RBP-RD52Boha Handheld Scanner

1 Boha Handheld Scanner RD52 User Manual 2 Thank you for your choosing Boha Handheld Scanner. This guide serves to enable users to get to know and familiar with our product as soon as possible. Here we have made a brief introduction to the key layout and definitions in figures and words. Attention：  This user guide is based on Android edition  This user guide is an introduction for full function Handheld Scanner.  This user guider applies to the following models: RD52  The illustrations in this manual may differ from the actual product.  Operating Temperature：-10°C~45°C 3 Contents I. Use of the previous note ..................................................................................... 3 II. Key Layout and Definitions ......................................................................... 4~6 III. Introduction to Desktop ..................................................................................... 7 1. opening interface ........................................................................................................ 7 2. Into the desktop, as shown in the following figure ........................................................... 8 3．Enter the menu interface ............................................................................................ 9 4．System settings ....................................................................................................... 10 IV.FCC Warning words...................................................................................... ......................11 I. Use of the previous note 1. With the wrong type of battery replacement will be explosive danger, be sure to use 4 the original battery. 2. The company shall not take any responsibility for the loss or removal of the information in the Handheld Scanner, which is caused by the operation, maintenance or other accidents of the non-normal operation of the software and hardware. 3. Please backup your important information at any time. 4. Please do not disassemble the Handheld Scanner; otherwise it will lose the right to guarantee. 5.Adapter description:INPUT: 100-240V~50/60Hz 0.4A OUTPUT:5V DC 2A II. Key Layout and Definitions 5 ○ 1LCD/ Touch screen : LCD display and Touch screen. ○ 2VOL button : Sound volume. ○ 3Charging interface: Charging the tablet via DC adapter/Micro USB 2.0/Micro USB 2.0 to OTG ○ 4Earphone Jack: The jack support outputs the audio signal to a loudspeaker. ○ 5POGO PIN : Link adaptable charging base. ○ 6/ ○ 7/ ○ 8/ ○ 9Interface operation button : Back/Camera/Menu/Home button. ○ 10/ ○ 15:Scavenging key / custom function keys : Scavenging key. ○ 11Front camera:Camera, video . ○ 12Light sensor：Perception of external pipeline strength, electrical signal to CPU. 6 ○ 13Indication LED:Boot charge indication ○ 14Scan Head :Scanning the light of one bit code / two dimensional code from here, pointing the light at one bit code / two dimensional code, will display the scanning content in the APP. ○ 16Power button:To start or close touch screen panel. You can also let the computer to sleep or wake up from hibernation mode. ○ 17Rear camera: Camera, video. ○ 18Rear camera flash : Provide light when photographing at night. ○ 19Speaker: Built-in speaker, so you can hear the sound without additional link equipment. ○ 20Battery：Removable lithium ion polymer battery. ○ 21NFC：NFC ANT ○ 22MIC：Recording sensor. 7 III. Introduction to Desktop 1. opening interface： If there is a lock screen interface in the next figure, please unlock the slide lock icon. 8 2.Into the desktop, as shown in the following figure: 9 3.Enter the menu interface: 10 4.System settings: System functions, please refer to the official Android 7 system. 11 Boha Handheld Scanner Model Number: RD52 FCC ID: Made In China This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This Mobile Phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: RD52 (FCC ID: RBP-RD52) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.215W/kg and when properly worn on the body is 0.623W/kg. This device was tested for typical body-worn operations with the back of …

Text truncated - open the document above for the full version.

TransAct Technologies Incorporatedc AgentAuthorization Company:TransAct Technologies Incorporated Addres s:2319 Whitney Avenue, Suite 3B Hamden, Connecticut 06518-3509, United States. ProductName:BohaHandheldScanner ModelNumber(s):RD52,BOHA! Handheld2 Pr oductDescription:BohaHandheldScanner We authorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA , toa ctonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. We declarethatMiCOMLabs Inc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregul atoryagenciesasrequiredandto di scussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesame effectasactsofourown. Signature:Date: 01/03/2020 Name: Donal dBrooks Title:ExecutiveVicePresident-Engineering Company: TransAct Technologies Incorporatedc

TransAct Technologies Incorporated Familymodelsdifferencedeclaration BohaHandheldScanner Model:RD52,BOHA!Handheld2 Differencedeclaration: AllmodelsarethesamecircuitandRFmodule, exceptthedifferentmodelsselltodifferentcustomers. Regards, Signature Name:DonaldBrooksDate:2020-01-03

Date:2020/01/03 < TransAct Technologies Incorporated > OfficeofEngineeringTechnology FederalCommunicationsCommission 74 35OaklandMillsRoad Columbia,MD21046 Subject;RequestforConfidentiality FCC ID:RBP-RD52 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,weare requestingtheCommissiontowithholdthefollowingattachment(s)asconfidentialdocuments frompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram OperationalDescription BOMandturnupprocedure FCC_Software_Security_Requirements_for_UNII_devices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulationsin Title47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:DonaldBrooks Title:ExecutiveVicePresident-Engineering

TransAct Technologies Incorporated Date: Nov. 12, 2019 FCC ID: RBP-RD52 Model Number: RD52, BOHA! Handheld 2 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, TransAct Technologies Inc declare that this EUT (FCC ID: RBP-RD52) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China) Please contact me if you have any question. Sincerely, (Signed) Name / Title: Donald Brooks / Executive Vice President - Engineering Company: TransAct Technologies Inc Address: 2319 Whitney Avenue, Suite 3B Hamden, CT 06518-3509

