BT Audio Module User Guide Class 1 Bluetooth Audio Module www.kcwirefree.com Version December 19, 2014 Page 1 Description The BT AUDIO‐5112 Class 1 Bluetooth Hi Power Audio Module is a highly tuned and completely integrated wireless audio transceiver subsystem ready for installation in audio devices. The BT AUDIO‐5112 is a pre‐engineered subsystem integrating a wireless radio, digital audio system, and programmed firmware profiles that define features, c onfigurations, and user interface. All firmware offered by KC Wirefree can be customized for OEM clients. In many cases a few changes can produce great value by differentiating and improving your product. Firmware can be updated via USB. kcAudioGateway Firmware Edition The kcAudioGateway firmware is a transmitter system, offering A2DP source profile or AGHFP gateway profile (default), but not both simultaneously. A2DP mode provides stereo transmission to Headset/Speaker devices. Stereo audio is sampled from the MIC_L+, MIC_L‐, MIC_R+, and MIC_R‐ pins at 44.1kHz, and will automatically transmit to a Headset device. AGHF P mode (default) provides two‐way voice communications, sampled at 8kHz, to a standard Bluetooth cell phone headset. Additionally, the Headset Voice Command prompt will toggle a PTT pin on kcAudioGateway, which enables standard Bluetooth cell phone headsets to provide a PTT function. Please refer to our kcAudioGateway User Guide for det ails. kcAudioHeadset Firmware Edition The kcAudioHeadset firmware is a receiver system, offering A2DP sink profile, and HFP profile. It can receive an A2DP wireless stereo signal, decompress, and convert to analog audio available on the SPK_L+, SPK_L ‐, SPK_R+, and SPK_R‐ pins. Additionally, it can “answer” phone calls, which will pause any A2DP stream, and sw itch modes, now providing two way mono communication channel. Please refer to our kcAudioHeadset User Guide for details. BT Audio Module User Guide Class 1 Bluetooth Audio Module www.kcwirefree.com Version December 19, 2014 Page 2 Dimensions & Layout BT AUDIO‐5112 Top View 434241 GNDANTGND 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 1718192021222324 GND RESET VDD ENABLE SPI_CSB SPI_MOSISPI_MISO SPI_CLK PIO2 PIO3 PIO4 PIO5 PIO6 PIO7 PIO8 PIO9 PIO10 LED_BLU LED_RED UART_RTS UART_CTS UART_TXD UART_RXD 3V3_OUT SPK_R+ SPK_R- SPK_L+ SPK_L- MIC_R+ MIC_R- MIC_L+ MIC_L- MIC_BIAS PCM_IN PCM_CLK PCM_OUT PCM_SYNC USB+ USB- CHARGE 1.4 PADS 1.0 X 2.0 1.8 2.69.82.6 21.0 1.8 15.0 MM 2.8 6.16.1 24.6 BT Audio Module User Guide Class 1 Bluetooth Audio Module www.kcwirefree.com Version December 19, 2014 Page 3 Pin Assignments Pin Function Type Description 1 PIO2 I/O Programmable I/O 2 PIO3 I/O Programmable I/O 3 PIO4 I/O Programmable I/O 4 PIO5 I/O Programmable I/O 5 PIO6 I/O Programmable I/O [I 2 C] 6 PIO7 I/O Programmable I/O [I 2 C] 7 PIO8 I/O Programmable I/O [I 2 C] 8 PIO9 I/O Programmable I/O 9 PIO10 I/O Programmable I/O 10 LED_BLU Input Blue LED Drain 11 LED_RED Input Red LED Drain 12 UART_RTS Output UART Request To Send 13 UART_CTS Input UART Clear To Send 14 UART_TXD Output UART Data Transmit 15 UART_RXD Input UART Data Receive 16 3V3_OUT Output Onboard 3.3V Regulator Output 17 GND ‐‐ Ground 18 RESET Input Reset (Active Low >5ms) 19 VDD Input VDD/Battery Input (2.9V – 4.4V) 20 ENABLE Input System Enable (with internal latch) 21 SPI_CSB Input SPI Chip Select 22 SPI_MOSI Input SPI Master Out 23 SPI_MISO Output SPI Master In 24 SPI_CLK Input SPI Clock 25 CHARGE Input Battery Charging Supply (only use when VDD is battery powered) 26 USB‐ I/O USB Data Negative 27 USB+ I/O USB Data Positive 28 PCM_SYNC I/O PCM Sync [I 2 S WS] 29 PCM_OUT Output PCM Out [I 2 S Out] [SPDIF Out] 30 PCM_CLK I/O PCM Clock [I 2 S Clk] 31 PCM_IN Input PCM In [I 2 S In] [SPDIF In] 32 MIC_BIAS Output Microphone Bias 33 MIC_L‐ Input Audio Input Left Negative 34 MIC_L+ Input Audio Input Left Positive 35 MIC_R‐ Input Audio Input Right Negative 36 MIC_R+ Input Audio Input Right Positive 37 SPK_L‐ Output Audio Output Left Negative 38 SPK_L+ Output Audio Output Left Positive 39 SPK_R‐ Output Audio Output Right Negative 40 SPK_R+ Output Audio Output Right Negative 41 GND ‐‐ Ground 42 ANT I/O 50 Ohm 2.4GHz Antenna Port 43 GND ‐‐ Ground [Option features in brackets] BT Audio Module User Guide Class 1 Bluetooth Audio Module www.kcwirefree.com Version December 19, 2014 Page 4 Interface Pins PIO Pins [1‐9] PIO pins are LOW by default, and button presses used for device operation are HIGH signals. PIO inputs are debounced to 20ms. Several PIO pins are assigned functions in default versions of firmware. Custom programmed functions are available. Inputs can be configured for weak pull‐up, weak pull‐do wn, strong pull‐up, strong pull‐down. Voltage input tolerance and output level is directly related to the VDD level. Specific functions are enabled on designated PIO pins depending on firmware version. Please refer to the specific firmware Audio User Guides for complete information regarding PIO features and assignments. LED Pins [10‐11 ] Two open‐drain LED output pins are available. The LED's need a positive 3.3V (maximum) supply, and a current limiting resistor. UART Pins [12‐15] The UART is compatible with the 16450 industry standard. Upcoming kcAudio firmware will implement an AT Command set for configuration and operation. 3V3 _OUT Pin [16] The module has several onboard regulators. The onboard 3V3 regulator supplies the PIO, PCM, SPI, UART, and USB Pins. The class 2 module has up to 100mA available from this pin. The class 1 module also uses the onboard 3V3 regulator to supply the RF Power Amp, and ha s less than 30mA available from this pin. GND Pin [17] VSS ground plane. RESET Pin [18] The module will reset when pulled LOW >5ms. VDD Pin [19] Minimum VDD is 2.9V. Supplies several onboard regulators, and is also the designated Battery P terminal if powering directly from a Lithium Io n battery. The VDD pin may receive a recharge current supply whe…
