RTTAB-WLNBAirborne WLN-B Module

www.dpactech.com Airborne TM Wireless LAN Node Module Data Book DPAC Technologies Confidential Page ii Airborne™ Wireless LAN Node Module Data Book 39L3702-01 DPAC Technologies Confidential Rev. D 10/25/2004 JR Copyright © 2003, 2004 DPAC Technologies ® Corporation ALL RIGHTS RESERVED. No part of this publication may be copied in any form, by photocopy, microfilm, retrieval system, or by any other means now known or hereafter invented without the prior written permission of DPAC Technologies ® Corp. This document may not be used as the basis for manufacture or sale of any items without the prior written consent of DPAC Technologies Corp. DPAC Technologies Corp is a registered trademark of DPAC Technologies Corp. Airborne™ and AirborneDirect™ are trademarks of DPAC Technologies Corp. All other trademarks used in this document are the property of their respective owners. Disclaimer The information in the document is believed to be correct at the time of print. The reader remains responsible for the system design and for ensuring that the overall system satisfies its design objectives taking due account of the information presented herein, the specifications of other associated equipment and the test environment. DPAC Technologies ® Corp has made commercially reasonable efforts to ensure that the information contained in this document is accurate and reliable. However, the information is subject to change without notice. No responsibility is assumed by DPAC for the use of the information, nor for infringements of patents or other rights of third parties. This document is the property of DPAC Technologies ® Corp. and does not imply license under patents, copyrights or trade secrets. Corporate Headquarters DPAC Technologies ® Corp. 7321 Lincoln Way Garden Grove, CA 92841 USA Telephone: 714-898-0007 Toll Free: 800-642-4477 Fax: 714-897-1772 Technical Support: 714-899-7543 / [email protected] Web Site: www.dpactech.com Page vi Airborne™ Wireless LAN Node Module Data Book 39L3702-01 DPAC Technologies Confidential Rev. D 10/25/2004 JR FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for assistance. FCC RF EXPOSURE STATEMENT To satisfy RF expose requirements, this device and its antenna must operate with a separation distance of a least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. INFORMATION FOR CANADIAN USERS (IC NOTICE) This device has been designed to operate with an antenna having a maximum gain of 5 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. To Reduce potential radio interference to other users, the antenna type and its gain should be so chosen than the equivalent isotropically radiated power (EIRP) is not more than the required for successful communication. Page iii Airborne™ Wireless LAN Node Module Data Book 39L3702-01 DPAC Technologies Confidential Rev. D 10/25/2004 JR CONTENTS CHAPTER 1 INTRODUCTION....................................................................................... 1 1.1 OVERVIEW.................................................................................................................................... 1 1.2 CONFIGURATIONS.......................................................................................................................... 1 1.3 FEATURES..................................................................................................................................... 1 1.4 APPLICATIONS...............................................................................................................................2 1.5 USING THIS DOCUMENT................................................................................................................. 2 1.6 CONVENTIONS...............................................................................................................................3 1.6.1 Terminology ......................................................................................................................... 3 1.6.2 Notes .................................................................................................................................. 3 1.6.3 Cautions............................................................................................................................... 3 1.6.4 Courier Typeface ................................................................................................................. 4 1.7 RELATED DOCUMENTATION............................................................................................................ 4 CHAPTER 2 AIRBORNE WIRELESS LAN NODE MODULE ....................................... 7 2.1 OVERVIEW.................................................................................................................................... 7 2.2 SPECIFICATIONS................................…

Text truncated - open the document above for the full version.

05-12-05 Request for a modular approval - FCC ID: RTTAB-WLNB Dear Application Examiner: The DPAC Technologies Airborne WLN-B Module BT260146 is seeking FCC authorization as a modular transmitter. The requirement of the FCC Public notice DA00-1407 are met. The following requirements are fulfilled: 1. The modular transmitter must have its own RF shielding The radio portion of the module is contained in its own RF shielding. See the external photos. 2. The modular transmitter must have buffered modulation/data inputs The transmitter (Radio) is buffered through the CPU and associated latches on the Application processor board. 3. The modular transmitter must have its own power supply regulation The IC contains its own voltage regulation. In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The transmitter shall only be used with the tested antennas or with an antenna that has less antenna gain. The antennas that can be used are shown in the antenna information exhibit. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. The module was fixed in test/programming board during the test. See also the test report and Test setup photos. 6. The modular transmitter must be labeled with its own FCC ID number The EUT will be labeled with its own FCC ID number. If the module is installed inside of an end product, the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the Users Guide. 05-12-05 8. The modular transmitter must comply with any applicable RF exposure requirements. Please See the MPE Calculations Exhibit. Please contact us if you have any additional questions. Best Regards, Kyle Fujimoto Test Engineer Compatible Electronics, Inc. 114 Olinda Drive Brea, CA 92823 Phone: (714) 579-0500 Fax: (714) 579-1850

