SHFSDID1020RFID Reader

Wireless Dynamics Inc. SDiD 1020 User Instructions SDiD 1020 User Instructions Preliminary Version V 0.1 PDF created with pdfFactory trial version www.pdffactory.com Wireless Dynamics Inc. SDiD 1020 User Instructions FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Any change or modification not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Overview The SDiD 1020 is a Radio Frequency Identification, RFID, Reader/Writer device in the form of a Secure Digital Input/Output, SDIO, card. The SDiD 1020 card enables PDAs, cellular phones and other handheld devices to operate as Radio Frequency Identification Readers and Writers. The SDiD 1020 is a complete Secure Digital, SD, Card design that incorporates the antenna, RFID transceiver, SDIO interface and all necessary software drivers. PDF created with pdfFactory trial version www.pdffactory.com Wireless Dynamics Inc. SDiD 1020 User Instructions Features Radio Frequency Identification Reader/Writer: • ISO 14443A/B, ISO 15693 Compliant. • Supports Philips’ I-Code® SLI, Texas Instruments Tag-it TM HF. • Data exchange speeds of 106, 212, 424 and 848 kbit/sec. Secure Data, SD, Card: • SDIO compliant, version 1.10. • SD-1, SP-4, SPI mode. Host Support: • Utilizable on terminals with SDIO enabled SD card socket. • Supports Microsoft® Pocket PC 2002/2003, Windows Mobile TM 2003. • Supports Palm OS® 4.1 and more recent versions. Read and Write Range: • Up to 8 cm, depending on tag. Operating Frequency: • 13.56 MHz, license-free ISM band. Integrated Antenna: • Compact Antenna. Low Power Consumption: • 150 mA typical operational current. Card Status LED Indicator: • Standby, search and data communications indication. PDF created with pdfFactory trial version www.pdffactory.com Wireless Dynamics Inc. SDiD 1020 User Instructions Physical Dimensions Parameter Nominal Value Outline Dimensions (LxWxH): 52.9x24.0x2.1 Weight: Less than 10g PDF created with pdfFactory trial version www.pdffactory.com Wireless Dynamics Inc. SDiD 1020 User Instructions LED Specification The SDiD 1020 has an integrated LED that is used to indicate the card status. The following table shows the different LED states and the corresponding card status: LED Status Indicator Card Status LED State Standby Mode OFF Reader/Writer in 14443 Mode Two blinks every two seconds Reader/Writer in 15693 Mode Three blinks every two seconds Operating Instructions 1) Insert the SDiD 1020 card into the SD card slot of the host device. The integrated LED on the SDiD 1020 will initially be ON for two seconds and it will turn OFF after. 2) Start the application software in the host device. 3) When the card is configured to act as a reader/writer the LED will blink twice every two seconds. At this point the SDiD 1020 card is ready to read/write from/to a target. 4) When the SDiD 1020 card is in the Standby Mode, the LED will be OFF and the SDiD 1020 card will not be able to read/write from/to cards until the appropriate mode is selected in the Host Software Application. PDF created with pdfFactory trial version www.pdffactory.com

NATIONAL TECHNICAL SYSTEMS, INC. www.ntscorp.com 5151 47 th Street NE • Calgary, Alberta T2E 3R2 (403)295-5134 • • (403) 295-4190 fax December 6, 2005 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: SHFSDID1020 IC #: 5998A-SDID1020 Please be advised pursuant to 47CFR 0.459 that the following information is to be held confidential on behalf of Wireless Dynamics Inc: • Schematics • Detailed block diagram • Operational description • Internal photographs (due to proprietary antenna design) This application contains technical information that Wireless Dynamics Inc deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the marketplace. Thank you for your attention to this matter. Sincerely, Glen Moore EMC Manager NTS On Behalf of Wireless Dynamics Inc

Wireless Dynamics FCC ID: SHFSDID1020 IC Number: 5998A-SDID1020 External Photographs Figure 1 Top of EUT Wireless Dynamics FCC ID: SHFSDID1020 IC Number: 5998A-SDID1020 Figure 2 Bottom Side of EUT Wireless Dynamics FCC ID: SHFSDID1020 IC Number: 5998A-SDID1020 Figure 3 Side View