S19111503202 Model: RD52 N20190309V1 ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 S19111503202 Model: RD52 N20190309V1 Photo 3 Photo 4 S19111503202 Model: RD52 N20190309V1 Photo 5 Photo 6 S19111503202 Model: RD52 N20190309V1 Photo 7 Photo 8 S19111503202 Model: RD52 N20190309V1 Photo 9 Photo 10

33.46 mm Input: 5V 2A Boha Handheld Scanner Model No. : RD52 (This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interfere nce received, including interference that may case undesired operation. Made in China FCC ID:RBP-RD52 label location

S19111503202 Model: RD52 N20190309V1 ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 S19111503202 Model: RD52 N20190309V1 Photo 3 Photo 4 S19111503202 Model: RD52 N20190309V1 Photo 5 Photo 6 S19111503202 Model: RD52 N20190309V1 Photo 7 Photo 8 S19111503202 Model: RD52 N20190309V1 Photo 9 Photo 10 S19111503202 Model: RD52 N20190309V1 Photo 11 Photo 12 S19111503202 Model: RD52 N20190309V1 Photo 13 Photo 14 S19111503202 Model: RD52 N20190309V1 Photo 15 Photo 16 NFC ANT BT/2.4GWiFi /5.2GWiFi /5.8GWiFi ANT LTE Stepped ANT S19111503202 Model: RD52 N20190309V1 Photo 17 LTE Main ANT

Page 1 of 25 Report No.: S19111503202006 FCC RADIO TEST REPORT FCC ID: RBP-RD52 Product： Boha Handheld Scanner Trade Mark： BOHA! Model Name： RD52 Family Model： BOHA! Handheld 2 Report No.： S19111503202006 Prepared for TransAct Technologies Incorporated 2319 Whitney Avenue, Suite 3B Hamden, Connecticut 06518-3509, United States. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District Shenzhen, Guangdong, China Tel.: +86-755-6115 9388 Fax.: +86-755-6115 6599 Website:http://www.ntek.org.cn Page 2 of 25 Report No.: STR190610001007E ` TEST RESULT CERTIFICATION Applicant’s name ................. : TransAct Technologies Incorporated Address ................................. : 2319 Whitney Avenue, Suite 3B Hamden, Connecticut 06518-3509, United States. Manufacturer's Name .......... : TransAct Technologies Incorporated Address ................................. : 2319 Whitney Avenue, Suite 3B Hamden, Connecticut 06518-3509, United States. Product description Product name ........................... : Boha Handheld Scanner Model and/or type reference : RD52 Family Model: BOHA! Handheld 2 Standards ............................. : FCC Part15.225 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 19 Nov. 2019 ~ 20 Dec, 2019 Date of Issue ........................................... : 23 Dec, 2019 Test Result ............................................... : Pass Testing Engineer : (Jerry Xie) Technical Manager : (Jason Chen) Authorized Signatory : (Sam Chen) Page 3 of 25 Report No.: STR190610001007E ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . ANTENNA REQUIREMENT 11 3.1 STANDARD REQUIREMENT 11 3.2 EUT ANTENNA 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST CONFIGURATION 12 4.1.3 TEST PROCEDURE 12 4.1.4 TEST RESULT 13 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 TEST PROCEDURE 16 4.2.3 DEVIATION FROM TEST STANDARD 16 4.2.4 TEST SETUP 17 4.2.5 TEST RESULTS (BELOW 30MHZ) 18 4.2.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 20 5 . BANDWIDTH TEST 22 5.1 TEST PROCEDURE 22 5.2 DEVIATION FROM STANDARD 22 5.3 TEST SETUP 22 5.4 TEST RESULTS 23 6. FREQUENCY TOLERANCE 24 Page 4 of 25 Report No.: STR190610001007E ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.225) Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.205(a) 15.209 15.225(abcd) Radiated Spurious Emission Pass 15.225 15.215(c) 20dB Bandwidth Pass 15.225(e) Frequency Tolerance Pass 15.203 Antenna Requirement Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. Page 5 of 25 Report No.: STR190610001007E ` 1.1 TEST FACILITY All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. Site Description CNAS-Lab. : The Laboratory has been assessed and proved to be in compliance with CNAS-CL01:2006 (identical to ISO/IEC 17025:2005) The Certificate Registration Number is L5516. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 A2LA-Lab. The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005 General requirements for the competence of testing and calibration laboratories. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 25 Report No.: STR190610001007E ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Boha Handheld Scanner Trade Mark BOHA! Model Name RD52 Family Model BOHA! Handheld 2 Model Difference All models are the same circuit and RF module, except the different models sell to different customers. Product Description The EUT is a Boha Handheld Scanner Operation Frequency: 13.56MHz Modulation Type: ASK Number Of Channel 1CH. Antenna Designation: Induction coil Adapter Model: AW010WR-0500200UU Input: 100-240V~50/60Hz 0.4A Output: 5V2A Rating DC 3.8V/4000mAh …

Text truncated - open the document above for the full version.

FCC ID: RBP-RD52 Radiated Measurement Photos FCC ID: RBP-RD52 Conducted Measurement Photos
