RAD550HSDPA/HSUPA/HSPA+/UMTS quad band /GSM quad band/LTE 4 band mobile phone

English -CJB6156ALAAA Quick Start Guide For more information about how to use your cellphone, please visit www.alcatelonetouch.com to download the complete user manual. From the website, you can consult the FAQ, perform software upgrades, etc.




1 1 Your mobile ������������������ 1�1 Keys and connectors Micro-USB Connector Front camera Headset connector Power key Volume key LED indicator Home key Touch screen Back key Recents key Camera Camera Flash/Flashlight PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. Table of contents 1 Your mobile ���������������������������������������������������������������������1 2 Text input ����������������������������������������������������������������������12 3 Phone call ����������������������������������������������������������������������13 4 Contacts ������������������������������������������������������������������������15 5 Messaging�����������������������������������������������������������������������16 6 Email ������������������������������������������������������������������������������17 7 Getting connected ��������������������������������������������������������18 8 Find my location using GPS satellites ������������������������20 9 Data backup ������������������������������������������������������������������21 10 Factory data reset ��������������������������������������������������������21 11 Applications & Internal storage ����������������������������������22 12 Making the most of your phone ����������������������������������23 Safety and use �������������������������������������������������������������������������24 General information ��������������������������������������������������������������32 Warranty ���������������������������������������������������������������������������������35 Troubleshooting����������������������������������������������������������������������37 www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on page 30 of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 1.0 cm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 23 1�2 Getting started 1�2�1 Set-up Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card. To install, place the SIM card with the chip facing downwards into the housing and slide it into its slot. Make sure that it is correctly inserted. To remove the card, press and slide it out. Your phone only supports micro-SIM cards. Do not attempt to insert other SIM types like mini and nano cards; otherwise this may cause damage to your phone. Recents key • Touch: this shows you images of your recently-used apps. Touch an image to open the associated app, or swipe it left or right to remove it from the list. Home key • From any application or screen, touch to return to the Home screen. Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. These keys are visible once you click the key position when the screen lights up. Power key • Press: Lock the screen/Light up the screen. • Press and hold: Show the pop-up menu to select from Power off/Reboot/Airplane mode. • Press the Power key for more than 9s to restart. • Press the Power key and Volume up key to reset when the phone is powered off. • Press the Power key and Volume down key to capture a screenshot. Volume Keys • In call mode, adjusts the earpiece or headset volume. • In Music/Video/Streaming mode, adjusts the media volume. • In general mode, adjusts the ringtone volume. • Mutes the ringtone of an incoming call. • In camera preview mode, press Volume up or down key to enter burst shoot. 45 Installing or removing the battery • To install, insert and click the battery into place, then close the phone cover. • To remove the battery, first power the phone off. Then unclip the cover and remove the battery. Installing or removing the microSD card Insert the microSD card with the golden contacts facing downwards into the slot. To remove the microSD card, gently press and slide it out. To avoid data loss and SD card damage, before removing the SD card, please ensure that the SD card is unmounted (Settings\Storage\Unmount SD card). Charging the battery Connect the battery charger to your phone and wall socket respectively, the LED indicator will light while charging. To reduce power consumption and energy waste, when the battery is fully charged, disconnect your charger; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: Input method, Google account, Location, etc. Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, sign into your Google account and use some of the phone's features. 1�2�3 Power off your phone Hold down the Power key from the Home screen until the phone options appear, select Power off. 1�3 Home screen You can move all of items (applications, shortcuts, folders and widgets) you use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen.

