RB8A2WMiracast Dongle

Measy Electronics Co., Ltd.
Miracast Dongle - FCC ID RB8A2W - Measy Electronics Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Feb 26, 2014
Application Purpose
Original Equipment
Date of Application
Feb 26, 2014
Equipment Note
Miracast Dongle
Frequency Range
2412.00000000 - 2462.00000000
Company
Measy Electronics Co., Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

A2W Wireless Miracast TV Dongle User Manual I. Product instruction A2W is a powerful home-multimedia-sharing slides dongle. Through a wireless connection, you can switch the complete screen of the smart mobile phone, tablet, PC perfectly to the big HDTV screen, to achieve the best multi-screen interactive function. A2W can cast all photos, music, movies and 3D somatosensory from your smart mobile phone onto HDTV. II. Product operation instruction Booting interface, you can get the information from the interface. 1. The name of the wireless LAN: EZCAST-6AOC. Password: 253014, the IP address of the device: 192.168.111.2. 2. The download addresses of the Windows/Mac OS http://www.iezvu.com/download. 3. The download address of the iPhone or iPad.You can take the two-dimensional code recognition to enter the download address, or open the app store, search EZCast to download and install. 4. The download address of the Android: you can take the two-dimensional code recognition to enter the download address, or open the Google player, search EZCast to download and install. III. Download and install For example: Mac OS user to download: Please according to the information which supplied by the boot interface, you can download the Mac OS EZCast from http://www.iezvu.com/download Install Double click the installed program, according to the showing, click “Next” Download: Installing: Go on installing After installed the EZCast, it will prompts that need to install The Soundflower, which is necessary Because while the EZCast projecting, it will also spread the sound of the Mac onto the large TV screen. So you also need to install Soundflower. You also can go on click “next” to install After install, you need to reboot the Mac PC. After reboot, you will find the EZCast from the application files .You will find the EZCast application program after you enter it. IV. Starting of the EZCast and the function instructions The EZCast EZCast will determine if the Mac computer have connected the wireless LAV of the dongle or not. So if you want to run the EZCast, you must connect it with EZCast –xxxxxxxx wireless LAN After connected the wireless LAN, you will find there are four functions. You can press” ON” to turn on each one ① EZCast Click “ON”, you can turn on the EZCast function, means you can cast your Mac PC screen onto the big TV screen. Application instruction Visit Help Page: Click “Link” will connect to www.iezvu.com/help/EZ Cast/MacOS/help.html, You will find all the content showed on the page. Mode: divided into the Graphic and the Video two modes .Graphic is a static displayer mode. You can select them when you need to display some static contents. Video mode is a dynamic display model. It is mainly for videos playing via Mac PC, and then spread to the big TV screen to achieve the best display effect. Display: mainly are Mirror and Extension, Mirror model is mirrored projection: E.g. The screen of the Mac PC projecting onto TV completely. Extension model also called extended projection, meaning you make the big TV screen as a second screen of the Mac PC ② DLNA function Click “ON “to turn it on, you can search the EZCast-xxxxxxx DMR from DMC, then you can share the pictures, music and videos on the TV screen. Please refer to www.iezvu.com/help/MacOS/DLNA/help.html ③ EZAir function Click “ON”, turn on the EZAir function, now you can share your pictures, music and videos on the big TV screen through your Apple device (iPhone/iPad) ④ .Setting It mainly be used for setting the resolution, upgrading online and others of the dongle by Mac PC .Same as the remote control function: left, right, up, down, confirm and back key. And you also can input the password via the PC. V. Specification Miracast TV dongle Model A2W CPU AM8251 Memory DDR3 128M Flash Nand flash 1G Power consumption Main unit ≤ 400mA@5V OS Linux DLNA Airplay EZcast Support protocol Miracast Wi-Fi IEEE 802.11 b/g/n (Built-in Realtek 8188EUS WiFi Module) Audio MP3/WMA/WAV/OGG/AAC/FLAC/3GP... Video MP4/MKV/AVI/RM/RMVB/MOV/TS/MPEG(MPG)... Media format Photo JPEG/JPG/BMP/PNG/GIF/TIFF... Android Android4.0 or higher IOS IOS6 or higher Mac Mac10.7 Support OS Windows WinXP/7/8 Size 87.21mmX 32.21mmX 12.18mm Brand : MEASY Website : www.measy.com.cn FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. FCC Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance …

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Measy Electronics Co., Ltd. 2014-2-17 To: SIEMIC, INC. 775 Montague Expressway Milpitas, CA 95035 Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Measy Electronics Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Miracast Dongle model name: A2W FCC ID: RB8A2W We affirm that between SIEMIC and Measy Electronics Co., Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, (signture) Jack Gao/ Manager Tel: +86-755-23981801 Fax: +86-755-23981800 E-mail: [email protected] Measy Electronics Co., Ltd. Rm1506, Block B, Hai Song Building, Tai Ran 9th Road, Che Gong Miao, Shen Zhen, China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Measy Electronics Co., Ltd. 2014-2-17 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RB8A2W We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (signture) Jack Gao/ Manager Tel: +86-755-23981801 Fax: +86-755-23981800 E-mail: [email protected] Measy Electronics Co., Ltd. Rm1506, Block B, Hai Song Building, Tai Ran 9th Road, Che Gong Miao, Shen Zhen, China

