RSNLTE-VQuad Band Signal Booster

Cellphone-Mate Inc. dba SureCall

Click to zoom

Application Details

Equipment Class: B2W - Part 20 Wideband Consumer Booster (CMRS)
Date of Grant: Jun 25, 2020
Application Purpose: Original Equipment
Date of Application: Jun 24, 2020
Equipment Note: Quad Band Signal Booster
Frequency Range: 2110.00000000 - 2155.00000000
Company: Cellphone-Mate Inc. dba SureCall
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

LTE Active Antenna User Manual 1 LTE Active Antenna Draft v2 LTE Active Antenna User Manual 2 Table of Contents Overview ...................................................................................................................................................................... 3 Before Installation ..................................................................................................................................................... 3 Contents ........................................................................................................................................................ 3 Installation ................................................................................................................................................................... 3 Step 1 Connect the Power Injector Antenna Cable onto the Router Antenna Port ........................... 3 Step 2 Connect the Cable from the LTE Active Antenna to the Power Injector ................................. 3 Step 3 Plug the Power Adapter into a Nearby Outlet with the Other End into the Power Injector .. 3 Step 4 Identify the Location of Best Signal for Placement of the LTE Active Antenna ..................... 4 Step 5 Mount the Antenna at the Identified Location .............................................................................. 4 Step 6 Route and Secure the Cables ........................................................................................................ 4 Product specifications ............................................................................................................................................. 5 Regulatory Information ............................................................................................................................................ 5 LTE Active Antenna User Manual 3 Overview The LTE Active Antenna is a signal booster that, when placed on a window and connected to your router, delivers improved LTE signal to the LTE Router to improve data throughput speeds. Before Installation Remove Contents from packaging Contents • LTE Active Antenna with mounting adhesive • Power Adapter • Power Injector • Velcro straps and cable clips Figure 1: Contents Installation Step 1 Connect the Power Injector Antenna Cable onto the Antenna Port Step 2 Connect the Cable from the LTE Active Antenna to the Power Injector Step 3 Power up using the Power Adapter and connect the other end into the Power Injector Plug in the power adapter, then plug the other end into the power injector. Once connected, a GREEN LED on the power injector will appear to indicate that the LTE Active Antenna is receiving power. If the power injector is showing a RED LED, please double check that all cables are connected securely. If your LTE Router was not already turned on, please turn it on now. Please note – If you power on the LTE Router while the LTE Active Antenna is connected to the antenna port on the router but not connected to power, the router may not complete its boot up process properly and will not work as expected. If this occurs, please turn off the router and ensure the LTE Active Antenna is connected to power before turning the LTE Router back on. LTE Active Antenna User Manual 4 Step 4 Identify the Location for Placement of the LTE Active Antenna Identifying and mounting the LTE Active Antenna in the location of your with the best available LTE signal will provide the best performance of your LTE Router. The best signal and recommended mounting location for the antenna will be on a window. Step 5 Mount the Antenna at the Identified Location Once the best mounting location has been identified, prepare the area by cleaning it first (rubbing alcohol, window cleaner and similar solutions work well). Once the area has thoroughly dried, mount the antenna by removing the paper backing from the adhesive padding and firmly pressing it against the cleaned area. Please ensure the antenna is mounted vertically with the cable pointing down for the best performance. Step 6 Route and Secure the Cables Using the included cable clips and Velcro straps, route the cables as desired for the cleanest possible installation. If Velcro straps are used, coil the excess cable before wrapping to ensure a clean look and installation. LTE Active Antenna User Manual 5 Product specifications Name LTE Active Antenna Model: SC-LTE-V Certifications: FCC (North America Wireless Network: LTE Technology Compatibility: 4G-LTE Cable (Antenna): RG174; 20 ft. Cable (Power Injector): RG174; 7 ft. Regulatory Information LTE Active Antenna FCC ID: RSNLTE-V THIS IS A CONSUMER DEVICE BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Verizon: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html AT&T: https://securec45.securewebsession.com/attsignalbooster.com/ T-Mobile: https://support.t-mobile.com/docs/DOC-9827 Sprint: https://www.sprint.com/legal/fcc_boosters.html U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 Inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device. CLASS B EQUIPMENT: This equipment has been tested to, and found to be within the acceptable limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential env…

Text truncated - open the document above for the full version.

