RRK-WUSND12A802.11a/b/g/n USB module

ENGLISH Quick Install Guide 802.11a/b/g/n USB module Thank you for purchasing the Xtreme N® Dual Band USB Adapter. Follow the easy steps in this guide to properly set up your adapter. Please verify that all the package contents listed below are available. DWA-160 If any of the above items are missing, please contact your reseller. Before You Begin Before installing your new wireless module, please verify the following: • Remove any previous installations of wireless adapters. • Disable any built-in wireless adapters. • Verify the settings such as the wireless network name (SSID) and security settings of the network(s) you want to connect to. Note: If you’ve installed a different manufacturer’s adapter or a different model module, make sure the software is uninstalled before installing the new software. Some utilities may cause a conflict with the new software. Windows ® 7, Windows Vista ® and XP users may use the built-in wireless utility. T H u c U T I C T I © C p a Version 1.4(NA) | May 13, 2010 6DWA What This Product Does The WUS-ND12A is an 802.11a/b/g/n USB module that delivers unrivaled performance for your laptop or desktop computer. Once connected, access your network’s high-speed Internet connection while sharing photos, files, music, video, printers, and storage. Package Contents WUS-ND12A 802.11a/b/g/n USB module CD with drivers and software C • A desktop computer with an available USB slot • Windows® 7, Windows Vista® (32/64-bit), XP (32/64-bit with Service Pack 2 or higher) • 300MHz processor and at least 64MB of RAM • An 802.11n, 802.11g or 802.11a access point or wireless router System Requirements Note: Do NOT plug the adapter into your computer before installing the drivers. Insert the WUS-ND12A Driver CD into the CD-ROM drive. When the autorun screen appears, click Install and follow the on-screen instructions to install the wireless adapter drivers and software. Installation If the CD Autorun function does not automatically start on your computer, go to Start > Run. In the run box type “D:\autorun.exe” (where D: represents the drive letter of your CD-ROM drive) and click OK. 1. o 2. s y P W e w W Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: RRK-WUSND12A”. The grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Declaration for no non-US channel operation We, Alpha Networks Inc. declare that the device does not support any non-US channels in all the operational mode(s), like Ad-Hoc...etc, for the following product. FCC ID: RRK-WUSND12A Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886-3-5665091 E-mail: [email protected] 12/14/2011

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: RRK-WUSND12A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics/Block Diagram/ Operating description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886-3-5665091 E-mail: [email protected] 12/14/2011

FCC ID: RRK-WUSND12A Report No.: RF111109E16 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch December 16, 2011 Dear Application Examiner, Alpha Networks Inc., It’s an 802.11a/b/g/n USB module, FCC ID: RRK-WUSND12A would like to have your authorization as a modular device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip RT5572-QFN76. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is MX25L12835E. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: RRK-WUSND12A Report No.: RF111109E16 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Power of Attorney To whom it may concern: We, the undersigned Alpha Networks Inc. hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C/E approval and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. FCC ID: RRK-WUSND12A If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ Kelly Tsai / Senior Manager Alpha Networks Inc. TEL: 886-3-5636666 FAX: 886-3-5665091 E-mail: [email protected] 2011/12/14

Report No.: 110913E01A 1 Reference NO.:111109E16 CONSTRUCTION PHOTOS OF EUT Report No.: 110913E01A 2 Reference NO.:111109E16

Label drawing 23mm 10mm Label location Model: WUS-ND12A FCC ID: RRK-WUSND12A IC:4833A-WUSND12A

