Fusion2Go Adjustable 2G, 3G, 4G Vehicle Signal Booster Kit ™ User Guide SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected] How It Works Pg. 3 Package Contents Pg. 4 Installation: Step1: Connect outside antenna Pg.5 Step 2: Connect inside antenna Pg.6 Step 3: Install the signal booster Pg.6 Step 4: Configure Gain Setting Pg. 7 Troubleshooting Pg. 8 Specification Pg. 9 Kitting Information Pg. 9 Warranty Pg. 10-11 Safety Information Pg. 11 Table of Contents 2 Thank you for purchasing SureCall’s Fusion2Go cell phone signal booster kit. Fusion2Go provides enhanced 2G and 3G voice and 4G data reception and is configurable for any size vehicle. If you need any assistance during product installation please contact tech support at 1-888-365-6283 or email us at [email protected]. SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected] 3 The SureCall Fusion2Go is a high-quality bidirectional booster that enhances cellular signals for cars, motor homes, and other vehicles. The Fusion2Go works with two antennas: • An inside antenna that communicates with your cell phone. • An outside antenna that communicates with the cell tower. Signals sent from a cell tower are received by the outside antenna, amplified by the booster and then sent to your cell phone via the inside antenna. When your phone transmits, the signal is sent to the inside antenna, and then sent to the cell tower via the outside antenna. A minimum amount of cellular reception is required for the Fusion2Go to work properly. Cellular signal strength is measured in dBm, an abbreviation of the radio power per milliwatt. A minimum of -100 dBm is required. Signal readings usually appear as a negative number (for example, -85). The stronger the signal, the closer it gets to zero. See graph below. How it works Cell Tower Outside Antenna Signal Strength -50dB-60dB-70dB-80dB-90dB-100dB-110dB ExcellentGoodPoor SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected] 4 Package Contents 1. Unpack all package contents. For missing or damaged items, contact your reseller. 2. Turn over the signal booster and record the model and serial number for reference: Serial #: Purchase Date: 3. Keep the carton and packing material to store the product in case you need to return it. Your Fusion2Go signal booster package includes the following items: • One SureCall carrier-specific Fusion2Go signal booster • One magnetic-mount outside antenna with attached cable • One inside antenna with attached cable • One DC car charger for vehicle • Velcro ® and screw-mounting kit Warning: Unauthorized antennas, cables, and/or coupling devices are prohibited by FCC new rules. Please contact FCC for details: 1-888-CALL-FCC. Changes or modifications not expressly approved by SureCall could void the user’s authority to operate the equipment. Fusion2GoOutside Magnetic Mount Antenna Inside Patch Antenna Power Adapter SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected] 5 Installation Installation Steps: Step 1. Installing your Hardware Connect the Outside Antenna 1. Connect the magnetic outside antenna to the roof of the car in a location that: • Is on top of the vehicle • Has at least a 12-inch radius clear of obstructions and other radiating elements, such as a radio antenna. • Is at least 4-6 feet from the inside antenna. 2. Using the supplied cable, connect the outside antenna to the booster connector marked OUTSIDE. 3. Run the outside antenna cord across the car’s roof and under the front door insulation lining to hide and protect the antenna cable. Wrap up any loose cable 4. Hand tighten the connection Note: The outside antenna must not be collocated or operating with any other antenna or booster. FCC 27.5 (d)(4) Statement: Fixed, mobile, and portable (hand-held) stations operating in the 1710-1755 MHz band as well as mobile and portable stations operat- ing in the 1695-1710 MHz and 1755-1780 MHz bands are limited to 1 watt EIRP. Fixed stations operating in the 1710-1755 MHz band are limited to a maximum antenna height of 10 meters above ground. Mobile and portable stations operating in these bands must employ a means for limiting power to the minimum neces- sary for successful communications. Pursuant to the latest certification requirement you will need to register your booster. Please go to the link below for your cellular service carrier’s registra- tion site. AT&T: https://securec45.securewebsession.com/attsignalbooster.com/ Verizon: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html Sprint: http://www.sprint.com/legal/fcc_boosters.html T-Mobile: http://support.t-mobile.com/docs/DOC-9827 Click on the “Signal Booster Registration Tool” US Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp?_requestid=38383 Fusion2Go Magnetic Antenna Power Adapter Inside Patch Antenna SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected] 6 Note: Laboratory tests show that patch antennas can work from as close as 2 ft. from the outside antenna if the patch antenna is facing away from the outside antenna. If the alert lights blink red, showing oscillation, turn the dial of the oscillating band down 3 dBs. Installation Step 2. Connect the Inside Antenna 1. Mount the inside antenna so it is: • Within 2-3 feet of the cell phone, or directly to the back of the cell phone. • Mounted on a surface that is at least 4” (10cm) away from metal. 2. Using the supplied cable, connect the antenna to the booster connector marked INSIDE 3. Hand tighten the connection Step 3. Install the Signal Booster 1. Mount the booster under the seat of the vehicle, or on the front or middle console of the vehicle. The location you select should: • Be away from excessive heat, direct sunlight, or moisture. • Provide proper ventilation. Refer to the illustration on page 7 for the following steps: 2. Connec…

Text truncated - open the document above for the full version.

