SE4SP-DXSound Port DirX

S S o o u u n n d d P P o o r r t t D D i i r r X X ( ( S S P P - - D D X X ) ) U U s s e e r r ’ ’ s s M M a a n n u u a a l l 1. Hardware 1) Bluetooth Core : BC3_Audio FLASH 2) Memory: Int. 6MB FLASH 3) Ant.: Chip Antenna 4) Mic: SDM (Special Directional MIC), Sensitivity : -47dB, CosmoSound Technology 5) Switch (3 Button, 1 Slide) : MFB (Multi Function Button) Tact SW Volume +, Volume – Tact SW MIC Gain (High or Low) – Slide SW 6) Regulator: Integrated Switch-mode Regulator (output : 1.8V) Integrated Linear Regulator (output: 1.8V) 7) Charger: Integrated Battery Charger (Programmable Current (25~100mA), DC 4.5V~6.5V Input Range) 8) Battery: Size : 4.0(T) X 12(W) X 35(L) (120mAh) 9) Mini USB Port: DC_IN(5V), SPI, UART 2. Bluetooth Profile & Stack 1) Bluetooth Stack V 1.2 2) Hands-Free Profile V 1.5 3) Headset Profile V 1.1 3. Specification 1) Bluetooth Sensitivity: -84dBm Max0.1% BER Output Power: Typically 2dBm (Class2) 2) Power Consumption Standby: 1mA Active Call: About 20mA 4. Features 1) Talk Time : Up to 6 Hours 2) Standby Time : 120 Hours 3) Charging Time : About 2 Hours 4) Range : 10 meters 5) Battery Type : Lithium-polymer 6) Version : Bluetooth v2.0 5. Operating Process 1) Power On/Off - Power ON Press Talk button for 2 seconds, Blue LED will blink 3 times when it’s Power Off. - Power OFF Press Talk button for 6 seconds. Red LED will blink 4 times indicate Power Off. 2) Reset Device List In order to set Primary AG (Audio Gateway), you should delete address memorized in the headset. Press Talk button and Vol(-) button at the same time for 2 seconds and more, then Red and Blue LED will blink 2 times. 3) Multi-Point Pairing Sound Port II has an ability to pair with 2 Audio Gateway or the BT Cell phone at the same time. When you have another incoming call while you are on the phone, you will hear an incoming call signal through the headset. Then the call you've had will be disconnected and the new caller will be connected. It’s possible to have Two Profile (HFP/HSP) connection simultaneously. (Multi-Point Connect function) To initiate the device pairing, it’s required to reset the other AG pairing information memorized on the headset. Please refers to 2) Reset Device List for the reset method. Press “Vol(+) button” and “Vol(-)button” at the same time for 2 seconds when it’s Power On, it goes pairing mode. Red LED and Blue LED will blink alternately. When linking the device supporting HFP first, RED LED and BLUE LED blink for three times which is a pairing mode signal. Then press VOL (+) and VOL(-) simultaneously again for 2 seconds and more, then the previous connection with AG will be end. Connect 2nd AG supporting HSP and choose Soundport II from Bluetooth list of AG and press a connection button, then the connection with two devices is completed. When linking the device supporting HFP first, RED LED and BLUE LED blink for three times which is a pairing mode signal. Then press VOL (+) and VOL(-) simultaneously again for 2 seconds and more, then the previous connection with AG will be end. Connect 2nd AG supporting HSP and choose Soundport II from Bluetooth list of AG and press a connection button, then the connection with two devices is completed. HFP will be primary AG and HSP will be secondary AG. * Attention facts when pairing with two Mobile phones: It's unable to pair SoundPort II with a same profile at the same time. One should be HFP and the other should be HSP. Also if you registered a new AG, press Talk button and Vol (-) button at the same time for 2 seconds and more in order to delete the pairing information. In this case, the AG with HFP profile should be the primary AG and HSP should be secondary. <Available Multi-Point Pairing setting up with Sound Port II> BT Phone A BT Phone B SoundPort II HFP HSP OK HSP HFP OK HFP HFP Not support HSP HSP Not support 4. Sending and receiving a call In order to make a call, press the talk button on the headset, then the call will connect at the primary device. If you push the talk button shortly, the last number will be redialed and if you press the talk button for 2 seconds and more, the voice dial will be operated. (Voice dial function will be supported depends on the kinds of Mobile phones) To receive a call, push the talk button shortly and if you want to reject the call, press the talk button for 2 seconds and more. If you have another call while you are having a call on the primary device, you will hear the melody from the secondary device. If you push the talk button shortly, the connection at the primary AG will be discontinued and the push the talk button shortly again, the call from secondary AG will be connected. After complete the call, press the talk button, then you can make another call from Primary AG again. 5. Charging - Connect the power cable to Mini USB port. - Red LED will be turned on during charging, then it will be turned off after full charge. 6. Button Operation * VOL (+/-) Button 1) Press “Vol (+) button” and “Vol (-)button” at the same time for 2 seconds, it goes pairing mode. 2) Press the Vol (+) button shortly, volume lever will increase by one step. Press the Vol (+) button longer, volume level will increase continuously. 3) Press the Vol (-) button shortly, volume level will decrease by one step. Press the Vol (-) button longer, volume level will decrease continuously. * Talk Button 1) Press Talk button for 2 seconds when it’s Power Off, it will be turned on. 2) Press Talk button for 6 seconds when it’s Power On, it will be turned off. 3) Press the Talk button shortly to receive a call. 4) Press the Talk button for 2 seconds and more to reject a call. 5) It will be disconnected when you push the Talk button shortly during the phone. 6) If you press the talk button for 2 seconds and more while you are on the phone, phone mode will work on the Mobile phone from Headset. * MIC Gain Select Switch 1) Switch UP: High Gain 2) Switch down: Low Gain 6. SoundPort I I LED Status LED COLOR RED (1) BLUE (2) Sta…