Cover Letter(s)

48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com FCC Confidential Authorization 10 th June, 2020 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: RSNLTE-V In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Cellphone-mate hereby requests long- term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • Parts list The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Sincerely Yours, Dennis Findley Authorized Representative Cellphone-Mate Inc. 510 770-0469 ext. 228 48346 Milmont Drive Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.cellphone-mate.com

Cover Letter(s)

1 48346 Milmont Dr., Fremont, CA 94538 Phone: 510-770-0469 Fax: 510-996-7250 www.surecall.com Antenna Kitting Information M2M-4 Kit Component Prod No. Description Gain/Loss Notes LTE-V 800MHz 1900MHz 1700MHz\2100MHz Outdoor Antenna M2M-4 Integrated antenna 2dBi 2dBi 3dBi 3dBi Integrated antenna Indoor Antenna - - - - - Indoor Cable RG174-7FT（7Feet） 3dB 3dB 4dB 4dB * All equivalent antennas and cables are suitable for use with the M2M-4. As above information. Remark: Lower gain antenna can also be used. Maximum Gain Minimum Gain Outdoor Antenna 3dBi 2dBi Indoor Antenna - -

Cover Letter(s)

MSCL M2M-4 V1.0 Explanation: Because the M2M device is directly connected to the router through the power box (with 7ft cable). Therefore, the MSCL of the M2M device is equal to the loss of the power box. Power Box Loss(with 7ft cable) Operation Frequency (MHz) Loss (dB) PCS(1850-1915) 4 Cellular(824-849) 3 LTE(776-787) 3 AWS(1710-1755) 4 Uplink center Frequency(MHz) 781 836.5 1732.5 1882.5 MSCL(dB) 3 3 4 4