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com FCC Authorization 26 th , March 2015 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To Whom It May Concern: We, Cellphone-mate, the undersigned, hereby authorize CKC Laboratories, Inc. to act on our behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Compliance Testing, LLC on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely yours, Hongtao Zhan, CEO Cellphone-Mate Inc. 1888 365 6283 ext. 301

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com FCC Confidential Authorization 26 th March, 2015 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: RSNFUSION2GO In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Cellphone-mate hereby requests long- term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description  Parts list The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Sincerely Yours, Hongtao Zhan, CEO Cellphone-Mate Inc. 1888 365 6283 ext. 301

1 48346 Milmont Dr., Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com Antenna Kitting Information Fusion 5S Mobile Vehicle Kit Component Prod No. Description Gain/Loss Notes LTE-A LTE-V 800MHz 1900MHz 1700MHz\2100MHz Outdoor Antenna CM200 3dBi 3dBi 3dBi 5dBi 5dBi\5dBi Outdoor Cable CM174-10FT 10Feet 3.8dB 3.8dB 4.3dB 8.8dB 6.98dB\8.96dB Indoor Antenna CM110W 1.1dBi 1.1dBi 1.1dBi 3dBi 3dBi\3dBi Table Top Antenna Indoor Cable CM174-10FT 10Feet 3.8dB 3.8dB 4.3dB 8.8dB 6.98dB\8.96dB Marine Kit Component Prod No. Description Gain/Loss Notes LTE-A LTE-V 800MHz 1900MHz 1700MHz\2100MHz Outdoor Antenna CM288W or Galaxy 5412-P 3dBi 3dBi 3dBi 4dBi 4dBi\4dBi Outdoor Cable CM240-40FN 40Feet 3.52dB 3.52dB 3.98dB 6.52dB 6.12dB\6.92dB Indoor Antenna CM248W 7dBi 7dBi 7dBi 10dBi 10dBi\10dBi Wall Mounted Antenna Indoor Cable CM240-20FN 20Feet 2.06dB 2.06dB 2.29dB 3.56dB 3.36dB\ 3.76dB 2 Desk top/RV Kit Component Prod No. Description Gain/Loss Notes LTE-A LTE-V 800MHz 1900MHz 1700MHz\2100MHz Outdoor Antenna CM288W 3dBi 3dBi 3dBi 4dBi 4dBi\4dBi Outdoor Cable CM240-40FN 40Feet 3.52dB 3.52dB 3.98dB 6.52dB 6.12dB\6.92dB Indoor Antenna CM120W 1.2dBi 1.2dBi 1.2dBi 3dBi 3dBi\3dBi Table Top Antenna

LETTER OF ATTESTATION 3 rd April, 2015 To Whom It May Concern, These statements are true. 1) Not applicable : Licensee consent for provider-specific booster has been obtained (consent to be made available upon FCC/TCB request) 2) Yes : NPS and other compliance/safeguard features have been implemented 3) Yes: NPS and other compliance/safeguard features are defaulted to be "On" (in operation) 4) Yes: NPS and other compliance/safeguard features cannot be field reconfigured, disabled or removed 5) Yes: Consumer booster is not user programmable, does not need fine tuning or adjustment, does not require professional installation 6) Yes: Future software upgrade will not cause non-compliance. Sincerely, Print Name: Hongtao Zhan Title: CEO Contact Telephone Number: 510-770-0469 Contact Email Address : [email protected] ,I/ SureCall® RAISE YOUR BARS 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone -mate.com

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 1 Explanation of MSCL Mobile antenna Booster server antenna Mobile Booster MSCL Indoor Cable Loss Path loss Mobile Antenna Gain Indoor Antenna Gain spatial distance=d Figure 1 MSCL= Path loss + Indoor Cable Loss - Mobile Antenna Gain- Indoor Antenna Gain......① 1.1 Decibel version of free-space propagation loss equation Path loss (dB) =20Lgf+20Lgd+32.45 ......② or Path loss (dB) =20Lgf+20LgD-27.55 ......