GS920 AND GS SERIES SENSORS INSTALLER AND USER GUIDE Document ID: GS920_ENG_Rev2023May GS920 & GS Series Sensors Installer and User Guide | 2 Corporate Office Trimble Inc. 935 Stewart Drive Sunnyvale, CA 94085 USA www.trimble.com Heavy Civil Construction Field Systems Division Trimble Civil Construction Field Systems 10368 Westmoor Drive Westminster, Colorado 80021 USA 800-361-1249 (Toll Free) +1-937-245-5154 Phone +1-937-233-9441 Fax lifting.trimble.com Legal Notices © 2023, Trimble Inc. All rights reserved. Trimble, and the Globe & Triangle logo are trademarks of Trimble Inc., registered in the United States and in other countries. All other trademarks are the property of their respective owners. Release Notice This is the May 2023 release of the GS920 & GS Series Sensors Installer and User Guide. It applies to version of the software. P/N GS920_ENG_Rev2023May. Product Limited Warranty Information For applicable product Limited Warranty information, please refer to the Limited Warranty Card included with this Trimble product or consult your local Trimble authorized dealer. GS920 & GS Series Sensors Installer and User Guide | 3 Safety Information Before proceeding, please read and understand the following information. For your safety and that of the people that come into contact with Trimble products, understand the significance of the instructions included in this guide, respect all laws and regulations and comply with applicable standards. Pay particular attention to items bearing the following types of alerts: GS920 & GS Series Sensors Installer and User Guide | 4 Contents 1 Introduction ............................................................................................. 9 1.1 Overview .............................................................................................................................................. 10 1.2 Startup 11 1.3 Technical support ................................................................................................................................ 11 2 Installation ............................................................................................. 12 2.1 GS920 13 2.1.1 Mounting Bracket ............................................................................................................................................. 14 2.1.2 Antenna Position ................................................................................................................................................. 15 2.1.3 Power Supply and Lockout Connection ............................................................................................................... 15 2.1.4 Lockout Settings .................................................................................................................................................. 18 2.1.5 Password Settings............................................................................................................................................... 21 2.1.6 Updated Sensor List: ........................................................................................................................................... 21 2.2 Load Cell 22 2.3 Angle Sensors ...................................................................................................................................... 24 2.3.1 Mounting Procedure......................................................................................................................................... 24 2.3.2 Angle Calibration Procedure No. 1: Mechanical Setup ........................................................................................ 26 2.3.3 Angle Calibration Procedure No. 2: Correct with GS920 ...................................................................................... 26 2.4 Anti-Two-Block Switch ........................................................................................................................ 27 2.4.1 Switch Bracket Installation LB011 ....................................................................................................................... 28 2.4.2 GS075B Installation ............................................................................................................................................. 30 2.4.3 Chain Length Adjustment ................................................................................................................................... 30 2.5 Length Sensor Cable Reel .................................................................................................................... 32 2.5.1 Maximum Boom Extension ................................................................................................................................. 32 2.5.2 Mounting the Cable Reel ..................................................................................................................................... 33 2.5.3 Boom Length Calibration Procedure No. 1: Mechanical Setup ............................................................................ 35 2.5.4 Boom Length Calibration Procedure No. 2: Correct with the GS920 .................................................................. 36 2.6 Radius 38 2.6.1 Radius Verification and Adjustment .................................................................................................................... 38 2.6.2 Radius Settings .................................................................................................................................................... 39 2.6.3 Basic Radius Parameters for a Lattice Crane ..................................................................................................... 41 2.6.4 Basic Radius Parameters for a Telescopic Boom Crane ..................................................................................... 42 2.6.5 Advanced Radius and Height Parameters ..............................................................................…

Text truncated - open the document above for the full version.

