RIPHM160Handheld marine transceiver

Page 1 Rev. 3 Commercial in Confidence Operational Logic of HM160 Page 2 Rev. 3 Engineering Specification Change Record Rev. No. Change Date Name Revision No.: 0.1 Date: Apr 12, 2013 Page 3 Rev. 3 RF Radiation Information RF Radiation Profile Your radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at operating duty factors of up to 50% transmitting and is authorized by the FCC for occupational use only. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio radiates measurable RF energy only while it is transmitting (during talking in PTT mode), not when it is receiving (listening) or in standby mode. The device complies with SAR and/or RF field strength limits of RSS-102 requirement RF Radiation Safety In order to ensure user health, experts from relevant industries including science, engineering, medicine and health work with international organizations to develop standards for safe exposure to RF radiation. These standards consist of: ¾ United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J; ¾ American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992; ¾ Institute of Electrical and Electronic Engineers (IEEE) C95. 1 – 1999; ¾ International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998; FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy. Part 15 Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. Note:“Changes or Page 4 Rev. 3 modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. Please note that the above information is applicable to EU countries only. Page 5 Rev. 3 TABLE OF CONTENT A. KEY FUNCTION ........................................................................................................................ 6 B.1 POWER ON/OFF (HARDWARE) .............................................................................................. 7 B.2 VOLUME CONTROL (HARDWARE)........................................................................................... 7 B.3 SQUELCH (HARDWARE) ........................................................................................................... 7 B.4 UP/DOWN............................................................................................................................... 7 B.5 16/9 CHANNEL......................................................................................错误！未定义书签。6 B.6 HI/LO TX POWER.................................................................................................................... 8 B.7 WX............................................................................................................................................ 8 B.8 BAND....................................................................................................................................... 9 B.9 SCAN....................................................................................................................................... 10 B.10 MEMORY OPEARTION .................................................................................................. 11 B.11 WATCH................................................................................................................................. 11 B.12 BACKLIGHT.......................................................................................................................... 13 B.13 KEYLOCK............................................................................................................................. 13 C. SPECIAL FUNCTION OPERATION ....................................................................................... 13 C.1 TX TIME OUT........................................................................................................................ 13 C.2 POWER SAVE MODE.............................................................................................................. 13 C.3 DINSTICT TONE...................................................................................................................... 13 C.4 RX …

Text truncated - open the document above for the full version.

深圳九州海全通科技股份有限公司 Shenzhen Jiuzhou Himunication Technology Co.,Ltd FCC ID: RIPHM160 DATE: Jun 03, 2013 To whom it may concern: We the undersigned, hereby authorize Shenzhen Huatongwei International Inspection Co., Ltd to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Shenzhen Huatongwei International Inspection Co., Ltd on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Shenzhen Jiuzhou Himunication Technology Co.,Ltd. Sincerely yours, Shenzhen Jiuzhou Himunication Technology Co.,Ltd. oliver.zou / RD manager Fax: + 86_755_26947285 Tel: + 86_755_26947359 E-mail: [email protected]

深圳九州海全通科技股份有限公司 Shenzhen Jiuzhou Himunication Technology Co.,Ltd Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Shenzhen Jiuzhou Himunication Technology Co.,Ltd. would like the following documents regarding this submission for FCC ID: RIPHM160 to be kept confidential. 1. Block Diagram 2. Theory of Operation 3. Schematic 4. Tune-up procedure 5. Part list The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Shenzhen Jiuzhou Himunication Technology Co.,Ltd. oliver.zou / RD manager Fax: + 86_755_26947285 Tel: + 86_755_26947359 E-mail: [email protected]

Shenzhen Jiuzhou Himunication Technology Co.,Ltd. FCC ID: RIPHM160 DATE: Jun 02, 2013 Dear sir / madam This equipment meets the requirements of the FCC Rules, Parts 80.203(b)3, as applicable. Programming of this product’s transmit frequencies can be performed only by the manufacturer of by service or by maintence personal. The operator cannot program transmit frequencies using the equipment’s external operation controls. Sincerely yours, Shenzhen Jiuzhou Himunication Technology Co.,Ltd oliver.zou / RD manager Fax: + 86_755_26947285 Tel: + 86_755_26947359 E-mail: [email protected]