67 Touch to enter application list. Status bar • Status/Notification indicators • Touch and drag down to open the notification panel. Touch an icon to open an application, folder, etc. Favourite tray applications • Touch to enter the application. • Touch and hold to move or change applications. Search bar • Touch  to enter text search screen. • Touch  to enter voice search screen. The Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen horizontally left and right to get a complete view. 1�3�1 Using the touchscreen Touch To access an application, touch it with your finger. Touch and Hold Touch and hold the item to enter the available options. Drag Place your finger on the screen to drag an object to another location. Slide/Swipe Slide the screen up and down to scroll through the applications, images, web pages, etc. The device also supports one finger zoom (Messaging, Browser, Email, Camera and Gallery) by double tapping the screen then sliding with one finger to zoom in/out). Flick Similar to swiping, but flicking makes it move quicker. Pinch/Spread Place your fingers of one hand on the screen surface and draw them apart or together to scale an element on the screen. Rotate Automatically change the screen orientation from portrait to landscape by turning the phone sideways to have a better view. 1�3�2 Status bar From the status bar, you can view both phone status (to the right side) and notification information (to the left side). 89 Notification icons New Gmail messageMissed call New Email messageCall forwarding is on New text or multimedia message / Song is playing/pause Problem with SMS or MMS delivery Connected to VPN New Google Hangouts message Radio is on New voicemailAudio share Upcoming eventUploading data Screenshot errorDownload finished Screenshot capturedSelect input method MicroSD card is full An open Wi-Fi network is available No SD card Phone is connected via USB cable Preparing SD cardSystem update available Both USB tethering and portable hotspot are on Carrier data use threshold approaching or exceeded USB tethering is on More notifications are hidden Portable Wi-Fi hotspot is on Status icons GPRS connectedNo signal GPRS in useAlarm is set EDGE connectedBluetooth is on EDGE in use Connected to a Bluetooth device 3G connected Speakerphone is on 3G in useRoaming HSPA (3G+) connectedHeadset connected HSPA (3G+) in useNo SIM card installed HSPA+ connectedVibrate mode HSPA+ in useRinger is silenced 4G connected Phone microphone is muted 4G in useBattery is very low Signal strengthBattery is low Wi-Fi is on Battery is partially drained Connected to a Wi-Fi network Battery is full Airplane modeBattery is charging GPS is on 1011 Drag down the Status bar to open the Notification panel and drag down again to open the Quick setting panel. Drag up to close it. When there are notifications, you can touch them to access notifications directly. Notification panel When there are notifications, touch and drag down the Status bar to open the Notification panel to read more detailed information. Touch to clear all event–based notifications (other ongoing notifications will remain). Touch to switch to the quick setting panel. Quick setting panel Touch and drag down the Notification panel or touch to open the Quick setting panel. You can enable or disable functions or change modes by touching the icons. Touch to enter user screen. Touch to access Settings, where you can set more items. 1�3�3 Search bar The phone provides a Search function which can be used to locate information within applications, the phone, or the web. 1�3�4 Lock/Unlock your screen To protect your phone and privacy, you can lock the phone screen by creating a variety of patterns, PIN or password etc. 1�3�5 Personalize your Home screen Add You can touch and hold a folder, an application, or a widget to activate the Move mode and drag the item to any Home screen as you prefer. Reposition Touch and hold the item to be repositioned to activate the Move mode, drag the item to the desired position and then release. You can move items both on the Home screen and the Favourite tray. Hold the icon on the left or right edge of the screen to drag the item to another Home screen. Remove Touch and hold the item to be removed to activate the Move mode, drag the item up to the top of the icon, and release after the item turns red. Create folders To improve the organisation of items (shortcuts or applications) on the Home screen, you can add them to a folder by stacking one item on top of another. To rename a folder, open it and touch the folder’s title bar to input the new name. Wallpaper customization Touch and hold the empty space in the homescreen and choose Wallpaper to customize wallpaper or you could access this function by Settings\Display\Wallpaper. 1�3�6 Volume adjustment You can set the ringer, media and phone ringtone volumes to your preference by pressing the Volume up/down key, or touching Settings\Sound & notification\Sound to set the volume. 1213 2 Text input ��������������������� 2�1 Using Onscreen Keyboard Onscreen Keyboard settings Touch Settings\Language & input, touch the keyboard you want to setup and a series of settings will become available for your selection. Adjust the Onscreen Keyboard orientation Turn the phone sideways or upright to adjust the Onscreen Keyboard orientation. You can also adjust it by changing the settings (Touch Settings\Display\Auto-rotate screen). 2�1�1 Android keyboard Touch to switch between symbol and numeric keyboard. Touch to input Period signal; Touch & hold to select symbols. Touch to enter text or numbers. Touch to input comma; Touch & hold to show input options. Touch to switch "abc/Abc" mode; Touch & hold to switch "abc/ABC" mode. 2�2 Text editing You can edit the text you have entered. • Touch and hold or double-tap within the text you would like to edit. • Drag the tabs to change the highlighted select…