③ f (MHz), d (km), D(m) , d=1000D 1.1.1 Operation Frequency At PCS (1850-1910MHz) f =1850MHz At Cellular (824-849MHz) f =824 MHz At AWS (1710-1755MHz) f =1710 MHz At LTE(698-716MHz) f =698 MHz At LTE(776-787MHz) f =776 MHz 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 1.1.2 Minimum Separation Distances for MSCL base on FCC new rule D (m) Minimum Separation Distances for MSCL Calculation or Measurements D(m) Indoor server antenna types Minimum separation distances D (m) Ceiling Mounted (i.e., Dome-type) Antennas 2.0 Wall Mounted (i.e., Panel or other type) Antennas 1.0 or 2.0* Table Top Antennas 1.0 * Note: Wall Mounted (i.e., Panel or other type) Antennas: Alternatively, if a manufacturer clearly specifies a minimum separation distance to consumer devices in the installation manual or other user documentation provided with the booster, a reasonable minimum separation distance could be up to 6 feet (or 2 meters) horizontally removed from the antenna. In this case, the user would be required to ensure this minimum separation distance for all CMRS devices authorized for use with this booster. 1.2 Mobile Antenna Gain Mobile Antenna Gain=0dBi 1.3 Indoor Cable Loss And Indoor Antenna Gain Indoor Cable Loss and Indoor Antenna Gain are listed in the separate submitted file of Fusion 5S Mobile Antenna Kitting . 1.4 Polarity Loss Polarity Loss dB = 10Log (E1/E2)2 dB = PL dB PL dB= 10Log (E12/ (E1Sin (45deg)) 2) dB = 20Log (1/Sin (45deg)) dB = 3.01dB Where: E1 = Maximum Possible Magnitude of the Electric Field from the Mobile Device. E2 = Magnitude of the electric field from the Mobile device with a 45deg polarity mismatch = E1Sin (г). г =45deg E1 E2 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com 2 MSCL Calculations Vehicle Kit Fixed booster Indoor Antenna Indoor Antenna Indoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM110W 1.1 1.1 3 3 3 MAX GAIN 1.1 1.1 3 3 3 Indoor Cable Indoor Cable Indoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dB) At 800MHz(dB) At 1900MHz(dB) At 1700MHz(dB) At 2100MHz(dB) CM174- 10FT 10Feet 3.8 4.3 8.8 6.98 8.96 MIN LOSS 3.8 4.3 8.8 6.98 8.96 Path loss=20Lgf+20LgD-27.55 Operation Frequency (MHz) f(MHz) D(m) Constant(dB) Path loss(dB) PCS(1850-1910) 1850 0.4 27.55 29.8 Cellular(824-849) 824 0.4 27.55 22.8 LTE(698-716) 698 0.4 27.55 21.4 LTE(776-787) 776 0.4 27.55 22.3 AWS(1710-1755) 1710 0.4 27.55 29.1 MSCL Calculations of fixed booster MSCL Band (MHz) Path loss （dB） Indoor Antenna Gain （dBi） Indoor Cable Loss（dB） Polarity Loss(dB) MSCL(dB) PCS(1850-1910) 29.8 3 8.8 3 38.6 Cellular(824-849) 22.8 1.1 4.3 3 29.0 LTE(698-716) 21.4 1.1 3.8 3 27.1 LTE(776-787) 22.3 1.1 3.8 3 28.0 AWS(1710-1755) 29.1 3 6.98 3 36.1 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com Marine Kit Indoor Antenna Indoor Antenna Indoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM248W 7 7 10 10 10 MAX GAIN 7 7 10 10 10 Indoor Cable Indoor Cable Indoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM240- 20FN 20Feet 2.06 2.29 3.56 3.36 3.76 MIN LOSS 2.06 2.29 3.56 3.36 3.76 Path loss=20Lgf+20LgD-27.55 Operation Frequency (MHz) f(MHz) D(m) Constant(dB) Path loss(dB) PCS(1850-1910) 1850 0.9 27.55 36.9 Cellular(824-849) 824 0.9 27.55 29.8 LTE(698-716) 698 0.9 27.55 28.4 LTE(776-787) 776 0.9 27.55 29.3 AWS(1710-1755) 1710 0.9 27.55 36.2 MSCL Calculations of fixed booster MSCL Band (MHz) Path loss （dB） Indoor Antenna Gain （dBi） Indoor Cable Loss（dB） Polarity Loss(dB) MSCL(dB) PCS(1850-1910) 36.9 10 3.56 3 33.4 Cellular(824-849) 29.8 7 2.29 3 28.1 LTE(698-716) 28.4 7 2.06 3 26.5 LTE(776-787) 29.3 7 2.06 3 27.4 AWS(1710-1755) 36.2 10 3.36 3 32.5 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com Desk top RV Kit Fixed booster Indoor