RRK-AWLC6080300N Draft 802.11n Wireless Cardbus Adapter

300N Draft 802.11n Wireless Cardbus Adapter Model # AWLC6080 User’s Manual Rev. 1.1 2 Table of Contents 1. Introduction................................................................................................................................. 3 1.1 Package Contents .................................................................................................................. 3 1.2 Features ................................................................................................................................. 3 2. Installation................................................................................................................................... 4 2.1 Install Driver & Utility.......................................................................................................... 4 2.2 Verify Driver Installation.................................................................................................... 12 3. Configuring the Adapter ........................................................................................................... 14 4. Wireless Monitor ...................................................................................................................... 19 4.1 Wireless Information .......................................................................................................... 19 4.2 AP List ................................................................................................................................ 20 4.3 Profile Settings.................................................................................................................... 21 4.4 Configuring Encryption ...................................................................................................... 23 4.5 Ad-hoc and Peer-to-Peer Wireless Networks ..................................................................... 29 4.6 About................................................................................................................................... 32 Appendix A – Specifications ........................................................................................................ 33 Appendix B – Information ............................................................................................................ 34 Technical Support ......................................................................................................................... 36 3 1. Introduction Congratulations on your purchase of the 300N Draft 802.11n Wireless Cardbus Adapter. The 300N Cardbus Adapter provides wireless data rate of up to 300 Mbps* when used with other AirLink101® 300N wireless products. The high bandwidth combined with extended wireless coverage delivers fast and reliable connection for all of your networking applications. A full range of security features such as WEP, WPA-PSK, and WPA2-PSK provide the highest level of wireless network security. The bundled Wireless Utility allows you to set up the adapter with an easy-to-use user interface. Best of all the 300N Cardbus Adapter works with 802.11g and 802.11b network devices ensuring compatibility with your existing wireless products. 1.1 Package Contents Before you begin the installation, please check the items of your package. The package should include the following items: • Wireless Cardbus Adapter • Quick Installation Guide • Installation CD (Driver/Utility/Manual) 1.2 Features • Industry’s highest wireless data rate of up to 300 Mbps* with IEEE 802.11n draft specification version 1.0. • Wider coverage and continuous connectivity eliminates dead spots • 64-bit/128-bit WEP encryption, Pre-shared Key (PSK), and Wi-Fi Protected Access (WPA2) and WPA support provide full protection for your wireless connection • Higher data rate increases the reliability and stability of wireless connections • Great for environments with higher wireless data traffic requirements • Fully backward-compatible with 802.11b/g devices • Works best with AirLink101® 300N wireless router AR680W 4 2. Installation 2.1 Install Driver & Utility This section provides instructions on how to install the 300N Draft 802.11n Wireless Cardbus Adapter. The driver is installed along with the utility. Note: Be sure to power off your computer before inserting the Cardbus adapter. Step 1 Insert the Cardbus adapter into an available Cardbus slot and turn on your computer. Step 2 After turning on the computer, Windows will launch the Found New Hardware Wizard. The Found New Hardware Wizard appears differently depending on your operating system. Click Cancel to quit the wizard and insert the Installation CD into your CD drive. Step 3 The Autorun screen will pop up. Select Install Utility and Driver from the menu. 5 Note: If the Autorun screen doesn’t appear automatically, or if you get a blank white screen, go to Start, Run, and type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK. Windows Vista users: At this point, you may get a warning message like the one below. Make sure that you click Allow to continue with the installation. 6 Step 4 Click Next at the welcome screen. Step 5 Click Next to accept the default destination folder. 7 Step 6 Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt). For Windows Vista, click the Install this driver software anyway button when the security warning appears. 8 Step 7 Click Yes, I want to restart my computer now and then Finish to restart your computer. Step 8 After the computer is restarted, Windows will ask to connect to Windows Update, select No, not this time and click Next. If this screen does not appear, you can skip to Section 2.2. 9 Step 9 Select Install the software automatically and click Next. 10 Step 10 Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt). For Windows Vista, click the Install this driver so…

Text truncated - open the document above for the full version.

