S53RC2021A2GRToy RC Ice Griffon

RUICHENG PLASTIC TOYS INDUSTRY CO., LTD

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jul 27, 2021
Application Purpose: Original Equipment
Date of Application: Jul 27, 2021
Equipment Note: Toy RC Ice Griffon
Frequency Range: 2403.00000000 - 2478.00000000
Company: RUICHENG PLASTIC TOYS INDUSTRY CO., LTD
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

BATTERY INSTALLATION ICE GRIFFIN • Remove demo batteries and install new alkaline batteries. • Remove the battery cover on the Griffin’s belly. • Insert batteries according to the diagram inside the battery compartment. • Replace the battery cover. REMOTE CONTROL • Remove the battery cover on the back of the remote control. • Insert batteries according to the diagram inside the battery compartment. • Replace the battery cover. The Ice Griffin uses 4 AAA 1.5V (included) alkaline batteries and the Remote Control uses 2 AAA 1.5V (not included) alkaline batteries. You will need to use a Phillips or Cross screwdriver to open the battery compartments. ™ FROSTBITE THE ICE GRIFFIN REMOTE CONTROL MYTHICAL CREATURE AGES 6 + FEATURES CONTENTS 1 Ice Griffin 1 Remote Control 2 Wings 1 Dispensing Kettle Thank you for your purchase of the Discovery Ice Griffin Remote Control Creature! Have fun with a Griffin you control. Be sure to use this product in a safe, traffic free environment. Please read all instructions and warnings on this sheet prior to use. Keep this instruction sheet as it contains important information for future reference. SPRAY INSTRUCTIONS Before spraying, use a dispensing kettle to add water to the water inlet. ADD WATER METHOD: 1. The water added to the kettle must be clear water. 2. When filling the water, squeeze the body by hand, align the mouth of the pot with the water source, and slowly reduce the pressing force until the water tank is full of kettle. WARNING: When the griffin does not spray, the water level is insufficient. WATER TANK OPENING ON/OFF TRY ME BUTTON DISPENSING KETTLE BACKWARD SCREAM SOUND FORWARD FROST BREATH WING FLAPPING SOUND 1.5V AAA1.5V AAA 1.5V AAA1.5V AAA 1.5V AAA 1.5V AAA TO PLAY SAFETY WARNINGS: PLEASE READ BEFORE USE • Never aim or shoot the remote at other people. • Adult supervision required. BATTERY WARNING: • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Alkaline batteries are recommended. Use only the specified voltage. • Insert batteries using the correct polarity. Always use, replace, and recharge (if applicable) batteries under adult supervision. • Do not charge with non-rechargeable batteries. • Do not short-circuit the battery supply terminals. • Do not dispose of batteries in a fire, batteries may explode or leak. • Remove batteries before storing. • Recycle or dispose of batteries according to federal, state, and local laws. • Keep this package for future reference. ™ AGES 6 + © 2020 Discovery or its subsidiaries and affiliates. Discovery and related logos are trademarks of Discovery or its subsidiaries and affiliates, used under license. All rights reserved. Distributed by and © 2020 MerchSource, LLC. Irvine, CA, 92618. All rights reserved. For technical support, please call 1-800-374-2744 Printed in China KEEP THIS INSTRUCTION MANUAL AS IT CONTAINS IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to continuous product improvements, the pictures on this manual may differ slightly from the actual product. • Power griffin on first before powering on remote. • LED eyes will be fading in and out. Once paired successfully, the eyes will be on. • Press the forward arrow for griffin to walk forward. • Press the back arrow for griffin to walk backward. • Press the scream sound button to make the griffin “smoke”. WING INSTALLATION WARNING: • Inspect the product before every use. If the product appears damaged in any manner, discontinue use and discard immediately. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, Including Interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio TV technician for help. Model No.: 1014135 WARNING: CHOKING HAZARD – Small Parts. Not for Children under 3 years. Sound EffectsVapor Spray Wings Flap Forward/Backward