ID Label/Location Info

COOL GRAY 2C - background color COOL GRAY 5C - label text LTE Active Antenna

RF Exposure Info

RADIO FREQUENCY EXPOSURE REPORT REVISED REPORT TO 104002-10 Device: Active Antenna Model: SC-LTE-V Report No.: 104002-10A Date of issue: June 25, 2020 PREPARED FOR: Dennis Findley Cellphone-Mate, Inc. 48346 Milmont Drive Fremont CA 94538 PREPARED BY: Hieu Song Nguyenpham CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 2 of 10 Report No: 104002-10A Revision History Original: Testing of the Model: SC-LTE-V for Radio Frequency Exposure Report. Revision A: The manufacturer declares the device name given at the time of testing was in error and should have been referenced as, Active Antenna. The manufacturer declares that any differences between the names does not affect their EMC characteristics and therefore meets the level of testing equivalent to the tested device name. Purpose: To demonstrate compliance with United States, Canada, Australia and/or European Union RF Exposure requirements for Portable equipment (devices used ≤20cm from the body) or Mobile equipment (devices used >20cm from the body) with power output below exemption levels and Mobile equipment, where Maximum Permissible Exposure (MPE) Calculations apply. Device and Antenna Operating Configuration: Device operating at maximum output power with continuous transmission of modulated data. The MPE calculation is based on highest radiated output power, worse case being the Uplink path on the UL 1710-1755MHz band. Test Procedure: This equipment is evaluated in accordance with the guidelines set forth in KDB 447498 & ANSI C95.1 for the US, Health Canada Safety Code 6 & RSS 102 for Canada, ARPANSA RPS3 for AU and EN 62479 or EN 62311 for EU. Other Considerations: Report considers stand-alone configurations only. RF Exposure limits are calculated at the max-point of each operating band. Maximum EIRP is presented further below. Referenced Test Reports: The following test reports were referenced in conjunction with this assessment: 104002-11 Page 3 of 10 Report No: 104002-10A RF Exposure Power Density Assessment (Single Transmitter, Stand Alone) MPE Calculation: 푃표푤푒푟 퐷푒푛푠푖푡푦 ( 푆 ) = 퐸퐼푅푃 4휋 푑 2 Given: EIRP in mW or W and d in cm or m US MPE Assessment Power Reported is: ☐ Peak ☒ Average Limit Used is: ☒ General Population ☐ Occupational Exposure Operating Band MHz Power dBm *Ant Type/Gain dBi & Cable loss EIRP dBm Distance cm MPE mW/cm 2 Limit mW/cm 2 Comments 1710-1755 26.1 Integral/3/0 29.1 20 0.16 1.0 Uplink band *Direct connect booster with Server port connected to section of RF cable for direct connector to cellular device and integral Outdoor/ Donor antennal Page 4 of 10 Report No: 104002-10A Summary: Exemptions: Equipment demonstrating compliance by portable RF exposure exemption have been evaluated, without further testing, for use under either portable or mobile RF exposure configurations. Additional configurations including collocation or simultaneous transmission with other transmitters (including necessary separation distances) are subject to further assessment. Certain exemption criteria may define specific separation distances. It is assumed that the manufacturer shall design the equipment such that these minimum separation distance is met. MPE Calculation Results: Equipment demonstrating compliance with MPE calculations have been evaluated, without further testing, for use under mobile RF exposure configurations as identified herein. Additional configurations including collocation or simultaneous transmission with other transmitters (including necessary separation distances) are subject to further assessment. It is assumed that the manufacturer shall design the equipment such that the minimum separation distance of 20cm (or greater, as listed above) is met or that the manufacturer provides a protection guide (e.g. installation instructions) to the end user such that the antenna(s) may be installed in accordance with the manufacturer’s instructions in such a manor to maintain the minimum separation distance. General Comments: The absorption and distribution of Electromagnetic energy in the body is a very complex phenomena that depends on the mass, shape and physiological condition of the body; the orientation of the body with respect to the fields; and, the electrical properties of the body and the environment. Variables that may play a substantial role in possible biological effects are those that characterize the environment (including but not limited to: ambient temperature, air velocity, relative humidity and body insulation); and those that characterize the individual (including but not limited to: age, gender, activity level and existing debilitation or disease). Because innumerable factors may interact to determine specific biological effects of exposure to electromagnetic fields, any protection guide should consider both intended and unintended operational environments and provide guidance for installation and use of the product such that proper separation distances can be maintained. (ANSI C95.1) Page 5 of 10 Report No: 104002-10A APPENDIX A - RF Exposure Limits United States Compliance Requirements (1.1310): RF Exposure Evaluation Limits Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842 / f MHz 4.89 / f MHz *(900 / f MHz 2 ) 6 30-300 61.4 0.163 1 6 300-1500 --- --- f MHz / 300 6…

Text truncated - open the document above for the full version.

