RQ7TE573BANG BANG BULLET

2/1/2013 Page 1 of 1 OWNER'S MANUAL Installation Of Battery Remote Controller 1. Remove the battery cover on back of Remote Controller. 2. Install one(1) piece L1028 12V battery in the battery compartment of Remote Controller. 3. Replace the battery cover. 4. Replace the battery when control distance gets short. Main Unit-The Bullet 1. Remove the battery cover on Bullet by pushing in the direction as shown. 2. Install two(2) N/LR1/AM5 1.5V batteries in the battery compartment of Bullet. 3. Replace the battery cover. 4. Replace the batteries when vibration gets weak. Operation 1. Press ON/OFF button on Remote Controller until the Bullet starts vibration at level 1 & blue LED illuminate The unit is now turned to "ON". 2. Press MODE button to select an ideal vibration level and pulse model. 3. The unit has built-in 5 different levels of vibration and 8 different models of pulse. 4. The 5 levels of vibration starts with very light at the beginning and finishes with very heavy vibration on the 5th level. 5. The 8 different models of pulse are specially designed for great pleasure. 6. All these 13 modes are operated in sequence by pressing the MODE button. 7. When you stop using the unit, press ON/OFF buttton to "OFF". The FCC wants you to know FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by party responsible for compliance coulk void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

impedance matching Oscillator LC LPF C15,L4,L5 Power Amplifier MCU U1 Q3 315MHz Signal BLOCK DIAGRAM Data output Q2,Y1,C3,L2 C10,L7 K2K1 ON/OFF MODE Antenna

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT –Top View EUT – Bottom View EUT –Left View EUT – Right View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – Battery Cover Off View EUT – Cover Off View EUT –Main Board Top View EUT –Main Board Bottom View

Circuit Description 1，RF part modulation mode ：OOK . U1 pin6 output High Level to enable ,Low to disable oscillator. Oscillator consists of Q2,Y1,C5,C6，L2, frequency: 315MHz modulated wave matched with C6，C15，L4，L5, amplified with Q3, filtered by C9，C10， L7,to Antenna. 2，MCU Part： 2 keys 3，power supply： DC12v 23A battery

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 22-Jan-2013 Sheet of File: D:\circuit_backup\GavinDesign.ddb Drawn By: Q2 S9018(J8) R851R R410k C5 3pF C46pF R668K Dout L227nH(+/-5%) C7 220pF L1 0.18uH(+/-5%) C12 0.1uF VCC C6 7PF L4 27nH(+/-5%) L5 100nH(+/-5%) Q3 S9018(J8) L60.1uH L8 0.1uH C8360pF C14 0.1uF C13 2/2.2UF C95pF C10 2pF C11 NOP(reserved) L7 0.22uH(+/-5%) ANT VDD 1 IO1 2 IO2 3 R 4 LED 5 TX 6 7 7 GND 8 U1TX MCU DoutLED K1K2 VDD Q1XC6206P502MR Bat12V R2 0 C11uF R1NOP C20.1uF C3 2.2UF VDD VCC R9620 LED LED 0805 blue LED VDD A07175 TE-573 TX_part M11010 1/1M_A Key1ON/OFFKey2Mode K2K1 C15 13PF d=0.55mm F=315MHz L=170mm(2.5+10.7+156.8) D1 1N4007 (reserve) D=3mm, R3reserved R7reserved 1 2 3 Y1 315M SAW FILTER

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). FCC PART 15.231 TEST REPORT For HUSTLER NOVELTIES,LLC 9400 Penfield Ave, Chatsworth, CA 91311, United States FCC ID: RQ7TE573 Report Type: Original Report Product Type: BANG BANG BULLET Test Engineer: Ares Liu Report Number: R2DG130111002-00 Report Date: 2013-01-21 Reviewed By: Ivan Cao RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2DG130111002-00 FCC Part15.231 Page 2 of 16 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 TEST FACILITY ............................................................................................................................................................. 3 SYSTEM TEST CONFIGURATION .......................................................................................................................... 4 JUSTIFICATION ............................................................................................................................................................. 4 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 4 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 4 SUMMARY OF TEST RESULTS ............................................................................................................................... 5 FCC §15.203 - ANTENNA REQUIREMENT ............................................................................................................. 6 APPLICABLE STANDARD .............................................................................................................................................. 6 FCC §15.205, §15.209, §15.231 (B) - RADIATED EMISSIONS ............................................................................... 7 MEASUREMENT UNCERTAINTY .................................................................................................................................... 7 EUT SETUP .................................................................................................................................................................. 7 EMI TEST RECEIVER SETUP ......................................................................................................................................... 8 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 8 TEST PROCEDURE ........................................................................................................................................................ 9 APPLICABLE STANDARD .............................................................................................................................................. 9 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................... 9 TEST RESULTS SUMMARY ............................................................................................................................................ 9 TEST DATA ................................................................................................................................................................ 10 FCC §15.231(C) – 20 DB BANDWIDTH TESTING ................................................................................................ 13 REQUIREMENT ........................................................................................................................................................... 13 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 13 TEST PROCEDURE ...................................................................................................................................................... 13 TEST DATA ................................................................................................................................................................ 13 ENVIRONMENTAL CONDITIONS .................................................................................................................................. 13 FCC §15.231(A) - DEACTIVATION TESTING ...................................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 EUT SETUP ................................................................................................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission View (Below 1GHz) Radiated Emission – Rear View (Above 1GHz)