June 15, 2007 Federal Communications Commission Authorization and Evaluation Division FCC ID: RRK-AWLC6080 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Leeming / Senior Manager Alpha Networks Inc. Tel: 886-3-563666 ext.6613 Fax: 886-3-5665091 E-mail: [email protected]

Date: June 15, 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Taiwan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS TW as our agent, we still recognize that we are responsible to: h) Comply with the relevant provisions of the certification program; i) Make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; j) Make claims regarding certification only in respect of the scope for which certification has been granted; k) Do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) Upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; l) Use certification only to indicate the products are certified as being in conformity with specified standards; g) Endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) Keep a record of all complaints made known to the us relating to the product compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) Document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, Leeming / Senior Manager Alpha Networks Inc. Tel: 886-3-563666 ext.6613 Fax: 886-3-5665091 E-mail: [email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

Chris Harvey From: vicky.liu [[email protected]] Sent: Sunday, July 08, 2007 10:15 PM To: [email protected]; [email protected] Cc: [email protected] Subject: RE: Alpha Networks Inc., FCC ID: RRK-AWLC6080, Assessment NO.: AN07T6979, Notice#1 Attachments: AWLC6080_Test Plot(960709).pdf; AWLC6080_SF Rev.(960709).pdf Page 1 of 4 7/10/2007 Dear Charveyemc, Thank you for your reply and my answer is as belowing. Q1. Please indicate whether this MIMO device operates as a.A 2x3 Spatial Multiplexed MIMO b.that drives each antenna incoherently c.and whether the unit uses Cyclic Diversity. Ans: a. You can find that the Ralink is a 2T3R device in page 1 of 2860 datasheet . The device supports 2 spatial streams . b. Yes c. Ralink chipset doesn't support Cyclic Diversity in 11b&g . The answer is the same the AR680W (RRK-AR680W;AN07T6875)which you have already reviewed before. Q3. The SAR test report has photographs of a model DWA-645, which appears to be a different device. The SAR test plots include plots for the model DWA-645 WLAN and USB device. Please confirm if these are incorrect photos and plots and update the SAR test report and plots exhibits as needed. Ans:Please find the attachment which I have already revised. In the SAR report page 19 & 20 is compares distance between phantom and EUT(DWA-645(KA2WA645B1;AN07T6680) & AWLC-6080). ----- 轉呈者 vicky.liu/ccsemc 於 2007/07/09 09:11 AM ----- Vicky, thank you for the reply. I see that the manual you have attached does not have the 20cm statement. I have attached the originally submitted manual, which has the 20cm statement on page 34 of 36. I will await your reply to all the questions. Best regards, Chris Harvey From: vicky.liu [mailto:[email protected]] Sent: Friday, July 06, 2007 2:40 AM To: [email protected] Subject: Alpha Networks Inc., FCC ID: RRK-AWLC6080, Assessment NO.: AN07T6979, Notice#1 Dear Charvey, Thank you for your rapidly reply. But I am confused about the Q2, I can not find the the ststement "This equipment should be installed and operated with minimum distance 20cm between the radiator & your body." Could you tell me where can I find it on page ?? "Chris Harvey" <[email protected]> 2007/07/06 05:50 PM 收件人： "'vicky.liu'" <[email protected]> 副本抄送： 主旨： RE: Alpha Networks Inc., FCC ID: RRK-AWLC6080, Assessment NO.: AN07T6979, Notice#1 Page 2 of 4 7/10/2007 PS..This device has already get FCC cert on KA2WA645B1, but changed outlooking. The assemble number is AN07T6680. 2. The Users Manual contains the following RF Exposure statement: "This equipment should be installed and operated with minimum distance 20cm between the radiator & your body." This device is a CardBus card that is categorized as a Portable RF Exposure condition device. The 20cm separation statement is not appropriate. Please provide a revised Users Manual RF exposure statement to address the portable nature of this device. The following is a possible example of another approved CardBus MIMO Users Manual RF Exposure statement: FCC RF Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment, and users must follow specific operating instructions for satisfying RF exposure compliance. This transmitter must not be collocated or operating in conjunction with any other transmitter or antenna. This equipment has been SAR - evaluated and is authorized for use in laptop and notebook computers. ----- 轉呈者 vicky.liu/ccsemc 於 2007/07/06 09:57 AM ----- Dear Vicky Liu, You are listed as the Technical Contact for the above referenced TCB application. The following item(s) need(s) to be resolved before the review can be continued: 1. Please indicate whether this MIMO device operates as a. A 2x3 Spatial Multiplexed MIMO b. that drives each antenna incoherently c. and whether the unit uses Cyclic Diversity. <[email protected]> 2007/07/05 11:05 PM 收件人： <[email protected]> 副本抄送： <[email protected]> 主旨： Alpha Networks Inc., FCC ID: RRK-AWLC6080, Assessment NO.: AN07T6979, Notice#1 Page 3 of 4 7/10/2007 2. The Users Manual contains the following RF Exposure statement: "This equipment should be installed and operated with minimum distance 20cm between the radiator & your body." This device is a CardBus card that is categorized as a Portable RF Exposure condition device. The 20cm separation statement is not appropriate. Please provide a revised Users Manual RF exposure statement to address the portable nature of this device. The following is a possible example of another approved CardBus MIMO Users Manual RF Exposure statement: FCC RF Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment, and users must follow specific operating instructions for satisfying RF exposure compliance. This transmitter must not be collocated or operating in conjunction with any other transmitter or antenna. This equipment has been SAR - evaluated and is authorized for use in laptop and notebook computers. 3. The SAR test report has photographs of a model DWA-645, which appears to be a different device. The SAR test plots include plots for the model DWA-645 WLAN and USB device. Please confirm if these are incorrect photos and plots and update the SAR test report and plots exhibits as needed. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] ________________________________________________________________________ This e-mail transm…

