Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 U1A Userβs Manual INDEX Declaration..........................................................3 A. Appearance Introduction...............................4 B. Initial Operation.............................................5 1. HARDWARE CONNECTING INSTRUCTION ....................4 2. OS INTERFACE....................................................................5 3. MANAGEMENT SOFTWARE ICON..................................... 6 4. DELETE ICON ......................................................................6 5. DRAG TO THE DESKTOP ................................................... 7 6. RETURN,HOMEPAGE,PROGRAM, PROPERTIES .......... 8 7. STATUS BAR ........................................................................8 8. PROGRAMME TOOL BUTTOM............................................9 C. Programmer, Tools Icon Management...............9 D. Setting .................................................................11 1. WIFI SETTING .........................................................................11 2. USB TO RJ45 LAN ADAPTER SETTING ................................. 12 E. Install/delete APK (Program) .............................12 1. Unknown Source APK (Program) Set Up ..............................12 2. INSTALL APK (PROGRAM) ......................................................13 3. DELETE APK (PROGRAM) ................................................13 F. Picture, Video, Filing Management, Webpage.....14 1. SET UP MEDIA FILE SEARCHING FUNCTION......................14 2. HOW TO PLAY HIGH DEFINITION MEDIA PLAYER .............. 15 3. FILEING MANAGEMENT. COPY, CUT, DELETE, RENAME ....15 4. MUSIC PLAYER.................................................................17 5. VISIT THE WEBSITE................................................................7 G. Language and Input....... ..................................17 1. SELECT LANGUAGE AND USUAL INPUT METHOD...............17 2. KEYBOARD AND MOUSE.........................................................18 3. SWITCH INPUT METHOD.................................................19 H. Question& Answer................................................20 I. Specifications.........................................................21 2 Declaration z The user manual includes all the information of safe and correct operation instruction. To avoid accident and product damaged, please make sure go through all the content carefully before using the product. z Please keep the product away from high temperature, humid and dusty environment. z Do not drop or crash the product. z Do not cut off power of the device when it is formatting or upgrading. Otherwise it will cause operation system error. z Do not dismantle the device. Do not clean it by alcohol, thinner and Benzene. 1. We keep the right to upgrade and modify the product. 2. Disclaimer: We only take the responsibility to provide the product warranty and after service. The users have to take care of their data in the device by themselves. We do not responsible for any data lost or related lost. 3. The product is not water-proof. 4. All the pictures in the instruction are just for reference. A. Appearance Introduction Left side panel 3 Right side panel Bottom side A: HDMI Jack-connect to HD TV set HDMI Host; B: DC-IN Jack-5V/500mA~2A; C: USB Host-play movies, pictures and music in USB Disk and USB portable HD, connect Air Mouse; D: USB OTG Host-connect PC USB host through USB cable While use U1A as a USB disk, copy data from each device; E: Factory Default key-when electrifying your U1A, press this Key 10 seconds, then release the button. F: TF Card Slot-Play Media file in TF (micro SD); G: LED-light state-the LED keep lighting when U1A was electrified. B. Initial operation Connection instruction for Hardware 1. Connect to the TV set or LCD monitor .Set up the TV data receive mode to HDMI port , (Refer to TV set user manual) 2. Suggest using Air mouse or 2.4G wireless mouse and keyboard. Plug 2.4G receiver on USB Host connector. Or Plug on USB OTG port by port converter. If only mouse plugged, the device will provide soft keyboard in operation system. If the device detected the physical keyboard, the soft keyboard will be 4 hiding by OS automatically. 3. Mouse left button for "OK", right button for *return", rolling for page up and down. Hold left button to pull icon or copy & paste file. Hold middle button for Properties. 1. OS interface Connect power supply and devices, the booting information will show up within 1min. 2. Management Software Icon Hold any icon and pull it could move it to any position you like 3. Delete Icon Hold the icon and throw it into the red mark "X"- it will be removed 5 4. Drag to the desktop Hold the arrow on any blanket space of the desktop, move it to left or right could move to next desktop. Rolling the mouse is same operation. 5. Return, Homepage, program, properties Return button: click to return to the upper level directory Homepage button: Click it anytime to return to homepage Program button: Click to check the entire running program Properties button: Click it will show up different in different software. It is similar functions with Windows properties button 6. Status bar The right bottom comer is status bar. It shows the status of T-Flash Card, USB connection. Time. WiFi and Download ...and so on. Click status bar, the hide menu will bound up 6 Click this icon . it will be show up more options 7. Program Tool button It shows up right top comer of desktop C. Program, Tools icon management 9 Click to show up all the installed program and setup tools icon 9 If the first desktop page files with icon, then pull or rolling mouse move it to second desktop page. 9 You could launch these programs or set up directly, or hold this and throw them to desktop to make shortcut. 9 Click it then hold any button to make shortcut on desktop 7 D. Setting It is in Tool bar. Click to show it up. 1. Wi-Fi Setting 2. USB to RJ45 LAN adapter setting If there is no Wi-Fi andβ¦
Text truncated - open the document above for the full version.
