RFM-ACCESS-ONE802.11 a/b/g Wireless Access Point

Strix Systems, Inc.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Jan 13, 2004
Application Purpose: Original Equipment
Date of Application: Jan 13, 2004
Equipment Note: 802.11 a/b/g Wireless Access Point
Frequency Range: 5260.00000000 - 5320.00000000
Company: Strix Systems, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Strix Systems, Inc. 310 N. Westlake Blvd., Suite 150 • Westlake Village, CA 91362 USA Tel 805.777.7911 • Fax 805.777.7916 www.strixsystems.com Access/One Network™ Quick Start Guide THIS GUIDE IS PLACED IN EVERY BOX. WE SUGGEST THAT YOU STILL GLANCE THROUGH IT AS THIS VERSION MAY BE DATED LATER THAN ONE YOU HAVE ALREADY READ. The box you have just opened contains several very similar-looking modules that, when assembled, form one of the Access/One Network Nodes that you purchased. Also included in the box with these modules are a separately-packaged power supply and Dual Lock™ patches that can be used to attach the Node to a desk, cubicle wall or mounting bracket. External antennas, wall/ceiling mounting brackets and/or security locking cables, if ordered, are all packaged separately. You may have a Strix Network Node map and inventory list that was generated by the Architect/One™ application. This information, or your own network map, will be a useful reference during the Access/One Network installation process. Instructions for adding a Node to your existing Access/One Network This section does not discuss Network Node assembly and mounting directions as you should be familiar with this process. If not, please skip to the next section. When adding a new Node to an existing Access/One Network you must enable the Node to be part of the wireless network, i.e. you must authorize it before it can become operational. To do this, simply: 1. Power on the Node 2. Start the Manager/One™ application in a web browser by clicking the Strix Access/One Network icon on the toolbar. 3. Locate any Network Server in the Manager/One listing and double click on it to display a map of all the Network Nodes. 4. Select the newly installed Node on the map and ‘join’ it into a) the Access/One Network; and b) the security domain if your network is partitioned into multiples. The new Node will inherit the network’s configuration and security settings – it will reboot itself and rejoin the network ‘cloud’ as a fully authorized member. Instructions for a new Access/One Network installation Box content details The Access/One Network modules in the box are already placed in the correct order for easy assembly of the Network Node. It is always a good idea to double-check that the correct modules are in the box. Remember the following visual clues on both the module’s model number label and the colored dot identification sticker on the module’s antistatic shipping bag: - The Base Module is always present. Its model number begins with the letters “BM” and the attached identification sticker is white. - The Network Server module, if present, is typically placed next to the Base Module. Its model number is “NWSV” and the attached identification sticker is red. - The Wireless Modules are placed next. These modules have a model number that begins with the letters “WM” and have attached identification stickers in varying shades of blue, which represent different radio technologies. If there are two Wireless Modules in the Node, the light blue one (802.11a), if present, should be placed below the other. This will guarantee that the correct antenna is engaged. - If present, the Antenna Module is placed last. Its model number begins with the letters “AM” and the attached identification sticker is green. The Strix Antenna Module does not look like a traditional antenna (rabbit ears, etc.), but like all other Strix modules. Assemble the Node Typically, it takes less than a minute to assemble a Network Node. There is only one way each module can be attached to any other, so: 1. Unpack the Base Module. Open the plastic bag with the Dual Lock™ patches. Turn the module over and attach the patches to the three sunken circles on the bottom of the module – press hard to make sure each patch sticks to the surface. Place the module upright with the LED window facing you. 2. Unpack other modules one by one and ‘snap’ each new one on top of the Node being assembled. Make sure you hear a ‘click’. The wave design on the modules only allows the modules to be assembled one way. The Node is completely assembled when the Antenna Module is snapped on. 3. Unless you plan to use Power-over-Ethernet (PoE), take power supply out of its box and insert the small DC power jack into the rear of the Base Module. For your convenience the power jack contains a locking mechanism, so you might have to turn it a quarter turn in either direction to correctly fit into place. Now, make sure you turn the jack again in any direction to lock it and prevent the power cord from being pulled out accidentally. The Node is now assembled! Mount the Node Nothing else needs to be done if you plan to place the Node on a desk, filing cabinet, book shelf, or any other flat surface – the Node will stand on its own four rubber feet. However, if you want a more permanent placement or are using a mounting bracket it is prudent to: a) attach the Node to the surface or mounting bracket with Dual Lock™ (it makes for a very strong attachment, yet the Node can still be removed by hand when a little force is applied); and b) secure the Node in place with a security locking cable to prevent theft, misplacement, etc. 1. If you have ordered a mounting bracket (packaged separately), use the installation hardware provided and follow instructions supplied to attach it to the wall or ceiling. Remember that the bracket is designed so that the Network Node ‘hangs’ upside down. - 2 - Strix Systems, Inc. 310 N. Westlake Blvd., Suite 150 • Westlake Village, CA 91362 USA Tel 805.777.7911 • Fax 805.777.7916 www.strixsystems.com 2. Place the mating side of the Dual Lock™ patches supplied in this box on the desk, cabinet, book shelf, bracket, etc. Included in the package is a Node footprint with appropriate cutouts for easy placement of the patches. Make sure that the surface is clean and you press hard enough for the patches to stick. Align the assembled Node with the Dual Lock™ patches and apply light …

