RI5WB-1Wrist Bluetooth speaker

INTRODUCTION Thank you for purchasing your Jambanz wearable speaker. This product is designed to provide high quality wireless sound for your iPad™, iPhone™, iPod™, computer or other Bluetooth® audio device. This Quick Bluetooth Connection Guide explains the basic operation and care of the unit. Please read them carefully and keep for future reference. Maintenance • Store your Jambanz bracelet in its “flat” state, on a level surface away from sources of direct sunlight or excessive heat. • Clean your unit with a soft cloth lightly moistened only with mild soap and water. Stronger cleaning agents, such as benzene, thinner or similar materials can damage the surface of the unit. Included in Box • One Jambanz Slap Bracelet • One Jambanz micro Bluetooth speaker • Micro USB to USB charging cable Power Button Status Light Band Volume -/+ Jambanz speaker SIDE 1 SIDE 2 SLAP » SYNC » JAM Charging the Unit 1. Plug the micro USB directly into your Jambanz micro speaker. No need to remove the speaker from the band. 2. If the wire is plugged into the speaker correctly, you should hear “Jambanz Charging” 3. Once fully charged, you will hear “Jambanz Charged” and the small blue light will glow steadily. 4. When the light starts to blink it means the battery is low and changing will be necessary soon. Using Bluetooth: Pairing Your Device 1. Charge your Jambanz Micro speaker for at least 5 hours before your first use or until the speaker says “Jambanz Charged.” 2. Turn on Bluetooth capability on your device and make it discoverable (see your device’s instructions to add or setup a Bluetooth device). 3. To pair the Jambanz, PRESS and HOLD the POWER button until you hear “Jambanz On, Hold to Pair.” 4. On your Bluetooth device, “Jambanz” should appear in your list of Bluetooth devices. If it doesn’t appear, switch Bluetooth off and back on again. Select “Jambanz” in the list of devices. 5. When pairing is successful, the device will say “Jambanz Paired, Ready to Jam” and the blue light will glow steadily. Once paired, your device should link to the Jambanz whenever it’s turned on within range. Playing Audio Via Bluetooth: Using the Jambanz 1. Press the play or pause audio from your Bluetooth device. 2. Use the Volume +/- Buttons on your device or your Jambanz to adjust volume. 3. When done listening, press the Power Button to turn the unit off, wait until you hear “Jambanz OFF” SLAP » SYNC »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ü5HRULHQWRUUHORFDWHWKHUHFHLYLQJDQWHQQD ü,QFUHDVHWKHVHSDUDWLRQEHWZHHQWKHHTXLSPHQWDQGUHFHLYHU ü&RQQHFWWKHHTXLSPHQWLQWRDQRXWOHWRQDFLUFXLWGLIIHUHQWIURPWK DWWRZKLFKWKHUHFHLYHULVFRQQHFWHG ü&RQVXOWWKHGHDOHURUDQH[SHULHQFHGUDGLR79WHFKQLFLDQIRUKHOS 7KLVGHYLFHFRPSOLHVZLWK3DUWRIWKH)&&5XOHV2SHUDWLRQLVVXEM HFWWRWKHIROORZLQJWZRFRQGLWLRQV  WKLVGHYLFHPD\QRWFDXVHKD UPIXOLQWHUIHUHQFHDQG  WKLVGHYLFHPXVWDFFHSWDQ\LQWHUIHUHQFH UHFHLYHGLQFOXGLQJLQWHUIHUHQFHWKDWPD\FDXVHXQGHVLUHGRSHUDWLRQ

DATE 2014-01-20 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Jamy Yu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-22891499 fax:+86-0769-22895596 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with: Applicant name Dongguan Earson Audio Technology Co.,Ltd. Address No.2-1 Chuangye Industrial Road, Chuangye Industrial Area, Xinhe Community, Wanjiang District, Dongguan City, Guangdong, China. Dated this 2014-01-20 Agency agreement expiration date: 2014-12-20 By: Shiqiang lu Signature Printed Title: engineer On behalf of : Dongguan Earson Audio technology Co..Ltd Telephone: 0769-89027603

