RBWEMCM51CMobile Computer
Elo Touch Solutions, Inc.
Click to zoom
Application Details
- Equipment Class
- NII - Unlicensed National Information Infrastructure TX
- Date of Grant
- Jan 07, 2025
- Application Purpose
- Original Equipment
- Equipment Note
- Mobile Computer
- Frequency Range
- 5180.00000000 - 5240.00000000
- Company
- Elo Touch Solutions, Inc.
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet1of46 RevAuthorDateDescription 1 11/4/2020Initialdraft 2 Levenliang16/11/2023Firstversion 3 Levenliang19/6/2024Updatemodelandcontent EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet2of46 TableofContents 1.ProductSpecificationOverview............................................................................................................................3 2.SystemBlockDiagram..........................................................................................................................................8 2.1.SystemConnection................................................................................................................................................9 2.2.WiringSchematic................................................................................................................................................10 2.3.CurrentSoftware/FWlist....................................................................................................................................11 2.4.Scaler,EDID,FWProgrammingProcedures.......................................................................................................11 2.5.FWProgramming................................................................................................................ 2.6.EDIDProgramming.............................................................................................................................................19 2.7.OtherCustomProgramming(Payment,Non-Paymentprocedures)..................................................................20 3.MechanicalReplacementPartsList(B.O.M)........................................................................................................20 4.PackagingSpecificationsandPalletLoading........................................................................................................24 5.TroubleShootingGuide.....................................................................................................................................25 6.FunctionTestforafterrepair..............................................................................................................................31 7.Disassembly/AssemblyProcedure.....................................................................................................................35 EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet3of46 1.ProductSpecificationOverview M51MobileComputer: ModelELOP/NDescriptionPartSpecDocument EMC-M51E446755EMC-M51-NS-A14-GMS-8G-12E-G-BK EMC-M51E449855EMC-M51-S-A14-GMS-8G-12E-G-BK EMC-M51CE450425EMC-M51C-NS-A14-GMS-8G-12E-NA-BK EMC-M51CE450619EMC-M51C-S-A14-GMS-8G-12E-NA-BK EMC-M51CE450052EMC-M51C-NS-A14-GMS-8G-12E-EU-BK EMC-M51CE450234EMC-M51C-S-A14-GMS-8G-12E-EU-BK Model EloP/NEloDescription PartSpecDocument AccessoryE534089ELO-KIT-M51-1-DEVICE-DOCK AccessoryE526176ELO-KIT-M51-4-DEVICE-CHARGER AccessoryE526745ELO-KIT-M51-4-AUX-BATTERY-CHARGER AccessoryE533892ELO-KIT-M51-BATTERY-SPARE AccessoryE527331ELO-KIT-M51-SCAN-HANDLE AccessoryE527713ELO-KIT-M51-USBCPTTHEADSET AccessoryE118460 ELO-KIT-M51-HANDSTRAP AccessoryE527515ELO-KIT-M51-LANYARD AccessoryE527141ELO-KIT-M51-HOLSTER AccessoryE525977ELO-KIT-M51-RUBBERBOOT AccessoryE367373 ELO-KIT-M51-1-DEVICE-DOCK-USBC EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet4of46 ID&MDModel ItemizedDescription AirInterface