REP-3600-1HotPort 3600-2400

Firetide Inc.
HotPort 3600-2400 - FCC ID REP-3600-1 - Firetide Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Feb 07, 2006
Application Purpose
Original Equipment
Date of Application
Feb 07, 2006
Equipment Note
HotPort 3600-2400
Frequency Range
2412.00000000 - 2462.00000000
Company
Firetide Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗
↗

ID Label/Location Info

↗
↗

Internal Photos

↗
↗

Operational Description

↗
↗
↗
↗

Parts List/Tune Up Info

↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

HotPort TM User Guide HotPort 3200 & 3600 Series Outdoor Wireless Mesh Nodes ii HotPort 3200 Series User Guide Manual Revision 1.3 011806 The contents of this user guide are subject to change without notice. Copyright Notice ©2003-2006 Firetide, Inc. All rights reserved. Trademarks Firetide, the Firetide logo, Instant Mesh Networks, HotPort, and HotView are trademarks of Firetide, Inc. All other trademarks are the property of their respective owners. User Guide HotPort 3200 Series & 3600 Series Outdoor Wireless Mesh Node January 2006 Firetide Instant Mesh Networks iii HotPort Limited End User Product Warranty Pursuant to all provisions described herein, Firetide products are warranted for one (1) year from the date of purchase against de- fects in the build materials and workmanship. Firetide also war- rants that the Software will materially conform to the documen- tation supplied by Firetide with the Software. In the event that the Software fails to materially conform to the documentation and an authorized Firetide reseller is notified in writing of such failure within the warranty period, Firetide or its reseller shall use commercially reasonable efforts to promptly correct the noncon- formity. Firetide does not warrant that the use of the Software will be uninterrupted or error free. Firetide does not warrant that the Products will meet any requirements or specifications of any End User Customer. This warranty applies to the entire Firetide product, including antennas and the AC power adapter. The above warranties are void if the alleged defect cannot be verified by Firetide or if, as determined by Firetide, the product failure was due to tampering, abuse, misuse, accident, shipping, handling, or storage; or if the product has been installed, used, or maintained in a manner not described in the product user manual, if the product has been altered In any way, or If product serialization has been altered. Any attempt to disassemble or re- pair the product by anyone other than Firetide immediately voids this warranty. This warranty applies only to the original End User purchaser of the product and may not be transferred to any other individual or entity. THE FOREGOING ARE THE EXCLUSIVE WARRANTIES APPLICABLE TO THE PRODUCT INCLUDING THE SOFTWARE, AND THE EXCLUSIVE REMEDY FOR DEFECTS IN THE PRODUCT. FIRETIDE DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING BUT NOT LIMITED TO IMPLIED WARRAN- TIES OF MERCHANTABILIT Y, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. SOME LAWS DO NOT ALLOW THE EXCLU- SION OF IMPLIED WARRANTIES SO TO THAT EXTENT THIS LIMITA- TION MAY NOT APPLY TO YOU. In no event will Firetide be liable for any special, inciden- tal, consequential, punitive or indirect damages whatsoever (including, without limitation, damages for loss of profits, business interruption, loss of information, or other pecuniary loss) arising out of the use or inability to use the product or the performance, interruption or failure of the product, irrespec- tive of the cause of action, even if Firetide has been advised of the possibility of such damages. Firetide’s cumulative liability for all claims arising out of or in connection with this warranty will not exceed the amount paid by the original End User purchas- er to purchase the product. The amounts payable for the product are based in part on these limitations and these limitations shall apply not-withstanding the failure of essential purpose of any remedy. Some jurisdictions do not allow the exclusion or limita- tion of incidental or consequential damages, so to that extent the above limitations or exclusions may not apply to you. By using the product the original End User purchaser agrees to and is bound by these terms and conditions. In the event that a product fails to meet this warranty and Firetide’s authorized reseller is notified in writing of such failure within the warranty period, Firetide shall, at its own dis- cretion, either repair the product or replace it with the same or a functionally-equivalent product free of charge. Replace- ment products may contain refurbished materials in whole or in part. Firetide will honor this warranty provided the prod- uct is returned through an authorized Firetide reseller or dealer with shipping charges prepaid, along with a proof of purchase describing the original purchase date and product serial numbers if applicable. The authorized reseller must acquire a Return Materials Authorization (RMA) number from Firetide prior to returning any product. Firetide does not accept ship- ments of defective products without shipping charges prepaid. iv HotPort 3200 Series User Guide Explanation of Graphical Symbols This symbol is intended to alert the user to the pres- ence of important operating, maintenance, and ser- vicing instructions in the literature accompanying this unit. Failing to comply with this instruction may result in electrical shock. This symbol is intended to alert the user to the pres- ence of important operating, maintenance, and ser- vicing instructions in the literature accompanying this unit. Failing to comply with this instruction may result in a hazard. DO NOT OPEN THE COVER • Dangerous voltages inside. • No serviceable parts inside. • Refer to qualified service personnel. • Unit must be disconnected from power prior to servicing. • Unit has tamper-evident labeling that indicates when the cover has been removed. Contents Firetide HotPort Outdoor Wireless Mesh Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 What is a Firetide Mesh Network? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Firetide High-Performance Mesh Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 High Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Users Manual

