R72IP100FM Handheld Transceiver

Table of Contents 1. Introduction 2. Description of Unit 3. Technical Specifications 4. Theory of Operation 5. Circuit Descriptions 6. Alignment Procedure - 1. Introduction IP-100 has a compact size with a various features in the range of 136~174MHz. IP-100 Has a various features shown as below. IP-100 constructed with a microprocessor controlled, temperature compensated Phase Locked Loop(PLL) frequency synthesizer. The radio features a double conversion receiver and a direct FM transmitter modulator. A special integrated circuit provides support to sub-audible signaling(CTCSS & DCS) and most of the receiving parts are switched off periodically in the power save mode to reduce battery current drain during standby. 2. Description of Unit Items Model Radio IP 100 Antenna IA-156 1700mAh Li-Ion battery pack BL 1800 Desktop rapid charter IC-170 Adaptor Supplied Package User manual Items Model External / Speaker MicrophoneES-1 Earpiece Microphone EP-1 Earpiece VOX Microphone EV-1 Accessories VOX & PTT Headset VP-1 3. Technical Specifications 3-1 General 1) Frequency range : 136~174 MHz 2) Channels : 255 Channels 3) Channel spacing : 12.5 kHz/25 kHz 4) Communication method : Simplex 5) Antenna Impedance : 50 ohm 6) Antenna : Helical Antenna 7) Power supply voltage : LI-1700mAh Li-Ion battery pack(Voltage: 7.5V DC) 8) Current Drain : When Transmitting(5W) - < 2A When Receiving(0.5W) - < 300mA Transmit standby - < 60mA Receiver standby(PSC MODE) - < 50mA 9) Microphone : Internal Condenser Microphone(External Speaker Micro phone is available) 10) Operating temperature range: -30 +60 11) Size : 56(W)x100(H)x34(D) 12) Weight : 285g 3-2 Transmitter 1) Power Output : HIGH – 5W, LOW - 1W 2) Modulation : 8K5F3E/16K0F3E 3) Oscillator method : PLL 4) Frequency Stability : less than ±0.00025% (±2.5PPM) 5) Maximum frequency deviation: ±2.5 kHz(Narrow)/ ±5 kHz(Wide) 6) Audio Distortion : less than 5% (1 kHz 60%) 7) SPURIOUS Emission : -65 [dBc] 8) FM Hum & Noise : -40 [dB] (HP8920A 300Hz 3kHz BPF) 9) BAND SPREAD : 38 [MHz] 3-3 Receiver 1) Receiver Type : Double Super Hetero type 2) Sensitivity : -0.25uV (12dB SINAD ) 3) Frequency Stability : ±0.00025%(±2.5PPM) 4) SPURIOUS Rejection : -60 dB 5) Adjacent Channel Selectivity: -60 dB (Narrow) , -70 dB (Wide) 6) Distortion : 5% (1 kHz 60%) 7) Hum & Noise : -40 dB(HP8920A 300Hz 3kHz BPF) 8) Audio output : 1000 mW 9) BAND SPREAD : 38MHz 10) Speaker size : 45 pi 4. Theory of Operation EXTERNAL VIEW 4-1 Features & Operation 1. Monitor Press the Monitor key momentarily to disable the Tone squelch. 2. Radio Call By using Various 5Tone, individual / Group call is available. 16 Receiving codes are available as well as open call. 3. Missed calls list 16 Missed calls can be listed. If a call remains unanswered, the call will be stored by the radio. 4. contact list During a call, the contact list may be used to give access to up to 16 preprogrammed numbers accessed via the menu. 5. status list A status is a code for transmitting prearranged messages, e.g. status “05” may indicate “launch”. Status list contains up to 30 entries. 