Text truncated - open the document above for the full version.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2015-01-19 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Terminals Test Lab of China Academy of Telecommunication Research of MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCT Mobile Limited

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 6/2/2015 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD550 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up- Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

EUT photograph Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile phone Charger AE1 Label of Charger AE1 USB Cable AE2 Headset AE3 Battery AE4 Battery AE4-1

Lable Placement

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly

©Copyright. All rights reserved by CTTL. FCC PART 15C TEST REPORT No. I15Z40923-SRD05 for TCT Mobile Limited HSDPA/HSUPA/HSPA+/UMTS quad band /GSM quad band/LTE 4 band mobile phone Model Name: 5042G FCC ID: RAD550 with Hardware Version: PIO Software Version: v4K2Z Issued Date: 2015-05-14 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No.52, HuayuanNorth Road, Haidian District, Beijing, P. R. China 100191. Te l:+86(0)10-62304633-2512,Fax:+86(0)10-62304633-2504 Email:[email protected], website:www.chinattl.com TESTING CNAS L0570 No. I15Z40923-SRD05 Page2 of 90 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z40923-SRD05 R ev.0 1st edition 2015-05-14 No. I15Z40923-SRD05 Page3 of 90 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. TESTING LOCATION ........................................................................................................... 4 1.1. TESTING ENVIRONMENT ................................................................................................... 4 1.2. PROJECT DATA ................................................................................................................... 4 1.3. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDERTEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT ................................................................................ 6 3.3. INTERNAL IDENTIFICATION OF AE ................................................................................... 6 3.4. N ORMAL ACCESSORY SETTING ............................................................................................. 6 3.5. G ENERAL DESCRIPTION ....................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................... 7 4.1. DOCUMENTS SUPPLIED BY APPLICANT ........................................................................ 7 4.2. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 7 5. TEST RESULTS........................................................................................................................ 8 5.1. S UMMARY OF TEST RESULTS ................................................................................................ 8 5.2. S TATEMENTS........................................................................................................................ 8 6. TEST FACILITIES UTILIZED ................................................................................................... 9 ANNEX A: DETAILED TEST RESULTS ....................................................................................... 10 A.1. MEASUREMENT METHOD ....................................................................................................... 10 A.2. PEAK OUTPUT POWER – CONDUCTED ..................................................................................... 11 A.3. FREQUENCY BAND EDGES – CONDUCTED .............................................................................. 12 A.4. CONDUCTED EMISSION .......................................................................................................... 20 A.5. RADIATED EMISSION .............................................................................................................. 45 A.6. TIME OF OCCUPANCY (DWELL TIME) ....................................................................................... 64 A.7. 20DB BANDWIDTH ................................................................................................................. 74 A.8. CARRIER FREQUENCY SEPARATION ........................................................................................ 80 A.9. NUMBER OF HOPPING CHANNELS .......................................................................................... 83 A.10. AC POWERLINE CONDUCTED EMISSION ............................................................................... 87 ANNEX B: ACCREDITATION CERTIFICATE ............................................................................... 90 No. I15Z40923-SRD05 Page4 of 90 ©Copyright. All rights reserved by CTTL. 1. Test Laboratory 1.1. Testing Location Location 1:CTTL(huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China100191 Location 2:CTTL(Shouxiang) Address: No. 51 Shouxiang Science Building, Xueyuan Road, Haidian District, Beijing, P. R. China100191 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -10/+55°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2015-05-7 Testing End Date: 2015-05-14 1.4. Signature Xu Zhongfei (Prepared this test report) Li Zhibin (Reviewed this test report) Lv Songdong (Approvedthis test report) No. I15Z40923-SRD05 Page5 of 90 ©Copyright. All rights reserved by CTTL. 2. Client Information 2.1…

Text truncated - open the document above for the full version.

FDD ID RAD550 Conducted emission RE Radiated Spurious Emission
