Juno T41/5 User Manual i Welcome Thank you for purchasing a Juno T41/5 Rugged Handheld Computer (Terminal)! This user manual will help you configure and use your device. Important information for using the user manual This user manual has been prepared to guide you through the configuration and operation of your device, which includes: 1. Initial configuration of the device 2. Operating basics 3. Navigating the operating system and software 4. Securing your device Please read this user manual carefully before using your device for the first time. In particular, read the Important Safety Information and all of Chapter 1 before using your device. This user manual describes features and functionality that may not be present on your particular device, as features vary by model. Document conventions It is important to understand the typographical conventions used in this user manual. The formatting of the text identifies special information: 1. CAPITAL — indicates the hardware items on the device. Example: press the POWER button. 2. Bold — indicates the items displayed on the screen, including icons, tiles, buttons, headings, field names and options. Example: tap the E-mail icon. 3. Italic — indicates the name of a screen/window as shown in the upper left corner of the display. Example: the Settings screen. ii 4. > — describes a procedure or a navigation path. 5. Example: Tap > Settings > System > System Information > Wireless is equivalent to: 1. Tap the (Start) icon or press the (Start) button 2. Tap the Settings icon 3. Tap the System icon 4. Tap the System Information icon 5. On the System Information screen, slide left or right until the Wireless tab is displayed. You can also tap the < or > in the horizontal scroll bar to activate different tabs in the System Information screen. Terms The following terms are used throughout this user manual to describe user actions. 1. Press — press and quickly release a hardware button. 2. Tap — touch and quickly release an item displayed on the screen. 3. Select — tap an item in a list or tap a command from a menu. 4. Drag — tap and hold on the item and then move it to the target position without releasing your fingertip. 5. Slide — touch and drag to the left/right/up/down to move to the next item on the list. Important safety information • THE DEVICE BATTERY IS PARTIALLY CHARGED WHEN SHIPPED NEW FROM THE FACTORY. • BEFORE INSERTING OR REMOVING A SIM CARD, THE PHONE MODULE MUST BE POWERED OFF. To do this, press and hold the POWER button for two seconds to display the Power Menu, then tap Enable Airplane mode. Alternatively, use the Wireless Manager to disable only the Phone module. iii • DO NOT OPERATE THE DEVICE WITHOUT THE CARD SLOT COVER PROPERLY INSTALLED. • IN MANY COUNTRIES YOU ARE REQUIRED BY LAW TO TURN OFF YOUR PHONE WHEN YOU FLY. THE MOST SECURE METHOD TO ACCOMPLISH THIS IS TO ENABLE AIRPLANE MODE. To do this, press and hold the POWER button for two seconds to display the Power Menu, then tap Enable Airplane mode. WARNING: TURNING OFF YOUR DEVICE DOES NOT TURN OFF THE PHONE; YOU MUST USE AIRPLANE MODE. • YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE OUTER CASING OF THE DEVICE. Unapproved modifications or operations beyond or in conflict with these instructions for use may void authorization by the authorities to operate the equipment. • ONLY APPROVED ACCESSORIES MAY BE USED WITH THIS EQUIPMENT. IN GENERAL, ALL CABLES MUST BE HIGH QUALITY, SHIELDED, CORRECTLY TERMINATED AND NORMALLY RESTRICTED TO TWO METERS IN LENGTH. THE POWER SUPPLY APPROVED FOR THIS PRODUCT EMPLOYS SPECIAL PROVISIONS TO AVOID RADIO INTERFERENCE AND SHOULD NOT BE ALTERED OR SUBSTITUTED. iv Disclaimers The manufacturer operates a policy of ongoing product development. The manufacturer reserves the right to make changes and improvements to any of the hardware and software products described in this document without prior notice. The screenshots and other presentations shown in this user manual may differ from the actual screens and presentations generated by the actual product. The manufacturer does not warrant that this document is error-free. Not all models are available in all regions of the world. Depending on the specific model purchased, the color and look of your device and accessories may not exactly match the graphics shown in this document. Not all models contain all of the hardware features and software applications described in this user manual. All such differences are minor and the actual product will deliver the described functionality as presented in this User Manual in all material respects, subject to limitations of the particular model operated by the user. Limited Warranty & Liability Limitations This unit and battery are limited warranted against defects in materials and workmanship for twelve (12) months from the original date of purchase. All accessories and peripherals are limited warranted against defects in materials and workmanship for twelve (12) months from the original date of purchase. If notice is received of such defects during the limited warranty period, the proven defective product(s) will either be repaired or replaced, at the manufacturer’s option. Replacement products may be either new or like new. The manufacturer does not warrant that the operation of the products will be uninterrupted or error free. If the product is not, within a reasonable time, repaired or replaced to a condition as limited warranted, the customer will be entitled to a refund of the purchase price upon prompt return of the product. Limited warranty does not apply to defects resulting from (a) improper or inadequate maintenance or calibration, (b) software, v interfacing, parts, or supplies not supplied by manufacturer, (c) unauthorized modification, or misuse, (d) operation in conditions outside of the published environmental specifications for the product, or (e) physical damage due to external causes, including accident, abuse, misuse or problems wi…