6. Channel : 255 channel 7. Scan ON/off 8. Power level : Power level is adjustable in each channel respectively. 9. Talkaround on/off 10. Emergency : 11. Lone Worker 12. Tx Tone select : In the menu, tx dcs /ctcss tone is adjustable. 13. Rx Tone select : In the menu, rx dcs /ctcss tone is adjustable. 14. Group : Defines group tone. You can select tone code for group, and it is used as a default value . 0~9 and a, b, c, d available. And “A” is used as a basic value.. 15. BEEP ON/OFF : BEEP sound ON/OFF. 16. KEY LOCK : LOCK/UNLOCK Button KEY. 17. SQUELCH : Squelch level is adjustable 18. AUTO SQUELCH : Squelch level is adjustable automatically by surroundings. 19. DTMF ON/OFF : DTMF function is available. 20. VOX : VOX LEVEL is adjustable by pushing up and down button. 21. AUTO VOX : VOX level is adjustable automatically by surroundings. 22. P - SCAN : Priority Scan 23. POWER SAVE : Power save mode is available. 24. PASS WORD : This function is useful for security reason. 25. LOCATION INDICATE : Indicate where the radio is located by blinking green light every 7 seconds. 26. SCRMABLE : Internal Voice Scrambler is available. 27. STUN / UNSTUN : For added security and to avoid abuse of the radio system in which you operate a feature known as Stun/Unstun is included in your radio. 28. BACKLIGHT : Lamp is lighting when you check LCD status. 4-2 LCD Display and Icons 1.ANT GAZE ; Shows the received signal strength. 2.TX POWER HIGH: Indicate power level 3.KEY LOCK: Appears during key lock function is ON. 4.ALART(BEEP) ON/OFF: Appears when beep sound is turned ON. 5.Battery level indicator: Indicates reaming battery power. 6.VOX ON/OFF: Appears when VOX function is turned On. 7.SCAN: Appears when Scan function is activated. 8.SCRAMBLE: Appears while the voice scrambler function is activated. 9.TALK AROUND Indicator. 4-3 Features 1. Channel This radio offers up to 255 channels 1). By using button, you can select the desired channel. 2. Missed calls list Up to 16 calls can be stored. If the same radio calls more than once, only the most recent call is stored. When fifteen calls have been stored by the radio, depending on the radio programming the sixteenth call received may overwrite the first or not be stored by the radio. 1). to enter Menu Mode. 2) Display shows 3) to select 4) orto scroll list 5) to exit 3. Contact list 1). to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) to exit 4. Status call list 4-1. Making STATUS call 1) to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) Push PTT KEY for sending message on the LCD. 4-2 Make STATUS Message 1) to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) to SELECT 5. Lone work 1). to enter Menu Mode. 2) orto until 3) to select 4) orto select ON/OFF 6. Tx power . 1). to enter Menu Mode. 2) orto until 3) to select 4) orto select HIGH / LOW POWER 5) to select 7…