ItemizedDescription TechnicalStandard3GPPR15 Frequency3G/4G/5G WIFIWiFi-2.4G/5G/6E Hardware Description ItemizedDescription PlatformQCM6490/QCS6490 Memory128GB+8GB Battery4500mA OSAndroid14 SIMNano-SIM/e-SIM T-flashMicroSD,upto128GB R-Camera13M,OV13B10-GA5A,AFWithawhite-LED. F-Camera8M,S5K4H7YX03-FGX9,FF Flash-LEDYes TorchlightFlash-LED LED1xPowerLED(Green/Amberdualcolor) EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet5of46 1xStatusLED(Red/Bluedualcolor) TP 5.96''Multi-touch1080*2160 οΌ GGVglass LCM 5.96''1080*12160 450nitstyp./400nitsmin 80degree+/-viewinganglehorizontalandvertical. 16.7Mcolorsminimum. AntennaLDS+FPC Sidekey 2xVOL+/- 1xPPT 2xPFB MainkeyPower TouchKeyMeun/Home/Back VibratorYesοΌβ₯0.5gforce AudioJackNA GPSGPS,GLONASS,GalileoandBeiDou Wifi IEEE802.11a/b/g/n/ac+ IEEE802.11ax/Wi-Fi6E2x2MiMo,DBS BTBT5.2οΌBLE FMNA RTCNA BackupBattery 90mA,0.5CchargeοΌLiPO/SuperCapοΌ20seconds BackupshouldsupportRTC Mic 2xAMIC M51:-44Β±3dB(0dB=1V/Pa,1kHz) EMC-M51/EMC-51C ENGSPEC,SERVICEMANUAL, E446755/E449855/E450425/E450619/E450052/E450234 ESxxxxxRev.A LastPrinted9/10/2024 UNCONTROLLEDCOPYOFARELEASEDDOCUMENTFROMDOCUMENTATIONSERVICES. ~VERIFYLATESTREVISIONLEVELPRIORTOUSE~ Sheet6of46 RecieverEarpiece&speaker1206 Spker 1WRMSStereospeaker 85dbSPLat0.1-meterdistance NFC NXPSN110TfromQualcommAVL ISO14443TypeA/B ISO15693 ISO18092R/W MIFARE Peer-to-peerMode USBinterfaceType-C3.0(QC4.0-3A) Otherinterface 1x2pinPOGOonthebacktofacilitatetriggeringascanner 1x2pinPOGOnearUSBCforcharging(support3Acurrent) HALLNA G-sensorYes,+/-15degreesaccuracy Gyroscope-sensorYes E-compassYes ScannerSE4100 Adapter Input:100-240V~0.5A,50/60Hz Output:5V/3.0A,9V/2.0A,PPS3.3V-5.9V/3.0A,3.3V-11.0V/2.0A Wattage:45WMax,conβ¦
Text truncated - open the document above for the full version.
Test Report
Document No: BL-EC22A0685 Page 1 of 1823 Annex A.4 RMS Power Spectral Density (PSD) Document No: BL-EC22A0685 Page 2 of 1823 Main Antenna 1. 802.11a_20M_U-NII-1_L 1.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 3 of 1823 2. 802.11a_20M_U-NII-1_M 2.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 4 of 1823 3. 802.11a_20M_U-NII-1_H 3.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 5 of 1823 4. 802.11n_20M_U-NII-1_L 4.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 6 of 1823 5. 802.11n_20M_U-NII-1_M 5.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 7 of 1823 6. 802.11n_20M_U-NII-1_H 6.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 8 of 1823 7. 802.11n_40M_U-NII-1_L 7.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 9 of 1823 8. 802.11n_40M_U-NII-1_H 8.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 10 of 1823 9. 802.11ac_20M_U-NII-1_L 9.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 11 of 1823 10. 802.11ac_20M_U-NII-1_M 10.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 12 of 1823 11. 802.11ac_20M_U-NII-1_H 11.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 13 of 1823 12. 802.11ac_40M_U-NII-1_L 12.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 14 of 1823 13. 802.11ac_40M_U-NII-1_H 13.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 15 of 1823 14. 802.11ac_80M_U-NII-1_M 14.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 16 of 1823 15. 802.11ac_160M_U-NII-2A_M 15.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 17 of 1823 16. 802.11ax_20M_U-NII-1_L 16.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 18 of 1823 17. 802.11ax_20M_U-NII-1_M 17.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 19 of 1823 18. 802.11ax_20M_U-NII-1_H 18.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 20 of 1823 19. 802.11ax_40M_U-NII-1_L 19.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 21 of 1823 20. 802.11ax_40M_U-NII-1_H 20.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 22 of 1823 21. 