R66-HBR6303MTV Stick, Smart TV Stick

FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Hisense Broadband Multimedia Technologies Co.,Ltd No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-10-2 To whom it may concern: We, Hisense Broadband Multimedia Technologies Co.,Ltd, hereby certify that the equipment for which authorization is sought (FCC ID: R66-HBR6303M) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Haitang Zhang Manager Hisense Broadband Multimedia Technologies Co.,Ltd 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Hisense Broadband Multimedia Technologies Co.,Ltd No.218 Qianwangang Road, Economy & Technology Development Zone, Qingdao, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/10/01 U.S. Agent Designation Hisense Broadband Multimedia Technologies Co.,Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: R66-HBR6303M): Name and company of U.S. agent: Hisense Broadband Inc Physical U.S. address of agent: 2580 North 1st St., Suite 400, San Jose, CA 95131,United States FRN of U.S. agent: 0036001816 Email address of U.S. agent: [email protected] Hisense Broadband Inc acknowledges their obligation to accept service of process on behalf of Hisense Broadband Multimedia Technologies Co.,Ltd Hisense Broadband Multimedia Technologies Co.,Ltd with the FRN [0022188387] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Haitang Zhang Quality leader for system Hisense Broadband Multimedia Technologies Co.,Ltd Signature Mrs Debbie Wei HR Manager Hisense Broadband Inc 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Hisense Broadband Multimedia Technologies Co.,Ltd Add: No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Date: 2024-10-2 FCC ID: R66-HBR6303M Dear Sir/Madam, We, Hisense Broadband Multimedia Technologies Co.,Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: TV Stick, Smart TV Stick Model no.: HBR6303M, HBR6303M-M1, HBR6303M-F0, HBR6303M-F1, HBR6303M-F2, HBR6303M-F3, HBR6303M-F4, HBR6303M-F5, HBR6303M-F6,HBR6303M-F7, HBR6303M-F8, HBR6303M-F9, Sincerely, Name/Title： Haitang Zhang/Manager Company: Hisense Broadband Multimedia Technologies Co.,Ltd Address: No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Phone: +86-13255576011 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-10-2> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name R66-HBR6303M HBR6303M For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Haitang Zhang/Manager Company: Hisense Broadband Multimedia Technologies Co.,Ltd Address: No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Phone: +86-13255576011 Fax: N/A E-Mail: [email protected]

Hisense Broadband Multimedia Technologies Co.,Ltd No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Date: 2024-10-2 FCC ID: R66-HBR6303M Model Number: HBR6303M To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Hisense Broadband Multimedia Technologies Co.,Ltd, declare that this EUT (FCC ID: R66-HBR6303M) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Haitang Zhang/Manager Company: Hisense Broadband Multimedia Technologies Co.,Ltd Address: No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Phone: +86-13255576011 Fax: N/A E-Mail: [email protected]

Hisense Broadband Multimedia Technologies Co.,Ltd No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-10-2 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: R66-HBR6303M including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Haitang Zhang/Manager Company: Hisense Broadband Multimedia Technologies Co.,Ltd Address: No.218 Qianwangang Road, Economy & Technology Development Zone Qingdao China Phone: +86-13255576011 Fax: N/A E-Mail: [email protected]

FCC ID: R66-HBR6303M External Photos of the EUT 2.4GWIFI ANT 1 5G WIFI ANT 1 2.4GWIFI ANT 2 5G WIFI ANT 3 5G WIFI ANT 2 FCC ID: R66-HBR6303M FCC ID: R66-HBR6303M FCC ID: R66-HBR6303M

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : R66-HBR6303M

FCC ID: R66-HBR6303M Internal Photos of the EUT FCC ID: R66-HBR6303M FCC ID: R66-HBR6303M