Report No.: 110913E01A 3 Reference NO.:111109E16

Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 1 RF EXPOSURE REPORT APPLICANT: Alpha Networks Inc. ADDRESS: No.8 Li-shing 7th Rd., Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 9 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement. The test results in the report only apply to the tested sample. REPORT NO.: SA110913E01A MODEL NO.: WUS-ND12A FCC ID: RRK-WUSND12A RECEIVED: Sep. 13, 2011 TESTED: Nov. 30, 2011 ISSUED: Dec. 15, 2011 Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 2 TABLE OF CONTENTS RELEASE CONTROL RECORD.....................................................................................3 1. CERTIFICATION......................................................................................................4 2. RF EXPOSURE LIMIT..............................................................................................5 3. MPE CALCULATION FORMULA.............................................................................5 4. CLASSIFICATION....................................................................................................5 5. ANTENNA GAIN.......................................................................................................6 2. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER...........................7 Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110913E01A Original release Dec. 15, 2011 Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 4 1. CERTIFICATION PRODUCT: 802.11a/b/g/n USB module BRAND NAME: Alpha MODEL NO.: WUS-ND12A TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Alpha Networks Inc. TESTED: Nov. 30, 2011 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: WUS-ND12A) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Nov. 10, 2011 ( Lori Chung, Specialist ) APPROVED BY : , DATE: Nov. 10, 2011 ( May Chen, Deputy Manager ) Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 5 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 6 5. ANTENNA GAIN 1. There are two antennas provided to this EUT, please refer to the following table: Transmitter Circuit Manufacture Antenna Type Gain (dBi) Antenna Connector Chain (0) Alpha PCB Printed 2.4GHz : 0.7 5.15~5.25GHz: 2.97 5.25~5.35GHz: 3.27 5.47~5.725GHz :2.60 5.725~5.850GHz :2.60 NA Chain (1) Alpha PCB Printed 2.4GHz : 1.39 5.15~5.25GHz: 3.61 5.25~5.35GHz: 3.98 5.47~5.725GHz :2.87 5.725~5.850GHz :2.87 NA Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 7 2. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): 802.11b: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 114.8 0.7 20 0.027 1.00 Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] Effective Legacy Gain (dBi) = 5 802.11g: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 416.9 0.7 20 0.097 1.00 Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] Effective Legacy Gain (dBi) = 5 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 709.8 1.39 20 0.194 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2422-2452 355.8 1.39 20 0.097 1.00 Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 8 For 15.247(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 251.2 2.6 20 0.091 1.00 Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] Effective Legacy Gain (dBi) = 7.5 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 458.3 2.9 20 0.178 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5755 ~ 5795 486.1 2.9 20 0.189 1.00 Report No.: SA110913E01A Report Format Version 4.0.0 Reference No.:111109E16 9 For 15.407(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DIST…

Text truncated - open the document above for the full version.

Report No.: RF110913E01A 1 Report Format Version 4.0.0 Reference No.:111109E16 FCC TEST REPORT (15.247) REPORT NO.: RF110913E01A MODEL NO.: WUS-ND12A FCC ID: RRK-WUSND12A RECEIVED: Sep. 13, 2011 TESTED: Oct. 04 to Nov. 30, 2011 ISSUED: Dec. 15, 2011 APPLICANT: Alpha Networks Inc. ADDRESS: No.8 Li-shing 7th Rd., Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 119 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110913E01A 2 Report Format Version 4.0.0 Reference No.:111109E16 Table of Contents RELEASE CONTROL RECORD........................................................................................5 1. CERTIFICATION....................................................................................................6 2. SUMMARY OF TEST RESULTS............................................................................7 2.1 MEASUREMENT UNCERTAINTY..........................................................................9 3. GENERAL INFORMATION...................................................................................10 3.1 GENERAL DESCRIPTION OF EUT.....................................................................10 3.2 DESCRIPTION OF TEST MODES.......................................................................13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL........................14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................18 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................19 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................20 4. TEST TYPES AND RESULTS (FOR 2.4GHZ, 2400 ~ 2483.5MHZ BAND)...........22 4.1 CONDUCTED EMISSION MEASUREMENT........................................................22 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................22 4.1.2 TEST INSTRUMENTS..........................................................................................22 4.1.3 TEST PROCEDURES..........................................................................................23 4.1.4 DEVIATION FROM TEST STANDARD.................................................................23 4.1.5 TEST SETUP.......................................................................................................24 4.1.6 EUT OPERATING CONDITIONS.........................................................................24 4.1.7 TEST RESULTS...................................................................................................25 4.2 RADIATED EMISSION MEASUREMENT.............................................................27 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................27 4.2.2 TEST INSTRUMENTS..........................................................................................28 4.2.3 TEST PROCEDURES..........................................................................................30 4.2.4 DEVIATION FROM TEST STANDARD.................................................................30 4.2.5 TEST SETUP.......................................................................................................31 4.2.6 EUT OPERATING CONDITIONS.........................................................................31 4.2.7 TEST RESULTS...................................................................................................32 4.3 6DB BANDWIDTH MEASUREMENT...................................................................61 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT.................................................61 4.3.2 TEST INSTRUMENTS..........................................................................................61 4.3.3 TEST PROCEDURE.............................................................................................61 4.3.4 DEVIATION FROM TEST STANDARD.................................................................61 4.3.5 TEST SETUP.......................................................................................................61 4.3.6 EUT OPERATING CONDITIONS.........................................................................61 4.3.7 TEST RESULTS...................................................................................................62 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................66 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.....................66 4.4.2 INSTRUMENTS....................................................................................................66 4.4.3 TEST PROCEDURES..........................................................................................66 Report No.: RF110913E01A 3 Report Format Version 4.0.0 Reference No.:111109E16 4.4.4 DEVIATION FROM TEST STANDARD.................................................................66 4.4.5 TEST SETUP.......................................................................................................66 4.4.6 EUT OPERATING CONDITIONS.........................................................................66 4.4.7 TEST RESULTS........................................................................…

