SFK-WF810BDual-band Wi-Fi 6 Wireless AP

1 OpenSync TM Wi-Fi DeskPod Ultra WF-810B Product Datasheet VERSION1.0 May, 2023 www.cigtech.com 2  Overview The Dual-band Wi-Fi 6 WF-810B is designed to extend Wi-Fi network connectivity for homes and business based on the latest 802.11ax chipset design. With the WF-810B, the user can utilize Plume HomePass and WorkPass, which provides a self-configuring, self-healing and self-managing Wi-Fi network. It dynamically selects the most reliable Wi-Fi path and enables fast and seamless handoffs for end-users. It is also able to interoperate with other OpenSync TM devices like the Plume SuperPod. WF-810B is one of the best performing WiFi 6 Plume router/extender in the market with up to 5.4Gbps aggregate throughput . It supports 802.11ax on all Wi-Fi radio bands. The 2.4G radio supports 2x2 802.11b/g/n/ac/ax MIMO. The 5G radio supports 4x4 802.11a/n/ac/ax MIMO with 160MHz channel width. WF-810B can meet the requirements for high-speed real-time traffic and high-bandwidth entertainment, such as 4K video, video game streaming and VR. WF-810B integrates OpenSync TM control plane launched by Plume. OpenSync TM creates a multi-industry, open service curation, delivery, management and support framework. WF-810B supports to be managed by Plume cloud remotely. This allows for curation, rapid and scalable delivery, comprehensive back office management, and enhanced support of cloud-based services to the consumer. With global deployments in mind, the WF-810B utilized standard USB-C AC adapter, allowing easy adaptation everywhere as locally certified USB-C AC adapters are available in every country. 3  Key Features  Desktop placement  Highest performance at 4.8Gbps aggregate throughput  2.4GHz 40MHz 2x2 802.11b/g/n/ac/ax  5GHz 160MHz band 4x4 802.11a/n/ac/ax  WPA/WPA2-PSK(AES)  BLE 5.0  5 x Integrated Wi-Fi antennas  1 x Integrated BLE antennas  1 x 2.5GbE WAN  1 x GE RJ45 LAN  1 x Status LED (multi-color)  1 x USB-C PD AC adapter  Supports OpenSync TM control plane  Integrated with Plume Cloud management and Plume mobile management application  Application Scenario  Three WF-810Bs forms a Wi-Fi mesh network. One configured as the Gateway and the other two configured as the Wi-Fi Extender: 4  Software Features Category Features Network Bridge Mode - DHCP Client - Backhaul with 2.4G/5G Wi-Fi/Ethernet Router Mode - IPv4/IPv6 - NAT/NATv6 - WAN DHCP client - WAN PPPoE client - LAN DHCP server - DNS server - DHCP reservation - uPNP - Port forwarding - Backhaul with Ethernet IGMP Snooping Wi-Fi 2.4GHz bandwidth: 20/ 40MHz, 5GHz bandwidth: 20/40/80/160MHz 802.11 k/ v/ r Band steering Channel scan DFS SSID broadcast WPA/WPA2/WPA3 PSK security uAPSD Cloud Management Network topology display - Device connected - Client accessed - Channel - Backhaul type Network optimize Network SSID based on the location WPA/WPA2 PSK security Freeze client Device information - Status - Online time - IP address - MAC address - Firmware version - Channel 5 Client information - Status - Online time - IP address - MAC address - Channel Network statistic chart - Bandwidth usage - RSSI - Channel congestion - Event Utilities - Reboot device - Upgrade remotely - Speed Test Mobile App Management Device discovery Add/ Delete the device Configure SSID Configure password Auto upgrade Antivirus LED Green Solid: Device power on. Blue Blinks: Device is connecting to the Cloud. OFF: Device has been connected to the Cloud. Blue Double Blinks: Network optimization in progress or locate device. 6  Specification Item WF-810B Dimension (D x H) 94mm (Diameter) × 124mm (High) Weight 390g Installation Desktop placement LEDs 1x Status LED (multi-color) Interface 1 x 2.5GbE RJ45 WAN 1 x GE RJ45 LAN 1 x USB 3.0 type-C power input operating at 12V/3A Input Voltage 12V/3A Power consumption < 24W Environmental Specification Temperature Operation: 0°C～+40°C Storage: -40°C～+85°C Operating Humidity 5%～95% (non-condensing) Elevations 86kPa～106kPa altitude Dustproof and Waterproof IP20 Compliance  IEC 62368-1:2014 (Second Edition)+A11: 2017  UL 62368-1, 2nd Ed, 2014-12-01 (Audio/video, information and communication technology equipment Part 1: Safety requirements)  CAN/CSA C22.2 No. 62368-1-14, 2nd Ed (Audio/video, information and communication technology equipment Part 1: Safety requirements)  FCC  CE 7 Item WF-810B  RoHS 2011/65/EU compliant (RoHS 10 compliant, no Pb) Reliability MTBF > 300,000 Hours Telcordia SR-332, Reliability Prediction Procedures for Electronic Equipment, Issue 3, Method 1, Case 3, GB/GC (Ground Benign, Controlled) environment, 25ºC ambient temperature. Steady state, not including software failure. AFR AFR (Annualized Failure Rate) < 1.5% (in continuous operation) Chipset Wi-Fi SoC Qualcomm Flash 256MB NAND flash DDR 512M DDR3L Wi-Fi Interface Operating frequency 2.4G radio:2.4000GHz~2.4835GHz 5G radio: 5.150~5.250, 5.250~5.350, 5.470~5.725, 5.725~5.850GHz Data Rate 802.11b: 1, 2, 5.5, and 11Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48 and 54Mb/s 802.11n: MCS0-MCS7 802.11ac: MCS0 ~ MCS9 802.11ax: MCS0~MCS11 Receive Sensitivity 802.11g: -90dBm@6Mbps -74dBm@54Mbps 8 Item WF-810B 802.11n: HT20 HT40 MCS0/8/16 -90dBm -87dBm MCS7/15 -71dBm -68dBm 802.11a: -90dBm@6Mbps -74dBm@54Mbps 802.11ac: VHT20 VHT40 VHT80 MCS0 -90dBm -87dBm -84dBm MCS8 -67dBm / / MCS9 / -61dBm -58dBm 802.11ax: VHT20 VHT80 VHT160 MCS0 -89dBm -83dBm -80dBm MCS11 -60dBm -54dBm -51dBm 9 Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarant…

