Cli matouch /CT03TS/217S31 Programmable Universal Touch Screen thermostat • Fully configurable 1-4 stages heat/ cool • Can be configured for heatpumps , air handlers , oil, gas electric furnaces in any combination • Backlit display with “Night Reverse” • Auto change over • Ultra friendly throw away this manual • Permanent memory no batteries required • Relay outputs provide reliable operation • Suitable for Residential / Commercial • Outdoor wireless Temperature sensor optional Specifications Electrical Rating: 24volt AC 1 amp maximum per terminal 4 amp maximum total load Temperature Control Ranges Accuracy +/- 1ºF 41ºF- 95ºF , adjustable dead band and differential System Configurations: 2 stage heat, 2 stage cool , heat pump , air handler , gas , oil, electric in any combination whatsoever (totally universal) Terminations I1-I2-Dh-H Future expansion C-Y2-R–Ob-W2-G-Y1 Safety Information: Always turn off power at the main power supply before installing or removing thermostat. • This product is for 24 VAC operation only • All wiring must conform to local and national electrical and building codes. FCC Statement NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT FCC ID: RAN217S31 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Installation Replacement Turn off power at the main service panel before proceeding . Remove the cover of the old thermostat . Loosen the screws holding the old thermostat base . Carefully disconnect the wires from the old thermostat make sure that you write down the connection label of each wire. This will simplify installation of your new thermostat. If the terminal designations on your old thermostat do not match those of your old thermostat please refer to the list below. Table 1. Terminal Designations on Old and New Thermostats C may not be used on all systems O/B is used if your system is a heat pump Configuration The configuration mode is used to setup your Climatouch thermostat to match the exact profile of your HVAC system . It can be configured as a single stage furnace thermostat right up to a 4 stage (2 heat 2 cool ) controller . Alternative Terminal Designations 217S31/ CT03TS Typical Terminal Designations from the Existing Thermostat Trane American Standard Lennox York Borg Warner General Electric Rheem Ruud Function Description C C C or X C B X B Common R R R R R V or VR b R R R Power Y1 Y or Y1 Y or Y1 Y or Y1 Y M Y Y Y or Y1 Compressor - - - - - - - - Stage 1 heating relay W2 W or W1 W,W1 or W2 W or W1 W or W1 jumped to U W1 or Y W or W2 W or W1 W2 Auxiliary heat relay G G G G G F or G G G G Fan Relay OB O a O a O a O a R or O a O a O a O a Cooling changeover relay B a B a B a - - H - - Heating changeover relay L L or X L F or L L F F or L L System monitor Y2 E E E or X X2 or E E X or E E or X2 E Emergency heat relay See configuration section To enter the configuration mode Touch the center of the Climatouch screen , this will bring you to the main control page . Touch “MENU” , this will take you to the main menu page . Press and hold for 5 seconds the “ADVANCED SETTINGS” button. All installation and configurations are made through the “ADVANCED SETTINGS “ menu. The following parameters should be set up , since the CT03TS/217S31 is the most user friendly , setup and configuration are very simple . * Installer Message: Up to a 42 character message can be entered here and set to display on your CT03TS/217S31 Climatouch thermostat at programmed intervals . Simply enter your message, when finished press “OK” and set the number of months for this message to repeatedly display . An example of a message is “ Call for maintenance 555-555-5555” for example if set for 6 months this message will display every 6 months on the main scree n . The message will disappea r when the CT03TS/217S31 screen is touched. *Filter : Turning on this function and setting the number of days will cause a filter icon to display after the fan run time has exceeded the entered number of days . Energy Watch: Entering in the KW ratings of your HVAC installation will allow the user to monitor the energy cost of the HVAC system . Simply enter in the compressor KW , the furnace KW if you are using an electric furnace and the fan KW rating . All KW ratings should be rounded for example if your fan is a 750w unit set to 1 KW . Min Diff: Heat and cool set points will never come closer then the value set . Dead Band : This is the area where there will be no demand for heating or air conditioning for example if the heat is set for 72ºF and the dead band is 2 then the heat will turn on when the room temperature reaches 70ºF . HVAC System Configuration In “advanced settings” menu there are two buttons used to tailor your Climatouch thermostat to function with your specific heating/cooling system. The correct setting influences the type of control buttons available to the user. For example if you configure your CT03TS/217S31 for heat only there will be no display of a cool button. The advanced touch screen and display icons provide the most user friendly thermostat interface in the world. “HEAT PUMP” “AIR CONDITIONING” “NO COMPRESSOR” :used for furnace only installations “FURNACE OFF” “ELECTRIC FURNACE” “EMERGENCY ELECTRIC FURNACE” SETS Y2 TO CONTROL AN ADDITIONAL HEATER ELEMENT (used in northern installations) “GAS FURNACE” fan is controlled by the operation of the furnace “OIL FURNACE” fan is controlled by the operation of the furnace Owners Information Your Climatouch CT03TS/217S31 has bee n engineered to the highest elec tronic and logica l standards . We have taken great pain to make the operation of this Climatouch…
Text truncated - open the document above for the full version.