Text truncated - open the document above for the full version.

Users Manual

Access/One ™ Network User Gu ide ACCESS/ONE ™ NETWORK User Guide Part Number: 210-0007-01 Revision A, September 2003 All rights reserved. This document may not be reproduced or disclosed in whole or in part by any means without the written consent of Strix Systems, Inc.  Strix Systems, Inc. 310 N. Westlake Blvd., Suite 150 • Westlake Village, CA 91362 USA Tel 805.777.7911 • Fax 805.777.7916 http://www.strixsystems.com i FCC Notice The enclosed wireless network device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This wireless network device has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This wireless network device generates, uses, and radiates radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this wireless network device does cause harmful interference to radio or television reception, which can be determined by turning the wireless network device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the wireless network device and the affected receiver. • Connect the wireless network device into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Industry Canada Notice This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. VCCI Notice This is a Class A wireless network device based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this wireless network device is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the wireless network device according to the instruction manual. European Community (EC) Directives and Conformity This wireless network device is in conformity with the Essential Requirements of R&TTE Directive 1999/5/EC of the European Union. Radio Frequency Interference Requirements This wireless network device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC regulations require this device to be used indoors to reduce the potential for harmful interference. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar transmitters can cause interference with and/or damage to the enclosed device. RF Exposure Requirements To ensure compliance with FCC RF exposure requirements, the antenna used for this wireless network device must be installed to provide a separation distance of a minimum of 20 cm (7.9 inches) or more from all persons, and must not be co-located or operated in conjunction with any other antenna or radio transmitter. Installers and end-users must follow these installation instructions. ii The Access/One™ Network contains a Lithium battery in the BME base module which is NOT replaceable by the user CAUTION: Discard used batteries according to manufacturer's instructions. ATTENTION: Mettre au rebut les batteries usagées conformément aux instructions du fabricant. VORSICHT: Entsorgung gebrauchter Batterian nach Angaben des Herstellers. Installation Warning Warning Read the installation instructions before you connect the wireless network device to its power source. Warning You must only use the UL Listed power supply supplied with this wireless network device. Lightning Activity Warning Warning Do not connect or disconnect cables during periods of lightning activity. Explosive Device Proximity Warning Warning Do not operate your wireless network device near unshielded blasting caps or in an explosive environment. Important Note: Intentional or unintentional changes or modifications to this wireless network device are prohibited. Any such modifications will void the user’s authority to operate the wireless network device, and will void the manufacturer’s warranty. MIC Notice: For additional information, please refer to Strix Systems, Inc., at http://www.strixsystems.com . iii Table of Contents APPENDIX 1: MODULE / DEVICE MANAGEMENT...................................39 INTRODUCTION....................................1 INSTALLATION.....................................2 DEVICE....................................................39 CONFIGURE.............................................40 ASSEMBLY AND SELF IDENTIFICATION...2 SECURITY................................................43 MANAGER/ONE..........................................2 MONITOR................................................44 HOST NETWORK REQUIREMENTS...........9 USER SECURITY CONSIDERATIONS.......11 APPENDIX 2: SPECIFICATIONS.....46 MANAGEMENT...................................13 PHYSICAL ATTRIBUTES.........................46 EMISSIONS AND SAFETY STANDARDS... 46 LOAD IMAGE...........................................16 USER COVERAGE RANGES FOR BLUETOOTH, 802.11A, 802.11B, & 802.11G....................................................47 REBOOT NETWORK................................17 UPDATE NAMES.......................................17 UPDATE MEMBERSHIP............................18 RENAME NETWORK................................18 APPENDIX 3: CLI COMMANDS.......48 VIEW ACTION STATUS............................18 NODE STATUS..........................................20 APPENDIX…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Cover Letter(s)