SR2 MANUAL The SR2 hi-power mini-PCI 802.11b/g radio card module has been specifically designed for use in outdoor wireless applications where additional link gain is critical. It is compatible with existing Atheros linux drivers and is capable of operation in the 2412-2462 MHz frequency range. Power and frequency limits are hard programmed into the radio card EEPROM, but card compatibility can be achieved with any Atheros Linux based software. Many SBC host platforms have been qualified for use with the SR2 module including: -Mikrotik Router Boards -PC Engines WRAP boards -Many SBC platforms from large telecommunication companies It is necessary that the system integrators perform all applicable retesting and certification for their final system configurations. EXAMPLE OEM SYSTEM USAGE MODULAR USAGE PC ENGINES WRAP Wireless Router Board ATHEROS PUBLIC MADWIFI Driver Ubiquiti Networks, Inc. 778 N. First St. San Jose, CA 95112 (408)-385-1103 SR2 Pac Wireless Roo Tenna Antenna/Enclosure Software Driver SR2 IMPORTANT MODULAR APPROVAL INFORMATION This device is intended only form OEM integrator under the following conditions: 1) The antenna must be installed such that 20cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example access points, routers, wireless ADSL modems, and similar equipment). The final end product must be labeled in visible area with the following: “Contains TX FCC ID SWX-SR2: End Product Manual Information The user manual for end users must include the following information in a prominent location “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” SR2 IMPORTANT OPERATION INFORMATION Safety Information 20 cm

Cover Letter(s)

www.firetide.com 16795 Lark Avenue, Los Gatos, CA 95032, Tel: 408-399-7771, Fax: 408-317-1777 Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: CONFIDENTIALITY REQUEST FOR HOTPORT 3600-2400 FCC ID # REP-3600-1 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the schematic diagrams, parts list/bill of materials (BOM), and block diagram required to be submitted with this application be withheld from public review. The documents are company proprietary information that should not get into the possession of our competition. Please contact me if there is any information you may need. Date: January 18, 2006 Hoss Hakimi Director of Hardware Engineering Firetide Inc. 16795 Lark Ave. Suite 200 Los Gatos, CA 95032

Cover Letter(s)

www.firetide.com 16795 Lark Avenue, Los Gatos, CA 95032, Tel: 408-399-7771, Fax: 408-317-1777 Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Agent Authorization To Whom It May Concern: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Date: January 18, 2006 Hoss Hakimi Director of Hardware Engineering Firetide Inc. 16795 Lark Ave. Suite 200 Los Gatos, CA 95032

Cover Letter(s)

UBIQUITI NETWORKS FCC ID: SWX-SR2 Request for transmitter modular approval Transmitter Module Characteristics Item Requirements EUT 1 Have its own RF shielding Device is equipped with Metal shielding to cover RF section. Refer to external photos 2 Have buffered modulation/data inputs (if such inputs are provided), All inputs to the modules are buffered through logic or microprocessor inputs. 3 Have it own power supply regulation Internal 2.5V/3.3V power regulator. Refer to Block diagram 4 Meet the antenna requirements of Section 15.203 Device is equipped with unique antenna ( u.FL(v)- LP-040) connector. Refer to external photos 5 Be tested in a stand-alone configuration, i.e., the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing Device was tested in a adapter exposed outside of the laptop host 6 Be labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. One modular FCC ID is submitted. Second FCC ID will be obtained by OEM customers for use in their hosts. 7 The modular transmitter is manufactured so that the user cannot influence the operation of the transmitter that will operate outside of the scope of the regulations. There are Specific EEPROM settings inside the module that prohibit illegal usage. 8 Address compliance with the Commission's RF exposure limits in Sections 1.1310 and 2.1093. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). Module is NOT a portable device for laptops. Only can be used in outdoor AP/CPE’s. MPE calculated minimum distance has been included in user manual.