Text truncated - open the document above for the full version.

Chris Harvey From: vicky.liu [[email protected]] Sent: Monday, June 25, 2007 5:04 AM To: [email protected]; [email protected] Cc: [email protected] Subject: RE: RE: RE: Alpha Networks Inc., FCC ID: RRK-AR680W, Assessment NO.: AN07T6875, Notice#1 Page 1 of 11 7/10/2007 Dear Chirs, Thank for your reply and my answer is as belowing. Q: Does this device use Spatial Multiplexing MIMO. Ans: Yes Q: and does it drive each antenna incoherently? Ans: Yes ----- 轉呈者 vicky.liu/ccsemc 於 2007/06/25 04:53 PM ----- Vicky, I am trying to find additional resources to give you additional guidance: I hope the article at this web address can help give some of the theory behind coherent and non-coherent RF channels: "Chris Harvey" <[email protected]> 2007/06/23 11:24 AM 收件人： "'vicky.liu'" <[email protected]>, <[email protected]> 副本抄送： <[email protected]> 主旨： RE: RE: RE: Alpha Networks Inc., FCC ID: RRK-AR680W, Assessment NO.: AN07T6875, Notice#1 http://www.nari.ee.ethz.ch/commth/pubs/files/commag06.pdf Traditionally, multiple antennas (at one side of the wireless link) have been used to perform interference cancellation and to realize diversity and array gain through coherent combining. Noncoherent MIMO-OFDM Systems — With perfect CSI (Channel State Information) at the receiver and no CSI at the transmitter, and fixed transmit power, capacity increases with bandwidth until it saturates and is given by the receive SNR. In the noncoherent case, where neither the transmitter nor the receiver have CSI, the capacity behavior as a function of bandwidth is markedly different: for full-band OFDM systems (i.e., the transmit signal occupies all time-frequency slots), beyond a certain critical bandwidth, “overspreading” occurs, and the capacity goes to zero. The “overspreading” phenomenon was first described in [10] in the context of SISO systems and can be explained as follows. Increasing the bandwidth results in a proportional increase in the number of independent frequency-diversity branches (provided the channel satisfies the uncorrelated scattering assumption). Since the receiver is not assumed to have CSI, these diversity branches contribute to “channel uncertainty” which leads to a capacity penalty. For large bandwidths (and hence small SNR per degree of freedom) this penalty eventually drives the capacity to zero. In the MIMO case, increasing the number of transmit and receive antennas, on the one hand, increases the total number of degrees of freedom for communication and, on the other hand, results in an increase in channel uncertainty. Since the total available transmit power is split uniformly across transmit antennas, increasing the number of transmit antennas results in a smaller SNR per degree of freedom which leads to the existence of a finite optimum (in the sense of capacity maximizing) number of transmit antennas. Increasing the number of receive antennas, on the other hand, yields an increase in the receive SNR and is hence always beneficial. In summary, for MIMO-OFDM systems operating at bandwidths of several GHz, such as MIMO-based ultra-wideband systems, it is generally not advisable to use a large number of transmit antennas. Figure 2 provides a numerical result illustrating this phenomenon. Page 2 of 11 7/10/2007 http://www.nari.ee.ethz.ch/commth/pubs/files/jsac04.pdf QUESTION: We are in the process developing the following systems: Phase array system, Sectorized antenna system, and Spatial Multiplexing Multiple-In Multiple-Out (MIMO) antenna system. From the FCC’s perspective, what are the calculations for the antenna gain of each system? ANSWER: Basic MIMO types of devices can be simply calculated using the sum of all powers into a single antenna element. This is somewhat of an overestimation in the calculation, but usually should meet mobile applications easily. For portable applications, the antennas are generally much closer together and therefore the overestimation is even smaller. However, the FCC, in its TCB training of May 2005, will accept the following calculations for the aforementioned systems: • Spatial Multiplexing Multiple-In Multiple-Out (MIMO) antenna system: spatial MIMO mode antenna systems in which the power is driven incoherently at each frequency, the directional gain equals the gain of each element. All other modes that drive multiple antennas including legacy modes for communicating with no MIMO devices, the directional gain equals the gain of antenna element plus 10 log the number of antenna elements. From: vicky.liu [mailto:[email protected]] Sent: Friday, June 22, 2007 10:07 PM To: [email protected]; [email protected] Cc: [email protected] Subject: RE: RE: RE: Alpha Networks Inc., FCC ID: RRK-AR680W, Assessment NO.: AN07T6875, Notice#1 Dear Chirs, We need your help, because our client wants to get FCC certification as soon as possible. Our client can not understand the question what do you mean, so they can not reply for you. Our client tries to guess what you want to ask and the answer is belowing. Q: Does this device use Spatial Multiplexing Ans: Yes, it supports 2 spatial streams . Q: and does it drive each antenna incoherently? Ans: 1. Does TCB want to know whether there is a phase difference between every antenna ? The phase difference on pcb between every antenna is not a critial parameter in 11n product . I can't find any similar description in 11n standard . If TCB really wants to know it , please explain why he needs this . 2. Does TCB want to know whether the antennas transmit signal at the same time ? Cyclic shift is disable in 11b/g , only Tx 0 is used in 11b/g . Cyclic shift is enable in 11n . Page 3 of 11 7/10/2007 ----- 轉呈者 vicky.liu/ccsemc 於 2007/06/23 09:51 AM ----- Dear Chris, Thank you for your reply. But our client does not understand what do you mean that "Does this device use Spatial Multiplexing and does it drive each antenna incoherently?" Could you explain for this sentence…