RF Exposure evaluation FCC ID: R66-HBR6303M Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information HBR6303M can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GWIFI / External antenna 5.05dBi for 2400-2500MHz for ANT 1 5.37dBi for 2400-2500MHz for ANT 1 5GWIFI / External antenna 5.13dBi for 5000-6000MHz for ANT 1 5.04dBi for 5000-6000MHz for ANT 2 5.06dBi for 5000-6000MHz for ANT 3 5. Manufacturing Tolerance 2.4GWIFI Mode Max. Peak Conducted Output Power (dBm) Max. tune-up 2.4GWIFI ANT1 14.2 14.0±1 2.4GWIFI ANT2 14.47 14.0±1 5GWIFI Mode Max. Average Conducted Output Power (dBm) Max. tune-up UNII-1WIFI ANT1 13.31 13.0±1 UNII-1WIFI ANT2 12.82 13.0±1 UNII-1WIFI ANT3 12.99 13.0±1 UNII-2AWIFI ANT1 13.21 13.0±1 UNII-2AWIFI ANT2 13.07 13.0±1 UNII-2AWIFI ANT3 13.3 13.0±1 UNII-2CWIFI ANT1 13.21 13.0±1 UNII-2CWIFI ANT2 12.68 13.0±1 UNII-2CWIFI ANT3 12.82 13.0±1 UNII-3WIFI ANT1 12.97 13.0±1 UNII-3WIFI ANT2 12.88 13.0±1 UNII-3WIFI ANT3 12.86 13.0±1 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is refer to section4, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW 2.4GWIFI ANT1 15.0 31.6228 5.05 3.1989 0.0201 1.0000 2.4GWIFI ANT2 15.0 31.6228 5.37 3.4435 0.0217 1.0000 UNII-1WIFI ANT1 14.0 25.1189 5.13 3.2584 0.0163 1.0000 UNII-1WIFI ANT2 14.0 25.1189 5.04 3.1915 0.0160 1.0000 UNII-1WIFI ANT3 14.0 25.1189 5.06 3.2063 0.0160 1.0000 UNII-2AWIFI ANT1 14.0 25.1189 5.13 3.2584 0.0163 1.0000 UNII-2AWIFI ANT2 14.0 25.1189 5.04 3.1915 0.0160 1.0000 UNII-2AWIFI ANT3 14.0 25.1189 5.06 3.2063 0.0160 1.0000 UNII-2CWIFI ANT1 14.0 25.1189 5.13 3.2584 0.0163 1.0000 UNII-2CWIFI ANT2 14.0 25.1189 5.04 3.1915 0.0160 1.0000 UNII-2CWIFI ANT3 14.0 25.1189 5.06 3.2063 0.0160 1.0000 UNII-3WIFI ANT1 14.0 25.1189 5.13 3.2584 0.0163 1.0000 UNII-3WIFI ANT2 14.0 25.1189 5.04 3.1915 0.0160 1.0000 UNII-3WIFI ANT3 14.0 25.1189 5.06 3.2063 0.0160 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. simultaneous MPE Result 2.4GWIFI ANT1 MPE (Ratio) 2.4GWIFI ANT2 MPE (Ratio) 5GWIFI ANT3 MPE (Ratio) simultaneous MPE (Ratio) MPE Limits (Ratio) 0.0201 0.0217 0.0160 0.0578 1.0000 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 1 SPECIFICATION FOR APPROVAL Customer Name： Customer P/N： AX3000 Jing Feng P/N： JF8960-1 Specification Description： JF8960-1-OPEN-IPEX- Dual frequency doubly-fed white rubber antenna -L175-70MM Production Date： 2024.04.09 Factory Confirmation： Department CHECKED BY APPROVED BY RF Department Tan Mu Chen Wang Shuo Structure Department Liang Sen Wang Shuo Quality Department Liu Xiao Jun Wang Shuo Customer Confirmation： INSPECTION CHECKED APPROVED 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 2 △ Record Of Document Formulation, Modification And Abolishment File name Date Control version Related content Formul ate Approv ed Sample Approved 2024.04.09 V1 First Tan Mu Chen Wang Shuo 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 3 Contents 1、Cover Signature ............................................................1 2、Text Control Record.........................................................2 3、Contents...........................................................................3 4、Main Technical Specifications..........................................4 5、Product Structure Drawing................................................5 6、Electrical Performance Test Report...........................6-10 7、Reliability test requirements .................................11-14 8、Environmental requirements ..........................................15 9、Packaging requirements ................................................16 10、Environmental requirements .................................17-19 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 4 4、Main technical specifications Electrical Parameters Frequency Range(MHZ) 