Cover Letter(s)

Ubiquiti Networks, Inc. 1111 Weyburn Ln, Ste. #41 San Jose CA 95129 Phone (408) 873-8760 Fax (408) 351-4973 April 5, 2005 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: SWX-SR2 and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation . These documents contain detailed system and equipment description and related information about the product that Ubiquiti Networks considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Ubiquiti Networks considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Sincerely Yours, Ram Malasani Senior Engineer Ubiquiti Networks, Inc.

ID Label/Location Info

127 mm 32.5 mm Black ink 8 mm 5 mm 8 mm radius 2 mm radius corners FCC ID: REP-3600-1 Input Power: 16 VDC, 2.5 A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that may cause undesired operation. HotPort Wireless Mesh Node Firetide Model: HotPort 3600-2400

ID Label/Location Info

3600-2400 and 3600-5000 FCC Label Placement Place FCC Label in Center Recessed Area - Model 3600-2400 Shown Place Model Number Label in Side Recessed Area Serial Number and Mfg. Date Code Labels

Operational Description

3600-2400 Series Theory of Operation Principle The 3600-2400 Series Hotport Mesh Node is comprised of three printed circuit assemblies; a Mother Board, a Daughter Board, and Radio Card. The Motherboard uses the Intel IXP425 as the central processing unit. Memory configuration is 32M bytes of FLASH and 64M bytes SDRAM. The Daughter Board is powered by via a AC/DC wall adapter (16V out, 2.5 A rating). The Daughter Board’s main function is to generate the system level voltages used by the Mother Board and Radio Card. The Hotport Node supports up to 2 10/100 Base-TX LAN network interfaces using Admtek 6996L Ethernet switch. The interface to the LAN network is through an LTW weatherized connector. The radio card (Type III mini PCI module) plugs into the Motherboard. Communication to/from the Motherboard is made via a 128 pin mini PCI connector. The Radio Card runs from 3.3 volts, which is provided by the Motherboard. The 3600-2400 series uses an Ubiquiti Networks SR2 radio card. The SR2 card is a full featured 802.11b/g client card. The Radio operates from 2412 MHz to 2462 MHz according to the IEEE 802.11b/g specification. The data rates supported are 1 Mbit (DBPSK), 2 Mbit (DQPSK), 5.5 Mbit (CCK), and 11 Mbit (CCK) for .11b and 6, 9, 12, 18, 24, 36, and 54 MBit OFDM for .11g. The Hotport Node uses 8 dBi omni directional diversity antennas.

Operational Description

Specification 1. Electrical Properties : 1.1 Frequency Range............ 1.2 Impedance .................. 1.3 VSWR ..................... ... 1.4 Return Loss.................. 1.5 Electrical Wave............... 1.6 Gain(peak)................... 5dBi 1.7 Admitted Power............ 2. Physical Properties : 2.1 Cable...........................RG-178 Coaxial Cable 2.2 Antenna Cover............ ...TPE 2.3 Antenna Base............... PC 2.4 Antenna Base............... PBT 2.5 Operating Temp. ......... ...-20 ~ +65 2.6 Storage Temp. ............ ...-30 ~ +75 2.7 Color ........................ .Black 2.8 Connector.................. ...SMA Plug Reverse RF Antenna Cable Assembly 1/2ȜDipole 1W 2.4GHz ~ 2.5GHz 50ȍ Nominal 1.92 Max. -10 dB Maximum 1 2 RF Antenna Assembly P/NO :C812-510010-A SPEC : 2.4GHz 6/24/2005 3

