8.0" PAD 800P31C 2.7 mm 24.0mm 6 2 1 3 . 8 m m 123.9 mm 8.7 mm

1. TEST METHODOLOGY The RF output of EUT was connected to the power meter by RF cable and attenuator. The pathloss was compensated to the results for each measurement. 2. FCC RULES According to 447498 D01 General RF Exposure Guidance v05 For minimum test separation distance ≤50mm, Wifi standalone SAR test exclusion power threshold is determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison 3.POWER Result Wifi worse case is 2462MHz ：8.8dBm （7.59mW ） Then (7.59 mW/5mm) X √2.462 =2.38 < 3 So SAR evaluation is not applicable BT worse case is 2442MHz：6.5dBm （4.47mW ） Then (4.47 mW/5mm) X √2.442 =1.40 < 3 So SAR evaluation is not applicable

FCC TEST REPORT For 8 " PAD Model Number: 800P**A, 800P**B, 800P**C (1st* could be 0-99 or A-Z, means different client code; 2nd* could be 0-99 or A-Z or blank, stands for the shape or color of enclosure, no impact on Products safety and EMC characteristics); &&800******(& could be “A-Z” or “a-z”, * could be “0-99”, “A-Z”, “a-z”, “-”, “/” or blank, means different client code, no impact on Products safety and EMC characteristics) FCC ID: ROU00006 Report Number : WT148000381 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Digital Electronic Product Testing Center Site Location : No.4 Tongfa Road, Xili Town, Nanshan District, Shenzhen, Guangdong, China Tel : 0086-755-86928965 Fax : 0086-755-86009898-31396 Web : www.smq.com.cn Report No.: WT148000381 Page 2 of 60 Test report declaration Applicant : : Shenzhen KTC Technology Co., Ltd. Address : :The workshop No#1，Northern Wuhe Road,Gangtou,Buji,Longgang,Shenzhen,China Manufacturer : : Shenzhen KTC Technology Co., Ltd. Address : : The workshop No#1，Northern Wuhe Road,Gangtou,Buji,Longgang,Shenzhen,China EUT Description : : Tablet Model No : : 800P32C，800P**A，800P**B，800P**C，&&800****** Trade mark : : / Serial Number : : / FCC ID : : ROU00006 Test Standards: FCC Part 15 15.207, 15.209, 15.247(2012) The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the maximum emissions from the EUT. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with FCC Rules Part 15.207, 15.209 and 15.247. The test report is valid for above tested sample only and shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: Mar.18.2014 (Liu Zheng Mar.18.2014 Checked by: Date: (Yang Dong Ping) Mar.18.2014 Approved by: Date: (Lin Bin) Report No.: WT148000381 Page 3 of 60 TABLE OF CONTENTS TEST REPORT DECLARATION ......................................................................................................... 2 1. TEST RESULTS SUMMARY ................................................................................................... 5 2. GENERAL INFORMATION ...................................................................................................... 6 2.1. Report information .......................................................................................................... 6 2.2. Laboratory Accreditation and Relationship to Customer ......................................... 6 2.3. Measurement Uncertainty ............................................................................................. 7 3. PRODUCT DESCRIPTION ...................................................................................................... 8 3.1. EUT Description ............................................................................................................. 8 3.2. Related Submittal(s) / Grant (s) ................................................................................... 8 3.3. Block Diagram of EUT Configuration .......................................................................... 8 3.4. Operating Condition of EUT ......................................................................................... 9 3.5. Support Equipment List ................................................................................................. 9 3.6. Test Conditions ............................................................................................................... 9 3.7. Special Accessories ....................................................................................................... 9 3.8. Equipment Modifications ............................................................................................... 9 4. TEST EQUIPMENT USED ..................................................................................................... 10 5. CONDUCTED DISTURBANCE TEST ................................................................................. 11 5.1. Test Standard and Limit .............................................................................................. 11 5.2. Test Procedure ............................................................................................................. 11 5.3. Test Arrangement ........................................................................................................ 11 5.4. Test Data ....................................................................................................................... 12 6. RADIATED DISTURBANCE TEST ...................................................................................... 15 6.1. Test Standard and Limit .............................................................................................. 15 6.2. Test Procedure ............................................................................................................. 15 6.3. Test Arrangement ........................................................................................................ 16 6.4. Test Data ....................................................................................................................... 16 7. 20DB BANDWIDTH MEASUREMENT ................................................................................ 28 7.1. LIMITS OF 20dB BANDWIDTH MEASUREMENT ................................................. 28 7.2. TEST PROCEDURE .................................................................................................... 28 Report No.: WT148000381 Page 4 of 60 7.3. TEST SETUP ..................................................................................…

Text truncated - open the document above for the full version.

FCC Part15C Radiated Emission below 1GHz -Front -Rear FCC Part15C Radiated Emission above 1GHz -Front -Rear AC Conducted Emission Test Setup
