RJPRDHC-0202N0-0XInductive Tag Reader Module

ASSA ABLOY Identification Technologies GmbH

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Sep 06, 2006
Application Purpose: Original Equipment
Date of Application: Sep 06, 2006
Equipment Note: Inductive Tag Reader Module
Frequency Range: 13.56000000 - 13.56000000
Company: ASSA ABLOY Identification Technologies GmbH
Country: Germany

Documents & Files

Select a file to view

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Document Nr.: QSI-040902-OM-1-a-UserManual Dual ISO Module, V2.0 ACG Identification Technologies GmbH Am Klingenweg 6A 65396 Walluf Germany Phone +49 (0) 6123 791 0 Fax +49 (0) 6123 791 199 www.acg-id.com [email protected] ACG HF Multi ISO RFID Reader Document No.: 1508-USM-01-0-02 Firmware: Version 1.0 User Manual ACG HF Multi ISO RFID Reader V1.0 ACG Identification Technologies GmbH 1 Edition Three - June 2006 ACG Identification Technologies GmbH (ACG) reserves the right to make changes to its products or services or to discontinue any product or service at any time without notice. ACG provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products. Therefore, ACG assumes no liability and is not responsible for customer applications or product or software design or performance relating to systems or applications incorporating ACG products. In addition, ACG assumes no liability and is not responsible for infringement of patents and/or any other intellectual or industrial property rights of third parties, which may result from assistance provided by ACG. ACG products are not designed, intended, authorized or warranted to be suitable for life support applications or any other life critical applications that could involve poten- tial risk of death, personal injury or severe property or environmental damage. With the edition of this document, all previous editions become void. Indications made in this manual may be changed without previous notice. Composition of the information in this manual has been done to the best of our knowledge. ACG does not guarantee the correctness and completeness of the details given in this manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since, despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips. The installation instructions given in this manual are based on advantageous boundary conditions. ACG does not give any guarantee promise for perfect function in cross environments. The ACG logo is a registered trademark of ACG Identification Technologies GmbH. The mifare ® logo is a registered trademark of Philips Electronic N.V. All other products mentioned in this document might be brands or brand names of the different suppliers. Copyright © 2006 ACG Identification Technologies GmbH (ACG) This document may be downloaded onto a computer, stored and duplicated as nec- essary to support the use of the related ACG products. Any other type of duplication, circulation or storage on data carriers in any manner not authorized by ACG represents a violation of the applicable copyright laws and shall be prosecuted. ACG HF Multi ISO RFID Reader V1.0 ACG Identification Technologies GmbH 2 Safety Instructions / Warning - Read before start-up! • The device may only be used for the intended purpose designed by for the manufacturer. The operation manual should be conveniently kept available at all times for each user. • Unauthorized changes and the use of spare parts and additional devices that have not been sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such unauthorized measures shall exclude any liability by the manufacturer. • The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors, or omissions in the manual or automatically set parameters for a device or for an incorrect application of a device. • Repairs may be executed by the manufacturer only. • Only qualified personnel should carry out installation, operation, and maintenance procedures. • Use of the device and its installation must be in accordance with national legal requirements and local electrical codes. • When working on devices the valid safety regulations must be observed. ACG HF Multi ISO RFID Reader V1.0 ACG Identification Technologies GmbH 3 Preface Read This First About This Guide This manual describes the ACG HF Multi ISO Reader Module. Its goal is to describe the reader, how it works, how to integrate it and how to use it. If You Need Assistance Our application center is located in Europe to provide direct support. For more information, please contact your nearest ACG Sales Center. The contact addresses can be found on our home page: http://www.acg-id.com ACG HF Multi ISO RFID Reader V1.0 ACG Identification Technologies GmbH 4 Table of contents 1 Scope ............................................................................................. 11 2 Extended Documentation ............................................................. 11 3 Definitions and Abbreviations ..................................................... 12 3.1 Definitions .................................................................................................. 12 3.1.1 Anti-collision loop ................................................................................ 12 3.1.2 Hex notation ........................................................................................ 12 3.1.3 ASCII notation ..................................................................................... 12 3.2 Abbreviations.............................................................................................. 13 4 Supported tags.............................................................................. 15 5 The mifare ® Transponder Family ................................................. 17 5.1 mifare ® Standard ........................................................................................ 17 5.1.1 Sector 0 / Block 0 ................................................................................ 17 5.1.2 Blocks 3, 7, 11, 15, ............................................................................ 18 5.2 State Diagram ................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

EMV-Prüfzentrum EMI/EMC-Testcenter Coordinates: Äussere Frühlingstrasse 45 y D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] y http://www.senton.de Senton GmbH y Äussere Frühlingstrasse 45 y D-94315 Straubing EMCCert DR. RAŠEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt 06 September 2006 In reference to FCC ID RJPRDHC-0202N0-0X Justification for Part 15 Unlicensed Modular Transmitter Approval according to DA 00-1407 1. Own RF shielding Complied, see EUT internal photographs. No shieldings required 2. Buffered Modulation inputs Complied, see schematic diagrams 3. Own power supply regulation Complied, voltage regulated power supply on board, see schematic diagram 4. Antenna requirements Complied, integrated antenna 5. Test in stand-alone configuration Complied, see test report for details. 6. Own FCC ID Complied, the exterior label will be „Contains FCC ID RJPRDHC-0202N0-0X" 7. The Modular Transmitter must comply with any specific rule and the manufacturer must provide adequate instructions. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the user guide. 8. RF Exposure requirements Not applicable since the unit operates under section 15.225 of the FCC rules, the reference guide contains general installation and operation instructions. Johann Roidt Senton GmbH