Operational Description

=aj]la\]Û@fklYflÛD]k`ÛE]logjckÛÛۆ I]d]Yk]Û~‡‡Û~‚ÛF[lgZ]jÛ‡‡‚ =aj]la\]Û~>G¤‡…:9~ÛJh][ax[Ylagfk K`]Û~>G¤‡…:9~ۅÛ\9aÛgefa\aj][lagfYdÛYfl]ffYÛakÛ\]ka_f]\Û lgÛhjgna\]ÛeYpaemeÛh]j^gjeYf[]ÛYf\Ûj]daYZadalqÛmf\]jÛl`]Û lgm_`]klÛo]Yl`]jÛ[gf\alagfkÛK`]ÛYfl]ffYÛ^]Ylmj]kÛYÛLM¤klYZd]Û jY\ge]Ûl`YlÛhjgna\]kÛhjgl][lagfÛY_YafklÛo]Yl`]jÛ <d][lja[YdÛJh][ax[YlagfkKqha[YdÛMYdm] =j]im]f[qÛIYf_]¤‚Û>?r >Yaf۳ۂ…Û>?r…Û\9a EgeafYdÛ@eh]\Yf[]‚‡Ûg`ek MJNI~‚ÛDYp IY\aYlagfÛGYll]jfFefa\aj][lagfYd M]jla[YdÛ9]YeÛNa\l`…μ GgdYjarYlagfM]jla[Yd D][`Yfa[YdÛJh][ax[Ylagfk :gff][lgjE•Û^]eYd] Fh]jYlaf_ÛK]ehÛIYf_]¤‡μ:Ûlgۃ‚μ: Naf\ÛJmjnanYd~‚ÛDG? <imanYd]flÛ=dYlÛGdYl]Û8j]Y‡~~ÛkiÛ^l CYl]jYdÛK`jmklÛ³Û~‚ÛDG?~‡~ÛdZk 9]f\af_ÛDge]flÛ³Û~‚ÛDG?~„Û^l¤dZk ?]a_`l~ƒ‚Ûaf[`]kÛ ̈‡Ûee© Dgmflaf_Û9Yk]Û;aYe]l]j~‚Ûaf[`]kÛ ̈€Ûee© N]a_`l‡ƒ‚ÛdZkÛ ̈‡€Ûc_©

Operational Description

…ÛÛÛ?glGgjlÛ8fl]ffYÛ@fkljm[lagfÛDYfmYd I]d]Yk]Û~‡‡Û~‚ÛF[lgZ]jÛ‡‡‚ IY\aYdd¤CYjk]fÛI€…‡‚‡‡‡ÛJh][ax[Ylagfk K`]ÛI€…‡‚‡‡‡ÛۅÛ\9aÛgefa\aj][lagfYdÛYfl]ffYÛakÛ\]ka_f]\Û lgÛhjgna\]ÛeYpaemeÛh]j^gjeYf[]ÛYf\Ûj]daYZadalqÛmf\]jÛl`]Û lgm_`]klÛo]Yl`]jÛ[gf\alagfkÛK`]ÛYfl]ffYÛ^]Ylmj]kÛYÛLM¤klYZd]Û jY\ge]Ûl`YlÛhjgna\]kÛhjgl][lagfÛY_YafklÛo]Yl`]jÛ <d][lja[YdÛJh][ax[YlagfkKqha[YdÛMYdm] =j]im]f[qÛIYf_]¤‚Û>?r >Yaf۳ۂ…Û>?r…Û\9a EgeafYdÛ@eh]\Yf[]‚‡Ûg`ek MJNI~‚ÛDYp IY\aYlagfÛGYll]jfFefa\aj][lagfYd M]jla[YdÛ9]YeÛNa\l`…‚μ GgdYjarYlagfM]jla[Yd D][`Yfa[YdÛJh][ax[Ylagfk :gff][lgjE•Û^]eYd] Fh]jYlaf_ÛK]ehÛIYf_]¤‡μ:Ûlgۃ‚μ: Naf\ÛJmjnanYd†€ÛDG? <imanYd]flÛ=dYlÛGdYl]Û8j]YE8 CYl]jYdÛK`jmklÛ³Û~‚ÛDG?E8 9]f\af_ÛDge]flÛ³Û~‚ÛDG?E8 ?]a_`l‡„‚Ûaf[`]kÛ ̈‚„Ûee© Dgmflaf_Û9Yk]Û;aYe]l]j~‚Ûaf[`]kÛ ̈€Ûee© N]a_`l‡€€ÛdZkÛ ̈‡~‚Ûc_© ‡ €‚‡ €‡ €€‡ €‡ €~‡ €‡‡ †‡ …‡ „‡ ƒ‡ ‚‡ ‡ €‡ ‡ ~‡ ‡‡ ~†‡ ~…‡ ~„‡ ~ƒ‡ ~‚‡ ~‡ ~€‡ ~‡ ~~‡ ~‡‡ †‡ …‡ „‡ ƒ‡ ‚‡ ‡ €‡ ‡ ~‡ ‚~‡‡¤‚¤~‡¤~‚¤‡¤‚¤‚¤‡¤~‚¤~‡¤‚‡‚ ~‡ ‡ €‚‡ €‡ €€‡ €‡ €~‡ €‡‡ †‡ …‡ „‡ ƒ‡ ‚‡ ‡ €‡ ‡ ~‡ ‡‡ ~†‡ ~…‡ ~„‡ ~ƒ‡ ~‚‡ ~‡ ~€‡ ~‡ ~~‡ ~‡‡ †‡ …‡ „‡ ƒ‡ ‚‡ ‡ €‡ ‡ ~‡ ‚~‡‡¤‚¤~‡¤~‚¤‡¤‚¤‚¤‡¤~‚¤~‡¤‚‡‚ ~‡ M]jla[YdÛ9]YeÛGYll]jf ?gjargflYdÛ9]YeÛGYll]jf

