RI7LE920NALE920-NAG

LLE920 HHardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05-21 ((Preliminary) LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 2 of 76 APPLICABILITY TABLE PRODUCT LE920--EU LE920--NA LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 3 of 76 SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. The information in this document has been carefully checked and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies or omissions. Telit reserves the right to make changes to any products described herein and reserves the right to revise this document and to make changes from time to time in content hereof with no obligation to notify any person of revisions or changes. Telit does not assume any liability arising out of the application or use of any product, software, or circuit described herein; neither does it convey license under its patent rights or the rights of others. It is possible that this publication may contain references to, or information about Telit products (machines and programs), programming, or services that are not announced in your country. Such references or information must not be construed to mean that Telit intends to announce such Telit products, programming, or services in your country. Copyrights This instruction manual and the Telit products described in this instruction manual may be, include or describe copyrighted Telit material, such as computer programs stored in semiconductor memories or other media. Laws in the Italy and other countries preserve for Telit and its licensors certain exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted material of Telit and its licensors contained herein or in the Telit products described in this instruction manual may not be copied, reproduced, distributed, merged or modified in any manner without the express written permission of Telit. Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Telit, as arises by operation of law in the sale of a product. Computer Software Copyrights The Telit and 3rd Party supplied Software (SW) products described in this instruction manual may include copyrighted Telit and other 3rd Party supplied computer programs stored in semiconductor memories or other media. Laws in the Italy and other countries preserve for Telit and other 3rd Party supplied SW certain exclusive rights for copyrighted computer programs, including the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Telit or other 3rd Party supplied SW computer programs contained in the Telit products described in this instruction manual may not be copied (reverse engineered) or reproduced in any manner without the express written permission of Telit or the 3rd Party SW supplier. Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Telit or other 3rd Party supplied SW, except for the normal non-exclusive, royalty free license to use that arises by operation of law in the sale of a product. LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 4 of 76 Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement. Copyrighted Materials Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by law. No part of the software or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without prior written permission of Telit High Risk Materials Components, units, or third-party products used in the product described herein are NOT fault-tolerant and are NOT designed, manufactured, or intended for use as on-line control equipment in the following hazardous environments requiring fail-safe controls: the operation of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic Control, Life Support, or Weapons Systems (High Risk Activities"). Telit and its supplier(s) specifically disclaim any expressed or implied warranty of fitness for such High Risk Activities. Trademarks TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service names are the property of their respective owners. Copyright © Telit Communications S.p.A. 2012. LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 5 of 76 Contents 1. Introduction ........................................................................................................... 9 1.1. Scope ............................................................................................................................ 9 1.2. Audience ................................…

Text truncated - open the document above for the full version.

LLE920 HHardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05-21 ((Preliminary) LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 2 of 76 APPLICABILITY TABLE PRODUCT LE920--EU LE920--NA LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 3 of 76 SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. The information in this document has been carefully checked and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies or omissions. Telit reserves the right to make changes to any products described herein and reserves the right to revise this document and to make changes from time to time in content hereof with no obligation to notify any person of revisions or changes. Telit does not assume any liability arising out of the application or use of any product, software, or circuit described herein; neither does it convey license under its patent rights or the rights of others. It is possible that this publication may contain references to, or information about Telit products (machines and programs), programming, or services that are not announced in your country. Such references or information must not be construed to mean that Telit intends to announce such Telit products, programming, or services in your country. Copyrights This instruction manual and the Telit products described in this instruction manual may be, include or describe copyrighted Telit material, such as computer programs stored in semiconductor memories or other media. Laws in the Italy and other countries preserve for Telit and its licensors certain exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted material of Telit and its licensors contained herein or in the Telit products described in this instruction manual may not be copied, reproduced, distributed, merged or modified in any manner without the express written permission of Telit. Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Telit, as arises by operation of law in the sale of a product. Computer Software Copyrights The Telit and 3rd Party supplied Software (SW) products described in this instruction manual may include copyrighted Telit and other 3rd Party supplied computer programs stored in semiconductor memories or other media. Laws in the Italy and other countries preserve for Telit and other 3rd Party supplied SW certain exclusive rights for copyrighted computer programs, including the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Telit or other 3rd Party supplied SW computer programs contained in the Telit products described in this instruction manual may not be copied (reverse engineered) or reproduced in any manner without the express written permission of Telit or the 3rd Party SW supplier. Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Telit or other 3rd Party supplied SW, except for the normal non-exclusive, royalty free license to use that arises by operation of law in the sale of a product. LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 4 of 76 Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement. Copyrighted Materials Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by law. No part of the software or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without prior written permission of Telit High Risk Materials Components, units, or third-party products used in the product described herein are NOT fault-tolerant and are NOT designed, manufactured, or intended for use as on-line control equipment in the following hazardous environments requiring fail-safe controls: the operation of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic Control, Life Support, or Weapons Systems (High Risk Activities"). Telit and its supplier(s) specifically disclaim any expressed or implied warranty of fitness for such High Risk Activities. Trademarks TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service names are the property of their respective owners. Copyright © Telit Communications S.p.A. 2012. LLE920 Hardware User Guide 1vv0301026 Rev.0 - draft4 – 2013-05- Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 5 of 76 Contents 1. Introduction ........................................................................................................... 9 1.1. Scope ............................................................................................................................ 9 1.2. Audience ................................…

Text truncated - open the document above for the full version.