Scott McCutchan From: Mike [[email protected]] Sent: Friday, May 27, 2005 9:28 AM To: Scott McCutchan; Kyle Fujimoto (Kyle Fujimoto) Subject: FW: Response to Inquiry to FCC (Tracking Number 595593) 7/13/2005 Here is the response from the FCC regarding omni-directional antennas. Best Regards, Mike Christensen Lab Manager Compatible Electronics, Inc. - Brea Division Phone: 714-579-0500 Fax: 714-579-1850 www.celectronics.com -----Original Message----- From: Generic Office of Engineering Technology [mailto:[email protected]] Sent: Friday, May 27, 2005 7:03 AM To: [email protected] Subject: Response to Inquiry to FCC (Tracking Number 595593) Inquiry: I have a couple of questions regarding what is considered an antenna type under FCC Part 15.204. I have a client who is certifying a device with multiple antennas, all of which are of the omni-directional whip type. However, even though they are omni-directional whips, inside their rubber covering they are either ½ wave dipole, ½ wave monopole and possible ¼ wave dipole or monopole. My understanding is that we only need to test the highest gain of each type of antenna and that antenna type is defined as having a similar in-band and out of band radiation pattern. At what point do variations of omni- directional whip (or rubber duckey) antennas become defined as different types? Under the definition of 15.204, would an omni-directional whip antenna be considered an antenna type as defined by the FCC even though this antenna may be also be a ½ wave dipole, ¼ wave dipole, ¼ wave monopole or ½ wave monopole? If so, I would think we should only need to test the omni-directional whip with the highest gain. Is this correct? It should be noted that the radiation pattern data for the expected frequency of use looks very similar regardless of whether it is a monopole or dipole style, however, I do not have any data, nor have I ever seen data for any antenna, that shows the out of band radiation pattern. Thank you for your help. Best Regards, Mike Christensen Lab Manager Compatible Electronics, Inc. - Brea Division Phone: 714-579-0500 Fax: 714-579-1850 www.celectronics.com Response: We agree that in this case you only need to test the omni-directional whip with the highest gain. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry S ystem to add any additional information pertaining to this inquiry.

Tested/Not tested DPAC P/N Antenna Type MFG P/N: Gain (dBi) Connector Type Tested 83L3704-01 Dipole 1/2 Wave Nearson S151AH-2450S 5.0 R/P SMA Tested 83L3712-01 Dipole 1/2 Wave Nearson S151M2-72-AH-2450S 5.0 R/P SMA Not Tested 83L3701-01 Monopole 1/2 Wave Linx ANT-2.4-CW-RCT-RP 2.2 - 2.7 R/P SMA Not Tested N/A Dipole 1/2 Wave Nearson S181TR-2450 2.0 R/P TNC Not Tested N/A Dipole 1/2 Wave Nearson S181TR-2450R 2.0 R/P SMA Not Tested N/A Dipole 1/2 Wave Nearson S181TR-2450S 2.0 R/P TNC Not Tested 83L3703-01 Dipole 1/2 Wave Nearson S131AH-2450S 2.0 R/P SMA Not Tested 83L3705-01 Dipole 1/2 Wave Nearson S151FL-6-PX-2450S 5.0 U.FL Not Tested 83L3701-01 Monopole 1/2 Wave Sunridge SMAX81-RH-ANTA1534-2 2.2 - 2.7 R/P SMA

Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 21 FCC PART 15, SUBPART B and C TEST REPORT for AIRBORNE WLN-B MODULE MODEL: ABDB-AN-DPxxx Prepared for DPAC TECHNOLOGIES 7321 LINCOLN WAY GARDEN GROVE, CALIFORNIA 92841 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 27, 2005 REPORT APPENDICES TOTAL BODY A B C D E PAGES 21 2 2 2 23 98 148 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 21 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment for Brea Facility – Part 1 12 5.3 EMI Test Equipment for Brea Facility – Part 2 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Antenna Gain 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 17 8.2 6 dB and 20 dB Bandwidth 19 8.3 Peak Output Power 19 8.4 RF Antenna Conducted Test 19 8.5 Spectral Density Output 20 8.6 RF Band Edges 20 9. CONCLUSIONS 21 Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 21 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map and Layout of 3 Meter Radiated Site Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 21 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST, or any other agency of the U.S. Government. Device Tested: Airborne WLN-B Module Model: ABDB-AN-DPxxx S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Manufacturer: DPAC Technologies 7321 Lincoln Way Garden Grove, California 92841 Test Dates: April 13, 14, 15, 18, and 19, 2005 Test Specifications : EMI requirements Limits: CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 21 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and Subpart C, section 15.207 2 Spurious Radiated RF Emissions, 10 kHz - 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and CFR Title 47, Part 15, Subpart C, section 15.247(d) 3 Fundamental and Emissions produced by the intentional radiator in non-restricted bands, 10 kHz – 40 GHz Complies with the relevant requirements of CFR Title 47, Part 15, Subpart C, section 15.247(d) 4 Emissions produced by the intentional ra…

Text truncated - open the document above for the full version.

Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E1 APPENDIX E DATA SHEETS Report Number: B50419D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report Airborne WLN-B Module Model: ABDB-AN-DPxxx Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E2 RADIATED EMISSIONS DATA SHEETS FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 1 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482441.96V74-32.04Peak2.73270 482436.26V54-17.74Avg2.73270 723640.3V74-33.7Peak2.1290 723627.75V54-26.25Avg2.1290 964848.71V----Peak2.16270 Not in Restricted Band 964839.31V----Avg2.16270 Not in Restricted Band 1206044.69V74-29.31Peak2.1690 1206031.9V54-22.1Avg2.1690 1447251.75V74-22.25Peak2.16270 1447237.52V54-16.48Avg2.16270 1688448.21V----Peak2.16135 Not in Restricted Band 1688435V----Avg2.16135 Not in Restricted Band 19296V74-74Peak No Emissions 19296V54-54Avg Detected 21708V----Peak No Emissions 21708V----Avg Detected 24120V----Peak No Emissions 24120V----Avg Detected FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 1 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h)LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 482442.7H74-31.3Peak2.71225 482436.33H54-17.67Avg2.71225 723640.17H74-33.83Peak2.71180 723627.62H54-26.38Avg2.71180 964848.26H----Peak2.42180 Not in Restricted Band 964840.35H----Avg2.42180 Not in Restricted Band 1206045.26H74-28.74Peak2.13225 1206032.36H54-21.64Avg2.13225 1447249.13H74-24.87Peak1.92225 1447236.67H54-17.33Avg1.92225 1688446.99H----Peak1.92225 Not in Restricted Band 1688434.23H----Avg1.92225 Not in Restricted Band 19296H74-74Peak No Emissions 19296H54-54Avg Detected 21708H----Peak No Emissions 21708H----Avg Detected 24120H----Peak No Emissions 24120H----Avg Detected FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 6 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 487440.99V74-33.01Peak2.34135 487436.38V54-17.62Avg2.34135 731141.03V74-32.97Peak1.77315 731127.51V54-26.49Avg1.77315 974848.41V----Peak2.26225 Not in Restricted Band 974841.54V----Avg2.26225 Not in Restricted Band 1218545.54V74-28.46Peak1.83270 1218532.56V54-21.44Avg1.83270 1462250.27V----Peak1.63135 Not in Restricted Band 1462235.68V----Avg1.63135 Not in Restricted Band 1705949.1V----Peak1.63315 Not in Restricted Band 1705936.18V----Avg1.63315 Not in Restricted Band 19496V74-74Peak No Emissions 19496V54-54Avg Detected 21933V----Peak No Emissions 21933V----Avg Detected 22001V74-74Peak No Emissions 22001V54-54Avg Detected 24370V----Peak No Emissions 24370V----Avg Detected FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 6 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h)LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 487441.48H74-32.52Peak2.66225 487434.65H54-19.35Avg2.66225 731139.67H74-34.33Peak2.05315 731127.11H54-26.89Avg2.05315 974847.53H----Peak2.76180 Not in Restricted Band 974834.76H----Avg2.76180 Not in Restricted Band 1218544.62H74-29.38Peak2.76180 1218532.35H54-21.65Avg2.76180 1462248.61H----Peak2.76180 Not in Restricted Band 1462235.9H----Avg2.76180 Not in Restricted Band 1705947.19H----Peak2.39270 Not in Restricted Band 1705935.59H----Avg2.39270 Not in Restricted Band 19496H74-74Peak No Emissions 19496H54-54Avg Detected 21933H----Peak No Emissions 21933H----Avg Detected 22001H74-74Peak No Emissions 22001H54-54Avg Detected 24370H----Peak No Emissions 24370H----Avg Detected FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 11 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m) Table Angle (deg)Comments 492443.93V74-30.07Peak2.14135 492439.2V54-14.8Avg2.14135 738641.04V74-32.96Peak1.88180 738626.71V54-27.29Avg1.88180 984848.15V----Peak2.03270 Not in Restricted Band 984840.94V----Avg2.03270 Not in Restricted Band 1231045.18V74-28.82Peak2.03180 1231031.83V54-22.17Avg2.03180 1477248.31V----Peak1.7790 Not in Restricted Band 1477235.57V----Avg1.7790 Not in Restricted Band 1723451.55V----Peak1.77225 Not in Restricted Band 1723437V----Avg1.77225 Not in Restricted Band 19696V74-74Peak No Emissions 19696V54-54Avg Detected 22158V74-74Peak No Emissions 22158V54-54Avg Detected 24620V----Peak No Emissions 24620V----Avg Detected FCC 15.247 DPAC TechnologiesDate: 4/13/05 Airborne WLN-B ModuleLab: B Model: ABDB-AB-DPxxxTested By: Kyle Fujimoto Configuration: With P/N: S151AH-2450S Model: 151 Swivel Antenna Channel 11 - 802.11 b Mode Transmit Mode - X-Axis Freq. (MHz) Level (dBuV) Pol (v/h) LimitMargin Peak / QP / Avg Ant. Height (m)…
