FCC TEST REPORT E05.0711.FCC.402N, Page 5 of 16 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 2.1 Equipment Description The Equipment Under Test (EUT) is the WAVESYSTEC Co., Ltd., MP3 Player, IMP-2000A. 2.2 General Specification Model name IMP-2000A Supported Compression Formats MP3(8 – 320 kbps), ADPCM(32 kbps), WMA Intermal Storage Capacity 128 / 256 / 512 MB Display Graphic (128 * 64) LCD (Blue Color LED backlight) Supported Languages 36 User Interface Language English File Transfer Rate Max. 20 MB Earphone Output 20 mW(L) + 20 mW(R) Signal to Noise Ratio Min. 85 dB Output Frequency Range 20 Hz – 20 kHz Battery AAA Battery 1EA Playing Time 18 hrs FM Frequency Range 87.5 MHz to 108.0 MHz Dimensions / Weight 32(W) * 77.8(H) * 21.5(D) mm / 42 g (Including Battery)

Test Report

www.etl.re.kr E-RAE Testing Laboratory This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the ETL,Inc. Electromagnetic Emission FCC MEASUREMENT REPORT CERTIFICATION OF COMPLIANCE FCC Part 15 Certification Measurement This is MP3 Player. Model IMP-2000A has been tested in accordance with the measurement procedures specified in ANSI C63.4-2001 at the ETL/EMC Test Laboratory and has been shown to be complied with the electromagnetic radiated emission limits specified in FCC Rule Part15 Subpart B : I attest to the accuracy of data. All measurement herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Yo Han, Park / Chief Engineer ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea PRODUCT : MP3 Player MODEL/TYPE NO : IMP-2000A FCC ID : R8DIMP-2000A APPLICANT : WAVESYSTEC Co., Ltd Daeryung Techno Town 6 – 901, 493-6 Gasan-dong, Geumchun-gu, Seoul, Korea Attn. : Kwang-Ho, Kim / R & D Director FCC CLASSIFICATION: Class B personal computers and peripherals FCC RULE PART(S) : FCC Part 15 Subpart B FCC PROCEDURE : Certification TRADE NAME : WAVESISTEC TEST REPORT No. : E05.0711.FCC.402N DATES OF TEST : July 01 – 11, 2005 DATES OF ISSUE : July 11, 2005 TEST LABORATORY : ETL Inc ( FCC Registration Number : 95422) #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel : (031) 885-0072 Fax : (031) 885-0074 FCC TEST REPORT E05.0711.FCC.402N, Page 2 of 16 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 Table of Contents FCC Measurement Report 1. Introduction 2. Product Information 3.Description of Tests 4.Test Condition 5.Test Results 5.1 Summary of Test Results 5.2 Conducted Emissions Measurement 5.3 Radiated Emissions Measurement 6. Sample Calculation 7. List of test Equipment used for Measurement Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. User Manual FCC TEST REPORT E05.0711.FCC.402N, Page 3 of 16 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information z EUT Type : MP3 Player z Model Number : INP-2000A z FCC ID : R8DIMP-2000A z S/N : N/A z FCC Rule Part(s) : FCC Part 15 Subpart B z Test Procedure : ANSI C63.4-2001 z FCC Classification : Class B personal computers and peripherals z Dates of Tests : July 11, 2005 z Place of Tests : ETL Inc. EMC Testing Lab (FCC Registration Number : 95422) 584, Sangwhal-Ri, Kanam-Myun, Yoju-Kun, Kyounggi-Do, Korea Tel : (031) 885-0072 Fax : (031) 885-0074 z Test Report No. : E05.0711.FCC.402N Applicant Name : WAVESYSTEC Co., Ltd Address : Daeryung Techno Town 6 – 901, 493-6, Gasan-dong, Gumchun-gu, Seoul, Korea Attention : Kwang-Ho Kim / R & D Director FCC TEST REPORT E05.0711.FCC.402N, Page 4 of 16 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 The measurement for radiated and conducted emission test were conducted at the open area test site of E-RAE Testing Laboratory Inc. facility located at 584, Sangwhal-ri, Ganam-myun, Youju-kun, Kyoungki-do, Korea. The open area test site is constructed in conformance with the requirements of the ANSI C63.4-2001 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 and 10 meter site configurations. Detailed description of test facility was found to be in compliance with the requirements of Section 2.948 FCC Rules according to the ANSI C63.4-2001 and registered to the Federal Communications Commission(Registration Number : 95422 ). The measurement procedure described in American National Standard for Method of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C.63.4-2001) was used in determining radiated and conducted emissions from the WAVESYSTEC Co., Ltd Model: IMP-2000A. FCC TEST REPORT E05.0711.FCC.402N, Page 5 of 16 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 2.1 Equipment Description The Equipment Under Test (EUT) is the WAVESYSTEC Co., Ltd., MP3 Player, IMP-2000A. 2.2 General Specification Model name IMP-2000A Supported Compression Formats MP3(8 – 320 kbps), ADPCM(32 kbps), WMA Intermal Storage Capacity 128 / 256 / 512 MB Display Graphic (128 * 64) LCD (Blue Color LED backlight) Supported Languages 36 User Interface Language English File Transfer Rate Max. 20 MB Earphone Output 20 mW(L) + 20 mW(R) Signal to Noise Ratio Min. 85 dB Output Frequency Range 20 Hz – 20…
