R3MW5101V01Wireless Repeater

Cipherium Repeater Administrator’s Manual © 2004 Cipherium Systems Co., Ltd. CIPHERIUM Repeater Administrator's Manual Version 1.0.1 Cipherium Repeater Administrator’s Manual © 2004 Cipherium Systems Co., Ltd. Copyright The intellectual property rights and copyright of this manual belong to Cipherium Systems Co., Ltd. and are protected by the R.O.C. copyright laws and international copyright laws. No part or the manual in its entirety may be transshipped, transmitted, duplicated, distributed, displayed, published, or broadcasted in any form or by any means without the prior written permission of Cipherium Systems Co., Ltd. The trademarks mentioned in the manual belong to the owners of the respective registered companies or organizations. Please contact Cipherium Systems if you have any questions on copyright: Tel.: +886-2-2731-6669 Fax: +886-2-2731-7776 E-mail：[email protected] Cipherium Repeater Administrator’s Manual i Table of Contents 1. Preface............................................................................................ 1 1.1. Brief Introduction of Repeater ........................................................................1 1.2. Before you Read ............................................................................................2 1.2.1. Audience................................................................................................2 1.2.2. Document Convention ...........................................................................2 2. Product Description ...................................................................... 3 2.1. Package Contents ..........................................................................................3 2.2. Front Panel.....................................................................................................3 2.3. Hardware Specifications.................................................................................5 2.4. Technical Specifications .................................................................................5 2.4.1. Standards ..............................................................................................5 2.4.2. Networking.............................................................................................6 2.4.3. Firewall ..................................................................................................6 2.4.4. User Management .................................................................................6 2.4.5. Administration........................................................................................7 2.4.6. Accounting .............................................................................................7 3. Installation...................................................................................... 8 3.1. Installing the Repeater ...................................................................................8 3.1.1. System Requirements ...........................................................................8 3.1.2. Installation Procedure............................................................................8 3.1.3. Setting up the PC for the Public LAN and Private LAN.........................9 3.2. Getting Started .............................................................................................17 3.2.1. System Concept ..................................................................................17 3.2.2. Connecting Network Devices ..............................................................18 3.2.3. Begin Installation .................................................................................20 4. Console Interface ........................................................................ 27 4.1. Main Menu of Console interface ..................................................................27 4.2. Utilities for network debugging of Console interface....................................28 Cipherium Repeater Administrator’s Manual ii 4.3. Change admin password of Console interface ............................................29 4.4. Reload factory default of Console interface .................................................30 4.5. Restart Cipherium Repeater ........................................................................30 5. Web Management Interface ........................................................ 31 5.1. System Configuration...................................................................................31 5.1.1. Configuration Wizard ...........................................................................32 5.1.2. System Information..............................................................................45 5.1.3. WAN Configuration ..............................................................................47 5.1.4. Authentication Configuration ...............................................................49 5.1.5. Private Configuration ...........................................................................61 5.2. User Authentication ......................................................................................64 5.2.1 Authentication Policy.................................................................................64 5.2.2 Group Configuration ..................................................................................75 5.2.3 Black List Configuration ...........................................................................76 5.2.4 Guest User Configuration ........................................................................78 5.2.5 Roaming Configuration ............................................................................79 5.2.6 Additional Configuration...........................................................................81 5.2.7 On-demand User Configuration...............................................................86 5.3 Group Profile ...................................................................…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 1 of 6 EXTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 2

C 2.7 29.23 mm 79.70 mm MADE IN TAIWAN FCC ID:R3MW5101V01 I 5050A-W5101V01C ID:01 FOR HOME OR OFFICE USE Tested To Comply With FCC Standards 671001173300 LABEL FREQUENCY 79.7*29.23mm (bonalinx W-5101)(CIPHERIUM)V1.0 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)Tthis device must accept any interference received, including interference that may cause undesired operation. Complies with CANADA RSS-210 / CNR-210, CLASS B This Class [*] digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe [*] est conforme a la norme NMB-003 du Canada. 0984

Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 3 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 4 Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 5 Compliance Certification Services Inc. Report No: B40415210 Date of Issue: June 10, 2004 Page 6

Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 141 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Cipherium System Co., Ltd. Wireless Repeater Model: bonalinx W-5101 Trade Name: CIPHERIUM Prepared for Cipherium System Co., Ltd. 8F, 56, Dunhua N. Rd, Taipei 105, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION................................................................................................................................3 2. EUT DESCRIPTION....................................................................................................................................................................4 3. TEST METHODOLOGY.........................................................................................................................................................5 3.1 EUT CONFIGURATION............................................................................................................ 5 3.2 EUT EXERCISE....................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 6 3.5 DESCRIPTION OF TEST MODES................................................................................................ 7 4. INSTRUMENT CALIBRATION......................................................................................................................................8 5. FACILITIES AND ACCREDITATIONS..................................................................................................................9 5.1 FACILITIES............................................................................................................................. 9 5.2 EQUIPMENT........................................................................................................................... 9 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 9 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................... 10 6. SETUP OF EQUIPMENT UNDER TEST...............................................................................................................11 6.1 SETUP CONFIGURATION OF EUT........................................................................................... 11 6.2 SUPPORT EQUIPMENT.................................................................................................. 11 7. FCC PART 15.247 REQUIREMENTS.......................................................................................................................12 7.1 6DB BANDWIDTH................................................................................................................. 12 7.2 PEAK POWER....................................................................................................................... 20 7.3 BAND EDGES MEASUREMENT................................................................................... 28 7.4 PEAK POWER SPECTRAL DENSITY........................................................................................ 53 7.5 RADIO FREQUENCY EXPOSURE............................................................................................ 61 7.6 SPURIOUS EMISSIONS.................................................................................................... 65 CO-LACATED OPERATION (MODULE 1 & MODULE 2 OPERATED SIMULTANEOUSLY) .............................................................105 7.7 POWERLINE CONDUCTED EMISSIONS................................................................................. 137 APPENDIX 1 PHOTOGRPHS OF TEST SETUP ...................................................................................................140 Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Page 4 2. EUT DESCRIPTION Product Wireless Repeater Trade Name CIPHERIUM Model Number bonalinx W-5101 Model Discrepancy N/A Power Supply Model No.: AM-121000 I/P: AC 120V, 60Hz, 20W O/P: DC 12V, 1000mA Frequency Range 2412 ~ 2462 MHz Transmit Power 802.11b mode: 21.01dBm 802.11g mode: 16.35 dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g: 54Mbps with fall back rates of 48/36/24/18/12/9/6 Mbps (OFDM) Number of Channels 11 Channels Antenna Specification Swivel Antenna / Gain: 2 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: R3MW5101V01 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its em…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Page 132 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: B40415210-RP FCC ID: R3MW5101V01 Date of Issue: June 10, 2004 Page 133 Conducted Emission Set Up Photos