Kyle, This product is used exclusively on our own private network which we install as part of the overall product. Since it is a wireless network, we only use one LAN connection generally at the last node which connects to the customer's server. Extra connections can be used for setup and test, when required. We do not use the base as an ITE hub/switch. Hopefully this explains why the product is called the Access/One(tm) Network, as opposed to just an access point. Best regards, Eric -----Original Message----- From: Kyle Fujimoto [mailto:[email protected] ] Sent: Friday, September 12, 2003 2:26 PM To: Eric Eustis Subject: Package is at the TCB now Eric, The package is right now at the TCB. I was wondering why the EUT was only tested with one ethernet cable (when the EUT had four ethernet ports) when it was tested in Agoura. Joey had mentioned this was because they used a unique proprietary protocol. Can you provide a brief statement on saying why it was tested that way? This is so in case the TCB asks, I will have a statement to provide them regarding this. Thank You, Kyle Fujimoto Test Engineer -- Compatible Electronics, Inc. -- Brea Division Phone:(714) 579-0500 Fax: (714) 579-1850 [email protected] http://www.celectronics.com From: "Eric Eustis" <[email protected]> To: "Kyle Fujimoto" <[email protected]> Date: 09/12/2003 02:32 PM Subject: RE: Package is at the TCB now Page 1 of 1 9/12/03http://www.celectronics.com:3000/WorldClient.dll?Session=CBXWKYH&View=Message&Number=931

Cover Letter(s)

Access/One™ Network The Access/One™ Network is a Dual Band, High Speed Wireless Network Access Point, which can connect to any device using 802.11a/b/g and Bluetooth RF technologies. The Access/One™ Network operates as a wireless LAN (WLAN) to provide reliable and continuous LAN coverage throughout office buildings, warehouses, manufacturing floors, hospitals, or similar places of installation.

Cover Letter(s)