Mesay Electronics Co., Ltd. Date: 2012-11-26 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: RB8U1A To Whom It May Concern: This letter is to ascertain that Mesay Electronics Co., Ltd. Product Android TV Dongle has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, (signture) Jack Gao/ Manager Tel: +86-755-23981801 Fax: +86-755-23981800 E-mail: [email protected] Measy Electronics Co., Ltd. Rm1506, Block B, Hai Song Building, Tai Ran 9th Road, Che Gong Miao, Shen Zhen, China
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Septβ25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012
SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August β 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012
Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F
Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F Lable Lable Location
Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F WIFI Chip Antenna
Dongguan NTC Co., Ltd. FCC ID: RB8U1A Report No.: NTC12111015 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in Β§1.1307(b) FCC ID: RB8U1A EUT Specification EUT Android TV Dongle Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 17.95dBm (62.37mW) Antenna gain -2.5 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Dongguan NTC Co., Ltd. FCC ID: RB8U1A Report No.: NTC12111015 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale ; Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b Lowest 2412 29.31 -2.5 0.003279 1 Middle 2437 35.73 -2.5 0.003997 1 Highest 2462 41.30 -2.5 0.004620 1 802.11g Lowest 2412 32.58 -2.5 0.003645 1 Middle 2437 40.09 -2.5 0.004850 1 Highest 2462 46.77 -2.5 0.005232 1 802.11n( HT20) Lowest 2412 46.56 -2.5 0.005209 1 Middle 2437 54.70 -2.5 0.006120 1 Highest 2462 62.37 -2.5 0.006978 1 802.11n( HT40) Lowest 2422 49.55 -2.5 0.005543 1 Middle 2437 55.08 -2.5 0.006162 1 Highest 2452 59.98 -2.5 0.006710 1 Sincerely, (signture) Jack Gao/ Manager Tel: +86-755-23981801 Fax: +86-755-23981800 E-mail: [email protected]
DONGGUAN NTC CO., LTD. Report No.: NTC12111015F FCC ID: RB8U1A Page 1 of 76 FCC PART 15 SUBPART C MEASURMENT AND TEST REPORT For Measy Electronics Co., Ltd. Rm1506, Block B, Hai Song Building, Tai Ran 9th Road, Che Gong Miao, Shenzhen, China E.U.T.: Android TV Dongle Model Name: U1A Trade name: Measy FCC ID: RB8U1A Report Number: NTC12111015F Test Date(s): November 06, 2012 to November 24, 2012 Report Date(s): November 26, 2012 Prepared by Dongguan NTC Co., Ltd. Building D, Gaosheng Science and Technology Park, Hongtu Road, Nancheng District, Dongguan City, Guangdong Province, China Tel: +86-769-22022444 Fax: +86-769-22022799 Prepared By Approved & Authorized Signer Rose Hu / Engineer Sunm Lv / Q.A. Director Note: This test report is for the customer shown above and their specific product only. It may not be duplicated or used in part without prior written consent from Dongguan NTC Co., Ltd. The test results referenced from this report are relevant only to the sample tested. DONGGUAN NTC CO., LTD. Report No.: NTC12111015F FCC ID: RB8U1A Page 2 of 76 Table of Contents 1. GENERAL INFORMATION ................................................................................................ 4 1.1 P RODUCT D ESCRIPTION FOR E QUIPMENT UNDER T EST .................................................................... 4 1.2 R ELATED S UBMITTAL ( S ) / G RANT ( S ) ................................................................................................ 6 1.3 T EST M ETHODOLOGY ....................................................................................................................... 6 1.4 E QUIPMENT M ODIFICATIONS ............................................................................................................ 6 1.5 S UPPORT D EVICE ............................................................................................................................ 6 1.6 T EST F ACILITY AND L OCATION .......................................................................................................... 7 1.7 S UMMARY OF T EST R ESULTS ........................................................................................................... 7 2. SYSTEM TEST CONFIGURATION.................................................................................... 8 2.1 EUT C ONFIGURATION ...................................................................................................................... 8 2.2 S PECIAL A CCESSORIES .................................................................................................................... 8 2.3 D ESCRIPTION OF TEST MODES ......................................................................................................... 8 2.4 EUT E XERCISE ................................................................................................................................8 3. CONDUCTED EMISSIONS TEST ...................................................................................... 9 3.1 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )..................................................................... 9 3.2 T EST C ONDITION ............................................................................................................................. 9 3.3 M EASUREMENT R ESULTS ................................................................................................................. 9 4. MAX. CONDUCTED OUTPUT POWER........................................................................... 12 4.1 M EASUREMENT P ROCEDURE ......................................................................................................... 12 4.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 12 4.3 M EASUREMENT R ESULTS ............................................................................................................... 12 5. 6DB BANDWIDTH............................................................................................................ 28 5.1 M EASUREMENT P ROCEDURE ......................................................................................................... 28 5.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 28 5.3 M EASUREMENT R ESULTS ............................................................................................................... 28 6. POWER SPECTRAL DENSITY ....................................................................................... 36 6.1 M EASUREMENT P ROCEDURE ......................................................................................................... 36 6.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 36 6.3 M EASUREMENT R ESULTS ............................................................................................................... 36 7. BAND EDGE AND CONDUCTED SPURIOUS EMISSIONS ........................................... 44 7.1 R EQUIREMENT AND M EASUREMENT P ROCEDURE ........................................................................... 44 7.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 44 7.3 M EASUREMENT R ESULTS ............................................................................................................... 44 DONGGUAN NTC CO., LTD. Report No.: NTC12111015F FCC ID: RB8U1A Page 3 of 76 8. RADIATED SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................ 55 8.1 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION )................................................................... 55 8.2 M EASUREMENT P ROCEDURE ......................................................................................................... 56 8.3 L IMIT ..........................................................................................................β¦
Text truncated - open the document above for the full version.
Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F Conducted Emission Dongguan NTC CO., LTD. FCC ID: RB8U1A Report No.: NTC12111015F Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz)
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 62.37 mW |

USB Dongle
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Air mouse
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Miracast Dongle
Equipment Class
DTS - Digital Transmission System
Android TV Box
Equipment Class
DTS - Digital Transmission System
Air Mouse
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
