your review. Please refer to the following file. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Mike Kuo <[email protected]> 2004/06/17 03:53 AM "CCS-Taiwan, Ting (E-mail)" <[email protected]>, "CCS-Taiwan, Wklo (E-mail)" <[email protected]> 7/1/2004

Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 1 of 6 EXTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 2

C 2.7 29.23 mm 79.70 mm MADE IN TAIWAN FCC ID:R3MW1300V01 I 5050A-W1300V C ID:01 FOR HOME OR OFFICE USE Tested To Comply With FCC Standards 671001173300 LABEL FREQUENCY 79.7*29.23mm (bonalinx W-1300)(CIPHERIUM)V1.0 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)Tthis device must accept any interference received, including interference that may cause undesired operation. Complies with CANADA RSS-210 / CNR-210, CLASS B This Class [*] digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe [*] est conforme a la norme NMB-003 du Canada. 0984

Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 3 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 4 Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 5 Compliance Certification Services Inc. Report No: B40415207 Date of Issue: June 7, 2004 Page 6

Customer Approval CUSTOMER MODEL NO . IWM-144G-101(Rev.01) DESCRIPTION 2.4GHz Tri-Band Flying Lead (Core) Swivel Antenna SENAO INTERNATIONAL CO., LTD. APPROVAL SHEET J OYMAX ELECTRONICS CO.,LTD. J No.5 Taiwan, R.O.C. Tel:+886-3-4335698 Fax:+886-3-4335798 [email protected] ,Dong Yuan Rd. 2, Jhongli Industrial Park, Jhongli City, Tao Yuan, Index 1. Antenna specification....................................................................................1-1 2. Drawing...........................................................................................................2-1 3. Test report Electrical test..............................................................................................3-1 Pattern test..................................................................................................3-2 4. Connector I-PEX MHF.................................................................................................4-1 5. Cable specification RG178..........................................................................................................5-1 6. Ferrite Core RH-04...........................................................................................................6-1 Model No .IWM-144G-101 Item Page OYMAX ELECTRONICS CO.,LTD.J SpecificationsModel No . 1.Description: The antenna is a flying lead swivel and 1/4dipole antenna. It's useful for the ISM Band of 2.4~2.5 GHz. 2. Electrical Properties¡G 2-1 Frequency Range............ 2-2 Impedance..................... 2-3 S.W.R. .......................... 2-4 Return Loss................... 2-5 Gain.............................. 2-6 Polarization................... 2-7 Admitted Power.............. 2-8 Electrical Wave............. 2.4~2.4835GHz 50 Ohms nominal 2.0 -10 dB 2 dBi Vertical 1W 1/4 Dipole 3. Mechanical Properties 3-1 Connector...................... 3-2 Cable............................. 3-3 Antenna Cover............... Antenna Base................. 3-4 Ferrite Core................... 3-5 Rotating Test.................. 3-6 Attachment Strength....... IWM-144G-101 I-PEX MHF RG178 Polyurethane Polycarbonate RH-04 1.0 Kg-cm, After 2000 cycles with the rate of 30 cycles/minute (max.). It shall be possible to remain it's position. 2.0 Kg (30 minutes) OYMAX ELECTRONICS CO.,LTD.J 1-1 Test ReportModel No . Return Loss S.W.R. IWM-144G-101 OYMAX ELECTRONICS CO.,LTD.J 3-1 Test ReportModel No .IWM-144G-101 OYMAX ELECTRONICS CO.,LTD.J E-Plane Field Patterns H-Plane Field Patterns Frequency: 2.45GHz Frequency: 2.45GHz 3-2 I-PEX MHFModel No .Connector OYMAX ELECTRONICS CO.,LTD.J 4-1 5-1 CableModel No . RG178 OYMAX ELECTRONICS CO.,LTD.J Model No .Ferrite CoreRH-04 OYMAX ELECTRONICS CO.,LTD.J 6-1

