RA3-86125TYPE PAD

Nyko Technolgies, Inc. SPECIFICATION FOR APPROVAL ： CUSTOMER： PRODUCT NAME： TYPE PAD MODEL DETAIL： 86125 V E R： A1.0 FILE NUMBER: Nyko Technolgies, Inc. 1 TYPE PAD CATALOG 1．Introduction and Application---------------------1 2，Product Image------------------------------------1 3．Product Size-------------------------------------1 4．The Introduction of Keyboard Interface-----------2 5．Instructions-------------------------------------4 6、Technical Parameters----------------- ----------5 7. Life Test Standard----------————- ----------5 8. Surface Requirements and Inspection Standards -------6 9、Attention---------------------------- ---------6 Nyko Technolgies, Inc. 2 TYPE PAD I、Production introduction and function application: 1. It is applied to TYX-581 XBOXONE controller keyboard which is designed and produced by Yuyuanxin. 2.The XBOX ONE controller keyboard is designed for a Microsoft XBOX ONE Handle.it can apply to original XBOX ONE old and new two kinds of handles perfectly. it will not affect the use of headphones.and be compatible the various of XBOX ONE console system (as image 1). It can input fond,test, and symbols conveniently and quickly. 3、The players can group chat with this keyboard comfortable .It is easy to use and also can combine with any version of XBOX one original handle controller, and provide text inputting,group chat and gaming as well. 4、Its silicon surface is used the import environmental silicone, and it will be shiny green in the dark. II．Product Picture： 图1 III．Product size Nyko Technolgies, Inc. 3 Length 142*wide63*high45mm IV、Introduction of Keyboard interface ： 1 2 3 4 5 6 7 8 9 10 11 14 12 13 1、0 -9(number key ) 2、Caps Lock 3、Signal pair key Nyko Technolgies, Inc. 4 4、Shift 5、SPACE 6、X one 7、26 letters and commonly symbol keys 8、Enter 9、Back space 10、Stick head for five direction 11、XBOX one headset male jack 12、Rotating 3.5 headset male jack 13、3.5 female headset 14、2.4G code indicating lamp V、User Instruction： 1．Connect the host power firstly then connect HDMI cable with display equipment. you open the console power of XBOX ONE while the indicator will be on. 2、Connect the controller with XBOX one console. (if have any question please check the console specification.) 3、Aim its joint pin to XBOX one guide hole, aim headset to the back seat of xbox one controller.then push the keyboard into the xbox one handle slowly until it connect .(Note:New controller need the 3.5 headset plug,you should open the silicone by arrow direction at the bottom of the keyboard,then turn 3.5 audio plug to external rotation until it is connected.) 4、Under the power on status, put the 2.4G receiver to any USB port of XBOX ONE.and enter the signal pairing key on the back of the xbox one keyboard within 15 seconds.It will be paired when the blue indicator will glitter. (Note:when pairing,the distance of Nyko Technolgies, Inc. 5 keyboard and receiving part must be within 0.5 meters,if pairing fails, try above steps again.) 5、It will work when the blue indicator will turn off after pairing. 6、Pair only once between the XBOX one keyboard with 2.4G receiver. Open the console to awake the controller automatically for future use. 7、Five direction analog stick similar to UP.DOWN.LEFT.RIGHT .A key function for stronger user’s experience. 8、Its headset jack can be compatible with the Xbox one original headset and have the same effect as connecting with the controllers, the new controlleralso can be compatible with 3.5 headset for PS4. 9、It will be in sleeping mode while the XBOX one handle sleeps, Please press “ ”Button to awake it and controller. VI、Technical parameters 1、Applicable range：suitable to work with XBOX ONE set. 2、Wireless version：2.4G 3、Wireless distance:effectiverange8-10M 4、Working current（when the buttons press）：0.8mA 5、Working current（No button pressing）：8uA 6、Product size：142x63x45MM 7、Material：ABS VII.Life test: 1 High temperature test：set the temperature in60°C±2°C and put the sample into the incubator then take it out after 4 hours,under the natural condition after 1-2 hours,function and appearance should be able to meet Nyko Technolgies, Inc. 6 the inspection requirements before test,slight deformation ,drops phenomenon. 2 Low temperature test：set the temperature in-20°C and do the same steps as the high temperature test. 3 Button life test：inspection methods and conditions:install button on the fixture analog buttons,at a rate of 25 times/min,the level not less than 250g of evenly buttons,press/ release as a results.requirement:press buttons at least 100000 times,keys should be able to work normally,silk screen and buttons/plating/paint shall have no loss. 4 Hardware salt spray test：Set the temperature of salt spray test chamber in 35 °C,configurationsalt solution concentration in 5%,the PH value of 6.5-7.2,salt fog settlement for 1-2ml/80 cm 2.h., put it into the testing machine, and test it in 24h at least. Wash it after testing, it will be acceptable that there is no falloff and rusting of its appearance after washing and wiping it. VIII. Appearance requirement and inspection standards: 1.No deformation.no shrinkage.no burrs,no gap,spray oilevenly,no surface scratched,no dirt,no black sports and no burr for the housing. 2.No screw losing, cracks,poor Logo printing 3.Packing material and accessories must according to the requirement of the order 4.Other standard please refer to the similar products. IX、Attention In order to use the bluetooth products correctly and ensure the performance is goodplease read follow carefully. ● Do not hit the keyboard seriously. ● Do not let this product contact with benzene,thinner,chemical.etc. Nyko Technolgies, Inc. 7 ● Do not close to strong magnetic field ,electric field. ● Please avoid direct lighting or heating apparatus. ● Do not repair and reconstruct by yourself. ● Waste packing,batteries ,electronic products,old classification properly handle. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization LetterPage 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project andProduct CertificationRepresentative AuthorizationLetter Reason for Amendment (current / obsolete) Revision History Approved Date FromTo Initial Release (obsolete)1.01.0Nov-14-2006 Revisedwording(obsolete)1.02.0Sept–25-2007 Updated company template (obsolete)2.03.0Jan-31-2012 Updatedletterinformation(obsolete)3.04.0May-23-2014 Added FCC ID field (current)4.05.0Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization LetterPage 2 of 2Rev 5.0 (Nyko Technolgies, Inc.) (2016-01-21) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____Nyko Technolgies, Inc. _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description:TYPE PAD Model name:86125 FCC ID:RA3-86125 Sincerely, Client’s signature Craig Erickson / Director R&D Company Name: Nyko Technolgies, Inc. Address: 1990 Westwood Blvd. Penthouse Suite, Los Angeles,CA 90025 USA Email: [email protected]