802.11ax_80M_U-NII-1_M 21.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 23 of 1823 22. 802.11ax_160M_U-NII-2A_M 22.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 24 of 1823 23. 802.11a_20M_U-NII-2A_L 23.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 25 of 1823 24. 802.11a_20M_U-NII-2A_M 24.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 26 of 1823 25. 802.11a_20M_U-NII-2A_H 25.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 27 of 1823 26. 802.11n_20M_U-NII-2A_L 26.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 28 of 1823 27. 802.11n_20M_U-NII-2A_M 27.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 29 of 1823 28. 802.11n_20M_U-NII-2A_H 28.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 30 of 1823 29. 802.11n_40M_U-NII-2A_L 29.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 31 of 1823 30. 802.11n_40M_U-NII-2A_H 30.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 32 of 1823 31. 802.11ac_20M_U-NII-2A_L 31.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 33 of 1823 32. 802.11ac_20M_U-NII-2A_M 32.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 34 of 1823 33. 802.11ac_20M_U-NII-2A_H 33.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 35 of 1823 34. 802.11ac_40M_U-NII-2A_L 34.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 36 of 1823 35. 802.11ac_40M_U-NII-2A_H 35.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 37 of 1823 36. 802.11ac_80M_U-NII-2A_M 36.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 38 of 1823 37. 802.11ax_20M_U-NII-2A_L 37.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 39 of 1823 38. 802.11ax_20M_U-NII-2A_M 38.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 40 of 1823 39. 802.11ax_20M_U-NII-2A_H 39.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 41 of 1823 40. 802.11ax_40M_U-NII-2A_L 40.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 42 of 1823 41. 802.11ax_40M_U-NII-2A_H 41.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 43 of 1823 42. 802.11ax_80M_U-NII-2A_M 42.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 44 of 1823 43. 802.11a_20M_U-NII-2C_L 43.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 45 of 1823 44. 802.11a_20M_U-NII-2C_M 44.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 46 of 1823 45. 802.11a_20M_U-NII-2C_H 45.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 47 of 1823 46. 802.11n_20M_U-NII-2C_L 46.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 48 of 1823 47. 802.11n_20M_U-NII-2C_M 47.1. A.4-RMS Power Spectral Density (PSD)(NTNV)_Step22 Document No: BL-EC22A0685 Page 49 of 1823 48. β¦
Text truncated - open the document above for the full version.
Test Report
Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 949 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11n40 CH38 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5084.025 58.32 4.22 74.0 15.68 Peak 6.00 150 Vertical Pass 1** 5084.025 47.11 4.22 54.0 6.89 AV 6.00 150 Vertical Pass 2 5149.675 56.49 4.06 74.0 17.51 Peak 67.00 150 Vertical Pass 2** 5149.675 47.29 4.06 54.0 6.71 AV 67.00 150 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 950 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11n40 CH46 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5350.000 58.77 5.11 74.0 15.23 Peak 139.00 100 Vertical Pass 1** 5350.000 48.34 5.11 54.0 5.66 AV 139.00 100 Vertical Pass 2 5402.965 59.91 4.64 74.0 14.09 Peak 106.00 200 Vertical Pass 2** 5402.965 47.94 4.64 54.0 6.06 AV 106.