2. Installation GS920 & GS Series Sensors Installer and User Guide | 68 Figure: Mounting bracket footprint. Dimensions are in inches. Once the mounting bracket is installed, screw on the encoder with the nuts and bolts provided. Put tension on the spring by inserting the cotter pin in the middle hole in front of the hinge. Figure: Slew encoder installation. Typical installation. 2. Installation GS920 & GS Series Sensors Installer and User Guide | 69 2.14.5 Slew Transmitter Location The slew transmitter is connected to the slew encoder with a 6 ft. cable, but it can be installed beside the transmitter if convenient; the cable can be cut to the length required. 2.14.6 Slew Transmitter Installation Figure: Slew transmitter. Dimensions are in inches. Not to scale. Screw the slew transmitter to a flat surface with 1/4 in. screws. If needed, weld pads can be used to facilitate transmitter installation. 1. 2. 3. NOTE – The transmitter must be installed such that it does not interfere with the 2. Installation GS920 & GS Series Sensors Installer and User Guide | 70 Tie wraps can be used to secure the cable between the encoder and transmitter. 2.14.7 Cable Length Adjustment If the cable between the encoder and transmitter is too long, it can be cut to the desired length; Remove the cover from the transmitter using either a flat or a Phillips No. 2 screwdriver. Using a small flat screwdriver, loosen the 6 screws of the terminal block and remove the wires from it. Lay down the transmitter cover on a clean surface. Loosen the cable gland with a 3/4 in. wrench and pull the cable from the inside of the transmitter box until you reach the desired length. Tighten the gland back with the wrench. Do not to overtighten. Cut the cable excess, leaving about 4 in. in the transmitter box. Remove the sheath to about 2 in., remove the shield and remove the individual sheaths on the 6 wires to about 1/4 in. Connect the 6 wires in the terminal block respecting the color codes and tighten the terminal block screws. Replace the transmitter cover and screw it in place. Test the sensor for proper function: start-up the LiftingWorks application and move the encoder wheel. Figure: Cable length adjustment Terminal Block 2. Installation GS920 & GS Series Sensors Installer and User Guide | 71 2.15 Slow Sensor Calibration The slew sensor needs to be calibrated on the crane where it is installed on before utilization. Go to menu, select the slew sensor. Menu Set crane gear teeth number; enter the teeth count of crane’s slew gear. Menu Set slew sensor gear teeth; enter the teeth count of the gear of the slew sensor installed. Menu Slew angle must increase when rotates to the right. Reverse rotation; depending on how the slew sensor is installed, the rotation direction may be reversed. The slew value should go up when you swing to right (clockwise). Menu Adjust/confirm slew value; enter the current position of the slew (swing). Menu Press enter to save calib in sensor; the settings will be saved in the sensor. 2.16 Data Logger The GS920 includes a data logger that records all significant events including actual sensor values and a date and time stamp. The data logger memory can hold over 32 000 records, this is equivalent to several days or several years of operation depending on the recording mode selected and machine use. The data can be extracted using a USB mass storage device (USB key) and then transferred to a personal computer for analysis. 2.16.1 Recording Modes Adjust the data logger recording mode as required: Go to menu and select Data Logger. Enter the user password. Select the data logger recording mode. Return to the main page of the LiftingWorks application or scroll down to adjust the data logger date and time (see Date and Time, page 74). 2. Installation GS920 & GS Series Sensors Installer and User Guide | 72 2.16.1.1 Recording Modes description Alarm only. Record alarms only. All the other data logger modes also record alarms. Automatic recording. A record is added at a specified interval. When the automatic recording data logger mode is selected on menu Click Minutes, press Enter and then use Up and Down to adjust the record interval in minutes. Automatic variation. A record is added when load increases by more than the operator adjusted percentage. When the automatic variation data logger mode is selected on menu Variation (%), Click and then adjust the variation threshold. Automatic peak. In the automatic peak mode, the data logger analyzes the measured weight and records the peak value only. One threshold per load cell must be adjusted. When the weight drops by more than the peak threshold the peak weight is recorded. Only one event is recorded for each pick when the threshold is adjusted correctly. When the automatic peak data logger mode is selected on menu (see step 3 above) click Threshold No. 1 and adjust the peak threshold for the first load cell. Go down to repeat for the second load cell etc. Up to four load cells can be programmed for automatic peak data logging. User input. The status of all sensors is recorded on demand. A normally open push button must be installed on a digital input to the GS920 through a pre-determined wire of the power supply and lockout cable. All data. All communications between a main unit and its sensors are recorded. 2. Installation GS920 & GS Series Sensors Installer and User Guide | 73 2.16.2 Date and Time Adjust the data logger date and time as required: Go to menu and click Data Logger. Enter the user password. Click Date. The digits of the year should be flashing: adjust the year and press Next. Adjust the month and press Next. Adjust the day. Click Time and adjust the time. The hour should be flashing: adjust the hour from 00 (midnight) to 23 (11 pm). Press Next to adjust the minute. Adjust the minute and press Next. Adjust the second and press Enter to save any changes. Return to the main page of the LiftingWorks application. 2. Installation GS920 & GS Series Sen…

Text truncated - open the document above for the full version.