Product Declaration June 03, 2013 FCC ID: RIPHM160 To Whom It May Concern, We , Shenzhen Jiuzhou Himunication Technology Co.,Ltd hereby declare that the hardware of our (A handheld marine transceiver) Model Number: HM160A is exactly Model Number HM160, HM160 and HM160A are named differently due to marketing purposes. Please contact me if you have any question. Sincerely yours, Oliver.zou/RD Manager Shenzhen Jiuzhou Himunication Technology Co.,Ltd Fax: +86-755-26947285 Tel: +86-755-26947359

FCC PART 80 TEST REPORT FCC Part 80 Report Reference No. ..................... : FCC ID. ............................................. : TRE13030160 R/C: 80910 RIPHM160 Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Apr 22, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Shenzhen Jiuzhou Himunication Technology Co.,Ltd Address............................................. : B702,7F,Jiuzhou Electric Building,southern No.12 Road,Hi-Tech Industrial Park,Nanshan District,Shenzhen,China 518057 Test specification: Standard ........................................... : FCC Part 80: STATIONS IN THE MARITIME SERVICES TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: A handheld marine transceiver Trade Mark ....................................... : / Manufacturer .................................... : Shenzhen Jiuzhou Himunication Technology Co.,Ltd Model/Type reference ....................... : HM160 List Model ......................................... : HM160A Modulation ......................................... PM Channe Separation ............................ 25KHz Operation Frequency ......................... From 156.05 MHz to 157.425 MHz Rated Power .................................... : 5 Watts(36.99dBm)/1 Watts(30.00dBm) Ratings.............................................. : DC 7.4 V Result ................................................ : Positive Report No.: TRE13030160 Page 2 of 61 Issued:2013-04-22 FCC ID: RIPHM160 T E S T R E P O R T Test Report No. : TRE13030160 Apr 22, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : A handheld marine transceiver Model /Type : HM160 Listed Models : HM160A Applicant : Shenzhen Jiuzhou Himunication Technology Co.,Ltd Address : B702,7F,Jiuzhou Electric Building,southern No.12 Road,Hi-Tech Industrial Park,Nanshan District,Shenzhen,China 518057 Manufacturer : Shenzhen Jiuzhou Himunication Technology Co.,Ltd Address : B702,7F,Jiuzhou Electric Building,southern No.12 Road,Hi-Tech Industrial Park,Nanshan District,Shenzhen,China 518057 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE13030160 Page 3 of 61 Issued:2013-04-22 FCC ID: RIPHM160 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT Configuration 5 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Discription of Tested Modes 8 3.6. Statement of the measurement uncertainty 8 3.7. Test Description 9 3.8. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS 12 4.1. Conducted Emissions Test 12 4.2. Occupied Bandwidth and Emission Mask Test 15 4.3. Transmitter Radiated Spurious Emssion 21 4.4. Spurious Emssion on Antenna Port 25 4.5. Modulation Charcateristics 33 4.6. Frequency Stability Test 37 4.7. Maximum Transmitter Power 39 4.8. Receiver Radiated Spurious Emssion 43 4.9. Receiver Conducted Spurious Emssion 49 5. TEST SETUP PHOTOS OF THE EUT 53 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 56 Report No.: TRE13030160 Page 4 of 61 Issued:2013-04-22 FCC ID: RIPHM160 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 80: STATIONS IN THE MARITIME SERVICES. TIA/EIA 603 D: Land Mobile PM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS Report No.: TRE13030160 Page 5 of 61 Issued:2013-04-22 FCC ID: RIPHM160 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Apr 01, 2013 Testing commenced on : Apr 01, 2013 Testing concluded on : Apr 22, 2013 2.2. Product Description The Shenzhen Jiuzhou Himunication Technology Co.,Ltd’s Model: HM160 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT A handheld marine transceiver Model Number HM160,HM160A Rated Output Power 5 Watts(36.99 dBm)/1 Watts(30.00 dBm) Modilation Type PM for Analog Voice DSC function Not Supported DSC function Emission Designator Analog 16K0G3E for 25KHz Channel Separation Channel Separation Analog Voice 25KHz Antenna Type External Frequency Range From 156.05 MHz to 157.425 MHz 2.3. Equipment under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / …

Text truncated - open the document above for the full version.