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 951 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac20 CH36 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5123.025 58.73 4.47 74.0 15.27 Peak 283.00 150 Vertical Pass 1** 5123.025 47.26 4.47 54.0 6.74 AV 283.00 150 Vertical Pass 2 5149.675 56.81 4.06 74.0 17.19 Peak 69.00 100 Vertical Pass 2** 5149.675 47.48 4.06 54.0 6.52 AV 69.00 100 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 952 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac20 CH48 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5350.055 58.22 5.10 74.0 15.78 Peak 337.00 150 Vertical Pass 1** 5350.055 48.41 5.10 54.0 5.59 AV 337.00 150 Vertical Pass 2 5402.415 59.35 4.66 74.0 14.65 Peak 35.00 200 Vertical Pass 2** 5402.415 48.00 4.66 54.0 6.00 AV 35.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 953 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac40 CH38 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5069.725 58.55 4.31 74.0 15.45 Peak 306.00 150 Vertical Pass 1** 5069.725 47.03 4.31 54.0 6.97 AV 306.00 150 Vertical Pass 2 5149.675 56.70 4.06 74.0 17.30 Peak 0.00 200 Vertical Pass 2** 5149.675 47.35 4.06 54.0 6.65 AV 0.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 954 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac40 CH46 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5350.055 58.74 5.10 74.0 15.26 Peak 195.00 200 Vertical Pass 1** 5350.055 48.48 5.10 54.0 5.52 AV 195.00 200 Vertical Pass 2 5355.720 59.62 4.57 74.0 14.38 Peak 252.00 200 Vertical Pass 2** 5355.720 47.74 4.57 54.0 6.26 AV 252.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 955 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac80 CH42 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5061.600 58.63 4.07 74.0 15.37 Peak 340.00 150 Vertical Pass 1** 5061.600 46.59 4.07 54.0 7.41 AV 340.00 150 Vertical Pass 2 5149.675 57.09 4.06 74.0 16.91 Peak 117.00 100 Vertical Pass 2** 5149.675 47.29 4.06 54.0 6.71 AV 117.00 100 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 956 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac80 CH42 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5350.055 58.02 5.10 74.0 15.98 Peak 359.00 100 Vertical Pass 1** 5350.055 48.45 5.10 54.0 5.55 AV 359.00 100 Vertical Pass 2 5385.475 59.82 4.59 74.0 14.18 Peak 340.00 200 Vertical Pass 2** 5385.475 47.65 4.59 54.0 6.35 AV 340.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 957 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China U-NII-1 11ac160 CH50 No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 5072.325 59.17 4.37 74.0 14.83 Peak 333.00 150 Verticβ¦
Text truncated - open the document above for the full version.
Test Report
Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 559 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 11n40, U-NII-2C, 1 GHz to 18 GHz, Middle Channel, ANT H No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1438.300 40.07 -16.73 74.0 33.93 Peak 188.00 400 Horizontal Pass 1** 1438.300 35.53 -16.73 54.0 18.47 AV 188.00 400 Horizontal Pass 2 4321.750 48.63 -4.10 74.0 25.37 Peak 4.00 200 Horizontal Pass 2** 4321.750 38.86 -4.10 54.0 15.14 AV 4.00 200 Horizontal Pass 3 5584.500 102.44 -1.16 -- -- Peak 257.00 150 Horizontal N/A 3** 5584.500 94.27 -1.16 -- -- AV 257.00 150 Horizontal N/A 4 7473.750 53.68 1.86 74.0 20.32 Peak 319.00 100 Horizontal Pass 4** 7473.750 44.34 1.86 54.0 9.66 AV 319.00 100 Horizontal Pass 5 11132.387 52.10 -0.97 74.0 21.90 Peak 60.00 150 Horizontal Pass 5** 11132.387 42.80 -0.97 54.0 11.20 AV 60.00 150 Horizontal Pass 6 15748.013 52.08 0.35 74.0 21.92 Peak 157.00 300 Horizontal Pass 6** 15748.013 42.65 0.35 54.0 11.35 AV 157.00 300 Horizontal Pass 11n40, U-NII-2C, 1 GHz to 18 GHz, Middle Channel, ANT V No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1537.400 40.96 -16.55 74.0 33.04 Peak 244.00 100 Vertical Pass 1** 1537.400 35.80 -16.55 54.0 18.20 AV 244.00 100 Vertical Pass 2 4384.500 47.86 -4.18 74.0 26.14 Peak 360.00 100 Vertical Pass 2** 4384.500 38.84 -4.18 54.0 15.16 AV 