- Antenna Specification - BOM - Tune up procedure

Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 1 Rev.00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 2 Rev.00

Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 1 Rev.00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 2 Rev.00

Label Location “Contains FCC ID：RI7LE920NA “Contains IC：5131A-LE920NA

Label Location “Contains FCC ID：RI7LE920NA “Contains IC：5131A-LE920NA

Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 3 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 4 Rev.00 Antenna

Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 3 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 5, 2013 A1 - 4 Rev.00 Antenna

Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 07, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT LE920-NAG Model LE920-NAG Frequency band (Operating) GSM/GPRS/EDGE 850MHz: 824.2MHz ~ 848.8MHz GSM/GPRS/EDGE 1900MHz: 1850.2MHz ~ 1909.8MHz WCDMA/HSDPA/HSUPA Band II: 1852.4MHz ~ 1907.6MHz WCDMA/HSDPA/HSUPA Band IV: 1712.4MHz ~ 1752.6MHz WCDMA/HSDPA/HSUPA Band V: 826.4MHz ~ 846.6MHz LTE Band I: 1920.0MHz ~ 1980.0MHz LTE Band II: 1850.0MHz ~ 1910.0MHz LTE Band IV: 1710.0MHz ~ 1755.0MHz LTE Band V: 824.0MHz ~ 849.0MHz LTE Band XVII: 704.0MHz ~ 716.0MHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification 1. Laird DBA6927C1 / Dipole Blade Omnidirectional Antenna Gain: 0.5 dBi (698~960MHz), Gain: 2.2 dBi (1710~2700MHz) 2. Laird DBA6927 / LTE Dipole Antenna Gain: 0.99 dBi (698~960MHz), Gain: 2.81 dBi (1710~2700MHz) Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 07, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Average output power GSM850 : 32.20 dBm (1659.587mW) GPRS850 : 28.49 dBm (706.318mW) for 4Up EDGE850 : 23.89 dBm (244.906mW) for 4Up GSM1900 : 29.30 dBm (851.138mW) GPRS1900 : 25.39 dBm (345.940mW) for 4Up EDGE1900 : 23.09 dBm (203.704mW) for 4Up WCDMA Band II : 24.96 dBm (313.329mW) HSDPA Band II : 24.93 dBm (311.172mW) HSUPA Band II : 24.92 dBm (310.456mW) WCDMA Band IV : 24.93 dBm (311.172mW) HSDPA Band IV : 24.83 dBm (304.089mW) HSUPA Band IV : 24.82 dBm (303.389mW) WCDMA Band V : 24.93 dBm (311.172mW) HSDPA Band V : 24.91 dBm (309.742mW) HSUPA Band V : 24.86 dBm (306.196mW) LTE Band I : 23.59 dBm (228.560mW) LTE Band II : 24.64 dBm (291.072mW) LTE Band IV : 24.02 dBm (252.348mW) LTE Band V : 24.06 dBm (254.683mW) LTE Band XVII : 24.57 dBm (286.418mW) Tune up limit (Frame Average Power) GSM850 : 24 dBm ± 2 dB GPRS850 : 30 dBm ± 2 dB EDGE850 : 24 dBm ± 2 dB GSM1900 : 21 dBm ± 2 dB GPRS1900 : 27 dBm ± 2 dB EDGE1900 : 23 dBm ± 2 dB WCDMA Band II : 24 dBm +1/-3 dB WCDMA Band IV : 24 dBm +1/-3 dB WCDMA Band V : 24 dBm +1/-3 dB LTE Band I : 23 dBm ± 2 dB LTE Band II : 23 dBm ± 2 dB LTE Band IV : 23 dBm ± 2 dB LTE Band V : 23 dBm ± 2 dB LTE Band XVII : 23 dBm ± 2 dB Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: The maximum output power is 32.20dBm (1659.587mW) at 824.2MHz (without 1.12 numeric antenna gain.) Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 07, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d GP E   30 & 377 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   22 0796.0 100/377 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 07, 2013 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: GPS000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 GSM850 mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 128824.4398.1071.12200.08870.55 GPRS850 mode(4Up): Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 190836.61584.8931.12200.35320.55 EGPRS850 mode(4Up): Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 190836.6398.1071.12200.08870.55 GSM1900 mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 8101909.8199.5261.66200.06591 GPRS1900 mode(4Up): Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 8101909.8794.3281.66200.26241 EGPRS1900 mode(4Up): Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 8101909.8316.2281.66200.10451 WCDMA Band II mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 92621852.4316.2281.66200.10451 HSDPA Band II mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 94001880.0316.2281.66200.10451 HSUPA Band II mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 92621852.4316.2281.66200.10451 Compliance Certification Services Inc. Report No.: T130708W02 Date of Issue: August 07, 2013 Page 5 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. WCDMA Band IV mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 13121712.4316.2281.66200.10451 HSDPA Band IV mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm 2 ) 13121712.4316.2281.66200.10451 HSUPA Band IV mode: Ch.Frq.(MHz)P (m…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 171 Rev.00 FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & INDUSTRY CANADA RSS-132 & RSS-133 TEST REPORT For LE920-NAG Trade Name: LE920 Model: LE920-NAG Issued to Telit Communications S.P.A. Via Stazione di Prosecco 5/B 34010 Sgonico, Trieste - Italy Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: July 24, 2013 Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 July 24, 2013 Initial Issue ALL Kelly Cheng Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 3 Rev.00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 7 3.1 EUT CONFIGURATION .............................................................................................................. 7 3.2 EUT EXERCISE ......................................................................................................................... 7 3.3 GENERAL TEST PROCEDURES .................................................................................................. 7 3.4 DESCRIPTION OF TEST MODES ................................................................................................. 8 4. INSTRUMENT CALIBRATION ................................................................................................. 9 4.1 MEASURING INSTRUMENT CALIBRATION ........................................................................... 9 4.2 MEASUREMENT EQUIPMENT USED ............................................................................ 