Text truncated - open the document above for the full version.

Report No.: RF110913E01A-1 1 Report Format Version 4.0.0 Reference No.:111109E16 FCC TEST REPORT (15.407) REPORT NO.: RF110913E01A-1 MODEL NO.: WUS-ND12A FCC ID: RRK-WUSND12A RECEIVED: Sep. 13, 2011 TESTED: Oct. 04 to Dec. 06, 2011 ISSUED: Dec. 15, 2011 APPLICANT: Alpha Networks Inc. ADDRESS: No.8 Li-shing 7th Rd., Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 77 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110913E01A-1 2 Report Format Version 4.0.0 Reference No.:111109E16 Table of Contents RELEASE CONTROL RECORD........................................................................................4 1. CERTIFICATION....................................................................................................5 2. SUMMARY OF TEST RESULTS............................................................................6 2.1 MEASUREMENT UNCERTAINTY................................................................................7 3. GENERAL INFORMATION.....................................................................................8 3.1 GENERAL DESCRIPTION OF EUT.......................................................................8 3.2 DESCRIPTION OF TEST MODES.......................................................................11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL........................12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................15 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................16 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................17 4. TEST TYPES AND RESULTS..............................................................................19 4.1 CONDUCTED EMISSION MEASUREMENT........................................................19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................19 4.1.2 TEST INSTRUMENTS..........................................................................................19 4.1.3 TEST PROCEDURES..........................................................................................20 4.1.4 DEVIATION FROM TEST STANDARD.................................................................20 4.1.5 TEST SETUP.......................................................................................................21 4.1.6 EUT OPERATING CONDITIONS.........................................................................21 4.1.7 TEST RESULTS...................................................................................................22 4.2 RADIATED EMISSION MEASUREMENT.............................................................24 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................24 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS..........25 4.2.3 TEST INSTRUMENTS..........................................................................................26 4.2.4 TEST PROCEDURES..........................................................................................28 4.2.5 DEVIATION FROM TEST STANDARD.................................................................28 4.2.6 TEST SETUP.......................................................................................................29 4.2.7 EUT OPERATING CONDITION............................................................................29 4.2.8 TEST RESULTS...................................................................................................30 4.3 OUTPUT TRANSMIT POWER MEASUREMENT.................................................51 4.3.1 LIMITS OF OUTPUT TRANSMIT POWER MEASUREMENT...............................51 4.3.2 TEST INSTRUMENTS..........................................................................................51 4.3.3 TEST PROCEDURE.............................................................................................52 4.3.4 DEVIATION FROM TEST STANDARD.................................................................52 4.3.5 TEST SETUP.......................................................................................................52 4.3.6 EUT OPERATING CONDITIONS.........................................................................52 4.3.7 TEST RESULTS...................................................................................................53 4.4 PEAK POWER EXCURSION MEASUREMENT...................................................57 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT.................................57 4.4.2 TEST INSTRUMENTS..........................................................................................57 Report No.: RF110913E01A-1 3 Report Format Version 4.0.0 Reference No.:111109E16 4.4.3 TEST PROCEDURE.............................................................................................57 4.4.4 DEVIATION FROM TEST STANDARD.................................................................57 4.4.5 TEST SETUP.......................................................................................................58 4.4.6 EUT OPERATING CONDITIONS.......................................................................…

Text truncated - open the document above for the full version.

Report No.: 110913E01A Reference No.:111109E16 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 110913E01A Reference No.:111109E16 2 RADIATED EMISSION TEST Report No.: 110913E01A Reference No.:111109E16 3
