Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
www.tuv.com Test Report No.: 14007527 001 Appendix 4 page 9 of 9 1.6 User Manual
www.tuv.com Test Report No.: 14007527 001 Appendix 3 page 1 of 7 Appendix 3 Construction Photos www.tuv.com Test Report No.: 14007527 001 Appendix 3 page 2 of 7 1.1 External view 1.1.1 Front view 1.1.2 Rear view www.tuv.com Test Report No.: 14007527 001 Appendix 3 page 3 of 7 1.1.3 Side view 1 1.1.4 Side view 2 www.tuv.com Test Report No.: 14007527 001 Appendix 3 page 4 of 7 1.1.5 Side view 3 1.1.6 Side view 4
www.tuv.com Test Report No.: 14007527 001 Appendix 4 page 2 of 9 1.1 FCCID Label Artwork The yellow rectangle shows the location of the Rating Label.
www.tuv.com Test Report No.: 14007527 001 Date: 24.01.2005 page 2 of 14 Table of Content Page Cover Page .................................................................................1 Table of Content ..........................................................................2 Product information.......................................................................................................4 Manufacturers declarations ....................................................................................................................... 4 Product function and intended use........................................................................................................... 4 Submitted documents ................................................................................................................................ 4 Special accessories and auxiliary equipment.......................................................................................... 4 List of Test and Measurement Instruments.................................................................5 Result FCC Part 15 โ Subpart C ...................................................................................6 Subclause 15.203 โ Antenna Information....................................................................... Pass................. 6 Subclause 15.204 โ Antenna Information....................................................................... Pass................. 6 Subclause 15.207 โ Disturbance Voltage on AC Mains ................................................ Pass................. 6 Subclause 15.247 (a) โ Carrier Frequency Separation.................................................. Pass................. 7 Subclause 15.247 (a) โ Time of Occupancy (Dwell Time) ............................................. Pass................. 8 Subclause 15.247 (a) โ 20 dB Bandwidth .............................................................................. .................. 9 Subclause 15.247 (a) โ Hopping Sequence .................................................................... Pass.................9 Subclause 15.247 (a) โ Equal Hopping Frequency Use ................................................ Pass............... 10 Subclause 15.247 (a) โ Receiver Input Bandwidth ........................................................ Pass............... 11 Subclause 15.247 (a) โ Receiver Hopping Capability.................................................... Pass............... 11 Subclause 15.247 (b) โ Peak Output Power ................................................................... Pass............... 11 Subclause 15.247 (b) โ Band edge compliance ............................................................. Pass............... 12 Subclause 15.247 (c) โ Spurious Conducted Emissions .............................................. Pass............... 12 Subclause 15.247 (c) โ Spurious Radiated Emissions.................................................. Pass............... 13 Appendix 1 โ Test protocols 59 pages Appendix 2 โ Test setup 2 pages Appendix 3 โ Photo documentation 7 pages www.tuv.com Test Report No.: 14007527 001 Date: 24.01.2005 page 3 of 14 Appendix 4 โ Product documentation 9 pages www.tuv.com Test Report No.: 14007527 001 Date: 24.01.2005 page 4 of 14 Product information Manufacturers declarations Transmitter Receiver Operating frequency range 2402 - 2480 MHz 2402 - 2480 MHz Type of modulation FHSS modulation FHSS modulation Number of channels 79 79 Channel separation 1 MHz 1 MHz Type of antenna Dielectric Antenna Dielectric Antenna Antenna gain (dBi) 1.65 Power level fix Type of equipment stand alone stand alone Connection to public utility power line Yes Nominal voltage V nor : 3.6 V V nor : 3.6 V Independent Operation Modes Page scan Inquiry scan Connection state - ACL Link Connection state - SCO Link Product function and intended use The test item is a Wireless Keyboard based on the Bluetooth technology. Bluetooth is a short-range radio link intended to be a cable replacement between portable and/or fixed electronic devices. Bluetooth operates in the unlicensed ISM Band at 2.4 GHz. In the US a band of 83.5 MHz width is available. In this band, 79 RF channels spaced 1 MHz apart are defined. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625 ฮผs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. The symbol rate on the channel is 1 Ms/s. Submitted documents Circuit Diagram Block Diagram Bill of material User manual Special accessories and auxiliary equipment The product has been tested together with the following additional accessory: 1. AC/DC Power adaptor Model number: IT03024UK Input: 100-240VAC Output: 5.0VDC 200mA www.tuv.com Test Report No.: 14007527 001 Date: 24.01.2005 page 5 of 14 List of Test and Measurement Instruments Kind of Equipment Manufacturer Type S/N Test Receiver Rohde & Schwarz ESH-3 890173/033 L/I/S/N Rohde & Schwarz ESH 3-Z5 849876/026 Oscilloscope HP 54713B US34510455 Test Receiver Rohde & Schwarz ESVP 882402/033 Absorbing Clamp Rohde & Schwarz MDS-21 979 3/4 Test Receiver Rohde & Schwarz ESVS30 842807/009 Biconical Antenna Rohde & Schwarz HK116 841489/015 Log.-Periodic Antenna Rohde & Schwarz HL223 841516/017 Universal Power Analyzer Voltech PM3000A 9915 Reference Impedance Network Voltech IEC 555 Standard 9946 AC Power Source California Instr. 4500L HK51895 Trip-Loop Antenna Chase LLA6142 1019 Double Ridge Horn Antenna EMCO 3115 9002-3351 Double Ridge Horn Antenna EMCO 3115 9002-3347 RF Comms Test Set HP 8920B US36492628 Spectrum Analyser + Tracking G. HP 8596E 3639A00758 Signal Generator Rohde & Schwarz SMY 01 844146/024 Signal Generator Rohde & Schwarz SMY 01 844146/023 BiLog Antenna EMCO 3143 9607-1287 Isotropic Field Probe Holladay HI-4422 90956 Power Amplifier Kalmus 757-LC 7620-1 Power Amplifier Kalmus 122-FC 7โฆ
Text truncated - open the document above for the full version.
www.tuv.com Test Report No.: 14007527 001 Appendix 2 page 2 of 2 Set-up for Radiation Emission (Transceiver) Set-up for Voltage Disturbance in AC mains
Unit 8, 25/F., Skyline Tower ยท Hong Kong ยท Hong Kong
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 800.00 ยตW |