Text truncated - open the document above for the full version.

300-5,Wooman-Dong,Paldal-Ku, Suwon-City,Gyeonggi- Do, Korea 442-190 TEL No : +82-31-243-8212 FAX No : +82-31-243-3089 January 29, 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : INSUNG Electronics Co., Ltd. FCC ID : SE4SP-DX Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [SE4SP-DX] SCH.pdf), Parts list(File name: [SE4SP-DX] PL.pdf), Block diagram (File name: [SE4SP-DX] BLK.pdf) and Operational description (File name: [SE4SP-DX] Op Description.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Won Dae Hui / Manager

Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 3 Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 3 Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 3

Model No.: SP-DX FCC ID: SE4SP-DX Copyright Ⓒ 2007, LTA Co., Ltd. SAMPLE LABEL & LOCATION Label INSUNG ELECTRONICS M/N: SP-DX FCC ID:SE4SP-DX

Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 3 Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 3 Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 3

Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 32 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: January 22 ~ 31, 2007 Test Report S/N: LR500190701H Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FHSS Sequence Spread Spectrum (FHSS) Manufacturing Description : SoundPort DirX Manufacturer : INSUNG Electronics Co., Ltd. Model name : SP-DX Test Device Serial No.: : Identification Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480MHz RF power : 1.007mW - Conducted Data of issue : January 31, 2007 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 SE4SP-DX INSUNG Electronics Co., Ltd. Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 32 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND - EDGE ----------------------------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.8 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 11 13 15 17 26 28 31 Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 32 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2007-09-30 ECT accredited Lab. RRL KOREA KR0049 2007-07-13 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 32 2. Information’s about test item 2-1 Client & Manufacturer Company name : INSUNG Electronics Co., Ltd. Address : 300-5, Wooman-Dong, Paldal-Ku, Suwon-City, Gyeonggi-Do, Korea 442-190 Tel / Fax : +82-31-243-8212 / +82-31-243-3089/ 2-2 Equipment Under Test (EUT) Trade name : Sound Port DirX FCC ID : SE4SP-DX Model name : SP-DX Serial number : Identification Date of receipt : January 19, 2007 EUT condition : Pre-production, not damaged Antenna type : Chip antenna Gain 1dBi Frequency Range : 2402 ~ 2480MHz RF output power Range : 0.03 dBm - Conducted Number of channels : 79 Duty Cycle : 78 % Channel spacing : 1MHz Channel Access Protocol : Frequency Hopping Type of Modulation : GFSK Power Source : 3.7V (Polymer Lithium-Ion Battery) 2-3 Tested frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 2-5 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 5 of 32 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies ≥ 15 hops C 15.247(a) 20 dB Bandwidth < 1 MHz C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 1Watt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Ref. No.: LR500190701H Copyright ○ c 2007, LTA Co., Ltd. Page 6 of 32 3.2 Transmitter requirements 3.2.1 Carrier Frequency Separation Procedure: The carrier frequency separation was measured with a spectrum analyzer connected to the antenna terminal, while EUT had its hopping function enabled. After the trace being stable, the reading value between the peaks of the adjacent channels using the marker-delta function was recorded as the measurement results. The spectrum analyzer is set to: Span = 3 MHz (wide enough to capture the peaks of two adjacent channels) RBW = 30 kHz (1% of the span or more) Sweep = auto VBW = 30 kHz Detector function = peak Trace = max hold Measurement Data: T…

Text truncated - open the document above for the full version.

Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 2 Radiated Emission Model No.: SP-DX FCC ID: SE4SP-DX Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 2 Conducted Emission