Cover Letter(s)

Federal Communications Commission 445 12 th Street SW Washington, DC 20554 USA Request for Confidentiality in accordance with CFR 0.457 and 0.459 06 September 2006 EMCCert DR. RAŠEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt RE: Certification Application FCC ID: RJPRDHC-0202N0-0X Please be advised that the following information is to be held confidential on behalf of ACG Identification Technologies GmbH: • Schematics • Parts List • Block Diagram • Technical Description The application contains technical information which ACG Identification Technologies GmbH deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

External Photos

Created by Erich Rohrhofer ACG Identification Technologies GmbH 27.06.2006 Photos RDHC-0202N0-0X Created by Erich Rohrhofer ACG Identification Technologies GmbH 27.06.2006 Created by Erich Rohrhofer ACG Identification Technologies GmbH 27.06.2006

ID Label/Location Info

TYPE LABEL RDHC-0202N0-0x LABEL SIZE: 21,00 x 13,00 mm

Internal Photos

Test Report

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 55449-050757 (Edition 1) Page 1 of 48 Pages Straubing, 05 December 2005 T E S T - R E P O R T No. 55449-050757 (Edition 1) for RDHC-020xN0-0x Inductive Tag Reader Module Applicant: ACG Identification Technologies AT GmbH Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207, 15.215 and 15.225 Industry Canada Radio Standards Specifications RSS-Gen Issue 1, Section 7.2.2 and RSS-210 Issue 6, Sections 2.2, 2.6, A2.6 (Category I Equipment) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55449-050757 (Edition 1) Page 2 of 48 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 4 3 Identification of the Test Laboratory ........................................................................... 5 4 Summary .................................................................................................................... 6 5 Operation Mode and Configuration of EUT................................................................. 7 6 Measurement Procedures........................................................................................... 8 6.1 Bandwidth Measurements .................................................................................... 8 6.2 Conducted AC Powerline Emission ...................................................................... 9 6.3 Radiated Emission Measurement 9 kHz to 30 MHz ........................................... 11 6.4 Radiated Emission in Fully or Semi Anechoic Room.......................................... 13 6.5 Radiated Emission at Open Field Test Site........................................................ 15 6.6 Carrier Frequency Stability ................................................................................. 16 7 Photographs Taken During Testing .......................................................................... 18 8 Test Results .............................................................................................................. 24 8.1 Occupied Bandwidth........................................................................................... 26 8.2 Bandwidth of the Emission ................................................................................. 31 8.3 Designation of Emissions ................................................................................... 33 8.4 Conducted Powerline Emission Measurement 150 kHz to 30 MHz................... 34 8.5 Spectrum Mask................................................................................................... 37 8.6 Radiated Emission Measurement 9 kHz to 30 MHz .......................................... 39 8.7 Radiated Emission Measurement 30 MHz to 1 GHz ......................................... 41 8.8 Carrier Frequency Stability ................................................................................. 43 8.9 Exposure of Humans to RF Fields...................................................................... 46 9 Referenced Regulations ........................................................................................... 47 10 Charts taken during testing ....................................................................................... 48 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55449-050757 (Edition 1) Page 3 of 48 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : RDHC-020xN0-0x Parts 2 : 1 Serial number(s): 45000856 Manufacturer: ACG Identification Technologies AT GmbH Type of equipment: Inductive Tag Reader Module Version: As delivered FCC ID: Additional parts/accessories: Technical data of EUT Application frequency range: 13.553 - 13.567 MHz Frequency range: 13.553 - 13.567 MHz Operating frequency: 13.56 MHz Type of modulation: ASK Pulse train: --- Pulse width: --- Number of RF-channels: 1 Channel spacing: --- Designation of emissions 3 : 10K0A1D Type of antenna: Integrated loop on printed board Size/length of antenna: 65 x 43 mm Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 5.00 V minimum voltage: 4.25 V maximum voltage: 5.75 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55449-050757 (Edition 1) Page 4 of 48 Pages 2 Administrative Data Application details Applicant (full address): ACG Identification Technologies AT GmbH Parkring 1 A-8074 Grambach Contact person: Herr Erich Rohrhofer Contract identification: BF05 - 098 Receipt of EUT: 28 November 2005 Date(s) of test: November - December 2005 Note(s): Report details Report number: 55449-050757 Edition: 1 Issue date: 05 December 2005 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55449-050757 (Edition 1) Page 5 of 48 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: Senton GmbH EMI/EMC Test Center Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-P-171/94-02 FCC test site registration number 90926 Industry Canada test site registration: IC 3050 Contact person: Mr. Johann Roidt Phone: (+49) (0)9421 5522-0 Fax: (+49) (0)9421 5522-99 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55449-050757 (Edition 1) Page 6 of 48 Page…
