RQ7TE573RBANG BANG BULLET

2/1/2013 Page 1 of 1 OWNER'S MANUAL Installation Of Battery Remote Controller 1. Remove the battery cover on back of Remote Controller. 2. Install one(1) piece L1028 12V battery in the battery compartment of Remote Controller. 3. Replace the battery cover. 4. Replace the battery when control distance gets short. Main Unit-The Bullet 1. Remove the battery cover on Bullet by pushing in the direction as shown. 2. Install two(2) N/LR1/AM5 1.5V batteries in the battery compartment of Bullet. 3. Replace the battery cover. 4. Replace the batteries when vibration gets weak. Operation 1. Press ON/OFF button on Remote Controller until the Bullet starts vibration at level 1 & blue LED illuminate The unit is now turned to "ON". 2. Press MODE button to select an ideal vibration level and pulse model. 3. The unit has built-in 5 different levels of vibration and 8 different models of pulse. 4. The 5 levels of vibration starts with very light at the beginning and finishes with very heavy vibration on the 5th level. 5. The 8 different models of pulse are specially designed for great pleasure. 6. All these 13 modes are operated in sequence by pressing the MODE button. 7. When you stop using the unit, press ON/OFF buttton to "OFF". The FCC wants you to know FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by party responsible for compliance coulk void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

impedance matching Antenna MIXER LO RC LPF R12,C17 Q5,C20,C10 LF Amplifier MCU RX DATA INPUT M MOTOR MOTOR DRIVER U1 Q3,Q4 Q7 315MHz Signal BLOCK DIAGRAM L5,C21

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT –Top View EUT – Bottom View EUT –Left View EUT – Right View

EXHIBIT C - EUT EXTERNAL PHOTOGRAPHS EUT –Uncover View EUT – Cover Off View EUT – Cover Off View EUT –Main Board Top View EUT –Main Board Bottom View EUT – Antenna View

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 22-Jan-2013 Sheet of File: D:\circuit_backup\GavinDesign.ddb Drawn By: C220.1uF M1 motor D1IN4148 VCC1 C13 680P C142.2UF R3 Nop R239K L33.5T VCC ANT C211P C9100P R63.3K R5 47k C11100p VCC C19 1.2P 1/1 TE-573 RX_part M11010 B1225 M_A Motor R182.4K L5 5.6uH(1206) L13.9uH(0603) C2315P C204PF C10 1.5p L25.6uH C7100P C8 150p R1320k D24148 C18 330pF R17620 R123.6K C17220P C162.2uF C15 680PF R111MR430K C410nF C24 100PF R16 5.1K C321pF VCC1 C120.1uF BAT3V d=1.00mm F=315MHz L=55mm(5+19+12+18) C250.1uF on shell C26 0.1uF Rx_In Rx_In Motor 1 32 Q5 2SC3356(R25) 1 32 Q4HJ6C(9014C) 1 32 Q3 HJ6C(9014C) Reset 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 U1RX_MCU R733KR13KR851k C5 0.1uF R9120K VCC1 VCC1 R1010K R141.5K 123 45 U2XC6204B202MR VCC VCC1 R1510K VCC1 C3 470uF(DIP) C60.1uF C22.2uF R198.2M VCC VDD VDD VDD VDD C27 22uF 1 32 Q28050d(HY3D) 1 32 Q6 HJ6C(9014C) 1 32 Q78050d(HY3D) C1 100uF(DIP) B1222: R19=1.5M,R3=2.4M,C3=100uF(DIP),Q1 footprint, Revision: reserve D3 1N4007 (reserve) Vin 3 GND 1 Vout 2 U3 XC6206P252MR C2822uF

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). FCC PART 15B, CLASS B TEST REPORT For HUSTLER NOVELTIES,LLC 9400 Penfield Ave, Chatsworth, CA 91311, United States Report Type: Original Report Product Type: BANG BANG BULLET Test Engineer: Ares Liu Report Number: R2DG130121005-00 Report Date: 2013-01-24 Reviewed By: Ivan Cao RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID: RQ7TE573R Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2DG130121005-00 FCC Part15B, Class B Page 2 of 12 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST FACILITY ............................................................................................................................................................. 3 SYSTEM TEST CONFIGURATION .......................................................................................................................... 4 JUSTIFICATION ............................................................................................................................................................. 4 EUT EXERCISE SOFTWARE .......................................................................................................................................... 4 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 4 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 4 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 4 SUMMARY OF TEST RESULTS ............................................................................................................................... 5 FCC §15.109 - RADIATED EMISSIONS ................................................................................................................... 6 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 EUT SETUP .................................................................................................................................................................. 6 EMI TEST RECEIVER SETUP ......................................................................................................................................... 7 TEST PROCEDURE ........................................................................................................................................................ 7 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................... 7 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 7 TEST RESULTS SUMMARY ............................................................................................................................................ 8 TEST DATA .................................................................................................................................................................. 8 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2DG130121005-00 FCC Part15B, Class B Page 3 of 12 GENERAL INFORMATION Product Description for Equipment under Test (EUT) The HUSTLER NOVELTIES,LLC’s product, model number: TE-573R (FCC ID: RQ7TE573R) (the "EUT") in this report was a BANG BANG BULLET, which was measured approximately: 15.5 cm (L) x 3.5 cm (W) x 3.0 cm (H), rated input voltage: DC3.0V from battery. The highest working frequency is 315MHz. * All measurement and test data in this report was gathered from production sample serial number: 130121005 (Assigned by BACL.Dongguan). The EUT was received on 2013-01-22. Objective This report is prepared on behalf of HUSTLER NOVELTIES,LLC in accordance with Part 2, Subpart J, Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to determine compliance with FCC Part 15B, Class B. Related Submittal(s)/Grant(s) No related submittal(s)/Grant(s). Test Facility The Test site used by Bay Area Compliance Laboratories Corp. (Dongguan) to collect test data is located on the No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Test site at Bay Area Compliance Laboratories Corp. (Dongguan) has been fully described in reports submitted to the Federal Communication Commission (FCC). The details of these reports have been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 02, 2012. The facility also complies with the radiated and AC line conducted test site criteria set forth in ANSI C63.4- 2009. The Federal Communications Commission has the reports on file and is listed under FCC Registration No.: 273710. The test site has been approved by the…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emissions View