10 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 11 5. FACILITIES AND ACCREDITATIONS ................................................................................. 12 5.1 FACILITIES ............................................................................................................................ 12 5.2 EQUIPMENT ........................................................................................................................... 12 5.3 LABORATORY ACCREDITATIONS AND LISTING ..................................................................... 12 5.4 TABLE OF ACCREDITATIONS AND LISTINGS .......................................................................... 13 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 14 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 14 6.2 SUPPORT EQUIPMENT ..................................................................................................... 14 7. FCC PART 22 & 24 REQUIREMENTS & INDUSTRY CANADA RSS-132 & RSS-133 ... 15 7.1 99% BANDWIDTH ............................................................................................................. 15 7.2 PEAK POWER ......................................................................................................................... 36 7.3 AVERAGE POWER ............................................................................................................... 39 7.4 ERP & EIRP MEASUREMENT .......................................................................................... 42 7.5 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................. 47 7.6 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ............................. 82 7.7 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT .......................... 156 7.8 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT .................................... 163 APPENDIX II PHOTOGRAPHS OF TEST SETUP .................................................................... 170 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 4 Rev.00 1. TEST RESULT CERTIFICATION Applicant: Telit Communications S.P.A. Via Stazione di Prosecco 5/B 34010 Sgonico, Trieste - Italy Manufacturer: Telit Communications S.P.A. Via Stazione di Prosecco 5/B 34010 Sgonico, Trieste - Italy Equipment Under Test: LE920-NAG Tr a d e N a m e : LE920 Model Number: LE920-NAG Date of Test: July 9, 2008 ~ July 25, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & IC RSS-132 Issue 2: September 2005 and IC RSS-133 Issue 5: February 2009 No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA-603-C and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC Rule FCC PART 22 Subpart H, PART 24 Subpart E, IC RSS-132 Issue 2 and IC RSS-133 Issue 4. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Miller Lee Angel Cheng…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 114 Rev.00 FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & INDUSTRY CANADA RSS-132 & RSS-133 TEST REPORT For LE920-NAG Trade Name: LE920 Model: LE920-NAG Issued to Telit Communications S.P.A. Via Stazione di Prosecco 5/B 34010 Sgonico, Trieste - Italy Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: July 26, 2013 Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 July 26, 2013 Initial Issue ALL Kelly Cheng Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 3 Rev.00 TABLE OF CONTENTS 1. JTEST RESULT CERTIFICATION ........................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION .............................................................................................................. 6 3.2 EUT EXERCISE ......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES .................................................................................................. 6 3.4 DESCRIPTION OF TEST MODES ................................................................................................. 7 4. INSTRUMENT CALIBRATION ................................................................................................. 8 4.1 MEASURING INSTRUMENT CALIBRATION ........................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 9 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ................................................................................. 11 5.1 FACILITIES ............................................................................................................................ 11 5.2 EQUIPMENT ........................................................................................................................... 11 5.3 LABORATORY ACCREDITATIONS AND LISTING ..................................................................... 11 5.4 TABLE OF ACCREDITATIONS AND LISTINGS .......................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 13 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 13 6.2 SUPPORT EQUIPMENT ..................................................................................................... 13 7. FCC PART 22 & 24 REQUIREMENTS & INDUSTRY CANADA RSS-132 & RSS-133 ... 14 7.1 99% BANDWIDTH ............................................................................................................. 14 7.2 PEAK POWER ......................................................................................................................... 33 7.3 ERP & EIRP MEASUREMENT .......................................................................................... 44 7.4 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................. 51 7.5 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ............................. 76 7.6 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT .......................... 108 7.7 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT .................................... 111 APPENDIX II PHOTOGRAPHS OF TEST SETUP .................................................................... 113 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: RI7LE920NA IC: 5131A-LE920NA Report No.: T130708W02-RP1 Page 4 Rev.00 1. JTEST RESULT CERTIFICATION Applicant: Telit Communications S.P.A. Via Stazio…

Text truncated - open the document above for the full version.
