RI2AP-200Digital Audio Player With FM Transmitter

Sodiff E&T Co., Ltd.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: May 11, 2004
Application Purpose: Original Equipment
Date of Application: May 11, 2004
Equipment Note: Digital Audio Player With FM Transmitter
Company: Sodiff E&T Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USER’S MANUAL AP-200 SODIFF E&T Co., Ltd. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. FCC RF INTERFERENCE STATEMENT Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. ◎ Caution () Do not change or modify the product without permission or authority of manufacturer. It may cause undesirable operations, permanent damages or harmful interferences. ◎ Notice () · Design and specification are subject to change without notice for product improvement purposes. Introduction!! Thank you for purchasing our compact digital audio player iLyn!!! iLyn's digital audio players are designed and manufactured to meet the international quality standards. These products undergo humidity, impact, dust, vibration, and drop tests to assure high quality. Thank you once again for purchasing the AP-200 and we hope that you’ll be satisfied with the superior quality of AP-200. SODIFF E&T reserves the copyrights to the product manual, pictures, and software. These cannot be used or redistributed in any forms without a prior written approval from SODIFF E&T. Violating copyrights law will result in legal actions. z Contents of this manual and the products specification may change without prior notices. Components Model : AP-200 Series Manual AAA Battery USB CABLE AUDIO CABLE Install CD Portable necklace w/ earphone Table of Contents Introduction ....................................................................................................................... i Components ........................................................................................................ ii Table of Contents ......................................................................................................... iii Product Features .................................. Loading Saved Frequency .............................. View ........................................ Recording .............................. Turning iLyn On/Off .............................. FM Recording .............................. Connecting to Computer .............................. Listening to Recorded Files .............................. File Copy, Transfer, Delete ..............................Main Menu .............................. Disconnecting from Computer...........................Setup Menu .............................. Selecting Mode .............................. User Logo .............................. Playback .............................. Net Sync .............................. Section Repeat .............................. Installing UMS driver on Windows 98 ...... PLAY MENU .............................. Firmware Upgrade – Installing iLyn Explorer ...... FM Transmit.............................. - Installing Driver ...... FM Radio .............................. Firmware Upgrade .............................. Presetting FM Radio Frequency ..................... Forced Upgrade of Firmware .................. Warning .......................................................................................... Troubleshooting .......................................................................................... Product Specification for iLyn .......................................................................................... Product Warranty .......................................................................................... Product Features -. MP3, WMA music file playback and lyrics function (LRC TYPE) This MP3 player can store and play typical MP3 files as well as Microsoft Window Media Audio files. It also has lyrics function. -. FM RADIO / Direct Recording This product is equipped with functions that are available only on high-end models such as FM radio tuner, FM digital recording, and recording of the output from all analog audio into MP3 files without a PC. -. Play & Plug This product can store any type of data without having to install a separate program (except on Win98). -. Built-in Equalizer 5 preset equalizers to choose from during playback (Normal, Rock, Pop, Live, Classic). -. Voice Recording You can save/transfer up to 38 hours (128MB memory) of high quality voice recording in mp3 format. -. Playback You can select such playback functions like “One”, “All One”, “All RPT”, “Random”, “Intro”, “A- B” playback to listen to your MP3 and/or WMA files. -. Folder (Can Create Unlimited Number of Folders) MP3, WMA, REC are stored in folders for easier access and organization. -. Language Support The MP3 player supports Korean, English, Traditional Chinese, and Simplified Chinese fonts so that the title and lyrics of the music can be displayed on the screen. Other languages are also supported with different firmware upgrades. -. Graphic LCD and 3 COLOR LED BACKLIGHT With its graphic LCD displ…

Text truncated - open the document above for the full version.