Text truncated - open the document above for the full version.

From: vicky.liu [mailto:[email protected]] Sent: Monday, June 25, 2007 5:04 AM To: [email protected]; [email protected] Cc: [email protected] Subject: RE: RE: RE: Alpha Networks Inc., FCC ID: RRK-AR680W, Assessment NO.: AN07T6875, Notice#1 Dear Chirs, Thank for your reply and my answer is as belowing. Q: Does this device use Spatial Multiplexing MIMO. Ans: Yes Q: and does it drive each antenna incoherently? Ans: Yes

Compliance Certification Services Inc. Report No.70613002 Page 1 of 9 External Photo Compliance Certification Services Inc. Report No.70613002 Page 2 of 9

Compliance Certification Services Inc. Report No.70613002 Page 3 of 9 Internal Photo Compliance Certification Services Inc. Report No.70613002 Page 4 of 9 Compliance Certification Services Inc. Report No.70613002 Page 5 of 9 Compliance Certification Services Inc. Report No.70613002 Page 6 of 9 Compliance Certification Services Inc. Report No.70613002 Page 7 of 9 Compliance Certification Services Inc. Report No.70613002 Page 8 of 9 Compliance Certification Services Inc. Report No.70613002 Page 9 of 9

Alpha Antenna Design for 11N Cardbus Illustration of Antenna Location Antenna M Antenna L Antenna R Return Loss of Antenna L Return Loss of Antenna M Return Loss of Antenna R Isolation between Antenna M & Antenna R Isolation between Antenna M & Antenna L Isolation between Antenna R & Antenna L Rotation Angle for scanning 0 90 180 270 Radiation Pattern of Antenna L – H Polarization Peak Gain = -0.23 Radiation Pattern of Antenna L – V Polarization Peak Gain = -10.44 Radiation Pattern of Antenna M – H Polarization Peak Gain = -2.87 Radiation Pattern of Antenna M – V Polarization Peak Gain = -12.94 Radiation Pattern of Antenna R – H Polarization Peak Gain = 0.56 Radiation Pattern of Antenna R – V Polarization Peak Gain = -11