1 Mike Kuo From: Kyle Fujimoto [[email protected]] Sent: November132003Thursday 7:52 AM To: Mike Kuo Subject: RESPONES: FCC ID:RFM-ACCESS-ONE, AN03T3261 ( UNII ) AccessOne Network User Guide_1... Access_One Quick Start Guide_1... HP_8482H_Power_ Sensor_Informat... WLL4030 Specification0701_11-1... Mike, We are answering your questions here due to being unable to access the questions on the website. Question #1: As indicated in the test report, output power was measured with power meter. Section 5.2 of main test report did not list such power meter. Please provide the power meter information. Since you are using power meter to measure DTS , please also provide the power sensor specification to make sure the bandwidth is wide enough to measure this device. Reponse: We are using the Hewlett Packard Power Meter (Model: 436A, S/N: 2236A15362, Cal Due Date: June 20, 2003) with the Hewlett Packard Power Sensor (Model: 8482H, S/N: GG00000006, Cal Due Date: June 20, 2003). Also attached will be the Application Note from Agilent showing the 8482H sensor has an unlimited bandwidth range). Question #2: In the Expository statement made by the applicant, this device can communicate with Bluetooth device. Based upon this device is equipped with 802.11 a/b/g radio, please explain how this device can communicate with Bluetooth device. Response: From client "The Access/One (tm) Newtwork has a Bluetooth radio module which we will be adding to this approval shortly. If this is of concern, then let's drop the reference to the Bluetooth Functionality until we come back with the Bluetooth test data to add to this approval." The client just wants to approve the 802.11 stuff right now. Question #3: In accordance with user manual, the 802.11 a/b/g radio will be shipped as add-on device. In the user manual provide the instruction on how to install this radio. In addition, user manual also indicates that this device can detect the type of antenna that can be used with this radio. Please provide detail technical description to explain how such detection can be done. Reply to this question will be used to determine the integral antenna requirements for 5.15-5.25GHz band as required per section 15.407(d)of FCC rules. Response: From the Client -- "The radio module installation instructions wre provided in the Quick Start Guide which was provided earlier...howerver, I have attached it again. These instructions are repeated in the full Users Guide which is attached. Also, we use a programmed EPROM in our antenna module. When the node power up, the systems interrogates the antenna module, looking for a Strix Systems identifier. If it finds the correct identifier, the system will allow the M-PCI radio module(s) to transmit and receive normally. If the wrong identifier is detected, or if no identifier is detected, the system will not allow the M-PCI radio module to transmit or recieve in any manner. This method of antenna identification has been approved for Strix by the FCC. If necessary we can provide e-mail verification of same." Question #4: Please address the requirement per section 15.407(a)(7) of FCC rules. 2 The EUT uses the standard program that most access points use for setting the channel. A look at the 6dB bandwidth plots shows the frequncy of the fundamental is right where they are supposed to be (i.e. 5180 MHz, 5260 MHz, 5320 MHz). Question #5: Please provide information to address section 15.407(g) of FCC rules. Response: "The Askey M-PCI radio card that we use has been tested for compliance with the frequency stability requirements of section 15.407 (g) of the FCC rules, as has the Atheros chipset which is used in the M- PCI radio module. Frequency stability is maintained over the range of 0 degress celsius to +70 degress celsius. I have attached the Askey datasheet for the M-PCI radio we are using. In addition, Strix has performed DVT four-corners testing in a temperature chabmer to confirm proper transmitter operation over our stated frequency range of operation 5 degrees ceslius to 45 celsius. This data is proprietary however. Strix Systems is satisfied that we fully comply with our obligations under seciton 15.407 (g) or the FCC rules." Question #6: Please provide operational description or theory of operation. Reponse: From Client: "Attached is the complete users guide will all information required. Comment: There is nothing unique about an 802.11x wireless access point." Kyle Fujimoto Test Engineer -- Compatible Electronics, Inc. -- Brea Division Phone:(714) 579-0500 Fax: (714) 579-1850 [email protected] http://www.celectronics.com -----Original Message----- From: Mike Kuo <[email protected]> To: "'[email protected]'" <[email protected]>, "Scott McCutchan (E-mail)" <[email protected]> Date: Mon, 10 Nov 2003 15:19:46 -0800 Subject: Strix Systems, FCC ID:RFM-ACCESS-ONE, AN03T3261 ( UNII ) > Hi Scott and Kyle : > > Sorry for the long delay. I have done the technical review with the > following questions: > > Question #1: As indicated in the test report, output power was measured > with > power meter. Section 5.2 of main test report did not list such power > meter. > Please provide the power meter information. Since you are using power > meter > to measure DTS , please also provide the power sensor specification to > make > sure the bandwidth is wide enough to measure this device. > > Question #2: In the Expository statement made by the applicant, this > device > can communicate with Bluetooth device. Based upon this device is > equipped > with 802.11 a/b/g radio, please explain how this device can communicate > with > Bluetooth device. > > Question #3: In accordance with user manual, the 802.11 a/b/g radio > will be > shipped as add-on device. In the user manual provide the instruction 3 > on how > to install this radio. In addition, user manual also indicates that > this > device can detect the type of antenna that can be used with this radio. > Please provide detail technical descrip…

Text truncated - open the document above for the full version.

ID Label/Location Info

1.885" 1.385" Access/One Network TM Tested To Comply With FCC Standards FOR HOME OR OFFICE USE PoE: 48VDC, 0.35A Max DC: 18VDC, 1A Max Strix Systems, Inc. Made In Mexico 622-0003-01 Rev. B 622-0003-01 Rev. B 622-0004-01 Rev. B Made In Mexico 622-0004-01 Rev. B Tested To Comply With FCC Standards FOR HOME OR OFFICE USE Access/One Network TM 2.485" 1.985" Strix Systems, Inc. Materials: Silver - Gray Mylar Black text, Arial typeface or equiv. Clear thermal laminate Overall stack-up .008" or less FCC ID: RFM-ACCESS-ONE FCC ID: RFM-ACCESS-ONE Area for placement of barcode label ... crop-marks to be visible on label. Area for placement of barcode label ... crop-marks to be visible on label.