Parts List/Tune Up Info

www.firetide.com 16795 Lark Avenue, Los Gatos, CA 95032, Tel: 408-399-7771, Fax: 408-317-1777 January 28, 2006 Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Hotport 3600-2400 ; FCC ID # REP-3600-1 To Whom It May Concern: The radio module used in the Hotport 3600 is an “off-the-shelf” product produced by Ubiquiti Networks Inc. (San Jose, CA). The model number of the radio module is SR2. The SR2 is Ubiquiti’s version of the 802.11b/g mini PCI card developed by Atheros Communications (Sunnyvale, CA). The radio card utilizes the Atheros AR5213 (MAC) and AR5112 (Radio) IC’s, which are designed to cover the 2.4 GHz ISM band. Firetide purchases the SR2 module from Ubiquiti as a tested and calibrated card. No tuning or programming of the SR2 card prior to final assembly is performed by Firetide. Tuning of the Hotport 3600 (output power and operating frequency) is done by using the HotView SW application provided with each unit. With Hotview, the end user can change the operating frequency to pre-set/pre-defined channels and can change (increase/decrease) the TX output power. The end user can only increase the power up to a factory set limit and not beyond. The factory set limit is based on the TX power levels measured during the FCC certification testing. Please contact me if there is any information you may need. Hoss Hakimi Director of Hardware Engineering Firetide Inc. 16795 Lark Ave. Suite 200 Los Gatos, CA 95032