Text truncated - open the document above for the full version.

z View of EUT z Rear View of Product z Left View of EUT z Right View of Product z Top View of EUT z Bottom View of Product

FCC ID LABEL 1. FCC ID label drawing 2. FCC ID label location - Rear side of set E-TECH Co., Ltd. Model : IP100 FCC ID : R72IP100 Made in Korea

z Inner View of Product z Inner View of Product z Inner View of Product z Inner View of Product

1. Introduction IP100 has a compact size with a various features in the range of 136~174MHz. IP100 Has a various features shown as below. IP100 constructed with a microprocessor controlled, temperature compensated Phase Locked Loop(PLL) frequency synthesizer. The radio features a double conversion receiver and a direct FM transmitter modulator. A special integrated circuit provides support to sub-audible signaling(CTCSS & DCS) and most of the receiving parts are switched off periodically in the power save mode to reduce battery current drain during standby. 2. Description of Unit Items Model Radio IP 100 Antenna IA-156 1700mAh Li-Ion battery pack BL 1800 Desktop rapid charter IC-170 Adaptor Supplied Package User manual Items Model External / Speaker MicrophoneES-1 Earpiece Microphone EP-1 Earpiece VOX Microphone EV-1 Accessories VOX & PTT Headset VP-1 3. Technical Specifications 3-1 General 1) Frequency range : 136~174 MHz 2) Channels : 255 Channels 3) Channel spacing : 12.5 kHz/25 kHz 4) Communication method : Simplex 5) Antenna Impedance : 50 ohm 6) Antenna : Helical Antenna 7) Power supply voltage : LI-1700mAh Li-Ion battery pack(Voltage: 7.5V DC) 8) Current Drain : When Transmitting(5W) - < 2A When Receiving(0.5W) - < 300mA Transmit standby - < 60mA Receiver standby(PSC MODE) - < 50mA 9) Microphone : Internal Condenser Microphone(External Speaker Micro phone is available) 10) Operating temperature range: -30 +60 11) Size : 56(W)x100(H)x34(D) 12) Weight : 285g 3-2 Transmitter 1) Power Output : HIGH – 5W, LOW - 1W 2) Modulation : 8K5F3E/16K0F3E 3) Oscillator method : PLL 4) Frequency Stability : less than ±0.00025% (±2.5PPM) 5) Maximum frequency deviation: ±2.5 kHz(Narrow)/ ±5 kHz(Wide) 6) Audio Distortion : less than 5% (1 kHz 60%) 7) SPURIOUS Emission : -65 [dBc] 8) FM Hum & Noise : -40 [dB] (HP8920A 300Hz 3kHz BPF) 9) BAND SPREAD : 38 [MHz] 3-3 Receiver 1) Receiver Type : Double Super Hetero type 2) Sensitivity : -0.25uV (12dB SINAD ) 3) Frequency Stability : ±0.00025%(±2.5PPM) 4) SPURIOUS Rejection : -60 dB 5) Adjacent Channel Selectivity: -60 dB (Narrow) , -70 dB (Wide) 6) Distortion : 5% (1 kHz 60%) 7) Hum & Noise : -40 dB(HP8920A 300Hz 3kHz BPF) 8) Audio output : 1000 mW 9) BAND SPREAD : 38MHz 10) Speaker size : 45 pi 4. Theory of Operation EXTERNAL VIEW 4-1 Features & Operation 1. Monitor Press the Monitor key momentarily to disable the Tone squelch. 2. Radio Call By using Various 5Tone, individual / Group call is available. 16 Receiving codes are available as well as open call. 3. Missed calls list 16 Missed calls can be listed. If a call remains unanswered, the call will be stored by the radio. 