PDF created with pdfFactory trial version www.pdffactory.com

Confidentiality Statement: This report and the information contained herein represent the results of testing articles/products identified and selected by the client. The tests were performed to specifications and/or procedures approved by the client. National Technical Systems (“NTS”) makes no representations expressed or implied that such testing fully demonstrates efficiency, performance, reliability, or any other characteristic of the articles being tested, or similar products. This report should not be relied upon as an endorsement or certification by NTS of the equipment tested, nor does it represent any statement whatsoever as to its merchantability or fitness of the test article or similar products for a particular purpose. This document shall not be reproduced except in full without written approval from National Technical Systems (“NTS”) and the customer. Product Integrity Laboratory 5151-47 th Street, NE Calgary, Alberta T3J 3R2 Tel: (403) 568-6605 Fax : (403) 568-6970 Certification Test Report CFR 47 FCC Part 15, Subpart C Section 15.225 Industry Canada RSS 210, Issue 6 Wireless Dynamics Inc. FCC ID # SHFSDID1020 IC ID # 5998A-SDID1020 Project Code CG-225 (Report CG-225-1) Revision: 0 November 28, 2005 Prepared for: Wireless Dynamics Inc. Author: Glen Moore/ Kuganesan Pararajasingam Approved by: Nick Kobrosly Director of Operations CG-225 Rev: 10Model: SDID1020 Emissions Test Report Wireless Dynamics Inc. FCC ID # SHFSDID1020 IC ID # 5998A-SDID1020 The test results contained in this report refer exclusively to the product(s) presented for testing. The test results do not cover models or products not referred herein. This test report should not be published or duplicated in whole or part without permission from the testing body and the customer. NTS Product Integrity Laboratory, 5151-47 th Street N.E. Tel: 403-568-6605, Fax: 403-568-6970 Confidential Page 2 of 28 November 23, 2005 Report Summary NTS Canada Product Integrity Laboratory 5151-47 th Street, N.E. Calgary Alberta T3J 3R2 Accreditation Numbers: FCC 101386 IC 46405-3978 File # IC3978-2 Standards Council of Canada Accredited Laboratory No. 440 Performed For: Wireless Dynamics Inc. 220, 3636-23rd Street NE Calgary, T2E8Z5 Canada Customer Representative: Carlos Aguirre Charo RF Engineer EUT Description: EUT Description Manufacturer Model Revision Serial Number 13.56 MHz SDID Card Wireless Dynamics Inc. SDID1020 A 24, 29 CG-225 Rev: 10Model: SDID1020 Emissions Test Report Wireless Dynamics Inc. FCC ID # SHFSDID1020 IC ID # 5998A-SDID1020 The test results contained in this report refer exclusively to the product(s) presented for testing. The test results do not cover models or products not referred herein. This test report should not be published or duplicated in whole or part without permission from the testing body and the customer. NTS Product Integrity Laboratory, 5151-47 th Street N.E. Tel: 403-568-6605, Fax: 403-568-6970 Confidential Page 3 of 28 November 23, 2005 Test Summary Deviations* from: Appendix Test/Requirement Description Base Standard Test Basis NTS Procedure Pass / Fail Applicable Rule Parts A Radiated E-Field Emissions 30 MHz – 1 GHz No No No PASS FCC 15.209, RSS 210 A2.6 B Conducted Voltage Emissions 150 kHz – 30 MHz AC Power Leads No No No PASS 15.207, RSS 210 C Radiated H-Field Emissions 9 kHz – 30 MHz No No No PASS FCC 15.209 , 15.225, RSS 210 Issue 6 A2.6 D Frequency Stability No No No PASS FCC 15.225, RSS 210 A2.6 Test Result: The product presented for testing complied with test requirements as shown above. Prepared By: ______________________ Kuganesan Pararajasingam EMC Engineer Checked By: ______________________ Glen Moore EMC Manager CG-225 Rev: 10Model: SDID1020 Emissions Test Report Wireless Dynamics Inc. FCC ID # SHFSDID1020 IC ID # 5998A-SDID1020 The test results contained in this report refer exclusively to the product(s) presented for testing. The test results do not cover models or products not referred herein. This test report should not be published or duplicated in whole or part without permission from the testing body and the customer. NTS Product Integrity Laboratory, 5151-47 th Street N.E. Tel: 403-568-6605, Fax: 403-568-6970 Confidential Page 4 of 28 November 23, 2005 Table of Contents REPORT SUMMARY ........................................................................................................................................................2 TEST SUMMARY..............................................................................................................................................................3 REGISTER OF REVISIONS .............................................................................................................................................5 1.0 INTRODUCTION ................................................................................................................................................6 1.1 PURPOSE.................................................................................................................................................................................... 6 2.0 EUT DESCRIPTION ...........................................................................................................................................6 2.1 CONFIGURATION.......................................................................................................................................................................... 6 2.2 MODE OF OPERATION.................................................................................................................................................................. 6 3.0 SUPPORT EQUIPMENT ....................................................................................................................................6 3.1 CONFIGURATION.............................................................................................................................................................…

Text truncated - open the document above for the full version.

Wireless Dynamics CG-225 FCC ID: SHFSDID1020 IC Number: 5998A-SDID1020 Test Photographs Figure 1 Radiated Emissions Test Photograph Figure 2 Conducted Emissions Test Photograph