Test Report

This report contains a total of 158 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Cellphone-Mate, Inc. REVISED TEST REPORT TO 104002-11 Active Antenna Model: SC-LTE-V Tested to The Following Standard: FCC Part 20.21 / 22H / 24E / 27 Report No.: 104002-11A Date of issue: June 25, 2020 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Test Certificate # 803.01 Page 2 of 158 Report No.: 104002-11A TABLE OF CONTENTS Administrative Information .......................................................................................................................... 4 Test Report Information ............................................................................................................................................ 4 Revision History ......................................................................................................................................................... 4 Report Authorization ................................................................................................................................................. 4 Test Facility Information ............................................................................................................................................ 5 Software Versions ...................................................................................................................................................... 5 Site Registration & Accreditation Information .......................................................................................................... 5 Summary of Results ................................................................................................................................................... 6 Modifications During Testing ..................................................................................................................................... 8 Conditions During Testing.......................................................................................................................................... 8 Equipment Under Test ............................................................................................................................................... 8 General Product Information..................................................................................................................................... 9 FCC Part 20.21/22H/24E/27 ........................................................................................................................ 10 General Test Setup .................................................................................................................................................. 10 7.1 Authorized Frequency Band Verification ........................................................................................................... 11 Summary of Results ............................................................................................................................................. 11 7.2 and 7.3 Maximum Power and Power Gain ........................................................................................................ 16 Summary of Results ............................................................................................................................................. 16 7.4 Intermodulation Product ................................................................................................................................... 19 Summary of Results ............................................................................................................................................. 19 7.5 Out of Band Emissions ....................................................................................................................................... 27 Summary of Results ............................................................................................................................................. 28 7.6 Conducted Spurious Emissions .......................................................................................................................... 54 Summary of Results ............................................................................................................................................. 55 7.7 Noise limit .......................................................................................................................................................... 76 Summary of Results ............................................................................................................................................. 76 7.7.1 Maximum Transmitter Noise Power Level ................................................................................................. 80 7.8 Uplink Inactivity ................................................................................................................................................. 84 Summary of Results ............................................................................................................................................. 84 Page 3 of 158 Report No.: 104002-11A 7.9 Booster Gain Limit ............................................................................................................................................. 87 Summary of Results ................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Test Report