Cover Letter(s)

Mesay Electronics Co., Ltd. Date: 2014-2-17 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: RB8A2W To Whom It May Concern: This letter is to ascertain that Mesay Electronics Co., Ltd. Product Miracast Dongle has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, (signture) Jack Gao/ Manager Tel: +86-755-23981801 Fax: +86-755-23981800 E-mail: [email protected] Measy Electronics Co., Ltd. Rm1506, Block B, Hai Song Building, Tai Ran 9th Road, Che Gong Miao, Shen Zhen, China

External Photos

Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F

ID Label/Location Info

Label Label Location

Internal Photos

Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F WIFI Module Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F

RF Exposure Info

Dongguan NTC Co., Ltd. FCC ID: RB8A2W Report No.: NTC1401120F RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) FCC ID: RBA2W EUT Specification EUT Miracast Dongle Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 2.402GHz ~ 2.480GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 19.04dBm(80.17mW) Antenna gain 0dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Dongguan NTC Co., Ltd. FCC ID: RB8A2W Report No.: NTC1401120F Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale ; Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b Lowest 2412 26.36 0 0.005244143 1 Middle 2437 23.88 0 0.004750764 1 Highest 2462 20.75 0 0.004128072 1 802.11g Lowest 2412 80.17 0 0.015949277 1 Middle 2437 70.63 0 0.014051359 1 Highest 2462 62.23 0 0.012380236 1 802.11n( HT20) Lowest 2412 59.70 0 0.001187691 1 Middle 2437 50.00 0 0.009947161 1 Highest 2462 44.16 0 0.008785332 1

Test Report

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1401120F FCC ID: RB8A2W Page 2 of 58 Table of Contents 1. GENERAL INFORMATION ................................................................................................ 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST.................................................................... 4 1.2 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................ 6 1.3 TEST METHODOLOGY....................................................................................................................... 6 1.4 EQUIPMENT MODIFICATIONS............................................................................................................ 6 1.5 SUPPORT DEVICE............................................................................................................................ 6 1.6 TEST FACILITY AND LOCATION.......................................................................................................... 7 1.7 SUMMARY OF TEST RESULTS........................................................................................................... 7 2. SYSTEM TEST CONFIGURATION.................................................................................... 8 2.1 EUT CONFIGURATION...................................................................................................................... 8 2.2 SPECIAL ACCESSORIES.................................................................................................................... 8 2.3 DESCRIPTION OF TEST MODES......................................................................................................... 8 2.4 EUT EXERCISE................................................................................................................................8 3. CONDUCTED EMISSIONS TEST ...................................................................................... 9 3.1 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)..................................................................... 9 3.2 TEST CONDITION............................................................................................................................. 9 3.3 MEASUREMENT RESULTS................................................................................................................. 9 4. MAX. CONDUCTED OUTPUT POWER........................................................................... 12 4.1 MEASUREMENT PROCEDURE......................................................................................................... 12 4.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)................................................................... 12 4.3 MEASUREMENT RESULTS............................................................................................................... 12 5. 6DB BANDWIDTH............................................................................................................ 17 5.1 MEASUREMENT PROCEDURE......................................................................................................... 17 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)................................................................... 17 5.3 MEASUREMENT RESULTS............................................................................................................... 17 6. POWER SPECTRAL DENSITY ....................................................................................... 24 6.1 MEASUREMENT PROCEDURE......................................................................................................... 24 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)................................................................... 24 6.3 MEASUREMENT RESULTS............................................................................................................... 24 7. BAND EDGE AND CONDUCTED SPURIOUS EMISSIONS ........................................... 31 7.1 REQUIREMENT AND MEASUREMENT PROCEDURE........................................................................... 31 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)................................................................... 31 7.3 MEASUREMENT RESULTS............................................................................................................... 31 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1401120F FCC ID: RB8A2W Page 3 of 58 8. RADIATED SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................ 44 8.1 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)................................................................... 44 8.2 MEASUREMENT PROCEDURE......................................................................................................... 45 8.3 LIMIT.............................................................................................................................................. 46 8.4 MEASUREMENT RESULTS ..................................................................................................... 47 9. ANTENNA APPLICATION ............................................................................................... 57 9.1 ANTENNA REQUIREMENT................................................................................................................ 57 9.2 MEASUREMENT RESULTS............................................................................................................... 57 10. TEST EQUIPMENT LIST................................................................................................ 58 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1401120F FCC ID: RB8A2W Page 4 of 58 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test The EUT is a miracast dongle with WIFI functions which is powered by DC 5V come from mini USB port. For more details features, please refer to User’s Manual. Manufacturer : Measy Electronics Co., Ltd. Address : …

Text truncated - open the document above for the full version.

Test Setup Photos

Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F Conducted Emission Dongguan NTC CO., LTD. FCC ID: RB8A2W Report No.: NTC1401120F Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz)

Contact Information

Applicant

Jack Gao(Manager)
[email protected]+86-755-23981801Fax: +86-755-23981800

Test Firm

Dongguan NTC Co.,Ltd.,sunm lv sunm lv
[email protected]86-769-22022444

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz80.17 mW
Confidentiality
Long Term
Grant Notes
Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