Antenna Indoor Antenna Indoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM120W 1.2 1.2 3 3 3 MAX GAIN 1.2 1.2 3 3 3 Indoor Cable Indoor Cable Indoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dB) At 800MHz(dB) At 1900MHz(dB) At 1700MHz(dB) At 2100MHz(dB) 0.3 0.3 0.3 0.3 0.3 MIN LOSS 0.3 0.3 0.3 0.3 0.3 Path loss=20Lgf+20LgD-27.55 Operation Frequency (MHz) f(MHz) D(m) Constant(dB) Path loss(dB) PCS(1850-1910) 1850 0.6 27.55 33.3 Cellular(824-849) 824 0.6 27.55 26.3 LTE(698-716) 698 0.6 27.55 24.9 LTE(776-787) 776 0.6 27.55 25.8 AWS(1710-1755) 1710 0.6 27.55 32.7 MSCL Calculations of fixed booster MSCL Band (MHz) Path loss （dB） Indoor Antenna Gain （dBi） Indoor Cable Loss（dB） Polarity Loss(dB) MSCL(dB) PCS(1850-1910) 33.3 3 0.3 3 33.6 Cellular(824-849) 26.3 1.2 0.3 3 28.4 LTE(698-716) 24.9 1.2 0.3 3 27.0 LTE(776-787) 25.8 1.2 0.3 3 27.9 AWS(1710-1755) 32.7 3 0.3 3 33.0

Page 1 of 8 Report No: 96696-17 RADIO FREQUENCY EXPOSURE REPORT FOR THE Device: Mobile Wideband Consumer Booster Model: Fusion2Go Report No.: 96696-17 Date of issue: March 11, 2015 PREPARED FOR: Cellphone-Mate, Inc. 48346 Milmont Drive Fremont CA 94538 US PREPARED BY: Daniel Bertran CKC Laboratories, Inc. 1120 Fulton Place Fremont, CA 94539 The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 2 of 8 Report No: 96696-17 Purpose: To demonstrate compliance with United States, Canada and/or European Union RF Exposure requirements for Portable equipment (devices used ≤20cm from the body) or Mobile equipment (devices used >20cm from the body) with power output below exemption levels and Mobile equipment, where Maximum Permissible Exposure (MPE) Calculations apply. United States Compliance Requirements (1.1310): RF Exposure Evaluation Limits Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f 2 ) 6 30-300 61.4 0.163 1 6 300-1500 --- --- f/300 6 1500-100,000 --- --- 5.0 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 --- --- f/1500 30 1500-100,000 --- --- 1.0 30 * Plane wave equivalent power density Limit is calculated based on the mid-band frequency used in the operating frequency range. Exemption Level: Power output <60/f GHz (mW) Page 3 of 8 Report No: 96696-17 Canadian Compliance Requirements (RSS-102): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 600 4.9 --- 6 1.0-10 600/f 4.9/f --- 6 10-30 60 4.9/f --- 6 30-300 60 0.163 10 6 300-1500 3.54 f 0.5 0.0094*f 0.5 f/3 6 1500-15,000 137 0.364 50 6 15,000-150,000 137 0.364 50 616000/f 1.2 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 280 2.19 --- 6 1.0-10 280/f 2.19/f --- 6 10-30 28 2.19/f --- 6 30-300 28 0.073 2 6 300-1500 1.585 * f 0.5 0.0042 * f 0.5 f/150 6 1500-15,000 61.4 0.163 10 6 15,000-150,000 61.4 0.163 10 616000/f 1.2 *Power density limit applicable >100MHz Exemption Level: Frequency Range (MHz) Maximum Output Power (Conducted or EIRP) 0.003-1000 ≤ 200 mW 1000-2200 ≤ 100 mW 2200-3000 ≤ 20 mW 3000-6000 ≤ 10 mW Page 4 of 8 Report No: 96696-17 European Union Compliance Requirements (ICNIRP): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.00082-0.065 610 24.4 --- 6 0.065-1.0 610 1.6/f --- 1.0-10 610/f 1.6/f --- 6 10-400 61 0.16 10 6 400-2000 3.0 * f 0.5 0.008 * f 0.5 f/40 6 2000-300,000 137 0.36 50 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-0.150 87 5.0 --- 6 0.150-1.0 87 0.73/f -- 6 1.0-10 87/f 0.5 0.73/f --- 6 10-400 28 0.073 2 6 400-2000 1.375 f 0.5 0.0037*f 0.5 f/200 6 2000-300,000 61 0.16 10 6 *Power density limit applicable >100MHz Exemption Level: Power output < 20mW 1 1 May vary by product type Page 5 of 8 Report No: 96696-17 Device and Antenna Operating Configuration: Device operating at maximum