Text truncated - open the document above for the full version.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: CIG SHANGHAI CO., LTD. Address: 5F, Building 8, No.2388 Chenhang Road, Minhang District, Shanghai, China Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: Dual-band Wi-Fi 6 Wireless AP FCC ID: SFK-WF810B Model: WF-810B Brand: CIG Sincerely, _________ ________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-05-10

012623-17 Rev 2 U.S. Agent Designation for Service of Process TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Cambridge Industries USA Inc. Contact Name: Jimmy Fu Street Address: 2445 Augustine Drive, 6th Floor, Santa Clara, CA 95054，U.S.A City/Province/Zip: 95054 Telephone No: +1(408) 606-2200 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Feb 14, 2023 Signed by (Printed Name/Title): Jimmy Fu/General Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: CIG Shanghai Co., Ltd. Grantee Code: SFK Contact Name: Ma Zhonghua Street Address: 5F,Building 8,NO.2388 Chenhang Road,Minhang District,Shanghai,201112,P.R.C City/Province/Zip: 201112 Telephone No: +86（21）80233300 Email: FRN: 0022496871 [email protected] Applicant Signature 1 : Date: February 14, 2023 Signed by (Printed Name/Title): Ma Zhonghua/ Certification Manager 1 - Letters should be placed on appropriate letterhead. FRN:0033416108 CIG Shanghai Co., Ltd. 5F, Building 8, NO.2388 Chenhang Road, Minhang District, Shanghai, 201112, P.R.C