2400~2500/5150~5850MHz Impedance(Ω) 50Ω VSWR ≤2.0 Peak Gain(dBi) 4.5±0.5/5±0.5dBi Power Capacity 3W Withstand Voltage Test 1KV ON-Off Test ON Polarization Linear，Vertical Radiation Omni-Directional Connector Type OPEN-IPEX Mechanical Parameters Length (mm) 1.1.37White line175±3mm 1.1.37Black line70±3mm Drawing force ＞1KG Salt Spray Test 24H Environmental Parameters Operating Temp -30°C~+75°C Storage Temp -30°C~+75°C 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 5 5、Product Structure Drawing 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 6 6、Electrical Performance Test report VSWR:（2.4G） Return Loss 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 7 VSWR:(5.8G) Return Loss 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 8 Isolation 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 9 Efficiency & gain： Freq Effi Gain (MHz) (%) (dBi) 2400 76.04 4.68 2410 74.7 4.67 2420 77.5 4.71 2430 75.75 4.78 2440 76.72 4.82 2450 80.01 4.76 2460 78.48 4.54 2470 77.02 4.93 2480 77.44 5.01 2490 75.57 5.05 2500 74.51 4.84 Freq Effi Gain (MHz) (%) (dBi) 5150 72.02 4.64 5200 69.4 4.92 5250 75.88 4.97 5300 68.21 4.86 5350 75.18 4.95 5400 73.92 5.13 5450 76.47 4.74 5500 73.46 4.91 5550 71.03 4.89 5600 77.47 4.79 5650 67.61 4.88 5700 73.89 4.82 5750 66.03 4.76 5800 77.93 4.99 5850 77.53 4.73 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 10 3D Radiation pattern： 2D Radiation pattern： 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 11 7、Reliability test requirements Test items Specific instructions 1. bending enduran ce test Test purpose: To verify that the antenna elbow with bending function can meet the long-term durability; Prerequisites: 1) Test sample electrical properties meet the requirements, the appearance of the sample without cracking, wear and other defects; 2) Minimum sample quantity: 3pcs. Test process: 1. Check whether the mechanical and electrical functions of the antenna are normal before testing; Place the whole antenna horizontally and fix the antenna connector; 2, manually or mechanically rotate the antenna base to the position of 90 degrees with the connecting head, and then rotate to the original position, one reciprocating count, test frequency: 30~40 times per minute, a total of 500 bending, every 100 intermittent 5min; 3. After testing, check the appearance and mechanical properties of the antenna. Criteria: 1, after the test is completed, the antenna should not have obvious physical damage, and the antenna can not slide when it is folded into 30 degrees with the vertical direction. 2, no change in electrical performance before and after the test; 2. Antenna side pressur e test Test purpose: To verify the side pressure resistance of the integrated external antenna, test the strength of the antenna itself, the strength of the contact part between the product and the equipment, such as the strength of the shell and the strength of the stop limit bar. Prerequisites: 1) Test sample electrical properties meet the requirements, the appearance of the sample without cracking, wear and other defects. 2) Install the antenna on the product according to the normal state, and fix the product. 3) Each test sample should be at least 3pcs; Test steps: 1. Before testing, check the appearance and function of the sample to be tested; 2. Conduct the following two tests, using two sets of materials respectively: Test 1: Keep the antenna open and straight, and apply 20N force in, out, up, and down 5mm at the end of the antenna, respectively, and hold for 5 seconds. Repeat this operation 10 times in each direction. Test 2: When the antenna is bent at 90 degrees and the antenna is twisted until the stop limit bar is in effect, apply 20N force to the 5mm position at the end of the antenna and hold it for 5S. …