4. contact list During a call, the contact list may be used to give access to up to 16 preprogrammed numbers accessed via the menu. 5. status list A status is a code for transmitting prearranged messages, e.g. status “05” may indicate “launch”. Status list contains up to 30 entries. 6. Channel : 255 channel 7. Scan ON/off 8. Power level : Power level is adjustable in each channel respectively. 9. Talkaround on/off 10. Emergency : 11. Lone Worker 12. Tx Tone select : In the menu, tx dcs /ctcss tone is adjustable. 13. Rx Tone select : In the menu, rx dcs /ctcss tone is adjustable. 14. Group : Defines group tone. You can select tone code for group, and it is used as a default value . 0~9 and a, b, c, d available. And “A” is used as a basic value.. 15. BEEP ON/OFF : BEEP sound ON/OFF. 16. KEY LOCK : LOCK/UNLOCK Button KEY. 17. SQUELCH : Squelch level is adjustable 18. AUTO SQUELCH : Squelch level is adjustable automatically by surroundings. 19. DTMF ON/OFF : DTMF function is available. 20. VOX : VOX LEVEL is adjustable by pushing up and down button. 21. AUTO VOX : VOX level is adjustable automatically by surroundings. 22. P - SCAN : Priority Scan 23. POWER SAVE : Power save mode is available. 24. PASS WORD : This function is useful for security reason. 25. LOCATION INDICATE : Indicate where the radio is located by blinking green light every 7 seconds. 26. SCRMABLE : Internal Voice Scrambler is available. 27. STUN / UNSTUN : For added security and to avoid abuse of the radio system in which you operate a feature known as Stun/Unstun is included in your radio. 28. BACKLIGHT : Lamp is lighting when you check LCD status. 4-2 LCD Display and Icons 1.ANT GAZE ; Shows the received signal strength. 2.TX POWER HIGH: Indicate power level 3.KEY LOCK: Appears during key lock function is ON. 4.ALART(BEEP) ON/OFF: Appears when beep sound is turned ON. 5.Battery level indicator: Indicates reaming battery power. 6.VOX ON/OFF: Appears when VOX function is turned On. 7.SCAN: Appears when Scan function is activated. 8.SCRAMBLE: Appears while the voice scrambler function is activated. 9.TALK AROUND Indicator. 4-3 Features 1. Channel This radio offers up to 255 channels 1). By using button, you can select the desired channel. 2. Missed calls list Up to 16 calls can be stored. If the same radio calls more than once, only the most recent call is stored. When fifteen calls have been stored by the radio, depending on the radio programming the sixteenth call received may overwrite the first or not be stored by the radio. 1). to enter Menu Mode. 2) Display shows 3) to select 4) orto scroll list 5) to exit 3. Contact list 1). to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) to exit 4. Status call list 4-1. Making STATUS call 1) to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) Push PTT KEY for sending message on the LCD. 4-2 Make STATUS Message 1) to enter Menu Mode. 2) orto until 3) to select 4) orto scroll list 5) to SELECT 5. Lone work 1). to enter Menu Mode. 2) orto until 3) to select 4) orto select ON/OFF 6. Tx power . 1). to enter Menu Mode. 2) orto until 3) to select 4) orto select HIGH / LOW POWER 5) to select 7. Tx Tone Selecting Transmitting TONE(CTCSS/DCS). 1). to enter Menu Mode. 2) orto until 3) to select 4) orto Select TONE either CTCSS or DCS. 0= NON TONE 1-38 C…