Block Diagram

Single chip En/Decoder MCU Single chip En/Decoder MCU FM Module FM Module Flash Memory Flash Memory ADCDAC WM 8731 Sample data Sample data Decoded audio data Decoded audio data AUDIO MICFM Encoded Data Data for Decoding Control FM Control FM Control DAC FM Audio SignalFor Encoding FM Audio SignalFor Hearing PC Program Upload Download DC/DC Converter MAX1706 POWER 1*AAA 3V 3V LCD Driver ALL VOL JAZZ CLASSIC POP ROCK VOICE MUSIC REC FM I love you 시스템 구성도 FM Transmit

Cover Letter(s)

1 Mike Kuo To: Mike Kuo; '[email protected]' Cc: H. C. Kim (E-mail) Subject: RE: ACHOM EP Co.,LTD., FCC ID:RI2AP-200, AN04T3797 -----Original Message----- From: Mike Kuo Sent: Friday, March 26, 2004 5:44 PM To: '[email protected]' Subject: FW: ACHOM EP Co.,LTD., FCC ID:RI2AP-200, AN04T3797 -----Original Message----- From: CERTADM Sent: Friday, March 26, 2004 5:42 PM To: Mike Kuo Subject: ACHOM EP Co.,LTD., FCC ID:RI2AP-200, AN04T3797 Notice_content ------------- Question #1: The EUT is digital audio player with FM transmitter. Digital audio player with USB portion under FCC equipment class of JBP : Personal computer peripheral, and the transmitter portion is under FCC equipment class of DXX: Part15 low power communication device transmitter. Based upon two FCC equipment classes with two different part 15 section ( B and C ) on one device, this device shall be filed as composite applications. Since this device is composite device, two TCB assessment will be applied. Please confirm above assessment findings . Question #2: Please provide operational description ( or theory of operation ) for FM transmitter portion . Note : Operational description is required for all Part 15 subpart C low power transmitter device. Question #3: When the device is used as FM transmitter, this device is considered as handheld device. Per ANSI C63.4:2001 section 13.1.4.1( c ) requirement, the handheld device shall be investigated with three orthogonal axes. In the test report, it is not clear that such procedure was followed. Question #4: Applied modulation ANSI C63.4:2001 section 13.1.1.1, since this device is equipped with external audio connector, ANSI C63.4 requires external audio modulation to be applied to the device during the tests. In the test report, there is no indication that such procedure was followed. Question #5: Please provide spectrum plots to show the band edge compliance per section 15.239(a) requirement. Question #6: Please provide schematic diagram for transmitter. Please note : Schematic diagram is required for all Part 15 subpart C transmitter. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

External Photos

IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Inner Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045

ID Label/Location Info

IST Co., Ltd. FCC ID & Label Information of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 FCC ID : RI2AP-200