DATE 2014-01-20 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RI5 WB-1 Product Name: Wrist bluetooth speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2014-01-20 By: Shiqiang lu Signature Printed Title: engineer On behalf of : Dongguan Earson Audio technology Co..Ltd Telephone: 0769-89027603

FCCID:RI5WB-1 FCCID:RI5WB-1

东莞市东电检测技术有限公司 Dongguan Dongdian Testing Service Co.,Ltd Tel: 0769-22891499 http://www.dgddt.com IEIE Public Laboratory Page 1 of 1 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz, 4.40dBm (2.75mW) output power] (2.75/5) ·[√2.480(GHz)]= 0.866 <3.0 for 1-g SAR Then SAR evaluation is not required Jamy Yu 2014-02-20

Dongguan Dongdian Testing Service Co., Ltd Report No:DDT-RE140356 Page 1 of 60 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel: +86-0769-22891499 Http://www.dgddt.com Applicant : Dongguan Earson Audio Technology Co.,Ltd. Address : No.2-1 Chuangye Industrial Road, Chuangye Industrial Area, Xinhe Community, Wanjiang District, Dongguan City, Guangdong, China. Equipment under Test : Wrist bluetooth speaker Model No : WB-1 Trade Mark : JAM BANZ, EARSON FCC ID : RI5WB-1 Manufacturer : Dongguan Earson Audio Technology Co.,Ltd. Address : No.2-1 Chuangye Industrial Road, Chuangye Industrial Area, Xinhe Community, Wanjiang District, Dongguan City, Guangdong, China. Report No: DDT-RE140356 Issued Date: 2014/02/21 Dongguan Dongdian Testing Service Co., Ltd Report No:DDT-RE140356 Page 2 of 60 TABLE OF CONTENTS Test report declares......................................................................................................................4 1.Summary of test results ............................................................................................................... 5 2.General test information .............................................................................................................. 6 2.1.Description of EUT ..................................................................................................................... 6 2.2.Accessories of EUT ..................................................................................................................... 6 2.3.Assistant equipment used for test ................................................................................................ 6 2.4.Block diagram of EUT configuration for test ............................................................................. 7 2.5.Test environment conditions ....................................................................................................... 7 2.6.Test laboratory ............................................................................................................................. 7 2.7.Measurement uncertainty ............................................................................................................ 8 3.6dB Bandwidth ............................................................................................................................ 9 3.1.Test equipment ............................................................................................................................ 9 3.2.Block diagram of test setup ......................................................................................................... 9 3.3.Limits .......................................................................................................................................... 9 3.4.Test Procedure ............................................................................................................................. 9 3.5.Test Result ................................................................................................................................... 9 3.6.Original test data ....................................................................................................................... 10 4.Maximum Peak Output Power .................................................................................................. 12 4.1.Test equipment .......................................................................................................................... 12 4.2.Block diagram of test setup ....................................................................................................... 12 4.3.Limits ........................................................................................................................................ 12 4.4. Test Procedure ........................................................................................................................... 12 4.5.Test Result ................................................................................................................................. 12 4.6.Original test data ....................................................................................................................... 13 5.Power Spectral Density ............................................................................................................. 15 5.1.Test equipment .......................................................................................................................... 15 5.2.Block diagram of test setup ....................................................................................................... 15 5.3.Limits ........................................................................................................................................ 15 5.4.Test Procedure ........................................................................................................................... 15 5.5.Test Result ................................................................................................................................. 15 5.6.Original test data ....................................................................................................................... 16 6.Emissions in non-restricted frequency bands ............................................................................ 18 6.1.Test equipment .......................................................................................................................... 18 6.2.Block diagram of test setup ....................................................................................................... 18 6.3.Limits .....................................................................................................…