CAM350 PRO V 7.0 : Thu Mar 29 11:45:03 2007 - (Untitled) : art0 01.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:05 2007 - (Untitled) : art0 02.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:06 2007 - (Untitled) : art0 03.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:08 2007 - (Untitled) : art0 04.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:08 2007 - (Untitled) : dd00 1.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:09 2007 - (Untitled) : sm00 1.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:09 2007 - (Untitled) : sm00 4.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:09 2007 - (Untitled) : smd0 01.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:10 2007 - (Untitled) : smd0 04.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:10 2007 - (Untitled) : ssb0 04.pho CAM350 PRO V 7.0 : Thu Mar 29 11:45:10 2007 - (Untitled) : sst0 01.pho

Compliance Certification Services Inc. Reference report: 70226006-SF Report No.: 70613002-SF FCC ID: RRK-AWLC6080 Date of Issue: June 24, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 30 Rev. 00 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For 300N Draft 802.11n Wireless Cardbus Adapter Trade Name: AirLink101 Model: AWLC6080 Issued to Alpha Networks Inc. No.8, Li-shing Road VII, Science-based Industrial Park, Hsinchu, Taiwan R.O.C. Issued by Compliance Certification Services Inc. No. 11, Wugong 6th Rd., Wugu Industrial Park, Taipei Hsien 248, Taiwan. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 70613002-SF Date of Issue: June 24, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. EUT DESCRIPTION ..................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .................5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................................5 3.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................6 3.2 SYSTEM COMPONENTS.................................................................................................7 4. EVALUATION PROCEDURES ...............................................................................................9 5. MEASUREMENT UNCERTAINTY ......................................................................................13 6. EXPOSURE LIMIT ..................................................................................................................14 7. TYPICAL COMPOSITION OF INGREDIENTS FOR LIQUID TISSUE PHANTOMS .15 8. MEASUREMENT RESULTS..................................................................................................16 8.1 SYSTEM PERFORMANCE CHECK..............................................................................16 8.2 TEST LIQUID CONFIRMATION...................................................................................17 8.3 EUT TUNE-UP PROCEDURES AND TEST MODE.....................................................18 8.4 SAR MEASUREMENTS RESULTS...............................................................................21 9. EUT PHOTOS ...........................................................................................................................27 10. EQUIPMENT LIST & CALIBRATION STATUS................................................................28 11. FACILITIES..............................................................................................................................29 12. REFERENCES ..........................................................................................................................29 13. ATTACHMENTS......................................................................................................................30 Compliance Certification Services Inc. Report No.: 70613002-SF Date of Issue: June 24, 2007 Page 3 Rev. 00 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Applicant: Alpha Networks Inc. No.8, Li-shing Road VII, Science-based Industrial Park, Hsinchu, Taiwan R.O.C. Equipment Under Test: 300N Draft 802.11n Wireless Cardbus Adapter Trade Name: AirLink101 Model Number: AWLC6080 Date of Test: March 23 ~ 24, 2007 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE APPLICABLE STANDARDS STANDARD TEST RESULT FCC OET 65 Supplement C No non-compliance noted Deviation from Applicable Standard None The device was tested by Compliance Certification Services Inc. in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C (Edition 01-01). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Johnny Liu Rex Lai Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 70613002-SF Date of Issue: June 24, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product 300N Draft 802.11n Wireless Cardbus Adapter Trade Name AirLink101 Model Number AWLC6080 Model Discrepancy N/A Frequency Range 802.11b: 2400 ~ 2483.5 MHz 802.11g: 2400 ~ 2483.5 MHz 802.11n: 2400 ~ 2483.5 MHz Max. O/P Power: (Conducted/Peak) 802.11b: 23.51 dBm 802.11g: 21.09 dBm 802.11n: 22.96 dBm(HT20) 802.11n: 19.86 dBm(HT40) Sony host: 802.11b: 0.282 W/kg 802.11g: 0.452 W/kg 802.11n: 0.446 W/kg(HT20) 802.11n: 0.215 W/kg(HT40) Acer host: 802.11b: 0.681 W/kg 802.11g: 0.932 W/kg 802.11n: 1.010 W/kg(HT20) 802.11n: 0.969 W/kg(HT40) Max. SAR (1g): Dell host: 802.11b: 0.478 W/kg 802.11g: 0.597 W/kg 802.11n: 1.320 W/kg(HT20) 802.11n: 0.681 W/kg(HT40) Modulation Technique 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g: Orthogonal Fre…