Customer Approval CUSTOMER MODEL NO . IWM-144F-101(Rev.01) DESCRIPTION 2.4GHz Tri-Band Flying Lead (Core) Swivel Antenna SENAO INTERNATIONAL CO., LTD. APPROVAL SHEET J OYMAX ELECTRONICS CO.,LTD. J No.5 Taiwan, R.O.C. Tel:+886-3-4335698 Fax:+886-3-4335798 [email protected] ,Dong Yuan Rd. 2, Jhongli Industrial Park, Jhongli City, Tao Yuan, Index 1. Antenna specification....................................................................................1-1 2. Drawing...........................................................................................................2-1 3. Test report Electrical test..............................................................................................3-1 Pattern test..................................................................................................3-2 4. Connector I-PEX MHF.................................................................................................4-1 5. Cable specification RG178..........................................................................................................5-1 6. Ferrite Core RH-04...........................................................................................................6-1 Model No .IWM-144F-101 Item Page OYMAX ELECTRONICS CO.,LTD.J SpecificationsModel No . 1.Description: The antenna is a flying lead swivel and 1/4dipole antenna. It's useful for the ISM Band of 2.4~2.5 GHz. 2. Electrical Properties¡G 2-1 Frequency Range............ 2-2 Impedance..................... 2-3 S.W.R. .......................... 2-4 Return Loss................... 2-5 Gain.............................. 2-6 Polarization................... 2-7 Admitted Power.............. 2-8 Electrical Wave............. 2.4~2.4835GHz 50 Ohms nominal 2.0 -10 dB 2 dBi Vertical 1W 1/4 Dipole 3. Mechanical Properties 3-1 Connector...................... 3-2 Cable............................. 3-3 Antenna Cover............... Antenna Base................. 3-4 Ferrite Core................... 3-5 Rotating Test.................. 3-6 Attachment Strength....... IWM-144F-101 I-PEX MHF RG178 Polyurethane Polycarbonate RH-04 1.0 Kg-cm, After 2000 cycles with the rate of 30 cycles/minute (max.). It shall be possible to remain it's position. 2.0 Kg (30 minutes) OYMAX ELECTRONICS CO.,LTD.J 1-1 Test ReportModel No . Return Loss S.W.R. IWM-144F-101 OYMAX ELECTRONICS CO.,LTD.J 3-1 Test ReportModel No .IWM-144F-101 OYMAX ELECTRONICS CO.,LTD.J E-Plane Field Patterns H-Plane Field Patterns Frequency: 2.45GHz Frequency: 2.45GHz 3-2 I-PEX MHFModel No .Connector OYMAX ELECTRONICS CO.,LTD.J 4-1 5-1 CableModel No . RG178 OYMAX ELECTRONICS CO.,LTD.J Model No .Ferrite CoreRH-04 OYMAX ELECTRONICS CO.,LTD.J 6-1

Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 64 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Cipherium System Co., Ltd. Wireless AP / Router Model: bonalinx W-1300 Trade Name: CIPHERIUM Prepared for Cipherium System Co., Ltd. 8F, 56, Dunhua N. Rd, Taipei 105, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION...........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..............................................................................................8 5.1 FACILITIES....................................................................................................................................... 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT ...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS ................................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................21 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................22 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................32 7.6 SPURIOUS EMISSIONS ................................................................................................................36 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................60 APPENDIX 1 PHOTOGRPHS OF TEST SETUP......................................................................................63 Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Page 4 2. EUT DESCRIPTION Product Wireless AP / Router Trade Name CIPHERIUM Model Number bonalinx W-1300 Model Discrepancy N/A Power Supply Powered from host device Frequency Range 2412 ~ 2462 MHz Transmit Power 802.11b mode: 20.98 dBm 802.11g mode: 16.32 dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g: 54Mbps with fall back rates of 48/36/24/18/12/9/6 Mbps (OFDM) Number of Channels 11 Channels Antenna Specification Dipole Antenna Gain: 2 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: R3MW1300V01 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX frequency that was for the purp…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Page 63 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: B40415207-RP FCC ID: R3MW1300V01 Date of Issue: June 7, 2004 Page 64 Conducted Emission Set Up Photos
