RTW8120Remote Control

T3DP-Radio FM 27 MHz.pmdPAGE12005-11-12 T3DPS-FM T3DPS-FM FM 3CH DIGITAL PROPORTIONALR/C SYSTEM FOR MODEL AIRPLANES USER MANUAL Made In China T3DP-Radio FM 27 MHz.pmdPAGE 22005-11-12 For your safety using, please read this manual thoroughly. TECHNICAL SPECIFICATIONS: WARNING AND PRECAUTIONS Type:----------------------------------------------------- T3DPS-FM27 Channel:------------------------------------------------- 3CH Modulation:---------------------------------------------- FM Frequency:---------------------------------------------- 27MHz Working Voltage:-------------------------------------- 12V Working Current:---------------------------------------120mA * Read user manual carefully before putting the R/C into use. * Do not oprate the system in open crowd. * Do not oprate this system when models of the same frequency are in use. * Fully extend the antennas before operating. * Remove batteries after use. * Do not mix with old and new batteries. * Do not mix different brands of batteries. T3DP-Radio FM 27 MHz.pmdPAGE3 2005-11-12 For your safety using, please read this manual thoroughly. SYSTEM CONTENTS: ItemsUnit Piece Transmitter T3DPS-FM27 S-17(standard) FM27-3CH Servo Horn Servo Horn Retention Screw Servo Retention Screws 1 1 2 2 2 4 Receiver Servo Parts Check if you have the above items, otherwise, please contact your local distributor for assistance. ANTENNA BATTERY LEVEL INDICATOR CH1 & CH2 CH1 SUB-TRIM CH2 SUB-TRIM CH3 CRYSTAL REVERSING SWITCH POWER SWITCH Use for controlling the speed of the motor of the model. Use for small adjustments so that model travels in striaight line. Use for small adjustments to ensure model travel in a level course Use for controlling directions of traveling (left or right and up or down). Two LED display to indicate battery voltage level. If the red led flashes and beeping sound given out, replace batteries. Use for changing control arm control direction. 1. TRANSMITTER T3DP-Radio FM 27 MHz.pmdPAGE4 2005-11-12 BATTERIES INSTALLATION Battery Cover Receiving Antenna Connecting To Receiver Servo Horn Servo Horn Retention Screw * Remove battery cover at the back of transmitter. * Check carefully the polarity markings before inserting the 8 AA alkali or rechargeable battery(not provided). * Put back the battery cover. BATT. Connect battery(4.8~6V) CH.1Connect a servo to control the direction of model. CH.2Connect a servo to control the direction of model. CH.3Connect to a speed controller or servo. CH.3 CH.2 CH.1 BATT. X'TAL 2.RECEIVER OUTPUT CONNECTOR 3. SERVO Receiver FM27-3CH T3DP-Radio FM 27 MHz.pmd PAGE 5 2005-11-12 STORAGE ASSEMBLY 1.Servo/Receiver Installation Diagram 2.Servo Horn Installation CH.3 CH.2 CH.1 BATT. X'TAL Power Supply (Input 4.8V-6V) Connect to a Speed Controller or servo 90 0 * After connecting servo to receiver, turn on the power switch of the transmitter and receiver. * Ensure the trims on transmitter are at neutral position. * Install the servo horn according to drawing. * Store the R/C system in optimal conditions, keep away from extreme hot or cold conditions. * Keep away from dust or filthy environments. * Do not drop or tamp the system. Receiver FM27-3CH T3DP-Radio FM 27 MHz.pmd PAGE 6 2005-11-12 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment."

SIRDAR METAL & PLASTIC WORKS Bai Shi, San Xiang Town, Zhong Shan City, Guangdong, China Tel.: 86-760-6684427 Fax: 86-760-6682617 Page 1 of 1 Date: Nov.23,2005 RF.: Grant of Authorization for FCC ID: RTW8120 Dear Sirs, This is the letter of Confirmation to declare the product and frequency information as following: Product name: Radio Control Model numbers T3DPS-FM27 For 27MHz frequency band which apply for FCC Certification, it will use 10 frequencies: 26.995, 27.025, 27.045, 27.075, 27.095, 27.0968, 27.125, 27.145, 27.175, 27.195MHz. This Radio Control operating frequencies are crystal-controlled. All products are shipped from the manufacturer with their crystal installed.

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT REAR VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW

香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 1 of 21 No. : HM155445 This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre. 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Applicant: SIRDAR METAL & PLASTIC WORKS Bai Shi, San Xiang Town, Zhong Shan City, Guang Dong, China Description of Samples: Model name: Radio Control Model no.: T3DPS-FM27 Brand name: SDM FCC ID: RTW8120 Date Samples Received: 2005-10-31 Date Tested: 2005-11-05 to 2005-11-10 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- LEE Kam Chuen, EMD For and on behalf of The Hong Kong Standards and Testing Centre Ltd. 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 2 of 21 No. : HM155445 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). CONTENT: Cover Page 1 of 21 Content Page 2-3 of 21 1.0 General Details 1.1 Test Laboratory Page 4 of 21 1.2 Applicant Details Page 4 of 21 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 21 Description of EUT operation 1.4 Date of Order Page 5 of 21 1.5 Submitted Samples Page 5 of 21 1.6 Test Duration Page 5 of 21 1.7 Country of Origin Page 5 of 21 2.0 Technical Details 2.1 Investigations Requested Page 6 of 21 2.2 Test Standards and Results Summary Page 6 of 21 3.0 Test Results 3.1 Emission Page 7-14 of 21 3.2 Bandwidth Measurement Page 15-18 of 21 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 3 of 21 No. : HM155445 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Appendix A List of Measurement Equipment Page 19 of 21 Appendix B Photographs Page 20-21 of 21 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 4 of 21 No. : HM155445 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant SIRDAR METAL & PLASTIC WORKS Bai Shi, San Xiang Town, Zhong Shan City, Guang Dong, China Manufacturer SIRDAR METAL & PLASTIC WORKS Bai Shi, San Xiang Town, Zhong Shan City, Guang Dong, China 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 5 of 21 No. : HM155445 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.3 Equipment Under Test [EUT] Description of Sample Model Name: Radio Control Manufacturer: SIRDAR METAL & PLASTIC WORKS Brand Name: SDM Model Number: T3DPS-FM27 Rating: 12Vd.c (“AA” size battery x 8) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a SIRDAR METAL & PLASTIC WORKS, Radio Control. The transmitter is a 1 Joystick transmitter. The EUT continues to transmit while Joystick is being pressed, It is pulse transmitter, Modulation by IC, and type is FM modulation. 1.4 Date of Order 2005-10-31 1.5 Submitted Sample(s): 3 Samples per model 1.6 Test Duration 2005-11-05 to 2005-11-10 1.7 Country of Origin CHINA 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date : 2005-11-23 TEST REPORT Page 6 of 21 No. : HM155445 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.227 ANSI C63.4:2003 N/A Radiated Emissions FCC 47CFR 15.209 ANSI C63.4:2003 N/A Conducted Emissions on AC, 0.15MHz to 30MHz FCC 47CFR 15.207 ANSI C63.4:2003 N/A Note: N/A - Not Applicable 香 港 標 準 及 檢 定 中 心 Hong Kong Standards and Testing Centre Date :…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