Internal Photos

Test Report

IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 04-IST-0045 1 of 17 Certification of Compliance CFR 47 Part 15 Subpart B / Class B PC Peripherals CFR 47 Part 15 Subpart C / Operation in the band 88-108 MHz Test Report File No. 04-IST-0045 Date of Issue Apr. 11, 2004 Model AP-200 Kind of Product Digital Audio Player Applicant SODIFF E&T Co.,LTD. Address 678-7, Changman-ri, Kwangtan-myun, Paju City, Kyunggi Province, Korea Manufacturer SODIFF E&T Co.,LTD. Address 678-7, Changman-ri, Kwangtan-myun, Paju City, Kyunggi Province, Korea Test Result (*)Positive ( ) Negative Reviewed By Approved By J.H. Lee / General Manager of EMCG. Chung / Chief - Investigations requested : Measurement to the relevant clauses of F.C.C rules and regulations Part 15 Subpart B – Class B PC Peripherals / FM Broadcast receivers Part 15 Subpart C – Operation in the band 88-108MHz - The test report with appendix consists of 15 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2001. IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 04-IST-0045 2 of 17 TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental condition, Power used 3 Description of test Conducted Emission 4 Radiated Emission 5 Summary 6 Test conditions and data Conducted emissions 0.15 MHz – 30 MHz Applicable Test equipment 7 Data and plots 8-11 Radiated emissions 30 MHz – 1 GHz Applicable Test equipment 12 Data 13 Radiated Output Power & Occupied Bandwidth 14 Data & plots 15-16 IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 04-IST-0045 3 of 17 INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (Yongin Lab., Filed to FCC) San 21-8, Goan-Ri, Baekam-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 4093 FAX : +82 31 333 4094 EMC LABORATORY of IST Co., Ltd. (Yangji Lab., Filed to FCC ) 80, Jeil-RI, Yangji-Myun, Yongin-City Kyonggi-Do, 449-825, Korea TEL : +82 31 323 3012 FAX : +82 31 323 3014 ENVIRONMENTAL CONDITIONS Temperature 14 °C Humidity 38 % Atmospheric pressure 1002 mbar POWER SUPPLY SYSTEM USED Product Information Memory 128MB Voltage 1.5 V Batttery 1 AAA Size Battery LCD Display Graphic LCD Letter(128 x64 dot) Size(WxHxD)/ Weight 43 X 80 X 18mm35g / (Excluding battery) Case Plastic File Transfering Speed 4.5 Mbps Voice Recording MPEG 1, 2, 2.5 Layer-3, VAD Noise Ratio 90dB Earphone Output 10mW Output Frequency Rage 20Hz ~ 20KHz IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 04-IST-0045 4 of 17 DESCRIPTIONS OF TEST Conducted Emissions: The measurement were performed over the frequency range of 0.15MHz to 30MHz using a 50 Ω /50uH LISN as the input transducer to a Spectrum Analyzer or a Field Intensity Meter. The measurements were made with the detector set for “Peak” amplitude within an bandwidth of 10KHz or for “quasi-peak” within a bandwidth of 9KHz. - Procedure of Test The line-conducted facility is located in a shielded room. The wooden table 80cm height is placed 40cm away from the vertical wall and 1.5m away from the other wall of the shielded room. The LISNs are bonded to bottom of the shielded room. The EUT is located on the wooden table with distance more than 80cm from the LISN and powered from the powered LISN .The peripheral equipment is powered from the other LISN. Power to the LISNs are filtered by a noise cutting power line filters. All electrical cables are shielded by braided tinned steel tubing with inner φ 1.2cm. If the EUT is a DC-powered device, power will be derived from the source power supply it normally will be powered from and this supply lines will be connected to the appropriate LISN. All interconnecting cables more than 1m were shortened by non-inductive bundling to a 1m length. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditions. The RF output of the LISN was connected to the R/S receiver to determine the frequency producing the maximum emission from the EUT. The frequency producing the maximum level was re-measured using Quasi-Peak detector and average detector by manual measurement or final measurement program of R&S, after scanned by automatic Peak mode for frequency range from 0.15 to 30MHz. The bandwidth of the receiver was set to 10kHz. The EUT, peripheral equipment, and interconnecting cables were arranged and manipulated to maximize each EME emission. 215 >150 >40 80 Receiver DUT LISN 80 ≥ 80 80 40 ≥ 80 Measuring apparatus Mains Filter Mains Front side Equipment under test Coaxial cable Artificial mains networ k Screened room Non-metallic support 80 IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 04-IST-0045 5 of 17 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for “quasi-peak” within a bandwidth of 120KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-conical and log-periodic antennas, and spectrum analyzer to determine the frequency producing the max. emission in anechoic chamber. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turn-table azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30MHz to 230MHz using bi-conical antenna and 230 to 1000MHz using log-periodic antenna. Above 1GHz, linearly polarized double ridge horn antennas were used. Final measurements were made at open site with 3 or 10 meters test distance using Bi-log antenna, Bi…

Text truncated - open the document above for the full version.

Test Setup Photos

IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045 IST Co., Ltd. Test Photos of AP-200 EMC LABORATORY Ref . TEST REPORT NO. : 04-IST-0045
