RLY-BLE01BLE module

BLE Module User manual BLE Module Brand Name Brand NameBrand Name Brand Name: : : : ADATA Model No. Model No.Model No. Model No. : : : : BT10ZAC1 KEY FEATURES:
Bluetooth® v4.1 specification compliant ■ Bluetooth Smart ■ 128KB memory: 64KB RAM and 64KB ROM ■ Support for Bluetooth v4.1 specification host stack including ATT, GATT, SMP, L2CAP, GAP ■ RSSI monitoring for proximity applications ■ 32kHz and 16MHz crystal or system clock ■ Switch-mode power supply ■ Programmable general purpose PIO controller ■ 10-bit ADC ■ 12 digital PIOs ■ 3 analogue AIOs ■ UART ■ Debug SPI ■ 4 PWM modules
<900nA current consumption in dormant mode ■ Wake-up interrupt and watchdog timer
Radio performance  TX power: +8dBm  RX sensitivity: -88dBm Pinout and Terminal Description Pin Numbe r Pin Name Pin Type Descriptio n 1 GND4 GND GND 2 GND3 GND GND 3 WAKE_1 Input has no internal pull-up or pull-down, use external pull down. Input to wake module from hibernate or dormant. 4 VDD_BATT Supply voltage Supply voltage 1.8V - 3.6V 5 GND5 GND GND 6 VDD_PADS1 Positive supply for all digital I/O ports Supply voltage 1.2V - 3.6V 7 SPI_PIO1 Input with strong internal pull-down Selects SPI debug on PIO[8:5] 8 PIO[11]1 Bidirectional with programmable strength internal pull up/ down Programmable I/O line. 9 PIO[10]1 10 PIO[9]1 11 SPI_MISO1 Bidirectional with programmable strength internal Programmable I/O line or debug SPI MISO selected by SPI_PIO8 12 SPI_MOSI1 pull up/ down Programmable I/O line or debug SPI MOSI selected by SPI_PIO7. 13 SPI_CSB1 Programmable I/O line or debug SPI chip select (CS#) selected by SPI_PIO6. 14 SPI_CLK1 Programmable I/O line or debug SPI CLK selected by SPI_PIO5. 15 PIO[4]1 Bidirectional with programmable strength internal pull up/ down Programmable I/O line or SPI serial flash chip select (SF_CS#) 16 PIO[3]1 Programmable I/O line or SPI serial flash data (SF_DIN) input. If connecting to SPI serial flash, this pin connects to SI on the serial flash. 17 GND2 GND 18 UART_RX1 Bidirectional with programmable strength internal pull up/ down Programmable I/O line PIO[1] or UART RX. 19 UART_TX1 Programmable I/O line PIO[0] or UART TX. 20 AIO[0]1 Bidirectional analogue Analogue programmable I/O line. 21 AIO[1]1 22 AIO[2]1 SPI Master Interface SPI Flash Interface Pin Flash_VDD PIO[2] SF_DIN PIO[3] SF_CS# PIO[4] SF_CLK I2C_SCL SF_DOUT I2C_SDA Electrical Characteristics A. Absolute Maximum Ratings Rati Rating Min Max Storage temperature -20 85 °C Battery (VDD_BATT) operation 1.8 3.6 V I/O supply voltage -0.4 3.6 V Other terminal voltages VSS - 0.4 VDD + 0.4 B. Recommended Operating Conditions Operating Condition Min Max Operating temperature range -20 85 °C Battery (VDD_BATT) operation 1.8 3.6 V I/O supply voltage (VDD_PADS1) 1.2 3.6 V Parameter Min Typ Max Unit Logic-0 input voltage -0.4 _ 0.3 xVDD_PADS1 V Logic-1 input voltage 0.7 xVDD_PADS1 _ VDD_PADS1 +0.4 V Logic-0 output volatge ( Load 4 mA) _ _ 0.4 V Logic-1 output voltage (Load 4 mA) 0.75 xVDD_PADS1 _ _ V IOL output current low, VOL max 8 10 mA IOH output current high, VOH min 8 10 mA With strong pull-up -150 -40 -10 uA I²C with strong pull-up -250 uA With strong pull-down 10 40 150 uA With weak pull-up -5 -1 -0.33 uA With weak pull-down 0.33 1 5 uA AIO Input/Output Voltage Levels Min Typ Max Unit Input voltage 0 _ 1.35 V Output voltage 0 _ 1.35 V Auxiliary ADC Min Typ Max Unit Resolution _ _ 10 Bits Input voltage range 0 _ 1.35 V Accuracy INL -1 _ 1 LSB Accuracy DNL 0 _ 1 Offset -1 _ 1 Gain error -0.80% _ 0.80% % Input bandwidth _ 100 _ kHz Conversion time 1.38 1.69 2.75 μs Sample rate _ _ 21000 Samples/s ADC block conversion current _ 410 _ μA Auxiliary DAC Min Typ Max Unit Resolution _ _ 10 Bits Supply voltage 1.3 1.35 1.4 V Output voltage range 0 _ 1.35 Full-scale output voltage 1.3 1.35 1.4 LSB size 0 1.32 2.64 mV Offset -1.32 0 1.32 mV Integral non-linearity -1 0 1 LSB Settling time _ _ 250 ns Antenna characteristics The antenna radiation pattern depends on the mother board layout, placement and external mechanical housing. The following RF characteristics are measured from EVB board. 1. Impedance 2. Antenna Efficiency and Peak Gain Maximum Efficiency at 2450 MHz : 35 % Maximum Peak Gain at 2489 MHz : -1.96 dBi 3D Radiation Patterns 3. 2 D Radiation Patterns Physical Dimensions FCC FEDERAL COMMUNICATIONS COMMISION (FCC) STATEMENT 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference and 2) This device must accept any interference received, including interference that may cause undesired operation of the device. FCC RF Radiation Exposure Statement: 1. This tran…