Trimble Inc. 5475 Kellenburger Rd Dayton, OH 45424 United States Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: 06-08-2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) FCC ID: S9E-131488 Trimble Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Katherine Allen Title: Worldwide Compliance Manager Address: Trimble Inc.5475 Kellenburger Rd Dayton, OH 45424, United States Tel.: +1.818.600.1001 Email: [email protected]

To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046 USA From: Regarding: Attestation Statements - Not Covered Entity Applicant & Not Covered Equipment Ref: Information Required by Section 2.911(d)(5)(ii) FCC ID: S9E-131488 Trimble, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely, Trimble Inc. 5475 Kellenburger Rd Dayton, OH 45424 United States Katherine Allen Worldwide Compliance Manager Trimble, Inc. 08-01-2023

Katherine Allen Worldwide Compliance Manager [email protected] Trimble, Inc. 5475 Kellenburger Rd Dayton, OH 45424 United States August 10,2023 Authorization to Act as Agent On our behalf, I/We appoint Mr. Raghavendra Kulkarni of TUV Rheinland India Ltd. 27/B, 2 nd cross road, Electronic City, Phase 1 Hosur Road Bangalore – 560 100. INDIA to act as my/our agent in the preparation/signing of this application for equipment certification for the following FCC ID: S9E-131488 I/We certify that the submitted documents properly describe the device or system for which equipment certification is sought. I/We also certify that each unit manufactured, imported or marketed, as defined in FCC’s regulations, will have affixed to it a label identical to that submitted for approval with this application. Agency A greement Expiration Date: August 10, 2024 ________________ Signature

To: Federal Communications Commission7435 Oakland Mills Road,Columbia, MD 21046 USA From: Regarding: Confidentiality Request regarding application for FCC ID S9E-131488 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Parts List / BOM Tune Up Procedure The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Trimble Inc. 5475 Kellenburger Rd Dayton, OH 45424 United States Katherine Allen Worldwide Compliance Manager Trimble, Inc.

Produkte Products www.tuv.com EUT External Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 1 von 4 Page 1 of 4 EUT External Photos Figure 1: Front view of the EUT Figure 2: Rear view of the EUT Produkte Products www.tuv.com EUT External Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 2 von 4 Page 2 of 4 Figure 3: Top view of the EUT Figure 4: Bottom view of the EUT Produkte Products www.tuv.com EUT External Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 3 von 4 Page 3 of 4 Figure 5: Left side view of the EUT Figure 6: Right side view of the EUT Produkte Products www.tuv.com EUT External Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 4 von 4 Page 4 of 4 Figure 7: Dimensional view of EUT Figure 8: Dimensional view of EUT ****End of EUT External Photos****

75.00 35.00 TEXT & GRAPHICS COLOR BLACK TEXT & GRAPHICS COLOR WHITE WITHIN BLACK PATCH Specification Of TLS 2200®/TLS PC Link™ BradyBondz™ Labels Agency Approval(s)/Compliance: CSA Approved, UL Recognized Size: 1.37" W x 2.95" H (35 mm W x 75 mm H) Color: Silver Finish: Matte Material Type: Polyester Material Description: Ultra Aggressive Metallized Polyester Surface: Highly Textured, Low Surface Energy, Smooth, Textured/Rough Special Properties: Designed for powder coated surfaces, Ultra-aggressive adhesive RoHS Compatibility: Compliant with RoHS Directive. NOTE: All statements concerning RoHS Directive compliance refer to 2005/618/EC MCV amendment to RoHS Directive 2002/95/EC. Product compliance is based upon information provided by suppliers of the raw materials used by Brady to manufacture these products, or by independent laboratory testing of these products. As such, Brady makes no independent representations or warranties, express or implied, and assumes no liability in connection with the use of this information. A-INITIAL RELEASE 20-Dec-23 PMR FCC LABEL - GS920RD STD 920-RD-M107 C 2:121 A PMR FCC LABEL LOCATION GS920RD STD 920-RD-M109 C 2:122 A

Produkte Products www.tuv.com EUT Internal Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 1 von 2 Page 1 of 2 EUT Internal Photos Figure 1: Front view of the PCB Figure 2: Rear view of PCB Produkte Products www.tuv.com EUT Internal Photos Reference Test Report No: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 2 von 2 Page 2 of 2 ‚ Figure 3: PCB Dimensional view Figure 4: BLE Module Location ****End of EUT Internal Photos****

