RSD-22029TXR/C Vehicle

Limited 30-day warranty Product is warranted by Interactive Toy Concepts Limited against manufacturing defects in material and workmanship under normal use for thirty (30) days from the date of purchase. W arranty is validated upon receipt of proof or purchase and confirmation of UPC code. INS-22029-140603-US Lithium Polymer Rechargeable Batteries must be recycled or disposed of properly . RC Cooler 6-P ACK Batteries: The RC Cooler requires aix AA Batteries. 1. Turn the RC Cooler upside down to locate the battery compartment door. 2. Ensure that the RC Cooler is turned off. (The On/Off switch for the RC Cooler is located on the bottom.) 3. Using a Philips screwdriver, open the battery compartment door and insert the 6 AA Batteries according to the proper polarity and replace the door. Note: Make sure to turn off the RC Cooler when not in use or the Batteries will drain. The Controller will turn off on its own when not in use. Controller Battery: The controller requires two AAA Battery. 1. Slide open the Battery Compartment Door at the back of the Controller. 2. Insert the AAA Batteries according to the polarity shown, then replace the Battery Compartment Door. BA TTERY REQUIREMENTS: W elcome to the RC Cooler 6-PACK. This full function Remote Control Cooler has been designed to work outdoors and indoors with its 4 sturdy underside wheels within an effective radio range up to 50 feet (15 Meters). The RC Cooler operates on the 2.4GHz frequency, allowing up to 6 units to work in the same time and place. The RC Cooler holds up to six 12oz (355ml) ice cold cans or other drinks and is compact for easy storage and travel. The internal volume of the Cooler Bucket is 1.32 Gallons (5 Liters). The RC Cooler 6-PACK can carry a payload of up to 11 Lbs (5 Kilograms). Two AAA and six AA Batteries are required (not included) . DELIVER COLD DRINK S BY RADIO CONTROL! 1. Turn on the RC Cooler. The On/Off switch for the RC Cooler is located on the bottom. 2. Press any Button on the Controller . This will sync the Controller to this particular RC Cooler. Note: Once the RC Cooler is synced with the Controller , the connection will be memorized until the RC COOLER is powered off. Note: To sync up to 6 RC Cooler 6-PACKs in the same area and the same time, follow the above procedure one at a time. Ensure only one unsynced RC Cooler is turned on per one Controller during the syncing process. HOW TO SYNC THE CONTROLLER WITH THE RC COOLER 6-PACK: W ARNING: The RC Cooler and Controller are not water resistant. Customers are advised to not submerge the RC Cooler in water as this will cause damage to the mechanical driving base of the RC Cooler or to the Controller. Only the Cooler Bucket can contain water or ice. IMPOR TANT SAFETY INFORMATION The RC Cooler is a sophisticated model and should be treated as such. Please follow all safety precautions and assembly instructions listed in this manual and use common sense when operating the model. The RC Cooler is not waterproof. Keep out of rain and puddles. Do not submerge in water as it will damage the RC Cooler. Basic Safety: Do not modify the RC Cooler or Controller; this will void your warranty. Test your RC Cooler before every use and clean any debris from the wheel compartments. The RC Cooler is designed to be used indoor on carpet, wooden and laminate floors and outdoor on flat concrete, patios and pool decks. It is not designed to operate in sand, grass, snow or areas with small stones. The RC Cooler is designed for a maximum load capacity of 11 Lbs. (5 Kilograms). Overload may cause unexpected results or permanent damage IMPORTANT BATTERY INFORMATION Do not mix old and new batteries, different types of batteries, standard carbon zinc, or alkaline batteries of different capacities. Do not use rechargeable batteries. Ensure that the contact surfaces are clean and bright before installing new batteries. Please respect the correct polarity (-) or (+) when replacing batteries. Do not throw batteries into the fire. Replace all batteries of the same type/brand at the same time. The supply terminals are not to be short-circuited. Exhausted batteries must be removed from the toy. Batteries should be replaced by adults. Remove batteries if the toy is not going to be operated or store for a long time to prevent leakage or other damage. Non-rechargeable batteries are not to be recharged. Rechargeable batteries are only to be charged under adult supervision. Rechargeable batteries are to be removed from the toy before being charged. Never leave a battery unattended while it is being charged. Never leave a battery unattended in the presence of children. For optimal performance, use alkaline batteries only. FCC NOTE This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR CHANGE TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 4.0 Interactive Toy Concepts Limited 2014-08-07 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Interactive Toy Concepts Limited. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product Description: R/C Vehicle Model name: 22029 FCC ID: RSD-22029TX Sincerely, Client’s signature ： Virginia Yeung Client’s name / title：Manager Contact information / address ：0085223688166（Unit 709, 7/F., Tower 2, Cheung Sha Wan Plaza No. 833 Cheung Sha Wan Rd.Kowloon,Hong Kong）