Text truncated - open the document above for the full version.

文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 1 SPECIFICATION FOR APPROVAL Customer Name： Customer P/N： AX3000 Jing Feng P/N： JF8960-2 Specification Description： OPEN-1.13 white-2.4G white rubber antenna -L225MM Production Date： 2024.04.09 Factory Confirmation： Department CHECKED BY APPROVED BY RF Department Tan Mu Chen Wang Shuo Structure Department Liang Sen Wang Shuo Quality Department Liu Xiao Jun Wang Shuo Customer Confirmation： INSPECTION CHECKED APPROVED 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 2 △ Record Of Document Formulation, Modification And Abolishment File name Date Control version Related content Formula te Approve d Sample Approved 2024.04.09 V1 First Tan Mu Chen Wang Shuo 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 3 Contents 1、Cover Signature ............................................................1 2、Text Control Record.........................................................2 3、Contents...........................................................................3 4、Main Technical Specifications..........................................4 5、Product Structure Drawing................................................5 6、Electrical Performance Test Report...........................6-8 7、Reliability test requirements .................................9-12 8、Environmental requirements ..........................................13 9、Packaging requirements ................................................14 10、Environmental requirements .................................15-17 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 4 4、Main technical specifications Electrical Parameters Frequency Range(MHZ) 2400~2500MHz Impedance(Ω) 50Ω VSWR ≤2.0 Peak Gain(dBi) 5±0.5dBi Power Capacity 3W Withstand Voltage Test 1KV ON-Off Test ON Polarization Linear，Vertical Radiation Omni-Directional Connector Type welded Mechanical Parameters Length (mm) 225±3mm Coaxial line 1.13 White Line Drawing force ＞1KG Salt Spray Test 24H Environmental Parameters Operating Temp -30°C~+75°C Storage Temp -30°C~+75°C 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 5 5、Product Structure Drawing 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 6 6、Electrical Performance Test report VSWR:（2.4G） Return Loss 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 7 Efficiency & gain： Freq Effi Gain (MHz) (%) (dBi) 2400 73.78 5.23 2410 73.39 5.32 2420 75.84 5.01 2430 74.8 5.12 2440 72.84 5.25 2450 74.08 5.34 2460 72.03 5.41 2470 75.13 5.37 2480 78.41 5.25 2490 83.44 5.23 2500 79.74 5.19 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 8 3D Radiation pattern： 2D Radiation pattern 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 9 7、Reliability test requirements Test items Specific instructions 1. bending enduran ce test Test purpose: To verify that the antenna elbow with bending function can meet the long-term durability; Prerequisites: 1) Test sample electrical properties meet the requirements, the appearance of the sample without cracking, wear and other defects; 2) Minimum sample quantity: 3pcs. Test process: 1. Check whether the mechanical and electrical functions of the antenna are normal before testing; Place the whole antenna horizontally and fix the antenna connector; 2, manually or mechanically rotate the antenna base to the position of 90 degrees with the connecting head, and then rotate to the original position, one reciprocating count, test frequency: 30~40 times per minute, a total of 500 bending, every 100 intermittent 5min; 3. After testing, check the appearance and mechanical properties of the antenna. Criteria: 1, after the test is completed, the antenna should not have obvious physical damage, and the antenna can not slide when it is folded into 30 degrees with the vertical direction. 2, no change in electrical performance before and after the test; 2. Antenna side pressur e test Test purpose: To verify the side pressure resistance of the integrated external antenna, test the strength of the antenna itself, the strength of the contact part between the product and the equipment, such as the strength of the shell and the strength of the stop limit bar. Prerequisites: 1) Test sample electrical properties meet the requirements, the appearance of the sample without cracking, wear and other defects. 2) Install the antenna on the product according to the normal state, and fix the product. 3) Each test sample should be at least 3pcs; Test steps: 1. Before testing, check the appearance and function of the sample to be tested; 2. Conduct the following two tests, using two sets of materials respectively: Test 1: Keep the antenna open and straight, and apply 20N force in, out, up, and down 5mm at the end of the antenna, respectively, and hold for 5 seconds. Repeat this operation 10 times in each direction. Test 2: When the antenna is bent at 90 degrees and the antenna is twisted until the stop limit bar is in effect, apply 20N force to the 5mm position at the end of the antenna and hold it for 5S. Repeat this operation 10 times. Complete the 文档受控编号：JF-QS-WJ-023. 存档期：7年. 文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话： 北京010-80257683 或 深圳0755-23076842 10 test of both positive and negative limit positions. 3. In the above two groups of tests, if it is found that after the antenna is stressed, the antenna deformation Angle is greater than 30°, and the external force is still less than 20N, the deformation Angle is kept at 30°, the external force is withdrawn after 5s, and the above operations are repeated for 10 times; Completed the four directions of the test, a total of…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA24092500701 R66-HBR6303M Compiled by ( position+printed name+signature) . : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) . : Project Engineer Xudong Zhang Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 27, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Hisense Broadband Multimedia Technologies Co.,Ltd Address ............................................ : No.218 Qianwangang Road, Economy & Technology Development Zone, Qingdao, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : TV Stick, Smart TV Stick Trade Mark ....................................... : Hisense, Xiber Manufacturer .................................... : Hisense Broadband Multimedia Technologies Co.,Ltd Model/Type reference ...................... : HBR6303M Listed Models .................................. : HBR6303M-M1, HBR6303M-F0, HBR6303M-F1, HBR6303M-F2, HBR6303M-F3, HBR6303M-F4, HBR6303M-F5, HBR6303M-F6, HBR6303M-F7, HBR6303M-F8, HBR6303M-F9, Modulation Type ............................... : CCK/DSSS/OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 12.0V From external circuit Result ............................................... : PASS Report No.: CTA24092500701 Page 2 of 71 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : TV Stick, Smart TV Stick Model /Type : HBR6303M Series Model No. HBR6303M-M1, HBR6303M-F0, HBR6303M-F1, HBR6303M-F2, HBR6303M-F3, HBR6303M-F4, HBR6303M-F5, HBR6303M-F6, HBR6303M-F7, HBR6303M-F8, HBR6303M-F9, Applicant : Hisense Broadband Multimedia Technologies Co.,Ltd Address : No.218 Qianwangang Road, Economy & Technology Development Zone, Qingdao, China Manufacturer : Hisense Broadband Multimedia Technologies Co.,Ltd Address : No.21…

Text truncated - open the document above for the full version.