Parts List/Tune Up Info

ANTENNA GAIN FOR THE ANTENNAS Both antennas have a gain of 0 dBi per the client. Both antennas are manufactured by Strix Systems themselves.

RF Exposure Info

MPE Calculations For RF Exposure Requirements Emulation Engine Model: EE a/b/g Page 1 of 2 MAXIMUM PERMISSIBLE EXPOSURE FOR UNII Calculations Given E= √ (30*P*G) / d and S = E ^ 2 / 3770 where E= Field Strength in Volts / Meter P = Power in Watts G = Numeric antenna gain d = distance in meters S = Power Density in milliwatts / square centimeter Combining equations and rearranging the terms to express the distance as a function of the remaining variables yields d = √ ((30*P*G) / (3770*S)) Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = 100*d (m) yields d = 100√ ((30*(P/1000)*G) / (3770*S)) d = 0.282 * √ (P*G/S) where d = distance in cm P = Power in mW G = Numeric Antenna Gain S = Power Density in mW / cm ^ 2 P (mW) = 10 ^ (P(dBm) /10) and G (numeric) = 10 ^ (G(dBi)/10) MPE Calculations For RF Exposure Requirements Emulation Engine Model: EE a/b/g Page 2 of 2 MAXIMUM PERMISSIBLE EXPOSURE FOR UNII (continued) yields d = 0.282*10^((P+G)/20) √S Equation (1) where d = MPE safe distance in cm P = Power in dBm G = Antenna Gain in dBi S = Power Density Limit in mW / cm^2 Combining equations and rearranging the terms to express the distance as a function of the remaining variables yields d = √ ((30*P*G) / (3770*S)) Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = 100*d (m) yields d = 100 √ ((30*(P/1000)*G) / (3770*S)) d = 0.282 * √ (P*G/S) where d = distance in cm P = Power in mW G = Numeric Antenna Gain S = Power Density in mW / cm^2 Results EUT output power = 17.31 dBm Antenna Gain = 0.0 dBi S = 1.0 mW / cm ^ 2 from 1.1310 Table 1 Substituting these parameters into equation (1) above: MPE Safe Distance = 2.1 centimeters Note: For mobile or fixed location transmitters, the minimum separation distance is 20 cm, even if calculations indicate that the MPE distance would be less.

Test Report

Report Number: B30825D2 FCC Part 15 Subpart B and FCC Subpart E Test Report 802.11 a/b/g Wireless Access Point Model: Access / One Network Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 21 FCC PART 15, SUBPART B and SUBPART E TEST REPORT for 802.11 A/B/G WIRELESS ACCESS POINT MODEL: ACCESS / ONE NETWORK Prepared for STRIX SYSTEMS, INC. 310 NORTH WESTLAKE BLVD., SUITE 150 WESTLAKE VILLAGE, CALIFORNIA 91362 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ SCOTT McCUTCHAN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: AUGUST 5, 2003 REPORT APPENDICES TOTAL BODY A B C D E PAGES 21 2 2 2 24 69 120 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30825D2 FCC Part 15 Subpart B and FCC Subpart E Test Report 802.11 a/b/g Wireless Access Point Model: Access / One Network Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Alexander Berg(VP, R&D)

[email protected]818-251-1042Fax: 818-251-1099

Test Firm

Compatible ElectronicsScott McCutchan

714-579-0500Fax: 714-579-1850

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15E	5.26 GHz - 5.32 GHz	54.00 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. Grantee must ensure that installation and use procedures comply with 15.407 integral antenna and indoor-use-only requirements. This device must utilize an EPROM identification mechanism as described in this filing to allow user installation. Grantee is responsible to ensure that only the transmitter as specified in this filing can be used with this device. Section 15.107/15.109 complies with Class A limits. Marketing restriction per section 15.3(h) applied.