output power with continuous transmission of modulated data. The MPE calculation is based on highest output power, worse case being the Uplink path. Frequency Ant Gain Cable Loss UL1710-1755 5 6.12 UL1850-1915 5 6.52 UL824-894 3 3.98 UL 698-716 3 3.52 UL776-787 3 3.52 Test Procedure: This equipment is evaluated in accordance with the guidelines set forth in OET Guide 65 & ANSI C95.1 for the US and Health Canada Safety Code 6 & RSS 102 for Canada. Other Considerations: None Page 6 of 8 Report No: 96696-17 MPE Calculations Applicability: Limit Used X General Population / Uncontrolled Exposure Occupational / Controlled Exposure RF Exposure Exemption No United States NA Canada NA Europe Equipment operational details: Config# Freq Range Meas Power (dBm) Antenna Gain (dBi)+Cable Loss Antenna Type EIRP (dBm) EIRP (mW) US mW/cm 2 1 UL1710-1755 17.4 -1.12 External 1.63E+01 42.46195639 1.00 2 UL1850-1915 17.5 -1.52 External 1.60E+01 39.62780343 1.00 3 UL824-894 18.5 -0.98 External 1.75E+01 56.49369748 0.60 4 UL 698-716 19.0 -0.52 External 1.85E+01 70.4693069 0.48 5 UL 776-787 18.0 -0.52 External 1.75E+01 55.97576015 0.52 Measurements based from EMC Test Report(s): 96696-16 MPE Calculation: 2 4d EIRP DensityPower   Given: EIRP in mW or W and d in cm or m Config Freq Range EIRP Distance US # (mW) (cm) mW/cm 2 Limit 1 UL1710-1755 42.4619564 20.00 0.01 1.00 2 UL1850-1915 39.6278034 20.00 0.01 1.00 3 UL824-894 56.4936975 20.00 0.01 0.60 4 UL 698-716 70.4693069 20.00 0.01 0.48 5 UL 776-787 55.9757601 20.00 0.01 0.52 Page 7 of 8 Report No: 96696-17 Summary: Exemptions: In the case the equipment meets compliance requirements by exemption the product is approved for use under mobile or portable…

Text truncated - open the document above for the full version.

1 FCC§1.1307（b）(1)&§2.1091-RF EXPOSURE 1.1 Applicable Standard According to§1.1310 and §2.1091(Mobile Devices)RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Power Density (mW/cm²) Limits for General Population/Uncontrolled Exposure 0.3-1.34 *(100) 1.34-30 *(180/f²) 30-300 0.2 300–1,500 f/1500 1,500–100,000 1 Note: f= frequency in MHz *=Plane-wave equivalent power density 1.2 MPE Prediction 1.2.1 Calculation of MPE at 20 cm distance, Equation from OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G= maximum power gain of the antenna in the direction of interest relative to an isotropic radiator, subtract antenna’s cable loss, (result is in numeric form) R=distance to the center of radiation of the antenna (20cm in the following calculation) 1.2.2 Calculation formula of G（numeric ) G (numeric)=10 {Maximum Antenna Gain dBi () -Cable LossdB () } 1 10 Where: G（numeric）= Maximum power gain of the antenna in the direction of interest relative to an isotropic radiator, subtract antenna’s cable loss, (result is converted from decibel into numeric form with above equation) 1.3 Test Result Vehicle Kit Outdoor Antenna Outdoor Antenna Outdoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM200 3 3 5 5 5 Outdoor Cable Outdoor Cable Outdoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM174-10FT 10Feet 3.8 4.3 8.8 6.98 8.96 Indoor Antenna Indoor Antenna Indoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM110W 1.1 1.1 3 3 3 Indoor Cable Indoor Cable Indoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM174-10FT 10Feet 3.8 4.3 8.8 6.98 8.96 LET Band 707 UL: Maximum peak output power at antenna input terminal(dBm): 19.00 Maximum peak output power at antenna input terminal(mW): 79.43 Prediction distance(cm): 20 Prediction frequency(MHz): 708.40 Maximum Antenna Gain (dBi): 3 Cable Loss(dB): 3 G（numeric）: 0.83 Power