SCS-F19: Confidentiality Request LetterPage 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) RevisionHistory Approved Date FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 AddingCFR2.459(obsolete)1.02.0August–11-2008 Updated company template & Added text box (obsolete) 2.03.0Jan-31-2012 Added IC confidentiality letter form (obsolete)3.04.0March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.05.0Nov 19 2015 SCS-F19: Confidentiality Request LetterPage 2 of 2 Rev 5.0 (Nyko Technolgies, Inc.) (2016-01-21) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject:Permanent Confidentiality Requestfor FCC ID:RA3-86125 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: -BlockDiagram -Schematics -OperationalDescription The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Craig Erickson / Director R&D Company Name: Nyko Technolgies, Inc. Address: 1990 Westwood Blvd. Penthouse Suite, Los Angeles,CA 90025 USA Email: [email protected]

Figure 1 The EUT-Overall View Figure 2 The EUT-Top View Figure 3 The EUT-Bottom View Figure 4 The EUT-Front View Figure 5 The EUT-Back View Figure 6 The EUT-Right View Figure 7 The EUT-Left View

Product Name:TYPE PAD Model No.:86125 FCC ID:RA3-86125 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Label Location On EUT

Figure 8 The EUT-Inside View Figure 9 PCB of the EUT-Front View Figure 10 PCB of the EUT-Back View Figure 11 PCB of the EUT-Front View Figure 12 PCB of the EUT-Back View Figure 13 PCB of the EUT-Front View Figure 14 PCB of the EUT-Front View Antenna

Shenzhen Anbotek Compliance Laboratory Limited FCC ID: RA3-86125 Page 1 of 37 Report No.: R011512932I Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com FCC TEST REPORT for Nyko Technolgies, Inc. TYPE PAD Model No.: 86125 ReportNumber:R011512932I DateofTest:Dec.24,2015~Jan.12,2016 DateofReport:Jan.13,2016 Preparedfor:NykoTechnolgies,Inc. Address:1990 Westwood Blvd. Penthouse Suite, Los Angeles, CA 90025 USA PreparedBy:ShenzhenAnbotekComplianceLaboratoryLimited Address:1/F., Building 1, SEC Industrial Park, No.0409 Qianhai Road, NanshanDistrict,Shenzhen,Guangdong,China Tel:(86)755-26066544 Fax:(86)755-26014772 Shenzhen Anbotek Compliance Laboratory Limited FCC ID: RA3-86125 Page 2 of 37 Report No.: R011512932I Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com TABLE OF CONTENTS Description Page Test Report 1. GENERAL INFORMATION......................................................................................................4 1.1. Description of Device (EUT)................................................................................................................4 1.2. Auxiliary Equipment Used during Test................................................................................................ 5 1.3. Description of Test Facility.................................................................................................................. 5 1.4. Measurement Uncertainty.....................................................................................................................5 2. TEST METHODOLOGY............................................................................................................ 6 2.1. Summary of Test Results......................................................................................................................6 2.2. Description of Test Modes....................................................................................................................6 3. TEST PROCEDURE....................................................................................................................7 4. RADIATION INTERFERENCE................................................................................................ 8 4.1. Requirements (15.249, 15.209):............................................................................................................8 4.2. Test Procedure...................................................................................................................................... 8 4.3 Test Equipment......................................................................................................................................9 4.4. Test Results...........................................................................................................................................9 5. BANDEDGE................................................................................................................................15 5.1. Requirements (15.249):.......................................................................................................................15 5.2. Test Procedure.................................................................................................................................... 15 5.3. Test Configuration:.............................................................................................................................15 5.4. Test Results.........................................................................................................................................16 6. OCCUPIED BANDWIDTH...................................................................................................... 25 6.1. Requirements :.................................................................................................................................... 25 6.2. Test SET-UP.......................................................................................................................................25 6.3 Test Equipment....................................................................................................................................25 6.4. Test Results.........................................................................................................................................25 7. ANTENNA APPLICATION......................................................................................................28 7.1. Antenna requirement...........................................................................................................................28 7.2. Result.................................................................................................................................................. 28 8. PHOTOGRAPH......................................................................................................................... 29 8.1. Photo of Radiation Emission Test.......................................................................................................29 Shenzhen Anbotek Compliance Laboratory Limited FCC ID: RA3-86125 Page 3 of 37 Report No.: R011512932I Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com TEST REPORT Applicant: Nyko Technolgies, Inc. Manufacturer: Nyko Technolgies, Inc. EUT: TYPE PAD Model No.: 86125 Serial No.: N.A. Trade Mark: NYKO Rating: DC 3.3V, 10mA Measurement Procedure Used: FCC Part15 Subpart C, Paragraph 15.207, 15.249 & 15.209 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the deviceand the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accur…

Text truncated - open the document above for the full version.

1. Photo of Radiation Emission Test