360.00 100 Vertical Pass 3 5578.500 102.75 -1.19 -- -- Peak 15.00 100 Vertical N/A 3** 5578.500 94.77 -1.19 -- -- AV 15.00 100 Vertical N/A 4 7500.250 54.03 0.99 74.0 19.97 Peak 360.00 400 Vertical Pass 4** 7500.250 43.91 0.99 54.0 10.09 AV 360.00 400 Vertical Pass 5 11352.313 51.88 -1.84 74.0 22.12 Peak 322.00 100 Vertical Pass 5** 11352.313 41.94 -1.84 54.0 12.06 AV 322.00 100 Vertical Pass 6 15750.375 51.80 0.36 74.0 22.20 Peak 130.00 400 Vertical Pass 6** 15750.375 42.84 0.36 54.0 11.16 AV 130.00 400 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 560 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 11n40, U-NII-2C, 1 GHz to 18 GHz, High Channel, ANT H No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1437.600 40.31 -16.75 74.0 33.69 Peak 191.00 300 Horizontal Pass 1** 1437.600 35.96 -16.75 54.0 18.04 AV 191.00 300 Horizontal Pass 2 4258.750 48.34 -4.13 74.0 25.66 Peak 33.00 300 Horizontal Pass 2** 4258.750 39.35 -4.13 54.0 14.65 AV 33.00 300 Horizontal Pass 3 5658.500 99.93 -1.86 -- -- Peak 257.00 100 Horizontal N/A 3** 5658.500 92.19 -1.86 -- -- AV 257.00 100 Horizontal N/A 4 7382.000 53.13 0.53 74.0 20.87 Peak 203.00 400 Horizontal Pass 4** 7382.000 43.96 0.53 54.0 10.04 AV 203.00 400 Horizontal Pass 5 11140.700 51.37 -0.96 74.0 22.63 Peak 198.00 150 Horizontal Pass 5** 11140.700 43.09 -0.96 54.0 10.91 AV 198.00 150 Horizontal Pass 6 15782.925 51.38 -0.53 74.0 22.62 Peak 103.00 100 Horizontal Pass 6** 15782.925 41.81 -0.53 54.0 12.19 AV 103.00 100 Horizontal Pass 11n40, U-NII-2C, 1 GHz to 18 GHz, High Channel, ANT V No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1494.400 42.23 -16.87 74.0 31.77 Peak 214.00 300 Vertical Pass 1** 1494.400 34.20 -16.87 54.0 19.80 AV 214.00 300 Vertical Pass 2 4380.750 48.01 -4.14 74.0 25.99 Peak 348.00 300 Vertical Pass 2** 4380.750 39.39 -4.14 54.0 14.61 AV 348.00 300 Vertical Pass 3 5657.750 100.60 -1.77 -- -- Peak 259.00 200 Vertical N/A 3** 5657.750 92.47 -1.77 -- -- AV 259.00 200 Vertical N/A 4 7546.750 53.37 1.60 74.0 20.63 Peak 52.00 100 Vertical Pass 4** 7546.750 44.48 1.60 54.0 9.52 AV 52.00 100 Vertical Pass 5 11072.775 51.85 -1.52 74.0 22.15 Peak 19.00 200 Vertical Pass 5** 11072.775 41.97 -1.52 54.0 12.03 AV 19.00 200 Vertical Pass 6 15748.537 51.62 0.35 74.0 22.38 Peak 159.00 200 Vertical Pass 6** 15748.537 43.09 0.35 54.0 10.91 AV 159.00 200 Vertical Pass Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 561 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 11ac20, U-NII-2C, 1 GHz to 18 GHz, Low Channel, ANT H No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1438.000 40.51 -16.74 74.0 33.49 Peak 294.00 400 Horizontal Pass 1** 1438.000 34.78 -16.74 54.0 19.22 AV 294.00 400 Horizontal Pass 2 4356.250 48.28 -3.96 74.0 25.72 Peak 56.00 300 Horizontal Pass 2** 4356.250 38.68 -3.96 54.0 15.32 AV 56.00 300 Horizontal Pass 3 5502.000 102.38 -1.81 -- -- Peak 243.00 150 Horizontal N/A 3** 5502.000 94.41 -1.81 -- -- AV 243.00 150 Horizontal N/A 4 7482.250 53.12 1.49 74.0 20.88 Peak 147.00 200 Horizontal Pass 4** 7482.250 44.69 1.49 54.0 9.31 AV 147.00 200 Horizontal Pass 5 11401.950 52.14 -1.68 74.0 21.86 Peak 334.00 100 Horizontal Pass 5** 11401.950 41.35 -1.68 54.0 12.65 AV 334.00 100 Horizontal Pass 6 15728.062 51.82 0.07 74.0 22.18 Peak 236.00 400 Horizontal Pass 6** 15728.062 42.88 0.07 54.0 11.12 AV 236.00 400 Horizontal Pass 11ac20, U-NII-2C, 1 GHz to 18 GHz, Low Channel, ANT V No. Frequency (MHz) Results (dBuV/m) Factor (dB) Limit (dBuV/m) Margin (dB) Detector Table (Degree) Height (cm) Antenna Verdict 1 1499.700 41.75 -16.61 74.0 32.25 Peak 213.00 300 Vertical Pass 1** 1499.700 30.86 -16.61 54.0 23.14 AV 213.00 300 Vertical Pass 2 4267.250 48.10 -3.57 74.0 25.90 Peak 201.00 400β¦
Text truncated - open the document above for the full version.