AED Electronics Inc. Tel: (514) 737-9332 5756 Royalmount Avenue Fax: (514) 737-0922 Montreal, Quebec H4P 1K5 Canada July 25, 2003 FCC Communications Commission Authorization and Evaluation Division Confidentiality Request Regarding Application for Certification of FCC ID #RAN217S31 Pursuant to Sections 0.457 and 0.459 of the Commision’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Operational Description. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Howard Rosen, President AED Electronics Inc.
AED Electronics Inc. Model 217S31 FCC ID:RAN217S31
APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 REPORT #: A/AED_\801ZUT3\801ZUT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 TEST REPORT CONTAINING: PAGE 1-4...........TEST EQUIPMENT LIST PAGE 5.............TEST PROCEDURE PAGE 6-7...........RADIATION INTERFERENCE TEST DATA PAGE 8.............CALCULATION OF DUTY CYCLE PAGE 9-11..........DUTY CYCLE PLOTS – COMPLETE PULSE TRAIN PAGE 12............OCCUPIED BANDWIDTH PAGE 13............OCCUPIED BANDWIDTH PLOT EXHIBIT ATTACHMENTS: EXHIBIT 1...........BLOCK DIAGRAM EXHIBIT 2...........SCHEMATIC EXHIBIT 3...........INSTRUCTION MANUAL EXHIBIT 4...........LABEL SAMPLE EXHIBIT 5...........ID LABEL LOCATION EXHIBIT 6...........EXTERNAL PHOTOGRAPHS EXHIBIT 7...........INTERNAL PHOTOGRAPHS EXHIBIT 8...........TEST SET UP PHOTOGRAPHS EXHIBIT 9...........CIRCUIT DESCRIPTION APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 REPORT #: A/AED_\801ZUT3\801ZUT3TestReport.doc Page 1 of 13 EMC Equipment List Last Update: 6/27/03 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter HP 85650A 3303A01690 CAL 8/31/01 8/31/03 Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/03 Receiver, Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 RF Preselector HP 85685A 2926A00983 CAL 4/15/03 4/15/05 Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Receiver, Silver/Grey Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/14/02 10/14/04 RF Preselector HP 85685A 2620A00294 CAL 10/14/02 10/14/04 Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/14/02 10/14/04 Preamplifier HP 8449B 3008A01075 CHAR 1/28/02 1/28/04 Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 BiconiLog Antenna EMCO 3143 9409-1043 Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CAL 3/4/03 3/4/05 APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 REPORT #: A/AED_\801ZUT3\801ZUT3TestReport.doc Page 2 of 13 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Log-Periodic Antenna Eaton 96005 1243 CAL 5/8/03 5/8/05 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CAL 9/26/02 9/26/05 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 2/17/03 2/17/05 Horn Antenna *(at 3 meters) Electro-Metrics EM-6961 6246 CAL 3/31/03 3/31/05 Horn Antenna *(at 10 meters) Electro-Metrics EM-6961 6246 CAL 6/4/03 6/4/05 Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M08HW/A F30425-1 CHAR 4/25/03 4/25/05 Harmonic Mixer with Horn Antenna Oleson Microwave Labs M12HW/A E30425-1 CHAR 4/25/03 4/25/05 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CHAR 12/12/01 12/12/03 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/03 System One Audio Precision System One SYS1-45868 CHAR 4/25/02 4/25/04 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CHAR 9/26/01 9/26/03 APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 REPORT #: A/AED_\801ZUT3\801ZUT3TestReport.doc Page 3 of 13 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/03 Power Meter HP 432A 1141A07655 CAL 4/15/03 4/15/05 Power Meter And Sensor Bird 4421-107 4022 0166 0218 CAL 4/16/03 4/16/05 Power Sensor HP 478A 72129 CAL 4/15/03 4/15/05 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 Hygro-Thermometer Extech 445703 0602 CAL 10/4/02 10/4/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Frequency Counter HP 5385A 2730A03025 CAL 3/7/03 3/7/05 Power Sensor Agilent Technologies 84811A 2551A02705 CHAR 1/26/01 1/26/03 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 2/15/02 2/15/04 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Modulation Meter Boonton 8220 10901AB CAL 4/15/03 4/15/05 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 5BR4-10525/ 900-S Z1 CHAR 3/2/01 3/2/03 Notch Filter Lorch Microwave 5BRX-850/ X100-N AD-1 CHAR 4/17/03 4/17/05 High Pass Filter Unk 3768(5)-400 041 CHAR 12/17/02 12/17/04 APPLICANT: AED ELECTRONICS INC. FCC ID: RAN217S31 REPORT #: A/AED_\801ZUT3\801ZUT3TestReport.doc Page 4 of 13 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS High Pass Filter Microl…
