RX4MC-111AThumbDrive D.J.

Now you can listen to favorite mp3 files by car stereo. Plugging your ThumbDrive into Linxcel ThumbDrive D.J and tuning your stereo to the specific FM channels, you can enjoy your digital music immediate. The Linxcel ThumbDrive D.J can read mp3 files stored in storage devices, like ThumbDrive; any audio sources, like portable mp3 player, PDA or CD player. Features Built-in FM stereo transmitter The host controller conforms to Full-speed (12Mb/s) USB Specification, Version 1.1 Supports the USB flash disk device (Version 1.1 or 2.0) with Mass storage class Supports File System including FAT12;BFAT16;BFAT32 Search for whole disk (MP3 File) Input button for Play (Pause), Previous, Next, Channel Select Phone Jack For Stereo audio in One USB Port for charge (+5V 500mA) Transmission frequency (200kHz step) 88.1MHz~88.9MHz,106.7MHz~107.9MHz. Power Dissipation 1.6W Configuration 1. PLAY/PAUSE Attaching pen drive to our Thumbdrive D.J and you will see the LED solid; then Thumbdrive D.J will automatically search for mp3 files stored in pen drive. When the LED is blinking, press PLAY/PAUSE button afterwards. To press PLAY/PAUSE one more time, then it will switch to pause mode. 2. NEXT: Select the next media track. 3. PREV: Select the previous media track. 4. RESET: When system error happened, pressing RESET button to recover it. (All changes will be back to default setting) 5. Channel Select: refer to chart listed as below to select available frequency. LED1 LED2 LED3 LED4 Frequency 88.1 MHz 88.3 MHz 88.5 MHz 88.7 MHz 88.9 MHz 106.7 MHz 106.9 MHz 107.1 MHz 107.3 MHz 107.5 MHz 107.7 MHz 107.9 MHz LED ON LED OFF 6. Thumbdrive D.J will work through any attached audio sources, like mp3 portable player, PDA and CD player. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Per FCC 15.21, you are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment.

Mike Kuo From: [email protected] Sent: June29 2004 Tuesday 4:33 AM To: Mike Kuo Subject: RE: FW: Action Star Enterprise Co., Ltd., FCCID: RX4MC-111A, Assess ment NO.: AN04T3909 7/2/2004 Hi Liana : Please provide 26dB BW plot with transmitter tuned to 107.9MHz. Best Regards Mike Kuo -----Original Message----- Mike Kuo <[email protected]> 2004/06/22 05:25 AM "'[email protected]'" <[email protected]> From: [email protected] [mailto:[email protected]] Sent: Monday, June 21, 2004 1:56 AM To: Mike Kuo Subject: FW: Action Star Enterprise Co., Ltd., FCCID: RX4MC-111A, Assess ment NO.: AN04T3909 -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Monday, June 07, 2004 12:24 PM To: [email protected] Subject: Action Star Enterprise Co., Ltd., FCC ID: RX4MC-111A, Assessment NO.: AN04T3909 Question #1: In page 1 of the operational description file, the frequency range can be from 87.7MHz to 88.9MHz and from 106.7 MHz to 107.9MHz. Such frequency range does not agree with the frequency indicated in the test Mike Kuo <[email protected]> 2004/06/08 03:41 AM "'[email protected]'" <[email protected]> 7/2/2004 report. In addition, 87.7 MHz is outside the authorized frequency band. Please address this issue. -->Attached please find the revised operational description. Question #2: Per section 15.31 (m) of FCC rules, for the device can tune to more than 10 MHz, the investigation shall be done at low, middle and high frequency channel. In the test report, only the low channel was investigated and reported. Based upon section 3.5 of test report, all 12 channels were investigated, please provide additional test result for 106.7MHz and 107.9MHz . -->Attached please find page 15 of the revised report have added data. Question #3: In the test setup photo, USB cable is connected to the device. What is the support equipment on the other end of USB cable ? -->Attached please find the update setup photo and revised page 18 of the report. Question #4: Page 4 of external photo, it has RCA connector. What is this connector for ? -->We forgot to pass the test mode. Please find page 6 of the revised report. Question #5: The USB connector on the side of EUT with indication of " Power ". Will this device is powered from USB connection or it provide power to external peripheral ? If the device can be powered from external USB device, please provide AC line conducted data per section 15.207 requirement.--> It provides power to external peripheral. Question #6: Section 6.2 of test report, the FCC ID number for Sony Storage device can not be verified via FCC Database. -->It is BSMI code, please find page 9 of the revised report. Question #7: What is the type of modulation used during the tests. Based upon section 13.1.1.1 Applied modulation of ANSI C63.4:2001, " If a device is equipped with input connectors for external modulation, typical modulating signals shall be applied.." In the test report, it is not clear how the audio modulation was applied during the tests. Please explain. -->At MP3 media data from flash drive mode, there is no any external modulation signal. -->At audio signal from walkman mode, the audio signal is an analog signal. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 7/2/2004

Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page

FCC ID LABEL FORMAT AND LOCATION Applicant: Action Star Enterprise Co., Ltd. FCC ID: RX4MC-111A FCC ID: RX4MC-111A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page Compliance Certification Services Inc. Report No: C40308406 Date of Issue: May 10, 2004 Page

Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 1 Total Page: 19 Rev. 00 FCC CFR 47 PART 15 SUBPART C TEST REPORT For Action Star Enterprise Co., Ltd. ThumbDrive D.J Model: MC-111A Trade Name: N/A Issued for Action Star Enterprise Co., Ltd. 10F, No. 159, Ta-Tung Rd., Sec. 2, Hsichih City, Taipei Hsien, Taiwan R.O.C. 221 Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION......................................................................................3 2. EUT DESCRIPTION...........................................................................................................4 3. TEST METHODOLOGY.....................................................................................................5 3.1 EUT CONFIGURATION...............................................................................................5 3.2 EUT EXERCISE............................................................................................................5 3.3 GENERAL TEST PROCEDURES..................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.......................................6 3.5 DESCRIPTION OF TEST MODES................................................................................6 4. INSTRUMENT CALIBRATION.........................................................................................7 5. FACILITIES AND ACCREDITATIONS.............................................................................7 5.1 FACILITIES..................................................................................................................7 5.2 EQUIPMENT................................................................................................................7 5.3 LABORATORY ACCREDITATIONS AND LISTINGS.................................................7 5.4 TABLE PF ACCREDITATIONS AND LISTINGS..........................................................8 6. SETUP OF EQUIPMENT UNDER TEST............................................................................9 6.1 SETUP CONFIGURATION OF EUT.............................................................................9 6.2 SUPPORT EQUIPMENT...............................................................................................9 7. FCC PART 15.239 REQUIREMENTS...............................................................................10 7.1 26 DB BANDWIDTH..................................................................................................10 7.2 RADIATED EMISSIONS............................................................................................12 7.3 POWERLINE CONDUCTED EMISSIONS..................................................................17 APPENDIX 1 - PHOTOGRAPHS OF TEST SETUP...............................................................18 Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Action Star Enterprise Co., Ltd. 10F, No. 159, Ta-Tung Rd., Sec. 2, Hsichih City, Taipei Hsien, Taiwan R.O.C. 221 Equipment Under Test: ThumbDrive D.J Trade Name: N/A Model: MC-111A Model Difference N/A Report Number: C40308406-RP Date of Test: March 9- March 18, 2004 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2001) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.239. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: David Wang Vince Chiang Manager of Hsintien Laboratory Section Manager of Hsintien Laboratory Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 4 Rev. 00 2. EUT DESCRIPTION Product ThumbDrive D.J Trade Name N/A Model MC-111A Power Supply From DC 12V ~ 24 V Operate Frequency 88.1MHz; 88.3MHz; 88.5MHz; 88.7MHz; 88.9MHz; 106.7MHz; 106.9MHz; 107.1MHz; 107.3MHz; 107.5MHz; 107.7MHz; 107.9MHz Transmit Power N/A Modulation Technique FM Number of Channels 12 Channel Operating Mode Point-to-Point Antenna Designation Fixed Antenna, which is built in EUT Note: The product is a Transmitter. This submittal(s) (test report) is intended for FCC ID: RX4MC-111A filing to comply with Section 15.239 of the FCC Part 15 Subpart C Rules. Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 15 Subpart C. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The calibrated antennas used to sample the radiated field strength are …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 18 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF TEST SETUP X axis Y axis Compliance Certification Services Inc. Report No: C40308406-RP FCC ID : RX4MC-111A Date of Issue: June 17, 2004 Page 19 Rev. 00 Z axis