Request Letter Subject: Reuse the test data of authorized equipment (FCC ID: SFK-WF810E, Original Grant Date: 2023/05/10) Applicant: CIG SHANGHAI CO., LTD. Dear Sirs, This is to request for reuse the test data of authorized device (FCC ID: SFK-WF810E, Original Grant Date: 2023/05/09). The new device (FCC ID: SFK-WF810B) is based on the authorized device (FCC ID: SFK-WF810E) to remove all Wi-Fi 6E chip and components, all others (Wi-Fi 2.4G & 5G, BLE) are the same as the authorized equipment. According to the declaration as above, so this device reuses the test data of original device and adds some spot check verified data according to KDB 484596 D01v01, details of reuse data and spot check refer to table 2 as below. Table 2 Frequency and Part Rules Test Items of FCC Part Rule Original report No. New report No. Spot check message 2402~2480MHz Part 15.247 6dB Bandwidth 2210RSU047-U2 2305RSU025-U1 No verified Output Power Verified the power Power Spectral Density No verified Band Edge / Out-of-Band Emissions No verified General Field Strength Limits (Restricted Bands and Radiated Emission Limits) No verified AC Conducted Emissions 150kHz - 30MHz No verified 2412~2462MHz Part 15.247 6dB Bandwidth 2210RSU047-U3 2305RSU025-U2 No verified Output Power Verified the power Power Spectral Density No verified Band Edge / Out-of-Band Emissions No verified General Field Strength Limits (Restricted Bands and Radiated Emission Limits) No verified AC Conducted Emissions 150kHz - 30MHz No verified 5125~5250MHz 5250~5350MHz 5470~5725MHz 5725~5850MHz Part 15.407 26dB Bandwidth 2210RSU047-U4 2305RSU025-U3 No verified 6dB Bandwidth No verified Maximum Conducted Output Power Verified the power Peak Power Spectral Density No verified Frequency Stability No verified Undesirable Emissions No verified General Field Strength Limits (Restricted Bands and Radiated Emission Limits) No verified AC Conducted Emissions 150kHz - 30MHz No verified DFS (Master) 2210RSU047-U5 2305RSU025-U4 Verified In-Service Monitoring result Result: All verified result is less than the original data. If you have any questions regarding this application, please feel free to contact me. Sincerely, _________________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-06-16

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: SFK-WF810B Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________ ________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-05-10

Declaration of Authorization We Name: CIG SHANGHAI CO., LTD. Address: 5F, Building 8, No.2388 Chenhang Road, Minhang District, Shanghai, China Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Dual-band Wi-Fi 6 Wireless AP FCC ID: SFK-WF810B Model: WF-810B Brand: CIG Sincerely, _________ ________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-05-10

Declaration of Conformity We Name: CIG SHANGHAI CO., LTD. Address: 5F, Building 8, No.2388 Chenhang Road, Minhang District, Shanghai, China Declare that: Product: Dual-band Wi-Fi 6 Wireless AP FCC ID: SFK-WF810B Model: WF-810B Brand: CIG Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________ ________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-05-10

SDR (Software Defined Radio) Cover Letter Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Yes - go to 2. No, not an SDR Answer: YES 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. Answer: YES 3. Is the device capable of operating in any other in any other way than granted, or will be, granted? Yes, - go to 4. No - go to 5. Answer: YES 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. Answer: NO 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR Answer: YES Conclusion: According to the above questions reply, we can confirm this device (FCC ID: SFK-WF810B) must be a SDR device. ______ ____________ Name: Ma Zhonghua Position: Certification Manager Date: 2023-05-10

Report No.: 2305RSU025-UE 1 of 6 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2305RSU025-UE 2 of 6 (3) EUT Photo (4) EUT Photo Report No.: 2305RSU025-UE 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 2305RSU025-UE 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 2305RSU025-UE 5 of 6 (9) EUT Photo (10) EUT Photo Report No.: 2305RSU025-UE 6 of 6 (11) EUT Photo

