RAXWN8522D8CP

Arcadyan Technology Corporation

Dual Band WLAN Adapter

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Feb 15, 2011
Application Purpose: Original Equipment
Date of Application: Feb 15, 2011
Equipment Note: Dual Band WLAN Adapter
Frequency Range: 5510.00000000 - 5670.00000000
Company: Arcadyan Technology Corporation
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
6	15E	5.51 GHz - 5.67 GHz	114.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Power listed is the maximum combined conducted peak output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190-5230, 5270-5310 and 5510-5670 MHz respectively. Operating of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only.