Text truncated - open the document above for the full version.

– – – –° ° –° ° ’ - - - - - - - - - - - - - - - - - “” ’ – – – – – – – –– Appendix A Calibration Certificate - PROBE - DAE - DIPOLE Appendix B Measurement Plots 1 / 1 file://C:\DASY4 Report\E-Tech\IP100_Valid-3.htm2004-06-17 Date/Time: 06/15/04 10:31:15 Test Laboratory: SGS Testing Korea IP100_300MHz_Valid_Head_250mW DUT: Dipole 300 MHz; Type: UHAP-10dB ; Serial: 958 Communication System: CW; Frequency: 300 MHz;Duty Cycle: 1:1 Medium: H150 Medium parameters used: f = 300 MHz; s = 0.889 mho/m; e r = 46.8; ? = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1782; ConvF(7.6, 7.6, 7.6); Calibrated: 2004-04-28 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn567; Calibrated: 2004-04-30 - Phantom: Flat Phantom 4.3; Type: Flat Phantom 4.3; Serial: 1003 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Validation 300MHz /Area Scan (101x201x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 27.4V/m; Power Drift = -0.001 dB Maximum value of SAR (interpolated) = 0.770 mW/g Validation 300MHz 2/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 27.4V/m; Power Drift = -0.001 dB Maximum value of SAR (measured) = 0.772mW/g Peak SAR (extrapolated) = 0.967W/kg SAR(1 g) = 0.718mW/g; SAR(10 g) = 0.391mW/g 0 dB = 0.280mW/g 1 / 1 file://C:\DASY4 Report\E-Tech\IP100_10JUN-1.htm2004-06-17 Date/Time: 06/15/04 16:15:36 Test Laboratory: SGS Testing Korea IP100_136.025MHz_Head DUT: IP100; Type: VHF; Serial: none Communication System: CW; Frequency: 136.025 MHz;Duty Cycle: 1:1 Medium: H150 Medium parameters used (interpolated): f = 136.025 MHz; s = 0.745 mho/m; e r = 54.3; ? = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1782; ConvF(8.9, 8.9, 8.9); Calibrated: 2004-04-28 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn567; Calibrated: 2004-04-30 - Phantom: Flat Phantom 4.3; Type: Flat Phantom 4.3; Serial: 1003 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 IP100 (136.025MHz)-Final/Area Scan (61x171x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 25.3 V/m; Power Drift = -0.18 dB Maximum value of SAR (interpolated) = 0.640 mW/g Info: Interpolated medium parameters used for SAR evaluation! IP100 (136.025MHz)-Final/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 25.3 V/m; Power Drift = -0.18 dB Maximum value of SAR (measured) = 0.607 mW/g Peak SAR (extrapolated) = 0.865 W/kg SAR(1 g) = 0.587 mW/g; SAR(10 g) = 0.451 mW/g Info: Interpolated medium parameters used for SAR evaluation! 0 dB = 0.607mW/g 1 / 1 file://C:\DASY4 Report\E-Tech\IP100_10JUN-2.htm2004-06-17 Date/Time: 06/15/04 16:15:36 Test Laboratory: SGS Testing Korea IP100_155.025MHz_Head DUT: IP100; Type: VHF; Serial: none Communication System: CW; Frequency: 155.025 MHz;Duty Cycle: 1:1 Medium: H150 Medium parameters used (interpolated): f = 155.025 MHz; s = 0.762 mho/m; e r = 53.1; ? = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1782; ConvF(8.9, 8.9, 8.9); Calibrated: 2004-04-28 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn567; Calibrated: 2004-04-30 - Phantom: Flat Phantom 4.3; Type: Flat Phantom 4.3; Serial: 1003 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 IP100 (155.025MHz)-Final/Area Scan (61x171x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 29.5 V/m; Power Drift = -0.19 dB Maximum value of SAR (interpolated) = 0.925 mW/g Info: Interpolated medium parameters used for SAR evaluation! IP100 (155.025MHz)-Final/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 29.5 V/m; Power Drift = -0.19 dB Maximum value of SAR (measured) = 0.921 mW/g Peak SAR (extrapolated) = 1.28 W/kg SAR(1 g) = 0.889 mW/g; SAR(10 g) = 0.685 mW/g Info: Interpolated medium parameters used for SAR evaluation! 0 dB = 0.921mW/g 1 / 1 file://C:\DASY4 Report\E-Tech\IP100_10JUN-3.htm2004-06-17 Date/Time: 06/15/04 16:15:36 Test Laboratory: SGS Testing Korea IP100_173.975MHz_Head DUT: IP100; Type: VHF; Serial: none Communication System: CW; Frequency: 173.975 MHz;Duty Cycle: 1:1 Medium: H150 Medium parameters used (interpolated): f = 173.975 MHz; s = 0.777 mho/m; e r = 52.1; ? = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1782; ConvF(8.9, 8.9, 8.9); Calibrated: 2004-04-28 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn567; Calibrated: 2004-04-30 - Phantom: Flat Phantom 4.3; Type: Flat Phantom 4.3; Serial: 1003 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 IP100 (173.975MHz)Final/Area Scan (61x171x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 43.4 V/m; Power Drift = -0.17 dB Maximum value of SAR (interpolated) = 1.94 mW/g Info: Interpolated medium parameters used for SAR evaluation! IP100 (173.975MHz)Final/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 43.4 V/m; Power Drift = -0.17 dB Maximum value of SAR (measured) = 1.84 mW/g Peak SAR (extrapolated) = 2.61 W/kg SAR(1 g) = 1.78 mW/g; SAR(10 g) = 1.35 mW/g Info: Interpolated medium parameters used for SAR evaluation! 0 dB = 1.84mW/g 1 / 1 file://C:\DASY4 Report\E-Tech\IP100_136.025MHz_Muscle-1.htm2004-06-17 Date/Time: 06/16/04 16:24:53 Test Laboratory: SGS Testing Korea IP100_136.025MHz_Muscle DUT: IP100; Type: VHF; Serial: none Communication System: CW; Frequency: 136.025 MHz;Duty Cycle: 1:1 Medium: M150 Medium parameters used (interpolated): f = 136.025 MHz; s = 0.77 mho/m; e r = 63.4; ? = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1782; ConvF(8.5, 8.5, 8.5); Calibrated: 2004-04-28 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn567; Calibrated: 2004-0…

Text truncated - open the document above for the full version.

SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, 435-040, Korea wwwsgstestingcokrwwwsgscokr To: Steven Dayhoff ([email protected]) Date: 8/25/2004 /FCC Equipment Authorization Branch From: James Kwon ( [email protected]) /Lab manager of R&TTE Div CC: Klaus Knoerig ( [email protected]) Jong-woon Kim/E-TECH ( [email protected]) Applicant : E-TECH Co., Ltd. FCC ID : R72IP100 Correspondence Reference Number : 27442 731 Confirmation Number : EA878636 Subject : Reply for Info Request dated 8/23/2004 Q1) SAR system verification page 17 or 22 states 150MHz liquid - please describe how dipole SAR target value is obtained for Schwarzbeck dipole with this liquid. A1) As you know, for all frequency range in the 30~300 MHz, the system verification shall be made at 300 MHz using a 300 MHz dipole antenna and the 300 MHz tissue equivalent liquid. (We got this proposal information for 30~300 MHz testing from Mr. Meier Matthias ( [email protected]) by e-mail on 6/8/2004 and 6/9/2004)) The using frequency of IP100 is 136-174 MHz, so we made the liquid (30~300MHz) for 150 MHz test and named it as “150 MHz Head Simulated Liquid”. Then we did verification test with 300 MHz Schwarzbeck dipole antenna and the liquid (30~300 MHz) on point of 300 MHz. (Deviation is less than 10%) (That is, the name of “150 MHz Head” on page 17 and 22 is just the “name of liquid we made”.) And SPEAG does not offer the dipole antenna under 450 MHz. We surveyed many SAR test report from FCC web site, and we found that most of them used standard dipole antenna. (One example : FCC ID: ONKATP-100, pager 5 of 6 of SAR test report, manufacturer: Airtech, tested by ETS Dr. Genz GmbH) SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, 435-040, Korea wwwsgstestingcokrwwwsgscokr Therefore we used the standard dipole antenna that we had. (Schwarzbeck / Model:UHAP-10dB). Q2) Please submit photo of SAR sys. verification dipole setup. A2) Please refer to attached two set-up photos. If you have further questions feel free to contact me. Regards, ============================================== James Kwon ( [email protected] ) / R&TTE Division Tel : 82-31-428-5740 Fax: 82-31-427-2371 Mobile : 82-11-9788-0485 SGS Testing Korea Co., Ltd. (www.sgstesting.co.kr) Add: 18-34, Sanbon-Dong, Gunpo-City, Kyunggi-Do, Korea ============================================== SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, 435-040, Korea wwwsgstestingcokrwwwsgscokr SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, 435-040, Korea wwwsgstestingcokrwwwsgscokr SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, 435-040, Korea wwwsgstestingcokrwwwsgscokr

VERIFICATION OF COMPLIANCE Applicant : E-TECH Co., Ltd. FM Handheld Transceiver lris IP100 STROR-04-008 APPLICABLE STANDARDS 1. General Description of EUT 2. General Information of EUT – 3. Test Procedure 3.1 Output Power Conducted FCC 2.1046(a),FCC 90.205 3.2 Radiated Spurious Emissions FCC 2.1053, FCC 90.210 3.3 Conducted Spurious Emissions FCC 2.1051 3.4 Audio Frequency Response FCC 2.1047(a) 3.5 Audio Low Pass Filter Frequency Response FCC 2.1047(a), FCC 90.242(b)(8) 3.6 Modulation Limiting FCC 2.1047(b),22.915(b),90.210 ’ – 3.7 Occupied Bandwidth FCC 2.1049,90.210 3.8 Frequency stability FCC 2.1055,FCC 90.213 3.9 Transient frequency behaviour FCC 90.214 Output Power Conducted FCC 2.1046(a), FCC90.205 Test Equipment Used Spectrum Analyzer H/P 8565E Dec. 2004 Signal Generator Agilent E4438CMay. 2005 Power Meter Agilent E4416A May. 2005 Power Sensor Agilent E9327A May. 2005 DC Power Supply Agilent 6674A May. 2005 5.Radiated Spurious Emissions FCC 2.1053(a), FCC90.210 Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-periodic S/B UHALP9107 Jan. 2005 Anechoic Chamber Seo Young EMC - - Test Equipment Used Spectrum analyzer H/P 8593E Sep. 2004 Signal Generator Agilent 8648D May 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dipole Antenna Schwarzbeck Mess UHAP May. 2005 Dummy Load BIRD 8404 Dec. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Horn Antenna Schwarzbeck BBHA9120A Sep. 2004 Biconical Antenna EMCO 3110 Jan. 2005 Biconical Antenna EMCO 3104C Feb. 2005 Log-pe…

Text truncated - open the document above for the full version.

Photos of the test setup
