RDDIXBLIVERWireless XBOX Live Game Controller

THE INSTRUCTION FOR XBOX LIVE+GAMEPAD IFeature: 1. High technology of CMOS. 2. Working Voltage: 3.5V-6V(3 AAA or 4 AAA valid battery). 3. Working Current: 100mA(the VOICE is on),70mA(the VOICE is off). 4. Wireless transmit frequency: 2.4G. 5. Wireless transmit agreement: Blue Tooth 6. The valid operation distance: 7M. 7. 12-bit ADC inside. 8. Supporting dual-vibration mode. 9. Have “Turbo” function( can’t adjust the speed). 10. The battery lifetime(1800mAh battery): up to 5 hours during vibration, up to 8 hours during no-vibration. 11. The vibration can be exchanged into three levels. 12. 4 LED display on transmitter: Link,Turbo,Mute. 1 LED dispaly on receiver: Link. IIOperating instructions: 1. Turn on the TV&XBOX console. 2. Place the XBOX game CD into the XBOX console. 3. Open the battery cover at the back of controller&put 3 AAA batteries into it, insert the headset into the headset jack, turn on the power switch, then CONNECT LED on the controller will flash. 4. Insert the signal cable on the receiver into the relative game port, the CONNECT LED on the receiver will flash. 5. After several minutes, if the CONNECT LED on the transmitter&receiver turn to illuminate, which shows the connection is OK, and you can start to play the game. 6. If the CONNECT LED on the transmitter&receiver still flash after a long time ,which means the connection is lost, pls restart the above process. III. Function instruction: (I) LIVE function 1. Effect: if the played game have the LIVE function, also already connected with another console through network, so you can turn on the voice function while you play with your parter. 2. Operation and instruction: press&hold the MUTE key for above 3 minutes, then the voice function is on, so the MUTE LED will turn to green; restart to press and hold the MUTE key, the voice function is off and MUTE LED is off. (II) MUTE function 1. Effect: when start the VOICE function, if you don’t want your parter to hear your sound, you can turn off the mike through the MUTE function. 2. Operation&instruction: while the VOICE is on, press the MUTE key, then the green MUTE LED turn to red, the mike function is off; press the MUTE key again, The red MUTE LED turn to green, the mike function is on. (III) HEADSET volume adjust function You can adjust the HEADSET sound volume by VOLUME button (IV) VIBRATION function 1. Operation: you can set up the intension both for vibration and non-vibration through VIB SW, the intension (from left to right) is: non-vibration----the left&right motor will vibrate by 50% intension----the left&right motor will vibrate by 100% intension. (V) TURBO function Total have A.B.X.Y.BLACK.WHITE.LT.RT 8 keys to be set into TURBO function. 1. Operation&instruction: a. Press&hold TURBO key, then press the keys to be set up, so the keys will have TURBO function, TURBO LED will flash, un-press this key, the TURBO LED will illuminate, press again TURBO key, and the TURBO function is deleted. b. Can set up several keys into TURBO function at same time. c. When the pressed keys have been already set into TURBO function, so the keys will fire ceaselessly, the TURBO LED will flash at the speed of 16HZ. d. If any keys are to be set into TURBO function when you have not pressed any keys, so the TURBO LED will illuminate, otherwise it will be off. 2. Adjust the speed. The fixed speed is 16HZ. Gamepad & Host Gamepad & Host Gamepad & Host Host Gamepad & Host The users manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation

INTEC INCORPORATION 5255. NW 159TH STREET MIAMI, FL33014, USA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: RDDIXBLIVER To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

Label Location

Compliance Certification Services (Shenzhen) Inc. Report No.:SZ050602B01 (DONGLE) FCC ID:RDDIXBLIVER Date of Issue: June 11, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 46 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Wireless XBOX Live Game Controller Model: G8030 Trade Name: INTEC Issued to INTEC INC. 5255, NW 159 th STREET MIAMI, FL33014, USA Issued by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 6, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No.:SZ050602B01 (DONGLE) FCC ID: RDDIXBLIVER Date of Issue: June 11, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 MODIFICATION...............................................................................................................................5 3.5 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................6 3.6 DESCRIPTION OF TEST MODES........................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES 8 5.2 EQUIPMENT.....................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING...............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT......................................................................................................9 6.2 SUPPORT EQUIPMENT ..............................................................................................................9 7. FCC PART 15.247 REQUIREMENTS...................................................................................... 10 7.1 PEAK POWER.................................................................................................................................10 7.2 BAND EDGES MEASUREMENT .............................................................................................11 7.3 PEAK POWER SPECTRAL DENSITY.................................................................................................16 7.4 FREQUENCY SEPARATION ....................................................................................................19 7.5 NUMBER OF HOPPING FREQUENCY....................................................................................21 7.6 TIME OF OCCUPANCY (DWELL TIME) ................................................................................23 7.7 RADIO FREQUENCY EXPOSURE.....................................................................................................27 7.8 SPURIOUS EMISSIONS..............................................................................................................30 7.9 POWERLINE CONDUCTED EMISSIONS............................................................................................41 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................................... 45 Compliance Certification Services (Shenzhen) Inc. Report No.:SZ050602B01 (DONGLE) FCC ID: RDDIXBLIVER Date of Issue: June 11, 2005 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: INTEC INC. 5255. NW 159 th Street Miami, FL33014 Equipment Under Test: XBOX Bluetooth Game Controller Tr a d e N a m e : Asoka Model: G8030 Date of Test: May 30 ~ June 8, 2004 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Reviewed and Approved by: Clinton Kao Manager of the EMC testing Division Compliance Certification Services (SZ) Inc. Compliance Certification Services (Shenzhen) Inc. Report No.:SZ050602B01 (DONGLE) FCC ID: RDDIXBLIVER Date of Issue: June 11, 2005 Page 4 Rev. 00 2. EUT DESCRIPTION Product XBOX Trade Name INTEC Model Number G8030 Model Discrepancy N/A Power Supply Powered by the Host (XBOX) Frequency Range 2402 ~ 2480 MHz Transmit Power 1.97 dBm Modulation Technique FHSS Number of Channels 79 Channels Antenna Spe…