Cover Letter(s)

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] W ebsite: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 RUICHENG PLASTIC TOYS INDUSTRY CO., LTD 2021.7.26 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: S53RC2021A2GR Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name: Bing Yang Chen Title : General manager Contact information / address : Xinxiang industry, North side of Dengfeng road, Chenghai, Guangdong, China Permanent confidentiality may be requested in accordance with FCC KDB 726920

Cover Letter(s)

RUICHENG PLASTIC TOYS INDUSTRY CO., LTD Declaration of Identical Product Hereby, Name of manufacturer: RUICHENG PLASTIC TOYS INDUSTRY CO., LTD Address: Xinxiang industry, North side of Dengfeng road, Chenghai, Guangdong, China City: Chenghai,Guangdong Country: China declares that: Product description: Toy RC Ice Griffon Type designation(s): 1014135 Trademark: Discovery Family name is technically identical to: Product description: Toy RC Ice Griffon Type designation: RC2021A Trademark: Discovery Certificate number (if applicable) It is identical with test model except the appearance and model no. for trading purpose. Date: 2021.7.26 City: Chenghai,Guangdong Name: Bing Yang Chen Signature

External Photos

ID Label/Location Info

FCCIDLabelRX SIZE:40mmW*15mmH ModelNo.:1014135 MadeinChina FCCID:S53RC2021A2GR

Internal Photos

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 26 Report Version A Test Report No.: RF2104WDG0301-2 TEST REPORT Applicant RUICHENG PLASTIC TOYS INDUSTRY CO., LTD Address Xinxiang industry, North side of Dengfeng road, Chenghai, Guangdong, China Manufacturer or Supplier RUICHENG PLASTIC TOYS INDUSTRY CO., LTD Address Xinxiang industry, North side of Dengfeng road, Chenghai, Guangdong, China Product Toy RC Ice Griffon Brand Name Discovery Model RC2021A Additional Model & Model Difference 1014135 Date of tests Apr. 24, 2021 ~ Jun. 28, 2021 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.249 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Eric Fang Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Jul. 26, 2021 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at https://www.cps.bureauveritas.com/terms-conditions and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 26 Report Version A Test Report No.: RF2104WDG0301-2 TABLE OF CONTENTS RELEASE CONTROL RECORD ....................................................................................................................... 3 1 SUMMARY OF TEST RESULTS ............................................................................................................. 4 2 MEASUREMENT UNCERTAINTY........................................................................................................... 4 3 GENERAL INFORMATION ....................................................................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................. 5 3.2 DESCRIPTION OF TEST MODES ............................................................................................... 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................................. 8 3.4 DESCRIPTION OF SUPPORT UNITS ......................................................................................... 8 4. TEST TYPES AND RESULTS .................................................................................................................. 9 4.1 RADIATED EMISSION MEASUREMENT ...................................................................................... 9 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 9 4.1.2 TEST INSTRUMENTS ..................................................................................................... 10 4.1.3 TEST PROCEDURES ...................................................................................................... 11 4.1.4 DEVIATION FROM TEST STANDARD ............................................................................ 11 4.1.5 TEST SETUP ................................................................................................................... 12 4.1.6 EUT OPERATING CONDITIONS .................................................................................... 13 4.1.7 TEST RESULTS .............................................................................................................. 14 4.2 20DB BANDWIDTH MEASUREMENT ......................................................................................... 21 4.2.1 LIMITS OF 20DB BANDWIDTH MEASUREMENT ......................................................... 21 4.2.2 TEST INSTRUMENTS ..................................................................................................... 21 4.2.3 TEST PROCEDURE ........................................................................................................ 21 4.2.4 DEVIATION FROM TEST STANDARD ........................................................................... 21 4.2.5 TEST SETUP ................................................................................................................... 22 4.2.6 EUT OPERATING CONDITIONS .................................................................................... 22 4.2.7 TEST RESULTS ......................................................................................…
