RRK-WMPND03BMini-PCI Card

User Manual For WMP-ND03B 無線網路卡 Mini-PCI Card Version: 1.1 2008/6/12 Company Confidential This document contains confidential proprietary information and is the property of Alpha Networks Corporation. The contents of this document may not be disclosed to unauthorized persons without the written consent of Alpha Networks Corporation. Company Confidential Revision History Rev. Date Author Reason for Changes 1.0 2008/3/14 Alfred Chin • New release 1.1 2008/6/12 Alfred Chin • Add band 4 (5725~5850MHz) in item 2.2.1.3 and 2.2.4.3 Company Confidential Contents TEST OPERATION MANUAL.................................................................................................................5 Test Utility Installation:.........................................................................................................................5 Configuration:........................................................................................................................................6 1.0 SCOPE......................................................................................................................................................7 1.1 DOCUMENT............................................................................................................................................7 1.2 PRODUCT FEATURES.............................................................................................................................7 2.0 REQUIREMENTS.................................................................................................................................8 2.1 GENERAL REQUIREMENTS....................................................................................................................8 2.2.1 IEEE 802.11a Section...................................................................................................................8 2.2.2 IEEE 802.11b Section...................................................................................................................9 2.2.3 IEEE 802.11g Section...................................................................................................................9 2.2.4 IEEE 802.11 Draft n Section......................................................................................................10 2.2.5 General Section...........................................................................................................................11 2.3 COMPATIBILITY REQUIREMENTS........................................................................................................12 2.4 REGULATORY REQUIREMENTS...........................................................................................................12 2.5 REQUIREMENTS OF RELIABILITY, MAINTAINABILITY AND QUALITY...............................................13 2.6 ENVIRONMENTAL REQUIREMENTS.....................................................................................................13 END PRODUCT LABELING............................................................................................................................15 MANUAL INFORMATION TO THE END USER.............................................................................................15 Company Confidential Test Operation Manual Test Utility Installation: 1. Unzip “ART_V0_5_b25ALL.zip” to “C:\”. 2. The utility must run on Win2000 or WinXP. Hardware Installation: Before insert the card, please execute the below instruction at first !! 1. Win2000 OS : Enter in the directory : C:\ v0_5_b25ALL\art_driver\bin\2000 Execute the uninst_new_drv_2k.bat: Execute the inst_new_drv_2k.bat : WinXP OS : Enter in the directory : C:\ v0_5_b25ALL\art_driver\bin\xp Execute the uninst_new_drv_xp.bat: Execute the inst_new_drv_xp.bat 2. Insert the card, then install the driver , the driver is located at Win2000 OS : C:\ v0_5_b25ALL\art_driver\bin\2000 WinXP OS : C:\ v0_5_b25ALL\art_driver\bin\xp Company Confidential Configuration: 1. Enter the DOS command mode , then change the directory to : C:\ v0_5_b25ALL\art_driver\bin\xp 2. Input the instruction: art \id=2082 Then press enter . ART TEST MODE: 1. Once utility is executed, a menu with test options will appear. To run a test, press the character key that is assigned to the test option. For example, press “c” to run the continuous transmit test, or press “r ” to run the continuous receive test. For example: press “o” to change 11g or 11b test mode, Press “c” to continuous transmit mode . 2. Continuous Transmit Options. a. Before the Continuous Transmit test, need to press “e” first The command will load the calibrate data to the EEROM, then the card can transmit the target power b. The channel frequency, data rate and output power could be changed in continuous transmit options. Press “c” to increase the output power , 11g Power (data rate 6Mbps) is 17dBm, 11b Power is 17dBm , Press ESC to return to the main Test Options menu when finished. Company Confidential 3. Continuous Receive Options Continuous receive options will put the radio into receive mode to allow for radio measurements. Press ESC to return to the main Test Options menu when finished. 1.0 Scope 1.1 Document This document is to specify the product requirements for 802.11 a/b/g/n Mini-PCI Card. This Card is based on Atheros chipset that complied with IEEE 802.11g, IEEE 802.11b, IEEE 802.11n standard from 2.4~2.5GHz, and it can be used to provide up to 54Mbps for IEEE 802.11g, 11Mbps for IEEE 802.11b and 300Mbps for IEEE 802.11n to connect your wireless LAN. With seamless roaming, fully interoperability and advanced security with WEP standard, 802.11a/b/g/n Mini-PCI Card offers absolute interoperability with different vendors’ 802.11g, 802.11b, 802.11 draft n Access Points through the wireless LAN. 1.2 Product Features ü Compatible with IEEE 802.11a high rate standard to provide wireless 54Mbps data rate ü Compatible with IEEE 802.11g high rate standard to provide wireless 54Mbps data …

Text truncated - open the document above for the full version.