Prüfbericht – Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: IN23CPI5 001 & IN23HOHV 001 ULR-TC5688233000000094F&95F Auftrags-Nr.: Order no.: 0146716970 020 Seite 1 von 4 Page 1 of 4 Kunden-Referenz-Nr.: Client reference no.: 2269507 Auftragsdatum: Order date: 2023-06-01 Auftraggeber: Client: Trimble Inc. 5475 Kellenburger Road , Building 2,Dayton, Ohio 45424, United States Prüfgegenstand: Test item: GS920 Bezeichnung Identification GS920 Serien -Nr.: Serial no.: Engineering Sample Auftrags-Inhalt: Order content: Maximum Permissible Expsoure Prüfgrundlage: Test specification: FCC 1.1310, and RSS 102 Issue 5 KDB 447498 D01 Wareneingangsdatum: Date of sample receipt: 2022-11-11 Prüfmuster-Nr.: Test sample no: A003370833-001 A003370833-002 A003370833-003 Prüfzeitraum: Testing period: 2022-11-12 - 2022-11-20 Ort der Prüfung: Place of testing: Wireless laboratory, Bangalore Prüflaboratorium: Testing laboratory: TÜV Rheinland (India) Pvt. Ltd. 27/B,2nd cross road, Electronic city Phase1, Banglore-560100, India FCC Test Site Registration No: 496599 IC Test Site Registration No: 27711 HVIN: MB119-00SD-A Prüfergebnis*: Test result*: Pass geprüft von: tested by: genehmigt von: authorized by: Datum: Date: 2022-11-22 Ausstellatum: Issue date: 2023-09-12 Stellung / Position: Yogesh V Senior Engineer Stellung / Position: Madhu K.N Assistant Manager Sonstiges / Other: FCC ID: S9E-131488 IC: 5817A-131488 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (India) Pvt. Ltd, Plot No.27/B, 2nd Cross, Electronic city, Industrial Area, Phase I, Hosur Road Bangalore-560 100, India Mail: [email protected] ∙ Web: www.ind.tuv.com Produkte Products www.tuv.com Prüfbericht - Nr.: Test Report No.: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 2 von 4 Page 2 of 4 1 Maximum Permissible Exposure 1.1 RF Exposure Compliance Requirement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 1.2 RF Exposure Limits: 1.2.1 For FCC 1. According to FCC Part 1 Subpart I 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) showed in Table 1. F or ƒ = Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Produkte Products www.tuv.com Prüfbericht - Nr.: Test Report No.: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Seite 3 von 4 Page 3 of 4 Test Results: Manufacturer has declared the tune-up value as 1 dB is considered in MPE calculation. Antenna Gain: 2dBi for SubGHz & 0dBi for BLE Classification Frequency (MHz) Maximum measured RF output power at antenna terminal (dBm) Max power Including tune-up tolerance * (mW) Antenna Gain in linear scale (dB) Min Separation distance (CM) Power Density (Pd) (W/m²) FCC Limit (mW/cm2) SubGHz 903.00 4.09 3.2284 1.58 20 0.0010 0.6020 916.00 4.44 3.4994 1.58 20 0.0011 0.6107 927.00 3.91 3.0974 1.58 20 0.0009 0.6180 BLE 2402.00 7.99 7.9250 1.00 20 0.0015 1.0000 2440.00 7.43 6.9662 1.00 20 0.0013 1.0000 2480.00 5.60 4.5708 1.00 20 0.0009 1.0000 Note: Maximum conducted output power taken from test Reports: IN23HOHV 001 & AR19-0034275-01 1.2.2 For IC According to IC RSS 102 Issue 5: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radiofrequency (RF) radiation as specified in section 4 showed in Table 4. Classification Frequency (MHz) Maximum measured RF output power at antenna terminal (dBm) Max power Including tune-up tolerance * (mW) Antenna Gain in linear (dBd) Min Separation distance (CM) Power Density (Pd) (W/m²) RSS Limit (W/m²) SubGHz 903.00 4.09 3.2284 1.58 20 0.0100 2.7419 916.00 4.44 3.4994 1.58 20 0.0110 2.7688 927.00 3.91 3.0974 1.58 20 0.0090 2.7915 BLE 2402.00 7.99 7.9250 1.00 20 0.0150 5.3508 2440.00 7.43 6.9662 1.00 20 0.0130 5.4085 2480.00 5.60 4.5708 1.00 20 0.0090 5.4689 Note: Maximum conducted output power taken from test Reports: IN23HOHV 001 & AR19-0034275-01 Produkte Products www.tuv.com Prüfbericht - Nr.: Test Report No.: IN23CPI5 001, IN23HOHV 001, ULR-TC5688233000000094F&95F Se…