3179364 A/V I.C.T.E. FCC ID: SFK-WF810B Model: WF-810B Made in China DC 12V,3A

Report No.: 2210RSU047-UE 1 of 6 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2210RSU047-UE 2 of 6 (3) EUT Photo (4) EUT Photo Report No.: 2210RSU047-UE 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 2210RSU047-UE 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 2210RSU047-UE 5 of 6 (9) EUT Photo (10) EUT Photo Report No.: 2210RSU047-UE 6 of 6 (11) EUT Photo (12) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2503RSU025-U5 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2023-05-16 Template Version:0.0 1 of 10 RF Exposure Evaluation Declaration FCC ID: SFK-WF810B Applicant: CIG Shanghai Co., Ltd. Product: Dual-band Wi-Fi 6 Wireless AP Model No.: WF-810B Brand Name: CIG FCC Classification: Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): FCC Part 2.1091 Received Date: 2022-10-27 Result: Complies Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2305RSU025-U5 2 of 10 Revision History Report No. Version Description Issue Date Note 2305RSU025-U5 V01 Initial Report 2023-05-16 Valid Report No.: 2305RSU025-U5 3 of 10 CONTENTS Description Page 1. General Information ................................................................................................................................ 4 1.1. Applicant ........................................................................................................................................ 4 1.2. Manufacturer ................................................................................................................................. 4 1.3. Testing Facility ............................................................................................................................... 4 1.4. Product Information ....................................................................................................................... 5 1.5. Antenna Details ............................................................................................................................. 5 1.6. Device Classification ..................................................................................................................... 6 1.7. Applied Standards ......................................................................................................................... 6 2. RF Exposure Evaluation ......................................................................................................................... 7 2.1. Test Limits ..................................................................................................................................... 7 2.2. MPE Exemptions ........................................................................................................................... 8 2.3. Calculated Result ......................................................................................................................... 11 Report No.: 2305RSU025-U5 4 of 10 1. General Information 1.1. Applicant CIG Shanghai Co., Ltd. 5F, Building 8, NO.2388 CHENHANG ROAD, MINHANG DISTRTCT, SHANGHAI 1.2. Manufacturer CIG Shanghai Co., Ltd. 5F, Building 8, NO.2388 CHENHANG ROAD, MINHANG DISTRTCT, SHANGHAI 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: L3261-190725 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2305RSU025-U5 5 of 10 1.4. Product Information Product Name Dual-band Wi-Fi 6 Wireless AP Model No. WF-810B Wi-Fi Specification 802.11a/b/g/n/ac/ax Bluetooth Specification V5.0 (Single mode, LE only) Antenna Information Refer to Section 1.5 Accessories Adapter #1 Model No.: ADT-38FKJ-PCU00F Input: 100-240V, 50/60Hz, Max. 1.0A Output: 5.0V⎓3.0A or 12.0V⎓3.0A Adapter #2 Model No.: ADS036G-W 120300 Input: 100-240V, 50/60Hz, Max. 1.0A Output: 5.0V⎓3.0A, 9.0V⎓3.0A, 12.0V⎓3.0A Note: The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. 1.5. Antenna Details Antenna Type Frequency (MHz) TX Path Antenna Gain (dBi) Directional Gain (dBi) Ant 0 Ant 1 Ant 2 Ant 3 Correlated Uncorrelated Wi-Fi Antenna PIFA 2412 ~ 2462 2 3.80 4.10 -- -- 4.46 1.56 5180 ~ 5320 4 4.60 6.20 4.30 4.02 7.58 1.85 5500 ~ 5720 4 4.30 5.50 4.80 4.35 8.01 2.29 5745 ~ 5825 4 3.70 5.20 4.10 4.70 8.01 2.23 Bluetooth Antenna PIFA 2402 ~ 2480 1 0.9 -- Remark: 1. The antenna gain and directional gain refer to manufacturer’s antenna specification. 2. The device supports CDD Mode and STBC mode, details refer to the table as below. 3. CDD signals are correlated, the directional gain as follows, For power measurements: Array Gain = 0 dB for N ANT ≤ 4, the directional gain = max antenna gain + array gain For power spectral density (PSD) measurements: the max directional gain (each angle) = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 ) 2 /N ANT ] 4. STBC signals are uncorrelated, the directional gain as follows, the max directional gain (each angle) = 10 log[(10 G1 /10 + 10 G2 /10 + ... + 10 GN /10 )/N ANT ] Report No.: 2305RSU025-U5 6 of 10 Test Mode T X Paths CDD Mode STBC Mode Wi-Fi 2.4G 802.11b/g 2 √ X 802.11n/ax 2 X √ Wi-Fi 5G 802.11a 4 √ X 802.11n/ac/ax 4 X √ Remark: “√” means “Support”, “X” means “Not suppo…