General Declaration We, Alpha Networks Inc. declares that device does not have “Ad Hoc on non-US frequencies” while applying for the follow product. FCC ID: RRKWMPND03B If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886- 3-5665091 E-mail: [email protected] 2009/12/12 SSL.XNQOE14C!

Federal Communications Commission Authorization and Evaluation Division Declaration Letter To whom it may concern: We, the undersigned Alpha Networks Inc. hereby to declare our software and associated drivers will not initiate any transmission on DFS frequencies. This includes transmissions for beacon ad-hoc peer-to-peer modes. FCC ID: RRKWMPND03B Model name: WMP-ND03B Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886- 3-5665091 E-mail: [email protected] 2009/12/12 SSL.XNQOE14C!

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: RRKWMPND03B Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886- 3-5665091 E-mail: [email protected] 2009/12/12 SSL.XNQOE14C!

Power of Attorney To whom it may concern: I, the undersigned, Leeming, hereby authorize the person listed in below to act in behalf of me to sign all related documents for Alpha’s FCC application. Kelly Tsai / Senior Manager TEL: 886-3-5636666 FAX: 886- 3-5665091 E-mail: [email protected] Company Name: Alpha Networks Inc. Company Address: No.8 Li-shing 7th Rd., Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Authorization period: Nov 1 st , 2008 ~ Dec 21 st , 2015 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, _________________________________ Leeming / Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886- 3-5781861 E-mail: [email protected] 2009/11/19

Power of Attorney To whom it may concern: We, the undersigned Alpha Networks Inc. hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C and E approval and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. FCC ID: RRKWMPND03B If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886- 3-5665091 E-mail: [email protected] 2009/12/12 SSL.XNQOE14C!

FCC ID: RRK-WMPND03B Report No. : RF981020H04 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Dec. 23, 2009 Dear Application Examiner, Alpha Networks Inc.’s Mini-PCI Card, FCC ID: RRK-WMPND03B, would like to have your authorization as a modular approval. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR9106. 3. “The modular transmitter must have its own power supply regulation.” The modular transmitter has its own power supply regulation built in AR9106. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was placed on an extended card which connected to Notebook Computer as a stand-alone configuration. The EUT was tested via the outside a Notebook Computer. Please see section Photographs of Test Configuration in the test report. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: RRK-WMPND03B Report No. : RF981020H04 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, May Chen Deputy Manager of Hsinchu Certification Service Div. Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID： RRKWMPND03B FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Company Confidential

Company Confidential

Page 3 Page 4 Page 5

FCC ID: RRK-WMPND03B Report No. : RF981020H04 Technical Description This device is a Mini-PCI Card operates in both the 5GHz and 2.4GHz Bands with DSSS and OFDM technique. The transmitter rate could be 11Mbps for 11b; 54Mbps for 11a/g; 144.44Mbps for Draft 802.11n (20MHz); 300Mbps for Draft 802.11n (40MHz). The transmitter of EUT is powered by host equipment. NOTE: 1. There are four antennas provided to this EUT, please refer to the following table: 2.4GHz Chain Manufacture Model No. Antenna Type Connector Antenna Gain (dBi) Cable loss (dB) Net Gain (dBi) Cable length (cm) Chain (0) Antenna (1) WHA YU GROUP C037-510987-A (SSR-91251) Chain (1) Antenna (2) WHA YU GROUP C037-510987-A (SSR-91251) Dipole SMA Straight Plug Reverse 4 0.3 3.7 9.5 5GHz Chain Manufacture Model No. Antenna Type Connector Antenna Gain (dBi) Cable loss (dB) Net Gain (dBi) Cable length (cm) Chain (0) Antenna (1) WHA YU GROUP C037-510988-A (SSR-91252) Chain (1) Antenna (2) WHA YU GROUP C037-510988-A (SSR-91252) Dipole SMA Straight Plug Reverse Band 1: 5.18 Band 2: 5.52 Band 3: 6.63 Band 4: 6.14 0.6 Band 1: 4.58 Band 2: 4.92 Band 3: 6.03 Band 4: 5.54 9.5 2. The EUT incorporates a MIMO function with 802.11n. Physically, the EUT provides two completed transmitters and two completed receivers. 3. The EUT is 2 * 2 spatial MIMO (2Tx & 2Rx) without beam forming function. The antenna configurations are two transmitter antennas and two receiver antennas, as there are 2 Dipole antennas. Spatial multiplexing modes for simultaneous transmission using 2 antennas, and for simultaneous receiver using 2 antennas. 4. The EUT complies with 802.11n standards and backwards compatible with 802. 11a, 802.11b, 802.11g products. 5. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or user's manual. FCC ID: RRK-WMPND03B Report No. : RF981020H04 FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met. Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.