Test Report

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 33439 WESTERN AVENUE ! UNION CITY, CALIFORNIA 94587 ! PHONE (510) 489-6300 ! FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory January 5, 2006 Firetide 16795 Lark Ave. Los Gatos, CA 95032 Dear Hoss Hakimi, Enclosed is the Telecom test report for compliance testing of the Firetide, HotPort 3600-2400 as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-03 ed.), Part 15, Subpart B for a Class B Digital Device. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Cheryl Anicete Documentation Department Reference: (\Firetide\EMCS18793C-FCC247) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo, the Standards Council of Canada Logo, or the Nationally Recognized Testing Laboratory (NRTL) Letters in this report reflects MET Accreditation under these programs, these letters, logo, or statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. This letter of transmittal is not a part of the attached report. Firetide HotPort 3600-2400 CFR Title 47, Part 15, Subpart C MET Report: EMCS18793C-FCC247 © 2006, MET Laboratories, Inc. Page i of vi Electromagnetic Compatibility Criteria Test Report for the Firetide HotPort 3600-2400 Verified under the FCC Certification Rules contained in Title 47 of the CFR, Part 15.247, Subpart C for Intentional Radiators MET Report: EMCS18793C-FCC247 January 5, 2006 Prepared For: Firetide 16795 Lark Ave. Los Gatos, CA 95032 Prepared By: MET Laboratories, Inc. 33439 Western Ave. Union City, California 94587 Firetide HotPort 3600-2400 CFR Title 47, Part 15, Subpart C MET Report: EMCS18793C-FCC247 © 2006, MET Laboratories, Inc. Page ii of vi Electromagnetic Compatibility Criteria Test Report for the Firetide HotPort 3600-2400 Tested Under the FCC Certification Rules contained in Title 47 of the CFR, Part 15.247, Subpart C for Intentional Radiators Shawn McMillen, Project Engineer Cheryl Anicete Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15.407, of the FCC Rules under normal use and maintenance. Tony Permsombut, Manager Electromagnetic Compatibility Lab Firetide HotPort 3600-2400 CFR Title 47, Part 15, Subpart C MET Report: EMCS18793C-FCC247 © 2006, MET Laboratories, Inc. Page iii of vi Report Status Sheet Revision Report Date Reason for Revision ∅ January 5, 2006 Initial Issue. Firetide Table of Contents HotPort 3600-2400 CFR Title 47, Part 15, Subpart C MET Report: EMCS18793C-FCC247 © 2006, MET Laboratories, Inc. Page iv of vi Table of Contents I. Executive Summary .................................................................................................................................................. 1 A. Purpose of Test .................................................................................................................................................... 2 B. Executive Summary ............................................................................................................................................. 2 II. Equipment Configuration ........................................................................................................................................ 3 A. Overview.............................................................................................................................................................. 4 B. References............................................................................................................................................................ 5 C. Test Site ............................................................................................................................................................... 5 D. Description of Test Sample.................................................................................................................................. 5 E. Equipment Configuration .................................................................................................................................... 8 F. Support Equipment .............................................................................................................................................. 8 G. Ports and Cabling Information............................................................................................................................. 9 H. Mode of Operation ............................................................................................................................................... 9 I. Method of Monitoring EUT Operation................................................................................................................ 9 J. Modifications ....................................................................................................................................................... 9 a) Modifications to EUT .................................................................................................................... 9 b) Modifications to Test Standard ................................................................…

Text truncated - open the document above for the full version.

Test Report

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR 2.4 GHz 802.11 b/g MINI PCI CARD MODEL NUMBER: SR2 FCC ID: SWX-SR2 REPORT NUMBER: 05U3280-1 ISSUE DATE: MAY 9, 2005 Prepared for UBIQUITI NETWORKS 1111 WEYBURN LANE, SUITE 41 SAN JOSE, CA 95129 U.S.A. Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 05U3280-1 DATE: MAY 9, 2005 EUT: 2.4 GHz 802.11 b/g MINI PCI CARD FCC ID: SWX-SR2 Page 2 of 90 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 05U3280-1 DATE: MAY 9, 2005 EUT: 2.4 GHz 802.11 b/g MINI PCI CARD FCC ID: SWX-SR2 Page 3 of 90 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 3.1. ACCREDITED TESTS .................................................................................................................. 5 3.2. UNACCREDITED TESTS.............................................................................................................5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 6 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 6 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 6 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 7 5.4. SOFTWARE AND FIRMWARE .................................................................................................... 7 5.5. WORST-CASE CONFIGURATION AND MODE......................................................................... 7 5.6. DESCRIPTION OF TEST SETUP ................................................................................................ 8 6. TEST AND MEASUREMENT EQUIPMENT .............................................................................. 10 7. LIMITS AND RESULTS ................................................................................................................. 11 7.1. CHANNEL TESTS FOR THE 2400 TO 2483.5 MHz BAND ...................................................... 11 7.1.1. 6 dB BANDWIDTH ........................................................................................................... 11 7.1.2. 99% BANDWIDTH............................................................................................................ 18 7.1.3. PEAK OUTPUT POWER .................................................................................................. 25 7.1.4. MAXIMUM PERMISSIBLE EXPOSURE ........................................................................ 33 7.1.5. AVERAGE POWER........................................................................................................... 36 7.1.6. PEAK POWER SPECTRAL DENSITY ............................................................................ 37 7.1.7. CONDUCTED SPURIOUS EMI…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Sudhir Hirudayaraj(CTO)
[email protected],[email protected]+1-4083557203Fax: +1-4083171777

Test Firm

MET Laboratories, Inc.Carlton Bennett
[email protected]4103543300Fax: 4103543313

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz347.00 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. The antenna(s) used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