density at predication frequency and distance(mW/cm²): 0.0132 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.4723 LET Band 742 DL: Maximum peak output power at antenna input terminal(dBm): -13.00 Maximum peak output power at antenna input terminal(mW): 0.05 Prediction distance(cm): 20 Prediction frequency(MHz): 743.18 Maximum Antenna Gain (dBi): 1.1 Cable Loss(dB): 3.8 G（numeric）: 0.54 Power density at predication frequency and distance(mW/cm²): 0.0000 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.4955 LTE Band 781 UL: Maximum peak output power at antenna input terminal(dBm): 18.00 Maximum peak output power at antenna input terminal(mW): 63.10 Prediction distance(cm): 20 Prediction frequency(MHz): 784.40 Maximum Antenna Gain (dBi): 3 Cable Loss(dB): 3.8 G（numeric）: 0.83 Power density at predication frequency and distance(mW/cm²): 0.0104 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.5229 Cellular Band UL: Maximum peak output power at antenna input terminal(dBm): 18.50 Maximum peak output power at antenna input terminal(mW): 70.79 Prediction distance(cm): 20 Prediction frequency(MHz): 831.42 Maximum Antenna Gain (dBi): 3 Cable Loss(dB): 4.3 G（numeric）: 0.74 Power density at predication frequency and distance(mW/cm²): 0.0104 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.5543 Cellular Band DL: Maximum peak output power at antenna input terminal(dBm): -18.20 Maximum peak output power at antenna input terminal(mW): 0.02 Prediction distance(cm): 20 Prediction frequency(MHz): 880.17 Maximum Antenna Gain (dBi): 1.1 Cable Loss(dB): 4.3 G（numeric）: 0.48 Power density at predication frequency and distance(mW/cm²): 0.0000 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 0.5868 PCS Band UL: Maximum peak output power at antenna input terminal(dBm): 17.50 Maximum peak output power at antenna input terminal(mW): 56.23 Prediction distance(cm): 20 Prediction frequency(MHz): 1872.32 Maximum Antenna Gain (dBi): 5 Cable Loss(dB): 8.8 G（numeric）: 0.42 Power density at predication frequency and distance(mW/cm²): 0.0047 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000 PCS Band DL: Maximum peak output power at antenna input terminal(dBm): -12.80 Maximum peak output power at antenna input terminal(mW): 0.05 Prediction distance(cm): 20 Prediction frequency(MHz): 1960.77 Maximum Antenna Gain (dBi): 3 Cable Loss(dB): 8.8 G（numeric）: 0.26 Power density at predication frequency and distance(mW/cm²): 0.0000 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000 AWS Band UL: Maximum peak output power at antenna input terminal(dBm): 17.40 Maximum peak output power at antenna input terminal(mW): 54.95 Prediction distance(cm): 20 Prediction frequency(MHz): 1717.05 Maximum Antenna Gain (dBi): 5 Cable Loss(dB): 6.98 G（numeric）: 0.63 Power density at predication frequency and distance(mW/cm²): 0.0069 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000 AWS Band DL: Maximum peak output power at antenna input terminal(dBm): -12.30 Maximum peak output power at antenna input terminal(mW): 0.06 Prediction distance(cm): 20 Prediction frequency(MHz): 2120.80 Maximum Antenna Gain (dBi): 3 Cable Loss(dB): 8.96 G（numeric）: 0.25 Power density at predication frequency and distance(mW/cm²): 0.0000 MPE limit for uncontrolled exposure at predication frequency(mW/cm²): 1.0000 Marine Kit Outdoor Antenna Outdoor Antenna Outdoor Antenna Gain At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At 2100MHz(dBi) CM288W or Galaxy 5412-P 3 3 4 4 4 Outdoor Cable Outdoor Cable Outdoor Cable Loss At LTE-A and LTE-V (698-787MHz)(dBi) At 800MHz(dBi) At 1900MHz(dBi) At 1700MHz(dBi) At …