Page 138 of 158 Report No.: 104002-11A UL_824-849_ 842MHz UL_824-849_600sec_ 842MHz Page 139 of 158 Report No.: 104002-11A UL_1710-1755_ 1712.5MHz UL_1710-1755_600sec_ 1712.5MHz Page 140 of 158 Report No.: 104002-11A UL_1850-1915_ 1869.7MHz UL_1850-1915_600sec_ 1869.7MHz Page 141 of 158 Report No.: 104002-11A DL_746-757_ 752.53MHz DL_746-757_600sec_ 752.53MHz Page 142 of 158 Report No.: 104002-11A DL_869-894_ 889MHz DL_869-894_600sec_ 889MHz Page 143 of 158 Report No.: 104002-11A DL_1930-1995_ 1963.15MHz DL_1930-1995_600sec_ 1963.15MHz Page 144 of 158 Report No.: 104002-11A DL_2110-2155_ 2145.7MHz DL_2110-2155_600sec_ 2145.7MHz Page 145 of 158 Report No.: 104002-11A 7.12 Radiated Spurious Emissions Test Setup/Conditions Test Engineer: Hieu Song Nguyenpham Test Date(s): 6/8/2020 Configuration: 1 Test Setup: Frequency range of measurement = 9 kHz- 22 GHz. 9 kHz - 150 kHz -> RBW=200 Hz VBW=200 Hz 150 kHz - 30 MHz -> RBW=9 kHz VBW=9 kHz 30 MHz - 1000MHz -> RBW=120 kHz VBW=120 kHz 1000 MHz-22000MHz -> RBW=1 MHz VBW=1 MHz Note: No spurious emissions were found within 20dB of the limit line. Emissions in the band 1559-1610 MHz were investigated and these were not found within 20dB of the limit line. 27.53(f) For operations in the 746-758 MHz, 775-788 MHz, and 805-806 MHz bands, emissions in the band 1559-1610 MHz shall be limited to −70 dBW/MHz equivalent isotropically radiated power (EIRP) for wideband signals, and −80 dBW EIRP for discrete emissions of less than 700 Hz bandwidth. Environmental Conditions Temperature (ºC) 21.8 Relative Humidity (%): 38 Pressure: kPa 102.1 Test Equipment Asset # Description Model Calibration Date Cal Due Date 03471 Spectrum Analyzer E4440A 2/11/2020 2/11/2022 00852 Biconilog Antenna CBL 6111C 4/14/2020 4/14/2022 P06049 Attenuator PE7002-6 5/11/2020 5/11/2022 P06691 Cable PE3062-180 3/25/2020 3/25/2022 P00880 Cable RG214U 3/25/2020 3/25/2022 P07508 Preamp 310N 10/15/2018 10/15/2020 P01187 Cable CNT-195 8/20/2018 8/20/2020 02157 Horn Antenna 3115 1/15/2019 1/15/2021 P06897 Cable 32022-29094K-29094K-48TC 3/25/2020 3/25/2022 P01210 Cable FSJ1P-50A-4A 12/18/2018 12/18/2020 03713 Preamp 01001800-221055-202525 5/22/2019 5/22/2021 03302 Cable 32026-29094K-29094K-72TC 1/9/2020 1/9/2022 P06899 Cable 32022-29094K-29094K-72TC 1/7/2020 1/7/2022 P06126 Cable 32022-29094K-29094K-168TC 4/29/2020 4/29/2022 00432 Loop Antenna 6502 2/19/2019 2/19/2021 P00928 Cable various 1/9/2020 1/9/2022 P00929 Cable various 1/9/2020 1/9/2022 02693 Active Horn Antenna AMFW-5F-12001800-20-10P 8/15/2019 8/15/2021 02694 Horn Antenna AMFW-5F-18002650-20-10P 8/15/2019 8/15/2021 Page 146 of 158 Report No.: 104002-11A Summary of Results Pass: All Radiated Spurious Emissions were found with more than 20dB margin of the limit line. Frequency Range of measurement 9kHz – 22GHz LIMIT LINE FOR SPURIOUS RADIATED EMISSION REQUIRED ATTENUATION = 43+10 LOG P (DB) For radiated spurious emission measured at 3 meter test distance, Required attenuation = 43+10 Log P t at 3 meter dB Limit line (dBuV) = E dBuv - Attenuation E dBuv = Measured field strength at 3 meter in dBuV/m Power Density (Isotropic) P D = Power Density in Watts /m 2 Pt = Average Transmit Power r = Test distance Field Intensity E (V/m) 2 t D r 4 P P   2 t 2 t D r 30 x P E r 4 377 x P E 377 x P E     Page 147 of 158 Report No.: 104002-11A 10 Log P t = 10 Log E 2 (V/m)+ 10 Log r 2 – 10 Log 30 10 Log P t = 20 Log E (V/m) + 20 Log r – 10 Log 30 At 3 meter, r = 3 m 10 Log P t = 20 Log E (V/m) + 20 Log 3 – 10 Log 30 10 Log P t = 20 Log E (V/m) + 9.54 – 14.77 10 Log P t = 20 Log E (V/m) - 5.23 Since 20 Log E (V/m) = 20 Log E (uV/m) –120 10 Log P t = 20 Log E (uV/m) - 120 - 5.23 10 Log P t = 20 Log E (uV/m) –125.23 Limit line (dBuV) at 3 meter = E dBuv – Attenuation = E dBuv - ( 43+10 Log P t at 3 meter ) = E dBuv - 43 - 10 Log P t at 3 meter = E dBuv - 43 – (20 Log E (uV/m) –125.23…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Dennis Findley(Director of Operations)

[email protected]510-770-0469Fax: 510-996-7250

Test Firm

CKC Laboratories, Inc.Steve Behm

[email protected]209-966-5240Fax: 866 779 9776

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
24	27	2.11 GHz - 2.15 GHz	300.00 µW	W7D	Amp

Confidentiality

Long Term

Grant Notes

Power listed is conducted at antenna terminals. The antenna used with this signal booster must be installed to provide a separation distance of at least 20 cm from all persons. Users and installers must be provided with the installation instructions and operating conditions for satisfying RF exposure compliance. This device is a Direct Connect Mobile Wideband Consumer Signal Booster with integral antenna. When used with any mobile device utilizing the 1710-1755 MHz band, the FCC limits booster equipment placement to a maximum of 10 meters above ground level. Installation of this equipment which does not comply with federal requirements may subject the owner to FCC enforcement action. This Consumer Signal Booster is authorized only for operation by and marketing to members of the general public for their personal use in accordance with the requirements of 47 CFR 20.21(a) and 20.21(g).