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Interactive Toy Concepts Limited 2014-08-07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RSD-22029TX We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature ： Virginia Yeung Client’s name / title：Manager Contact information / address ：0085223688166（Unit 709, 7/F., Tower 2, Cheung Sha Wan Plaza No. 833 Cheung Sha Wan Rd.Kowloon,Hong Kong）

FCC ID:RSD-22029TX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1.This device may not cause harmful interference. 2.This device must accept any interference received, including interference that may cause undesired operation.

Antenna

Report No.: ATE20141460 Page 1 of 35 FCC ID: RSD-22029TX ACCURATE TECHNOLOGY CO., LTD APPLICATION CERTIFICATION FCC Part 15C On Behalf of Interactive Toy Concepts Limited R/C Vehicle Model No.: 22029 FCC ID: RSD-22029TX Prepared for : Interactive Toy Concepts Limited Address : Unit 709, 7/F., Tower 2, Cheung Sha Wan Plaza No. 833 Cheung Sha Wan Rd.Kowloon,Hong Kong Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Chan Yuan New Material Port, Keyuan Rd. Science & Industry Park, Nan Shan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20141460 Date of Test : July 28-Aug 06,2014 Date of Report : Aug 07,2014 Report No.: ATE20141460 Page 2 of 35 FCC ID: RSD-22029TX ACCURATE TECHNOLOGY CO., LTD TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION............................................................................................................ 4 1.1. Description of Device (EUT).................................................................................................................4 1.2. Special Accessory and Auxiliary Equipment......................................................................................4 1.3. Description of Test Facility ......................................................................................................................5 1.4. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. OPERATION OF EUT DURING TESTING ................................................................................. 7 3.1. Operating Mode ........................................................................................................................................7 3.2. Configuration and peripherals ..................................................................................................................7 4. TEST PROCEDURES AND RESULTS ......................................................................................... 8 5. 20DB BANDWIDTH MEASUREMENT ........................................................................................ 9 5.1. Block Diagram of Test Setup....................................................................................................................9 5.2. The Requirement For Section 15.215(c)...................................................................................................9 5.3. Operating Condition of EUT ....................................................................................................................9 5.4. Test Procedure ..........................................................................................................................................9 5.5. Test Result ..............................................................................................................................................10 6. BAND EDGE COMPLIANCE TEST ........................................................................................... 12 6.1. Block Diagram of Test Setup..................................................................................................................12 6.2. The Requirement For Section 15.249 .....................................................................................................12 6.3. EUT Configuration on Measurement .....................................................................................................12 6.4. Operating Condition of EUT ..................................................................................................................13 6.5. Test Procedure ........................................................................................................................................13 6.6. Test Result ..............................................................................................................................................13 7. RADIATED SPURIOUS EMISSION TEST ................................................................................ 19 7.1. Block Diagram of Test Setup..................................................................................................................19 7.2. The Limit For Section 15.249.................................................................................................................20 7.3. Restricted bands of operation .................................................................................................................20 7.4. Configuration of EUT on Measurement .................................................................................................21 7.5. Operating Condition of EUT ..................................................................................................................21 7.6. Test Procedure ........................................................................................................................................21 7.7. The Field Strength of Radiation Emission Measurement Results ..........................................................22 8. ANTENNA REQUIREMENT........................................................................................................ 35 8.1. The Requirement ....................................................................................................................................35 8.2. Antenna Construction .............................................................................................................................35 Report No.: ATE20141460 Page 3 of 35 FCC ID: RSD-22029TX ACCURATE TECHNOLOGY CO., LTD Test Report Certification Applicant& address : Interactive Toy Concepts Limited Unit 709, 7/F., Tower 2, Cheung Sha Wan Plaza No. 833 Cheung Sha Wan Rd.Kowloon,Hong Kong Manufacturer& address : Interactive Toy Con…

Text truncated - open the document above for the full version.

Radiated emissions test 30MHz- 1GHz Radiated emissions test > 1GHz