Test Report
Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: MeiG Smart Technology Co., Ltd Address: 2nd Floor, Office Building, No.5 Lingxia Road, Fenghuang, Fuyong Street, Bao'an District, Shenzhen, China. Equipment Type: Multi-mode 5G/LTE Smart Module Model Name: SRM955 Brand Name: MEIGLink FCC ID: 2APJ4-SRM955 ISED Number: 23860-SRM955 Test Standard: 47 CFR Part 15 Subpart E RSS-247 Issue 2 RSS-248 Issue 2 (refer section 3.1) Sample Arrival Date: Nov. 21, 2022 Test Date: Dec. 01, 2022 βFeb. 08, 2023 Date of Issue: Feb. 20, 2023 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Julie Zhu Checked by: Ye Hongji Approved by: Liao Jianming (Technical Director) _______________ _______________ _______________ Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Feb. 20, 2023 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................... 4 1.1 Test Laboratory .............................................................................................................. 4 1.2 Test Location .................................................................................................................. 4 2 PRODUCT INFORMATION ......................................................................................................... 5 2.1 Applicant Information ...................................................................................................... 5 2.2 Manufacturer Information ............................................................................................... 5 2.3 Factory Information ........................................................................................................ 5 2.4 General Description for Equipment under Test (EUT) ................................................... 5 2.5 Technical Information ..................................................................................................... 6 2.6 Channel List ................................................................................................................. 10 3 SUMMARY OF TEST RESULTS ............................................................................................... 20 3.1 Test Standards ............................................................................................................. 20 3.2 Test Verdict .................................................................................................................. 20 4 GENERAL TEST CONFIGURATIONS ...................................................................................... 21 4.1 Test Environments ....................................................................................................... 21 4.2 Test Equipment List ...................................................................................................... 22 4.3 Test Software List ......................................................................................................... 23 4.4 Measurement Uncertainty ............................................................................................ 23 4.5 Description of Test Setup ............................................................................................. 24 5 TEST ITEMS .............................................................................................................................. 27 5.1 RF Output Power .......................................................................................................... 27 5.2 Emission Bandwidth and 6 dB Bandwidth .................................................................... 29 5.3 Power Spectral density (PSD) ...................................................................................... 30 5.4 Conducted Emission .................................................................................................... 31 Report No.: BL-EC22A0685-604 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 1346 Web: www.titcgroup.com Template No.: TRP-FCC&ISED 407 (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 5.5 Radiated Spurious Emissions and Band Edge (Restricted-band) ................................ 32 5.6 Contention Based Protocol ........................................................................................... 37 5.7 In-Band Emissions ....................................................................................................... 38 ANNEX A TEST RESULT ............................................................................................................. 40 A.1 RF Output Power .......................................................................................................... 40 A.2 Emission Bandwidth & 99% Bandwidth ...................................................................... 196 A.3 6 dB Bandwidth .......................................................................................................... 208 A.4 Power Spectral Density .............................................................................................. 210 A.5 Conducted Emissions ................................................................................................. 365 A.6 Radiated Spurious Emissions and Band Edge (Restricted-band) .............................. 367 A.7 Contention Based Protocol .....................β¦
Text truncated - open the document above for the full version.
Contact Information
Applicant
Angela Huang(Safety Engineer)
[email protected]Fax: 886-2-8768-2089
Test Firm
DEKRA Testing and Certification (Suzhou) Co., Ltd.Janet Xu
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15E | 5.18 GHz - 5.24 GHz | 45.20 mW |
| 2 | 15E | 5.26 GHz - 5.32 GHz | 45.30 mW |
| 3 | 15E | 5.50 GHz - 5.72 GHz | 45.20 mW |
| 4 | 15E | 5.75 GHz - 5.83 GHz | 28.60 mW |
