Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 42 | 27 | 700.5 MHz - 713.5 MHz | 132.00 mW | 1M10W7D | 0.0123
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesOutput power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM integrators. This device is to be used only for mobile and fixed application. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter evaluation procedures as documented in this filing. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. The highest antenna gain including cable loss, must not exceed 11.0 dBi for Band 2 and Band 25, 8 dBi for Band 4 and Band 66, 12.4 dBi for Band 5, 11.6 dBi for Band 12, 12.1 dBi for Band 13, 12.3 dBi for Band 26, 11.6 dBi for Band 85, 11.4 dBi for Band 71. This device contains functions that are not operational in U.S. Territories. This filing is only applicable for U.S. operations.
